Angel 60K-GS User manual

■ Please read the instructions carefully to use the product properly and protect against any risk.
■ Please keep the user’s guide where it is easily accessible.
Product Name : ELECTRIC JUICE EXTRACTOR
Model No : ANGEL 60K-GS
User’s guide of Angel Commercial Juicer

Angel Juicer Synonymous with
A Health Guardian
We will be your reliable
partner for success.

C O N T E N T S
Before Use Precautions for safety
Parts and Features
01
.................... ....................
About the product
Please check before requesting for repair
04
....................
Operation, Use How to assemble
How to use
How to disassemble
Cleaning
02
....................
....................
P.03
.................... P.07
.................... P.08
.................... P.09
....................
....................
P.10
.................... P.12
Detailed specification of product
Before requesting for
repair service
03
P.11
.................... P.05

Precautions of Safety
Caution may be classified into ‘danger’, ‘warning’, ‘caution’.
Danger Warning Caution
03
Do not plug the power cord or operate the switch with wet hands.
It may cause fire or electric shock.
It may cause electric shock or damage to the product.
It may cause injury or damage should children touch inadvertently or tip over.
It may cause fire, electric shock, injury.
It may cause injury or accident.
It may cause injury, accident or damage to the product.
Make certain that the power cord is plugged into the outlet correctly.
It may cause electric shock or damage to the product.
Avoid contact with the inner part of control box or moter.
NOT FOR USE BY CHILDREN! Keep out of the reach of children.
Do not use the product should power cord or cable be damaged or outlet get loose.
It may cause fire, electric shock, damage.
It may cause damage to the product(Twin gear).
Do not use with the unauthorized modification or disassembly.
Do not put fingers into feeding chute.
Take caution not to let necktie, long necklace and scarf get into the running machine.
It may cause a fatal error or damage to the product.
Do not let any foreign materials, e.g. metal and stone, into feeding chute.
Do not let the juicer idle for over 5 seconds.
Be careful not to let liquid or other foreign materials into the switch.
Do not put the main body (motor, control box) in water or any other liquid.

Precautions of Safety
Caution may be classified into ‘danger’, ‘warning’, ‘caution’.
Danger Warning Caution
04
It may cause injury or accident, damage.
Place the product on secured, flat surface.
It may cause electric shock, destruction, fire.
Stop operation immediately should the unit produce unusual sound, overheating, smoke
and contact customer service you purchased from.
It may cause electric shock, destruction, fire.
Do not apply too much force or heat to the product.
It may cause injury or failure. Make sure the product is stopped and power cord is unplugged
in the first place.
Never move the main body or disassemble or mount the parts while the juicer is in operation.
It may cause injury or damage.
When putting ingredients into feeding chute, do not use any objects(chopstick, spoon,
hard object, etc) other than wooden stick.
It may cause injury, electric shock or fire.
Unplug from outlet when not in use.
It may cause injury or damage.
Avoid direct sunlight and high humidity while storing the product.
The destruction of power cord may cause fire, electric shock.
Do not implement any misbehavior by bending forcibly, tying or placing power cord near
hot materials.
It may cause injury.
Switch to OFF position after each use and be sure the motor stops completely before
disassembling and assembling.
It will prevent electrical shock by inducing the current into ground in case of short circuit.
Be sure to install the grounding cable.
It may cause injury or damage.
Do not heat or boil any parts.

Name of Parts
05
ANGEL 60K-GS
Control Box
Motor
Housing Splash Guard
Feeding Chute
Butterfly Nut
Pulp Guide
Juice Guide
Gear Box Housing
Pressure Adjustment
Screw

ANGEL 60K-GS
Feature(Disassembly)
06
Control Box
Housing Splash Guard
Fastening Bolt
Juice Separate
Guide
Pulp Guide
Juice Guide
Twin Gear SET
Housing Filter
U Groove
Pressure Unit
(Grinding)
Twin Main Gear
Twin Pinion Gear
Gear Box Housing
Breaker Operator
Pre-Filter
Pressure Adjustment
Screw

07
How to assemble
Please read instructions thoroughly before assembling the product.
ANGEL 60K-GS
Slide the twin main gear slowly into the right hole and push the gear fully for assembling
until it reaches spline gear groove by turning the twin main gear to the left and right.
Check up/down position of housing(the first hole facing upward) for assembling.
Assemble juice separate guide into housing filter ring correctly.
Assemble pressure unit.
Tip) Should pressure adjustment screw be tightened too much, take caution as it may not be
assembled with juice separate guide.
Tip) Then hold and lift up pressure unit and tighten butterfly nut.
Insert fastening bolt into U groove correctly and tighten butterfly nut.
Assemble housing splash guard.
Assemble twin pinion gear into the left housing hole.
1
2
3
4
5
6
7
※ Be sure to turn control switch to STOP position before assembling the product.

