Maintenance Manual
Spectrum Master™
MS2760A-0032, 9 kHz to 32 GHz
MS2760A-0044, 9 kHz to 44 GHz
MS2760A-0050, 9 kHz to 50 GHz
MS2760A-0070, 9 kHz to 70 GHz
MS2760A-0090, 9 kHz to 90 GHz
MS2760A-0110, 9 kHz to 110 GHz
MS2760A-0145, 9 kHz to 145 GHz
MS2760A-0170, 9 kHz to 170 GHz
MS2762A-0032, 6 GHz to 32 GHz
MS2762A-0044, 6 GHz to 44 GHz
MS2762A-0050, 6 GHz to 50 GHz
MS2762A-0070, 6 GHz to 70 GHz
MS2762A-0090, 6 GHz to 90 GHz
MS2762A-0110, 6 GHz to 110 GHz
MS2762A-0145, 6 GHz to 145 GHz
MS2762A-0170, 6 GHz to 170 GHz
Anritsu Company
490 Jarvis Drive
Morgan Hill, CA 95037-2809
USA
Part Number: 10580-00433
Revision: D
Published: November 2019
Copyright 2019 Anritsu Company

MS276xA MM PN: 10580-00433 Rev. D Safety-1
Safety Symbols
To prevent the risk of personal injury or loss related to equipment malfunction, Anritsu Company uses the
following symbols to indicate safety-related information. For your own safety, please read the information
carefully before operating the equipment.
Symbols Used in Manuals
Safety Symbols Used on Equipment and in Manuals
The following safety symbols are used inside or on the equipment near operation locations to provide
information about safety items and operation precautions. Ensure that you clearly understand the meanings of
the symbols and take the necessary precautions before operating the equipment. Some or all of the following
five symbols may or may not be used on all Anritsu equipment. In addition, there may be other labels attached
to products that are not shown in the diagrams in this manual.
Danger
This indicates a risk from a very dangerous condition or procedure that could result in
serious injury or death and possible loss related to equipment malfunction. Follow all
precautions and procedures to minimize this risk.
Warning This indicates a risk from a hazardous condition or procedure that could result in
light-to-severe injury or loss related to equipment malfunction. Follow all precautions
and procedures to minimize this risk.
Caution
This indicates a risk from a hazardous procedure that could result in loss related to
equipment malfunction. Follow all precautions and procedures to minimize this risk.
This indicates a prohibited operation. The prohibited operation is indicated symbolically
in or near the barred circle.
This indicates a compulsory safety precaution. The required operation is indicated
symbolically in or near the circle.
This indicates a warning or caution. The contents are indicated symbolically in or near
the triangle.
This indicates a note. The contents are described in the box.
These indicate that the marked part should be recycled.

Safety-2 PN: 10580-00433 Rev. D MS276xA MM
For Safety
Warning Always refer to the operation manual when working near locations at which
the alert mark, shown on the left, is attached. If the operation, etc., is
performed without heeding the advice in the operation manual, there is a
risk of personal injury. In addition, the equipment performance may be
reduced.
Moreover, this alert mark is sometimes used with other marks and
descriptions indicating other dangers.
Warning
When supplying power to this equipment, connect the accessory 3-pin
power cord to a 3-pin grounded power outlet. If a grounded 3-pin outlet is
not available, use a conversion adapter and ground the green wire, or
connect the frame ground on the rear panel of the equipment to ground. If
power is supplied without grounding the equipment, there is a risk of
receiving a severe or fatal electric shock.
Warning
This equipment can not be repaired by the operator. Do not attempt to
remove the equipment covers or to disassemble internal components.
Only qualified service technicians with a knowledge of electrical fire and
shock hazards should service this equipment. There are high-voltage parts
in this equipment presenting a risk of severe injury or fatal electric shock to
untrained personnel. In addition, there is a risk of damage to precision
components.
Caution
Electrostatic Discharge (ESD) can damage the highly sensitive circuits in
the instrument. ESD is most likely to occur as test devices are being
connected to, or disconnected from, the instrument’s front and rear panel
ports and connectors. You can protect the instrument and test devices by
wearing a static-discharge wristband. Alternatively, you can ground
yourself to discharge any static charge by touching the outer chassis of the
grounded instrument before touching the instrument’s front and rear panel
ports and connectors. Avoid touching the test port center conductors
unless you are properly grounded and have eliminated the possibility of
static discharge.
Repair of damage that is found to be caused by electrostatic discharge is
not covered under warranty.
Warning This equipment is supplied with a rechargeable battery that could
potentially leak hazardous compounds into the environment. These
hazardous compounds present a risk of injury or loss due to exposure.
Anritsu Company recommends removing the battery for long-term storage
of the instrument and storing the battery in a leak-proof, plastic container.
Follow the environmental storage requirements specified in the product
data sheet.

