Anolis ArcPix User manual

1
User instructions
ArcPix Outdoor 4 MC
The Anolis ArcPix Outdoor 4 MC is a multi-purpose, high-intensity RGB LED node for generating a wide
variety of effects without the limitations associated with a solid xture unit.The unit´s high light output can be
pixel mapped and therefore can be controlled and used for large scale matrix applications, as well as used for
individual illuminating needs.
1.Attention
Consider the respective national norms during the installation!
Do not install the module near high inammable liquids or materials
Do not allow anything to rest on the module
Do not install the unit near naked ames.
Avoid using the unit in locations subject to possible impacts.
Do not attempt to dismantle or modify the unit.
Do not install the module in badly ventilated location
2.Installation
The ArcPix Outdoor 4 MC can be arranged in any position orientation. Three holes of diameter of 4.3mm in the
ArcSource Outdoor´s base serve for mounting on the non-ammable surface. The light head can be adjusted
against the base in range of 120°.The ArcPix Outdoor units should be connected to the ArcPix Power. See
the ArcPix Power user manual for full details of mains power requirements, DMX operation and installation.
As the ArcPix Outdoor 4 MC is equipped with one input cable only, the T-connector Chogori has to be used
for connecting the ArcPix modules each other.
CAUTION!
Avoid looking directly into the LED light beam at close range!
The enclosed adapter stand (with M5x45 screw) allows to place light head higher:

Use the following way for connecting of the ArcPix Outdoor 4 MC only (examples for matrix of 4x4):
Horizontal sorting Vertical sorting
3. Wiring of the ArcPix Outdoor 4 MC connector
Chogori CGRBB-03BMMA-SL8001 (male)
1 GND (blue wire)
2 +48V (red wire)
3 Data (orange wire)
4.Technical specications
LED device: Osram Ostar RGBW multichip
Max. current per colour: 520 mA
Maximum power consumption: 5.5 Watts/48V
Compatible power supply: ArcPix Power
Available beam angles: 7.5°, 24°, 35°, 7.5°x37°
Led life expectancy: minimum 50.000 hours
Cooling system: convection
Operating ambient temp. range: -20°C/+45°C
Housing: alluminium
Weight: 0.62 kg
Mounting: via 3 holes in the base
Ingress protection: IP 65 (CE), Suitable for wet location (ETL)
Data cable: Li9Y11Y, 2xAWG16+1xAWG 20 ,open ended (length
according requirement, standard 0.5m)
2

5. Accessories
1x Adapter stand (P/N. 19730251)
1x Screw M5x45
1x Allen key 4
6. Optional accessories (quantity depends on size of installation)
(P/N 13051562) Connector Chogori CGRBB-03BMMA-SL8001 (male)
(P/N 13051564) T-connector Chogori T-CGRBA-030303FFM-TS
(P/N 1305 2023) Connection cable ArcDot-ArcDotPower, 2m *
(P/N 1305 2024) Connection cable ArcDot-ArcDotPower, 4m*
(P/N 1006 2330) Active Terminator for ArcDot*
(P/N 1006 2331 Passive Terminator for ArcDot*
(P/N 1305 1703) Ferrite GTFC 16-8-16 (for ArcDot) - CE only*
6. Dimensions (mm)
3
Version 1.2
August 10, 2015
Specications are subject to change without notice.
