Annovi Reverberi PROLINER 8.150 User manual

cod. 90816 - KN
High pressure washer
Original instructions
Hidrolimpiadora de alta presión
Traducción de las instrucciones originales
EN
ES
IT
Idropulitricealta pressione
Istruzioni originali
PROLINER 9.160
PROLINER 9.160
PROLINER 8.150PROLINER 8.150
HU
PT
PT
UK
Nagynyomású tisztítóberendezés
Az eredeti utasítások fordítása
Lavadora a alta pressão
Tradução das instruções originais
Мийка високого тиску
Переклад оригінальна інструкція

EN
Please read these instructions carefully before use. Please retain these instructions for future reference. In case of problems or
difficulties, please contact the consumer helpline: [email protected] Page: 7-15
ES
Leer atentamente estas instrucciones antes de usar el equipo. Guardar estas instrucciones para poder consultarlas en el futuro.
En caso de problemas o dificultades, ponerse en contacto con el servicio de asistencia al cliente:
[email protected] Página: 16-26
IT
Leggere attentamente queste istruzioni prima dell’uso. Conservare queste istruzioni per future consultazioni. In caso di problemi o
difficoltà, contattate l’helpline consumatori: [email protected] Pagina: 27-36

3
1
A4
A2
A3
A1
C1
C5
B1 D
B2
B2
C2
B3
B5
E1E3
B4
B6

4
2
1 2
4 53
CH 17
8
6 7
Ø13

5
3
4
F
G
psi
bar
0max
E
IO
D
2
I
1
H
I
D
2
1

6
I
5
Volt
230 3 x 1,5 mm23 x 2,5 mm2
1 ÷ 25 m 25 ÷ 50 m
CH 6
M
L

7English
1
SAFETY INSTRUCTIONS
1.1 The appliance you have purchased is a technologically advanced product designed by
one of the leading European manufacturers of high pressure washers. To obtain the
best performance from your unit, read this booklet carefully and follow the instructions
each time you use it. During connection, use and servicing of the appliance, take
all possible precautions to protect your own safety and that of the people in the
immediate vicinity. Read the safety regulations carefully and comply with them on all
occasions; failure to do so may put health and safety at risk or cause expensive damage.
2
SAFETY SIGNS
2.1 Comply with the instructions provided by the safety signs and symbols fitted to the
appliance and in this manual.
The appliance and manual only feature the symbols relevant to the model purchased.
Check that the symbols and signs affixed to the appliance are always present and legi-
ble; otherwise, fit replacements in the original positions.
Warning - Caution - Hazard
Please read these instructions carefully before use.
E2 symbol (if symbol appears in manual)- Indicates that the appliance is intended
for professional use, i.e. for experienced people familiar with the relative technical,
regulatory and legislative factors and capable of performing the operations involved in
using and maintaining the appliance. This appliance is not intended for use by children,
persons with impaired physical, sensory or mental capabilities, or persons without the
necessary experience and knowledge.
E3 symbol (if symbol appears in manual)- Indicates that the appliance is intended
for non-professional (domestic) use. This appliance may be used by persons with
impaired physical, sensory or mental capabilities, or who do not have the necessary
experience and knowledge, if they are under supervision or have been instructed in the
safe use of the appliance and understand the risks involved.
Moving parts. Do not touch.

8English
0Switch “OFF” position
ISwitch “ON” position
Guaranteed sound power level
Prohibition sign, informs users that local regulations may prohibit connection of
the product to the drinking water supply system.
Danger sign, warns users not to direct the water jet at people, animals, elec-
trical equipment or the product itself.
This product is rated in insulation class II. This means it has reinforced or double
insulation (only if symbol appears on appliance).
This product is rated in insulation class I. This means that it is equipped with a
protective earthing conductor (only if symbol appears on appliance).
The product complies with the relevant European directives.
E1 symbol - Indicates that the appliance must not be disposed of as municipal
waste; it may be handed in to the dealer on purchase of a new appliance. The appli-
ance’s electrical and electronic parts must not be reused for improper uses since they
contain substances which constitute health hazards.
Wear ear defenders.
Wear a protective mask.
Wear respiratory protection.
Wear protective gloves.
Wear safety footwear.
Wear protective clothing.