MS276xA MM PN: 10580-00433 Rev. D Contents-1
Table of Contents
Chapter 1—General Information
1-1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1-2 Anritsu Customer Service Centers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1-3 Recommended Test Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1-4 Replaceable Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Chapter 2—Spectrum Analyzer Verification
2-1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
PASS/FAIL Determination for Instrument Key Parameter Performance Tests . . . . . . . . . . 2-2
2-2 Frequency Accuracy Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2-3 Amplitude Accuracy Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2-4 Single Side Band (SSB) Phase Noise Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2-5 Spurious Response (Second Harmonic Distortion) Verification . . . . . . . . . . . . . . . . . . . . . . . 2-10
2-6 Residual Spurious Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
2-7 Input Related Spurs Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
2-8 Displayed Average Noise Level (DANL). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
Chapter 3—Troubleshooting
3-1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3-2 Connection Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Appendix A—Test Records
Frequency Accuracy Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Amplitude Accuracy Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
Single Side Band (SSB) Phase Noise Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5
Spurious Response (Second Harmonic Distortion) Verification . . . . . . . . . . . . . . . . . . . . . A-6
Residual Spurious Verification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-6
Input Related Spurs Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-8
Displayed Average Noise Level (DANL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-9

Contents-2 PN: 10580-00433 Rev. D MS276xA MM
Table of Contents (Continued)

MS276xA MM PN: 10580-00433 Rev. D 1-1
Chapter 1 — General Information
1-1 Introduction
This manual provides maintenance instructions for the Anritsu MS2760A and MS2762A Spectrum Masters.
When referring to both models MS276xA will be used. This manual includes:
•General information, including:
•List of necessary test equipment to perform verification testing (Table 1-1)
•Replaceable parts list (Table 1-2)
•Performance verification procedures in Chapter 2, “Spectrum Analyzer Verification”
•Troubleshooting procedures in Chapter 3, “Troubleshooting”
•Blank test records are included in Appendix A. Copy the blank test records and use them to record
measured values. These test records form a record of the performance of the MS276xA. Anritsu
recommends making a copy of the blank test records to document the measurements each time a
Performance Verification is performed. Continuing to document this process each time provides a
detailed history of the instrument’s performance, allowing trends to be observed.
Familiarity with the basic operation of the MS276xA using the GUI software is assumed, for example, how to
preset the instrument and set frequency, span, and RBW settings.
1-2 Anritsu Customer Service Centers
For the latest service and sales information in your area, please visit the following URL:
http://www.anritsu.com/contact-us
Choose a country for regional contact information.
Note Before making any measurement, verify that all equipment has warmed up for at least 30 minutes.

