Anilam 5000M Setup guide

5000M
CNC Control
TRAINING GUIDE

Navigation Instructions
Follow the bookmarks at the left side
of the page to navigate to desired topic.
Click plus and minus symbols to expand
and compress menu display.
Bookmarks

6000M CNC CONTROL
TRAINING GUIDE

1.
Turning the Control ON
F10
After the control has been turned ON press F10 to continue.
Then press ENTER to select CNC mode.
1. Control Software
This allows you enter CNC software
2. Setup Utility
Machine configuration
3. Motion Setup/Testing
Used to setup drive

2.
First CNC Screen
SECTION #1
SECTION #2
SECTION #3
Control Manual Screen

3.
Program name Machine status
Mode ofoperation
Machine position status
Messages display in this area
Error and warnings Command line for MANUAL(MDI) instructions
Position relative to machine HOME
Position relative to part ZERO
Target or position to reach
Distance to go to reach target
Section #1
Section #2

4.
Section #3
Active tool #
Tool diameter
Tool length offset
Spindle speed
Feedrate
Percentage of
feed and RPM’s
Number of loops
Dwell in seconds
Active fixture offset
Active M functions
Active G codes
Override of feed and rapid
Partscounter and timer

5.
SoftkeyinManualMode
Access help
menu
Access list of
programs
Edit program
in memory
Manual Mode
Single Step
Mode
Automatic
Mode
Delete from
command line
Insert in
command line
Access tool
page
Activate
handwheel
Softkeyin Manual mode when shift keyis pressed
Displaylast 8 messagesTeachMode
Sends machine home
Exits back main
manual screen
Note:When handwheel is active colors will be reversed in box
as shown below.
F10

6.
Alfa - Numeric key board
Note :- Most used key are yellow . Most key also double functions , the
shift key is use to use secondary functions.
D
A C D
C
B
F G H
I K LJ
M O PN
QSTR
U WV
X
8 97
Y
5 6
4
Z
23
1
0
<
{$
Clear key
Enter key
Cursor keys
Space key
Shift key
>^
[]!
~@
}
_‘/
?:
%“
|;/
()#
*
&
=
‘
Rapid Feed Arc
Feed Tool Mcode
mm/in Dwell Plane
R.M.P
...
.

7.
% FEED
X
YU
W
AXIS % SPDL OVRD
1
10 100 FEED
JOG
RAPID
SERVO
RESET SPDL
OFF SPDL
REV SPDL
FWD
+
C
O
O
L
R
E
A
D
Y
Z
Manual panel
There are two type of Manual panels.
1.As shown below.
2.The other without Handwheel on left side
Manual handwheel
Axis select for handwheel
Feedrate override
Axis feed type
Spindle override
Servo reset
Direction key for manual
Manual spindle keys
Hold
Start
Emergence stop

8.
MOVING WITH COMMANDS
Type commands as needed and press the START button located on the
MANUAL PANEL
EXAMPLE:
Type: G0 G90 Z-5. and press Start Z axis goes to Z-5. in ABS and RAPID
EXAMPLE:
Type G97 S1000 M3 and press START to start the spindle at a fixed 1000
rpm.
MOVING WITH JOG MOVEMENTS
1) Turn the jog mode selector switch on the MANUAL PANEL to 100, 10, 1, FEED or
RAPID
2) Select the axis to move with the AXIS SELECTOR switch at the MANUAL PANEL
3) Press the or the key to move in the desired direction.
_
+

9.
MOST COMMON G-CODE COMMANDS TO REMEMBER:
G00: Rapid move.
G01: Feed move.
G02: Arc clockwise
G03: Arc counter clockwise
G17: XY plane
G18: XZ plane
G19: Yz plane
G40: Cutter comp off
G41: Cutter comp left
G42: Cutter comp right
G53 Ox: Fixture offsets ( absolute shift from Machine Home).
G70: Inch programming
G71: MM programming
G80: Used for Drilling Cycles.
G90: Absolute co-ordinate system
G91: Incremental co-ordinate system
G92: Incremental shift
G94: Feed Rate in Inch per minute (mm per minute).
G95: Feed Rate in Inch per revolution (mm per revolution)
M0: Stop program .
M2: End of program
M3: Spindle forward
M4: Spindle reverse
M5: Spindle OFF
M8: Coolant ON
M9: Coolant OFF

