Anolis ArcControl 128 User manual

Version 1.0

ArcControl 128
2
1. Features
• DMX512 Stand Alone Controller with a glass face
• 128 channnels ma . (depends on QTY of steps)
• 3 touch sensitive buttons (on/off/mode, previous, ne t)
• Up to 24 dynamic or static scenes (8 first visualized by a led)
• Live setting of the intensity and color of a scene
• Compatible with any DMX fi ture or DMX LED driver.
• Ready to use (pre-loaded with 8 scenes and 42 RGB fi tures)
• 32-bit ARM technology
• Wall mountable
• Programmable through the included USB cable and control software
2. ArcControl 128 exterior view
COLOR MODE
Holding the left or right button allows for direct access to any color. A single touch gives access to
the basic colors. Pressing the 2 arrows at the same time will return to the default color.
Pressing previous and ne t simultanouesly will reset dimmer/color.

ArcControl 128
3
SCENE MODE
The left and right buttons allow you to change the current scene. A scene can be static (one step)
or dynamic (several steps with fade/holdtime).
DIMMER MODE
The left and right buttons can be used to change the brightness. Pressing the 2 arrows
simultaneously will reset to the default level.
3. Installation
1. Mount an electrical box inside the wall
The ArcControl 128 can be installed in a standard 60mm electrical backbo .
You can insert the AC/DC adapter (if you use it) inside or outside the backbo .
2. Connect the wires
DMX: Connect the DMX cable to the lighting receivers (Leds, Dimmers, Fi tures..)
(for XLR: 1=ground 2=DMX- 3=DMX+)
POWER: Connect the AC/DC adapter, 5,5-12V/500mA. Make sure to not invert the + and the ground.

ArcControl 128
4
Note: If you use the following ArcPower drivers: ArcPower 36 (ArcPower SmartWhite 36), ArcPower 72 (ArcPower
SmartWhite 72), ArcPower 144 (ArcPowerSmartWhite 72), ArcPower 360 (ArcPower SmartWhite 360), you can use
+12V on the pin 2 of DMX IN connector for supply of the ArcControl 128:
DMX Input
RJ45 * the Colours of wires respond standard Patch cabel cat.5. with four twisted pairs
Note: ArcPowers /K2 series do not allow to use 12V for supply of the ArcControl 128 (e.g. ArcPower 36/K2....).
3. Mount the interface on the wall
First, plug the 2 connectors (green connector block).
Secondly, mount the back side of the interface on the wall with 2 or more screws.
Then, close the unit by clipping the front panel onto the back plate.
Pin No.
Function
Wire
PinNo.
Function
Wire
Pin 1 Not connected Pin 5 not connected
Pin 2 +12V Orange* Pin 6 Data + Green*
Pin 3 Not connected Pin 7 Data - White/brown*
Pin 8 GND Brown
Pin 4
Not connected
Pin 8
GND
Brown
*

ArcControl 128
5
4. Software
1. TOOLS.EXE to set parameter 2. ArcControl 128 to program the memory
5. Technical specifications
PC requirement: Windows XP/VISTA/SEVEN 32/64 bits and USB 2.0
oftware: ArcControl 128
Versions: Black (No. 1080250), White (No. 10080255)
Connections: Power (2pins); DMX (3pins); Micro-USB
Channels: 128 ma . (depends on QTY of steps)
Power: from 5.5V to 12V DC
Keypad dimensions: 86 86 10 mm
Keypad weight: 130g
IP rating: IP20
Ambient operating temperature: 0°C to 50°C
Package: ArcControl 128, USB stick with software (ArcControl 128), USB cable, connector block
Optional accessories: AC/DC adapter (No. 1305 1648)
Available memory
Channels
8
16
32
48
64
80
96
112
128
teps
326
192
102
68
50
38
31
25
21
Specifications are subject to change without notice.
October 25, 2011
Version: 1.0