1-3 Recommended Test Equipment General Information
1-2 PN: 10580-00433 Rev. D MS276xA MM
1-3 Recommended Test Equipment
The following test equipment listed in Table 1-1 is recommended for use in testing and maintaining the
MS276xA.
Table 1-1. Test Equipment Required for Verifying Spectrum Analyzer Functions (1 of 2)
Instrument Critical Specification Recommended Manufacturer/Model
Synthesizer Frequency: 9 kHz to 70 GHz Anritsu Model MG3697C with
Options 2C/3/4/15D/22
Power Meter Frequency 9 kHz to 44 GHz Rohde and Schwarz, NRP40T
(used for the 32 and 44 GHz models)
Power Meter Frequency 9 kHz to 67 GHz Rohde and Schwarz, NRP67T
(used for the 50 and 70 GHz models)
Power Meter Frequency 9 kHz to 110 GHz Rohde and Schwarz, NRP110T
(used for the 90, 110, 145, and 170 GHz
models)
Power Meter Frequency 110 GHz to 170 GHz Elva-1 Model DPM-06
(used for 145 and 170 GHz models)
170 GHz Frequency Multiplier Input 27.5 to 42.5 GHz, +5 dBm
Output 110 to 170 GHz, -3 dBm
Sage Millimeter Model
STE-KF406-00-S1
(used for 145 and 170 GHz models)
110 GHz Frequency Multiplier Output 75 to 110 GHz Norden ND75110G0P0
(used for the 90, 110, 145, and 170 GHz
models)
12 Volt DC Power Supply 12 VDC Output Keysight E3631A
(Power supply for the 110 GHz
Multiplier)
WR6 Power Divider WR6, 1.2 dB insertion loss max,
VSWR better than 1.6
QuinStar Model QJH-DLFB00
(used for 145 and 170 GHz models)
Waveguide section Mi-Wave 690D-1.5
W1 to 0.8mm adapter W1(m) to 0.8mm(f), DC-110 GHz, 50
ohms
Anritsu Model 33W.8F50
(used for 145 and 170 GHz models)
0.8mm to WR6 adapter WR6 to 0.8mm(f), 114 - 170 GHz,
VSWR better than 1.5
Flann Model 29373-F
(used for 145 and 170 GHz models)
W1 to V adapter W1(f) to V(m), 50 ohms Anritsu Model 34WFV50
(used for 90/110/145/170 GHz models)
V to K adapter V(m) to K(f), 50 ohms Anritsu Model 34VKF50A
(used for 32/44 GHz models)
Isolator (Qty 2) Isolation: 20 dB
Frequency: 110-170 GHz
Millitech FBI-06
(used for 145 and 170 GHz models)
Termination VSWR: 1.10:1
Frequency: 110-170 GHz
Sage SWL-0627-S1
(used for 145 and 170 GHz models)
50 Ohm Termination K(f) connector, 50 ohms Anritsu 28KF50A
50 Ohm Termination V(f) connector, 50 ohms Anritsu 28VF50D
50 Ohm Termination W(f) connector, 50 ohms Anritsu 28WF50

General Information 1-4 Replaceable Parts
MS276xA MM PN: 10580-00433 Rev. D 1-3
1-4 Replaceable Parts
The MS276xA has no internal components that are field replaceable. If the unit fails the verification testing,
repairs can be performed at the local Anritsu Service Center. The following table provides the cable part
numbers if replacements are needed.
50 Ohm Termination 0.8mm(f) connector, 50 ohms Anritsu 28.8F50
Table 1-2. List of Replaceable Parts
Part Number Description
2000-1859-R USB Cable
2000-1605-R BNC(m) to MMCX(m) Cable
Table 1-1. Test Equipment Required for Verifying Spectrum Analyzer Functions (2 of 2)
Instrument Critical Specification Recommended Manufacturer/Model

1-4 Replaceable Parts General Information
1-4 PN: 10580-00433 Rev. D MS276xA MM

MS276xA MM PN: 10580-00433 Rev. D 2-1
Chapter 2 — Spectrum Analyzer Verification
2-1 Introduction
This chapter contains the following verification procedures:
•“Frequency Accuracy Verification” on page 2-3
•“Amplitude Accuracy Verification” on page 2-4
•“Single Side Band (SSB) Phase Noise Verification” on page 2-8
•“Spurious Response (Second Harmonic Distortion) Verification” on page 2-10
•“Residual Spurious Verification” on page 2-12
•“Input Related Spurs Verification” on page 2-13
•“Displayed Average Noise Level (DANL)” on page 2-15