10.
ADDRESS LETTERS USED IN PROGRAMMING
A: Used for angles around X axis.
B: Used for angles around Y axis.
C: Used for angles around Z axis.
D: Designates tool diameter in a program.
F: Feedrate.
I: Circle center X axis.
J: Circle center Y axis.
K: Circle center Z axis.
L: Dessignates tool length in a program.
M: Miscellaneous functions.
N: Line number prefix.
O: Program or subroutine number prefix.
P: Subroutine number call prefix.
S: R.P.M. prefix.
T: Tool call.
U: Rotary axis or spindle.
V: Rotary axis or spindle.
W: Rotary axis or spindle.
LOOP: Repete operation.
END: End of loop.
Note: Some of these letters are used inside canned cycles
also some that are not listed above.

11.
Programs can be restored into the control if they have been previously saved on a disk.
From the MANUAL mode press then press SHIFT
Next, press select “A:” and press ENTER
Using the arrow keys hi-lite the program to be restored and press
then press twice to select COPY and then C:
RETREIVING PROGRAMS FROM DISK
Insert the disk into the floppy disk drive (A:) on the machine.
Transferring a program from a disk into the control
Program
Log
Utility
WARNING
Remove the diskette when complete and save in a safe place. Do
not leave the diskette in the machine, the will not start correctly
with disk in the drive.

12.
FUNCTION CNC KEYBOARD COMPUTER KEYBOARD
Z Axis Command
X Axis Command
Preparity G Code
Machine Function Code
Spindle Function Code
Tool Command
ENTER
SHIFT
Cycle HOLD Key
Cycle START Key
Cursor UP, DOWN, LEFT and RIGHT
CLEAR Key
FUNCTION Keys F1 - F10
Z Key
X Key
G Key
M Key
S Key
T Key
ENTER Key
SHIFT Key
Alt + H Key
Alt + S Key
ARROW Keys
Alt + C Key
F1 - F10 Keys
X
Z
M
S
T
F1
Definitions of Function keys are given on
screen
Y
Y Axis Command Y Key
G
]
/
‘
Keys to use when using Computer key board

6000M CNC CONTROL
HELP MENU’S

1
HELP
F1
The HELP MENU’S are access by pressing.
This can be done from either Manual or Edit.
Manualmode softkeys
Edit mode softkeys
First Help screen
Note: The center of the screen. There are two different displays, one has text
about Help the other shows the program as it is being entered.
Press will toggle these screens.
F4
Text

2
Exit
F10
F3
F4
F5
F6
F7
F8
F9
F1
F2
Text
Select
ReEdit
Abort
Accept
Prev
There are two different set of soft keys , as shown above.
Arrow up and around to desired selection.
Arrow down and around to desired selection.
Not used.
Text changes center of screen to diplay program.
Selects required cycle.Enter will as do this.
ReEdits a cycle after it is already in a program.
Goes back to edit without saving last set of inputs.
Accepts inputs and stays in HELP.
Goes back to previous page in HELP menu.
Exits to EDIT page and saves inputs.

3
Section as shown below these are the major defaults. Hight lite the required in put and
press either or enter.
Select
Use up arrow key to move hight to next selection.

4
Press the number 2 key or arrow up to number 2 .
Press either or enter
Select
Note:- the reverse color around Compensation.
Press either or enter
Select
1. Puts a G40 into program comp off.
2. Enters G41 into program cutter comp left.
3. Enters G42 into program cutter comp right.
4. G68 rotates a shape around a center.
5. G72 scale program to required size.