9English
3
SAFETY RULES/RESIDUAL RISKS
3.1 SAFETY “DO NOTS”
3.1.1 Warning. DO NOT allow children to use the appliance; supervise them to ensure
that they do not play with it.
3.1.2 Warning. High pressure jets may be dangerous if incorrectly used.
3.1.3 Warning. DO NOT use the appliance with flammable or toxic liquids, or any
products which are not compatible with its correct operation. Use of the
appliance in a potentially inflammable or explosive atmosphere is forbidden.
3.1.4 Warning. RISK OF EXPLOSION. DO NOT use the appliance to spray flammable
liquids.
3.1.5 Warning. DO NOT point the water jet at people or animals.
3.1.6 Warning. DO NOT point the water jet at the unit itself, electrical parts or other
electrical equipment.
3.1.7 Warning. DO NOT use the appliance with people within its range of action unless
they are wearing protective clothing.
3.1.8 Warning. DO NOT point the jet at yourself or others to clean clothing or footwear.
3.1.9 Warning. DO NOT use the appliance outdoors when it is raining.
3.1.10 Warning. DO NOT allow children, incompetent persons or those who have not
read and understood the instructions to use the appliance.
3.1.11 Warning. DO NOT touch the plug and/or socket with wet hands.
3.1.12 Warning. DO NOT use the appliance if the electric cable is damaged. If the
electric cable is damaged, it must be replaced by the manufacturer, one of its
authorised Service Centres or similarly qualified persons in order to avoid a
safety hazard.
3.1.13 Warning. DO NOT use the appliance if a supply cable or important parts such as
the safety devices, high pressure hoses or gun are damaged.
3.1.14 Warning. DO NOT jam the trigger in the operating position.
3.1.15 Warning. Check that the data plate is affixed to the appliance; if not, inform your
dealer. Appliances without plates must NOT be used as they are unidentifiable
and potentially dangerous.
3.1.16 Warning. DO NOT tamper with or adjust the setting of the safety valve or the
safety devices.
3.1.17 Warning. DO NOT alter the original diameter of the spray head nozzle.
3.1.18 Warning. DO NOT move the appliance by pulling on the ELECTRIC CABLE.

10 English
3.1.19 Warning. DO NOT allow vehicles to drive over the high pressure hose.
3.1.20 Warning. DO NOT move the appliance by pulling on the high pressure hose.
3.1.21 Warning. When directed towards tyres, tyre valves or other pressurised
components, the high pressure jet is potentially dangerous. Do not use the
rotating nozzle kit, and always keep the jet at a distance of at least 30 cm during
cleaning.
3.1.22 Warning. The use of non-original accessories and any other spare parts not spe-
cifically intended for the model in question is prohibited. All modifications to
the appliance are prohibited; any modifications shall render the Declaration of
Conformity null and void and relieve the manufacturer of all liability under civil
and criminal law.
3.2 SAFETY “MUSTS”
3.2.1 Warning. All electrical conductors MUST BE PROTECTED against the water jet.
3.2.2 Warning. The electric supply connection must be made by a qualified electrician
and comply with IEC 60364-1. Either a residual current device that will cut off
the power supply if the leakage current to earth exceeds 30 mA for 30 ms or a
ground fault interrupt device must be installed.
3.2.3 Warning. DURING start-up, the appliance may cause network noise.
3.2.4 Warning. Use of a residual current breaker (RCB) will provide additional
protection for the operator (30 mA).
3.2.5 Warning. Models supplied without plug must be installed by qualified staff.
3.2.6 Warning. Use only approved electrical extension leads with suitable conductor
cross-section.
3.2.7 Warning. Always turn off the switch when leaving the appliance unattended.
3.2.8
Warning. High pressure may cause parts to rebound: wear all the protective
clothing (PPE) and equipment needed to ensure the operator’s safety.
3.2.9 Warning. Before doing work on the appliance, REMOVE the plug.
3.2.10 Warning. Before pressing the trigger, GRIP the gun firmly to counteract the recoil.
3.2.11 Warning. COMPLY WITH the local water supply authority regulations. Under IEC
60335-2-79, the appliance may only be connected to the mains drinking water
supply if the supply hose is fitted with a backflow preventer valve with drain
facility corresponding to EN 12729 type BA. The backflow preventer can be
ordered from the manufacturer.