2-1 Introduction Spectrum Analyzer Verification
2-2 PN: 10580-00433 Rev. D MS276xA MM
PASS/FAIL Determination for Instrument Key Parameter Performance Tests
Figure 2-1 shows the rule that is used to determine the pass/fail status of test results that are associated with
warranted specifications.
The measurement uncertainty listed in each test record includes the best estimate of the errors contributed by
the measurement, test equipment, standards, and other correction factors (for example, calibration factors and
mismatch error) based on the suggested equipment, the equipment setup, and the prescribed test procedure.
Most of the uncertainties are type-B per ISO/IEC Guide 98-3, Guide to the Expression of Uncertainty in
Measurement (GUM).
Figure 2-1. Pass/Fail Determination
Measurement Data - Failing Specifications
Measurement Data - Passing Specifications
Measurement Point (Reading)
+ Uncertainty
– Uncertainty
Measurement Data
Nominal
Lower
Specification
Upper
Specification
Nominal
Lower
Specification
Upper
Specification

Spectrum Analyzer Verification 2-2 Frequency Accuracy Verification
MS276xA MM PN: 10580-00433 Rev. D 2-3
2-2 Frequency Accuracy Verification
The following procedure is used to verify the frequency accuracy of the MS276xA.
Equipment Required
•Anritsu MG3697C Synthesized Signal Source
•10 MHz Reference Standard
•34VKF50A Adapter (For 32/44 GHz units)
•34WFV50 Adapter (For 90/110/145/170 GHz units)
•33W.8F50 Adapter (For 145/170 GHz units)
Frequency Accuracy Verification
1. Connect the 10 MHz Reference to the 10 MHz REF IN on the Anritsu MG3697C.
2. Connect the RF Output of the MG3697C to the RF In of the MS276xA.
3. Turn on the 10 MHz Reference Standard and the Anritsu MG3697C Synthesized Signal Source.
4. Set the MG3697C output to the frequency shown in the Frequency column of Table A-1, “Frequency
Accuracy” on page A-2, for the MS276xA model being tested.
5. Set the MG3697C RF Output Level to –10 dBm.
6. Preset the MS276xA.
7. Set the MS276xA center frequency to the frequency shown in the Frequency column of Table A-1,
“Frequency Accuracy” on page A-2, for the MS276xA model being tested.
8. Set the MS276xA span to 50 kHz.
9. Set the MS276xA display points to 4001.
10. On the MS276xA, perform a single sweep and then using the marker menu perform a peak search.
11. Record the measured frequency value in the Measured Value column of Table A-1, “Frequency Accuracy”
on page A-2.
12. Calcuate the deviation which is the difference between the Measured Value and Expected Value, and
record in the Deviation column of Table A-1, “Frequency Accuracy” on page A-2.
13. Ensure Deviation ± Uncertainty are within the Specification.
Note Do not connect the external 10 MHz Reference to the MS276xA.
Note Allow equipment to warm up for 30 minutes prior to taking measurements.
Note Frequency accuracy specification (+/-0.2 ppm) is at time of calibration (adjustment). Aging value
(+/-1.0 ppm) must be added to determine the specification when the instrument is verified.