How to use
08
※ Caution) Make certain to use wooden stick supplied by our company and do not use
metal bar, spoon, chopstick, knife, etc.
※ Caution) Do not idling-run for over 5 seconds.
Please read instructions thoroughly before using the product.
Prepare ingredients for juice extraction by cleaning and cutting them in advance.
Plug in the power cord and check if grounding cable is connected properly.
Press START button and operate the product to put ingredients immediately.
Slice the ingredients of bulbous plants at proper size to put into feeding chute and
push with wooden stick.
Tip) Stem or leaf vegetable will get into twin gear once it is put in without using wooden stick.
Tip) Should the quantity of ingredient put in be excessive than that of ejection,
the machine stops automatically. Then, START the machine after activating
REVERSE for a short while.
Tip) Should housing filter hole be clogged at the time of continuous juice extraction,
capability of juice extraction is reduced and it causes damage to the product,
so replace it with a spare part for operating again.
Tip) Finish putting in ingredient and STOP after doing idling-run for 1 to 2 minutes.
1
2
Turn a breaker operating handle to ON position.
3
Turn a control switch to ON position.
4
5
6
ANGEL 60K-GS

Tip ) Should housing filter be not pulled out, rotate twin gear for 2 to 3 seconds and housing
filter will be pushed out by turning ON control switch and pressing START. Then press
STOP button immediately and turn OFF control switch for safety and take out housing
filter completely.
※ Caution) Twin gear may be heavy and take caution to avoid falling down when
taking it out.
How to disassemble
09
After finishing juice extraction, do the idling-run for 1 to 2 minutes and press STOP button
then switch OFF control switch for safety.
Take out housing splash guard.
Unscrew butterfly nut at each side of pressure unit and turn fastening bolt back
to the both sides.
Take out pressure unit by pulling forward.
Take out juice separate guide by pulling forward.
Take out housing filter by pulling forward.
Take out twin gear by pulling forward one by one.
1
2
3
4
5
6
7
Please read instructions thoroughly before disassembling the product.
ANGEL 60K-GS

Tip ) Should it be laid down on rugged surface, the gear get damaged and may
cause trouble in extracting juice.
※ Caution) Do not put into water or boil for long. It may cause damage to bearing of
rotational shaft.
Tip ) Clean thoroughly housing filter hole and check if there is any clog by looking it
through light. Should housing filter hole be clogged excessively, capability of
juice extraction is reduced and it causes destruction of housing filter.
Cleaning
10
Spray water with hose into feeding chute and housing filter and clean with brush.
Lay twin gear on wooden or plastic plate to clean with brush.
Spray water into housing filter with high-pressure sprayer or clean in running water
with brush after cleaning pulp in the housing filter with knife.
Spray water and clean the pressure unit.
Dry each part completely not to get water spot after cleaning.
1
2
3
4
5
※ Be sure to clean it every time you use Angel Juicer.
※ Do not let water contact with motor and control box area for cleaning.
Wipe it out by using a soft cloth.
Please read instructions thoroughly before cleaning the product.
ANGEL 60K-GS

11
Please check before requesting for repair service
A. - Check if the power cord has been plugged in correctly.
- Check if the product has been assembled in sequence of assembling method.(Refer to p.7)
Q. Machine does not operate.
A. - Check if there are too many ingredients put in at once.
- Put in ingredients slowly.
- Try the reverse button for a while then try operating again by pressing START.
Q. Machine stops while it is under normal operation.
Please check before requesting for repair service.
Contact customer service you purchased from for A/S and other inquiries.
Please check model number, serial number and other necessary informations for requesting
service or spare parts.
ANGEL 60K-GS
※ Contact customer service you purchased from if the methods above don't
solve problems.

12
Specifications
ANGEL 60K-GS
Model
Type
Motor
Rated Voltage
Weight
Length of twin gear
Length of screw
Product size
Motor capacity
Operating method
Juice extraction
Feeding chute size
Twin gear RPM
Main material
Juice extraction rate
60Kg put in once/hr(on the basis of carrot)
173 mm
Reduction gear Ratio
Button type
upper : 252mm / lower : 70mm
246 mm
Stainless steel 304 (18-8)
Single phase 750W
75
1/20
220V / 50Hz
1 HP
ANGEL 60K-GS
W1160 x D440 x H1390(mm)
Twin gear multi-layer extraction
120 kg
Angel Commercial Juicer
is suitable for businesses,
e.g. hotel kitchen, college
food laboratory, fruit juice
store, healthy juice store.
fruit : about 80~90%
vegetable : 70~80% in accordance with ingredient type and season
(water content)

13
“Designed for the best Hygiene and Durability
thanks to the Know-How accumulated for
the last 30 years” [ALL 304 18-8 stainless]

14
The angel commercial juicer extraction rate
Other Juicers
Extract▶Pack
Chop and Grind with Mixer
▶Put in bags
▶Squeeze with
Centrifugal or ▶Pack
91~93%
50~57%
178ea
104ea
You can make more profit with the angel juicer in comparison with other
juicers under same condition.
$178 - $104 = $74
The money you can save in a day(10hours)($74 X 10hours)
1 Day : $740
MONTH : $22,200
Features of Angel Juicer for business use
Extraction Rate
85% Grinding and
extraction Rate,
minimize
nutrition loss,
cost saving.
Durable
Highly hardened
stainless gears,
durable filters
and sturdy
stainless steel
exterior design
Convenient
Super easy to
clean and maintain
Economical
efficiency
Minimized loss of
fruit and vegetable,
special motor use,
energy saving and
its durability.
Hygienic
Super easy to
dissemble and
clean for using
stainless Twin Gear
squeezing filters.
※ Experiment done with Mini (Hotel Use) 20K and corresponding
model from other company based on 10 hours of work.
Method Input Rate Extraction
Rate
Total Number
of Packets
Revenue
(1USD/Packet)
20Kg of grapes
per hour
20Kg of grapes
per hour $178
$104
Here are juicing videos! Scan QR code below.
