Anolis ArcSource Outdoor 4 MC User manual

1
User instructions
ArcSource Outdoor 4 MC 7°
The Anolis ArcSource Outdoor 4 MC is an Ostar RGBW multichip based high powered multicolored LED xture.
The unit can be used for large scale applications, as well as used for individual illuminating needs.
1.Attention
Consider the respective national norms during the installation!
Do not install the unit near naked ames.
Avoid using the unit in locations subject to possible impacts.
Do not attempt to dismantle or modify the unit.
Do not install the module in badly ventilated location
Avoid looking directly into the LED light beam at close range.
2.Installation
The ArcSource Outdoor 4 MC can be arranged in any position orientation. Three holes of diameter of 4.3mm
in the ArcSource Outdoor´s base serve for mounting on the non-ammable surface. The light head can be
adjusted against the base in range of 120°.The ArcSource Outdoor units should be connected to the ArcPower
drivers stated in technical specications. See their user manuals for full details of mains power requirements
and DMX operation.
CAUTION!
Avoid looking directly into the LED light beam at close range!
Use a cable splitter if more than one LED module has to be connected to the one LED output of the ArcPower
driver, the connection cable between the ArcPower and the splitter is a standard RJ45 patch cable category
5 wired 1:1.
Maximum possible number of LED modules connected to the one LED output of the ArcPower driver is men-
tioned in the table below.
LED RGBW
multichips
Max.number of connected
modules Compatible ArcPower drivers
ArcSource Outdoor 4 MC 1 10 ArcPower 36/K2, ArcPower 72/K2,
ArcSource Outdoor 4 MC 1 12 ArcPower 384 Rack Mount
The enclosed adapter stand (with M5x45 screw) allows to place light head higher:

3. Connection
4.Technical specications
LED Device: Osram Ostar multichip
Available beam angle: 7°
Colour variant: RGBCW
Max. Current per Colour: 700 mA
Maximum Power Consumption: 10 W
Recommened Power Supplies: ArcPower 36/K2, ArcPower 72/K2, ArcPower 384 Rack M.
Typical Lumen Maintenance: 70% @ 50.000 hours
Led Life Expectancy: minimum 50.000 hours
Cooling System: convection
Operating Ambient Temp.Range: -20°C/+45°C
Housing: alluminium
Weight: 0.62 kg
Mounting: via 3 holes in the base
Connection: Belden 7930A (cable), length=50 cm, connector RJ 45
Ingress Protection: IP 67
5. Accessories
1x Adapter stand (P/N. 19730251)
1x Screw M5x45
1x Allen key 4
1x Splitter (P/N 13050690)
6. Optional Accessories
Land spike 1 ASO 4 MC 100mm (P/N 10980178)
Land spike 2 ASO 4 MC 100mm (P/N 10980179)
Land spike 1 ASO 4 MC 500mm (P/N 10980180)
Land spike 2 ASO 4 MC 500mm (P/N 10980181)
Land spike 3 ASO 4 MC 500mm (P/N 10980183)
Top hat ArcSource Outdoor 4 MC (P/N 10980273)
Half top hat ArcSource Outdoor 4 MC (P/N 10980253)
2