2-3 Amplitude Accuracy Verification Spectrum Analyzer Verification
2-4 PN: 10580-00433 Rev. D MS276xA MM
2-3 Amplitude Accuracy Verification
The tests in this section verify the absolute amplitude accuracy of the MS276xA.
Equipment Required
•Anritsu MG3697C Synthesized Signal Source
•Rohde and Schwarz NRP40T Power Sensor (for 32 and 44 GHz units)
•Rohde and Schwarz NRP67T Power Sensor (for 50 and 70 GHz units)
•Rohde and Schwarz NRP110T Power Sensor (for 90, 110, 145, and 170 GHz units)
•Elva-1 DPM-06 Power Meter (for 145 and 170 GHz units)
•110 GHz Frequency Multiplier (for 90, 110, 145, and 170 GHz units)
•12 VDC Power Supply (for the 110 GHz Frequency Multiplier)
•170 GHz Frequency Multiplier (for 145 and 170 GHz units)
•Quinstar QJH-DLFB00 Power Divider (for 145 and 170 GHz units)
•Mi-Wave 690D-1.5 waveguide section
•Anritsu 33W.8F50 Adapter (for 145 and 170 GHz units)
•Flann 29373-F Adapter (for 145 and 170 GHz units)
•Millitech FBI-06 Isolator, Qty 2 (for 145 and 170 GHz units)
•Sage SWL-0627-S1 Termination (for 145 and 170 GHz units)
•10 MHz Reference Standard
•34VKF50A Adapter (For 32/44 GHz units)
•34WFV50 Adapter (For 90/110/145/170 GHz units)
•33W.8F50 Adapter (For 145/170 GHz units)
Level Accuracy Below 70 GHz at 0 dBm with IF Gain Off
1. Connect the 10 MHz Reference to the 10 MHz REF IN on the Anritsu MG3697C and Ref connector on the
MS276xA.
2. Connect the NRP power sensor to the MG3697C, ensure the RF Output is off, and zero the sensor.
3. Set the MG3697C to:
•100 MHz and 0 dBm, for all MS2760A models, and turn RF Output On..
•6020 MHz and 0 dBm for all MS2762A models, and turn RF Output On..
4. Record the measured power in column “NRP Reading” in Table A-2, “Amplitude Accuracy Below 70 GHz
at 0 dBm with IF Gain Off” on page A-3.
5. Repeat Step 3 and Step 4 for the remaining frequencies in Table A-2.
6. Turn off the RF Output, remove the NRP power sensor from the MG3697C, and attach the MS276xA to
the MG3697C.
7. Preset the MS276xA.
8. Set the MS276xA frequency reference to External.
9. Set the MS276xA reference level to 10 dBm.
10. Set the MS276xA RBW to 10 kHz.
11. Set the MS276xA span to 1 MHz.
12. Set the MS276xA center frequency to:
Note Allow equipment to warm up for 30 minutes prior to taking measurements.

Spectrum Analyzer Verification 2-3 Amplitude Accuracy Verification
MS276xA MM PN: 10580-00433 Rev. D 2-5
•100 MHz for all MS2760A models.
•6020 MHz for all MS2762A models.
13. Set the MG3697C to:
•100 MHz and 0 dBm, for all MS2760A models, and turn RF Output On.
•6020 MHz and 0 dBm for all MS2762A models, and turn RF Output On.
14. On the MS276xA, perform a single sweep and then using the marker menu perform a peak search.
15. Record the value in column “MS276xA Reading” of Table A-2, “Amplitude Accuracy Below 70 GHz at 0
dBm with IF Gain Off” on page A-3.
16. Repeat Step 12 through Step 15 for the remaining frequencies in Table A-2.
17. In Table A-2, subtract the MS276xA reading from the NRP reading and enter this value in the
“Difference Between NRP and MS276xA” column for each frequency.
18. Ensure (Difference Between NRP and MS276xA) ± (Uncertainty) are within the Specification.
Level Accuracy Below 70 GHz at –20 dBm with IF Gain On
1. Connect the 10 MHz Reference to the 10 MHz REF IN on the Anritsu MG3697C and Ref connector on the
MS276xA.
2. Connect the NRP power sensor to the MG3697C, ensure the RF Output is off, and zero the sensor.
3. Set the MG3697C to:
•100 MHz and -20 dBm, for all MS2760A models, and turn RF Output On..
•6020 MHz and -20 dBm for all MS2762A models, and turn RF Output On..
4. Record the measured power in column “NRP Reading” in Table A-3, “Amplitude Accuracy Below 70 GHz
at –20 dBm with IF Gain On” on page A-3.
5. Repeat Step 3 and Step 4 for the remaining frequencies in Table A-3.
6. Turn off the RF Output, remove the NRP power sensor from the MG3697C, and attach the MS276xA to
the MG3697C.
7. Preset the MS276xA.
8. Set the MS276xA frequency reference to External.
9. Set the MS276xA reference level to –10 dBm.
10. Set the MS276xA IF Gain to On.
11. Set the MS276xA RBW to 10 kHz.
12. Set the MS276xA span to 1 MHz.
13. Set the MS276xA center frequency to:
•100 MHz for all MS2760A models.
•6020 MHz for all MS2762A models.
14. Set the MG3697C to:
•100 MHz and -20 dBm, for all MS2760A models, and turn RF Output On.
•6020 MHz and -20 dBm for all MS2762A models, and turn RF Output On.
15. On the MS276xA, perform a single sweep and using the marker menu perform a peak search.
16. Record the value in column “MA276xA Reading” of Table A-3, “Amplitude Accuracy Below 70 GHz at
–20 dBm with IF Gain On” on page A-3.
Note Allow equipment to warm up for 30 minutes prior to taking measurements.

2-3 Amplitude Accuracy Verification Spectrum Analyzer Verification
2-6 PN: 10580-00433 Rev. D MS276xA MM
17. Repeat Step 13 through Step 16 for the remaining frequencies in Table A-3.
18. In Table A-3, subtract the MA276xA reading from the NRP reading and enter this value in the
“Difference Between NRP and MA276xA” column for each frequency.
19. Ensure (Difference Between NRP and MS276xA) ± (Uncertainty) are within the Specification.
Level Accuracy, 70 to 110 GHz, at –10 dBm with IF Gain Off (90, 110, 145 and 170 GHz units only)
1. Connect the 10 MHz Reference to the 10 MHz REF IN on the Anritsu MG3697C and Ref connector on the
MS276xA.
2. Connect the input of the 110 GHz Frequency Multiplier to the RF output of the MG3697C.
3. Apply the 12 volt DC power to the 110 GHz Frequency Multiplier.
4. Zero the NRP110T power sensor, and then connect it to the output of the frequency multiplier.
5. Turn on the MG3697C RF output and adjust the power level so the NRP110T reads approximately –10
dBm. Note the power level setting on the MG3697C.
6. Set the MG3697C frequency to 38 GHz, which provides 76 GHz at the output of the Frequency Multiplier.
7. Record the measured power in column “NRP110T Reading” in Table A-4, “Amplitude Accuracy 70 to 110
GHz at –10 dBm with IF Gain Off” on page A-4.
8. Repeat Step 6 through Step 7 for the remaining frequencies in Table A-4.
9. Turn off the MG3697C RF output, remove the NRP110T from the Frequency Multiplier, and attach the
MS276xA to the Frequency Multiplier.
10. Preset the MS276xA.
11. Set the MS276xA frequency reference to External.
12. Set the MS276xA reference level to 0 dBm.
13. Set the MS276xA RBW to 10 kHz.
14. Set the MS276xA span to 1 MHz.
15. Set the MS276xA center frequency to 76 GHz.
16. Set the MG3697C frequency to 38 GHz, the power level will be the same as noted in Step 5, and turn RF
Output On.
17. On the MS276xA, perform a single sweep and using the marker menu perform a peak search.
18. Record the value in column “MA276xA Reading” of Table A-4, “Amplitude Accuracy 70 to 110 GHz at
–10 dBm with IF Gain Off” on page A-4.
19. Repeat Step 15 through Step 18 for the remaining frequencies in Table A-4.
20. In Table A-4, subtract the MA276xA reading from the NRP reading and enter this value in the
“Difference Between NRP and MA276xA” column for each frequency.
21. Ensure (Difference Between NRP and MS276xA) ± (Uncertainty) are within the Specification.
Level Accuracy, 110 to 170 GHz, at –10 dBm with IF Gain Off (145 and 170 GHz units only)
1. Connect the 10 MHz Reference to the 10 MHz REF IN on the Anritsu MG3697C and Ref connector on the
MS276xA.
2. Ensure the MG3697C RF Output Off.
Note Allow equipment to warm up for 30 minutes prior to taking measurements.
Note Allow equipment to warm up for 30 minutes prior to taking measurements.