7. Dimensions (mm)
Land spike 1 ASO 4 MC 100mm
3

4
Land spike 2 ASO 4 MC 100mm
Land spike 1 ASO 4 MC 500mm
Land spike 2 ASO 4 MC 500mm

5
Land spike 3 ASO 4 MC 500mm

6
8. Installing the ArcSource Outdoor 4 MC onto a land spike
Land spike 1 ASO 4 MC 100mm / Land spike 2 ASO 4 MC 100mm
1. Hammer the sharp part (1) of the land spike into ground
(hammer the centre of the sharp part, not the edge).
2. Screw the threaded bar (2) into the sharp part (1) and
secure it with the socket head M5x5 (3).
3 .Put the cover (4) on the threaded bar (2).
4. Put the pipe 36.5 mm (5) on the threaded bar (2).
5. Put the cable holder (6) on the threaded bar (2).
Land spike 1 ASO 4 MC 100mm only.
6. Screw the nut (7) on the threaded bar (2).
7. Screw the ArcSource Outdoor 4 MC on the nut (7).
(Use the socket head M5x14 from the ArcSource Outdoor
4 MC to screw it to the nut (7)).
8. Pass the cable throw the cable holder (6).
Land spike 2 ASO 4 MC 100mm only.
6. Put the pipe 42 mm (6) on the threaded bar (2).
7. Put the ArcSources holder (8) on the threaded bar (2).
8. Screw the nut (9) on the threaded bar (2).
9. Screw both ArcSource Outdoor 4 MC on the ArcSources
holder (8).
(Use the socket heads M5x14 from the ArcSource Outdoors
4 MC to screw them to the holder (8)).
10. Pass the cable throw the cable holder (6).
Land spike 1 ASO 4 MC 500mm / Land spike 2 ASO 4 MC 500mm
1. Hammer the sharp part (1) of the land spike into ground
(hammer the centre of the sharp part, not the edge).
2. Screw the threaded bar (2) into the sharp part (1) and
secure it with the socket head M5x5 (3).
3 .Put the cover (4) on the threaded bar (2).
4. Put the pipe 36.5mm (5) on the threaded bar (2).
5. Put the cable holder (6) on the threaded bar (2).
6. Put the pipe 198mm (7) on the threaded bar (2).
7. Put the cable holder (6) on the threaded bar (2).
8. Put the pipe 198mm (7) on the threaded bar (2).
Land spike 1 ASO 4 MC 500mm only:
9. Put the cable holder (6) on the threaded bar (2).
10. Screw the nut (8) on the threaded bar (2).
11. Screw the ArcSource Outdoor 4 MC on the nut (8).
(Use the socket head M5x14 from the ArcSource Outdoor
4 MC to screw it to the nut (7)).
12. Pass the cable throw the cable holders (6).
Land spike 2 ASO 4 MC 500mm only:
9. Put the ArcSources holder (8) on the threaded bar (2).
10. Screw the nut (9) on the threaded bar (2).
11. Screw both ArcSource Outdoor 4 MC on the ArcSources
holder (8).
(Use the socket head M5x14 from the ArcSource Outdoors
4 MC to screw them to the holder (8)).
12. Pass the cable throw the cable holders (6).

7
Land spike Land spike 3 ASO 4 MC 500mm
1. Hammer the sharp part (1) of the land spike into ground
(hammer the centre of the sharp part, not the edge).
2. Screw the threaded bar (2) into the sharp part (1) and
secure it with the socket head M5x5 (3).
3 .Put the cover (4) on the threaded bar (2).
4. Put the pipe 36.5mm (5) on the threaded bar (2).
5. Put the cable holders (6) on the threaded bar (2).
6. Put the pipe 198mm (7) on the threaded bar (2).
7. Put the ArcSources holder (8) on the threaded bar (2).
8. Put the pipe 198mm (7) on the threaded bar (2).
9. Put the cable holder (6) on the threaded bar (2).
10. Screw the nut with holder (9) on the threaded bar (2).
11. Screw ArcSources Outdoor 4 MC on the ArcSources
holders (8,9).
(Use the socket head M5x14 from the ArcSource Outdoors
4 MC to screw them to the holder (8)).
12. Pass the cable throw the cable holders (6).
Version 1.0 CE
January 4, 2015
Specications are subject to change without notice.

8
9. Installing a top hat
1. Unscrew two screws (1) with washers (2) from the ArcSource Outdoor 4 MC housing and place
the top hat (3) on the ArcSource Outdoor 4 MC.
2. Screw the top hat (3) onto the ArcSource Outdoor 4 MC with two screws (1) and two washers (2) using
a tightening torque of 4Nm. Check that all screws are rmly screwed.
Version 1.1 CE
March 21, 2016
Specications are subject to change without notice.