Spectrum Analyzer Verification 2-3 Amplitude Accuracy Verification
MS276xA MM PN: 10580-00433 Rev. D 2-7
3. Connect the input of the 170 GHz Frequency Multiplier to the RF output of the MG3697C.
4. Connect the output of the 170 GHz Frequency Multiplier to the H port of the Power Divider using the
Mi-Wave 690D-1.5 waveguide section.
5. Connect the Sage SWL-0627-S1 Termination to the E port of the Power Divider.
6. Connect the two Millitech FBI-06 Isolators to each of the Power Divider’s outputs.
7. Connect the Elva-1 DPM-06 to one Isolator.
8. Connect the Flann 29373-F adapter to the other Isolator, and then connect the MS276xA to the adapter.
9. Preset the MS276xA.
10. Set the MS276xA frequency reference to External.
11. Set the MS276xA reference level to 0 dBm.
12. Set the MS276xA RBW to 10 kHz.
13. Set the MS276xA span to 1 MHz.
14. Set the MS276xA center frequency to 110 GHz.
15. Set the MG3697C frequency to 27.5 GHz, which provides 110 GHz at the output of the Frequency
Multiplier.
16. Set the MG3697C power level so the Elva-1 Power meter is reading approximately -10 dBm.
17. Record the measured power in column “Elva-1 Reading” in Table A-5, “Amplitude Accuracy 110 to 170
GHz at –10 dBm with IF Gain Off” on page A-4.
18. On the MS276xA, perform a single sweep and using the marker menu perform a peak search.
19. Record the value in column “MA276xA Reading” of Table A-5, “Amplitude Accuracy 110 to 170 GHz at
–10 dBm with IF Gain Off” on page A-4.
20. Repeat Step 15 through Step 18 for the remaining frequencies in Table A-5.
21. In Table A-5, subtract the MA276xA reading from the Elva-1 reading and enter this value in the
“Difference Between Elva-1 and MA276xA” column for each frequency.
22. Ensure (Difference Between Elva-1 and MS276xA) ± (Uncertainty) are within the Specification.

2-4 Single Side Band (SSB) Phase Noise Verification Spectrum Analyzer Verification
2-8 PN: 10580-00433 Rev. D MS276xA MM
2-4 Single Side Band (SSB) Phase Noise Verification
This test is used to verify the single side band (SSB) phase noise of the MS276xA.
Equipment Required
•Anritsu MG3697C Synthesized Signal Source
•10 MHz Reference Standard
•34VKF50A Adapter (For 32/44 GHz units)
•34WFV50 Adapter (For 90/110/145/170 GHz units)
•33W.8F50 Adapter (For 145/170 GHz units)
SSB Phase Noise Verification
1. Connect the 10 MHz Reference to the 10 MHz REF IN on the Anritsu MG3697C and Ref connector on the
MS276xA.
2. Connect the output of the MG3697C to the RF In connector of MS276xA.
3. Set the MG3697C to:
•6 GHz and -10 dBm, for all MS2760A models, and turn RF Output On.
•7 GHz and -10 dBm for all MS2762A models, and turn RF Output On.
4. Preset the MS276xA.
5. Set the MS276xA frequency reference to External.
6. Set the MS276xA display points to 2001.
7. Set the MS276xA center frequency to:
•6 GHz for MS2760A models
•7 GHz for MS2762A models
8. Set the MS276xA span to 25 kHz.
9. Set the MS276xA RBW to 300 Hz.
10. Set the MS276xA VBW to 100 Hz.
11. On the MS276xA, turn on Marker 1 and perform a peak search.
12. On the MS276xA, turn on Marker 2 and then change the Mode to Delta Relative to Marker 1. Move
Marker 2 to be 1 kHz offset from Marker 1.
13. Set the MS276xA reference level to –40 dBm.
14. Set the MS276xA IF Gain to On.
15. Record 10 amplitude measurements of Marker 2, average the 10 values and record in the Measured
Value of Table A-6, “SSB Phase Noise Verification for MS276xA” on page A-5.
16. Subtract 24.7 dB from the Measured Value to get a per hertz (/Hz) value and record this value in the
Calculated Value of Table A-6, “SSB Phase Noise Verification for MS276xA” on page A-5.
17. On the MS276xA, move Marker 2 to be 10 kHz offset from Marker 1 and repeat Step 15 and Step 16.
18. Set the MS276xA RBW to 1000 Hz
19. Set the MS276xA VBW to 300 Hz
20. Set the MS276xA span to 250 kHz
21. On the MS276xA, move Marker 2 to be 100 kHz offset from Marker 1.
Note Allow the equipment to warm up for 30 minutes prior to taking measurements.

Spectrum Analyzer Verification 2-4 Single Side Band (SSB) Phase Noise Verification
MS276xA MM PN: 10580-00433 Rev. D 2-9
22. Record 10 amplitude measurements of Marker 2, average the 10 values and record in the Measured
Value of Table A-6, “SSB Phase Noise Verification for MS276xA” on page A-5.
23. Subtract 30 dB from the Measured Value to get a per hertz (/Hz) value and record this value in the
Calculated Value of Table A-6, “SSB Phase Noise Verification for MS276xA” on page A-5.
24. Ensure (Calculated Value) ± (Uncertainty) both are within the Specification.
25. Repeat this procedure with a source and DUT frequency of 30 GHz for all MS276xA’s, and 60 GHz for
MS276xA’s supporting 60 GHz. Record the measurements in Table A-6, “SSB Phase Noise Verification
for MS276xA” on page A-5.

2-5 Spurious Response (Second Harmonic Distortion) Verification Spectrum Analyzer Verification
2-10 PN: 10580-00433 Rev. D MS276xA MM
2-5 Spurious Response (Second Harmonic Distortion) Verification
The following test is used to verify the spurious response of the MS276xA.
Equipment Required
•Anritsu MG3697C Synthesized Signal Source
•10 MHz Reference Standard
•34VKF50A Adapter (For 32/44 GHz units)
•34WFV50 Adapter (For 90/110/145/170 GHz units)
•33W.8F50 Adapter (For 145/170 GHz units)
Spurious Response Verification
1. Connect the 10 MHz Reference to the 10 MHz REF IN on the Anritsu MG3697C and Ref connector on the
MS276xA.
2. Connect the output of the MG3697C to the RF In connector of MS276xA.
3. Set the MG3697C to:
•1 GHz and 0 dBm, for all MS2760A models, and turn RF Output On.
•7 GHz and -25 dBm for all MS2762A models, and turn RF Output On.
4. Preset the MS276xA.
5. Set the MS276xA frequency reference to External.
6. Set the MS276xA display points to 1001.
7. Set the MS276xA Reference Level to:
•10 dBm for the MS2760A.
•-15 dBm for the MS2762A.
8. Set the MS276xA Center Frequency to:
•1 GHz for the MS2760A.
•7 GHz for the MS2762A.
9. Set the MS276xA span to 100 kHz.
10. Set the MS276xA RBW to 300 Hz.
11. Set the MS276xA VBW to 300 Hz.
12. On the MS276xA, using the marker menu perform a peak search and record the amplitude of the
fundamental signal in the Measured Value of Table A-7, “Spurious Response (Second Harmonic
Distortion)” on page A-6.
13. Set the MS276xA Center Frequency to:
•2 GHz for the MS2760A.
•14 GHz for the MS2762A.
14. Set the MS276xA reference level to -40 dBm.
15. Set the MS276xA IF gain to On.
16. On the MS276xA, using the marker menu perform a peak search and record the amplitude of the
harmonic signal in the Measured Value of Table A-7, “Spurious Response (Second Harmonic Distortion)”
on page A-6.
17. Subtract the harmonic from the fundamental and record as the 2nd Harmonic Distortion value in
Table A-7, “Spurious Response (Second Harmonic Distortion)” on page A-6.
Note Allow the equipment to warm up for 30 minutes prior to taking measurements.
