ANTAIRA INJ-C201G-bt-100-24-T User manual

INJ-C201G-bt-100-24-T
Industrial Gigabit Enhanced PoE++ Injector, with 1*10/100/1000Base-T(X)
with Enhanced PoE-PSE (100W/Port) and 1*10/100/1000Base-T(X),
Booster Version, 9~55VDC; EOT: -40°C ~ 75°C
Hardware Manual
Version 1.0
(November 2021)

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
© Copyright 2021 Antaira Technologies, LLC
All rights reserved
This document contains information, which is protected by copyright. Reproduction, adaptation, or
translation without prior permission is prohibited, except as allowed under the copyright laws.
Trademark Information
Antaira is a registered trademark of Antaira Technologies, LLC, Microsoft Windows, and the Windows logo
are the trademarks of Microsoft Corp. NetWare is the registered trademark of Novell Inc. WMM and WPA
are the registered trademarks of Wi-Fi Alliance. All other brand and product names are trademarks or
registered trademarks of their respective owners.
Notice: Copyrights © 2021 by Antaira Technologies, LLC. All rights reserved. Reproduction, adaptation, or
translation without prior permission of Antaira Technologies, LLC is prohibited, except as allowed under
the copyright laws.
Disclaimer
Antaira Technologies, LLC provides this manual without warranty of any kind, expressed or implied,
including but not limited to the implied warranties of merchantability and fitness for a particular purpose.
Antaira Technologies, LLC may make improvements and/or changes to the product and/or specifications
of the product described in this manual, without prior notice. Antaira Technologies, LLC will not be liable
for any technical inaccuracies or typographical errors found in this guide. Changes are periodically made
to the information contained herein and will be incorporated into later versions of the manual. The
information contained is subject to change without prior notice.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class-A digital device,
according to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy. It may cause harmful interference to radio communications if the equipment is not
installed and used following the instructions. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
●Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the grantee of this device could void
the user’s authority to operate the equipment.
Avertissement FCC
Cet équipement a été testé et déclaré conforme aux limites d'un appareil numérique de classe A,
conformément à la partie 15 des règles de la FCC. Ces limites sont conçues pour fournir une protection
raisonnable contre les interférences nuisibles dans une installation résidentielle. Cet équipement génère,
utilise et peut émettre de l'énergie radiofréquence. Cela peut provoquer des interférences nuisibles aux
communications radio si l'équipement n'est pas installé et utilisé conformément aux instructions.
Cependant, il n'y a aucune garantie qu'aucune interférence ne se produira dans une installation
particulière. Si cet équipement provoque des interférences nuisibles à la réception radio ou télévision, ce
qui peut être déterminé en éteignant puis en rallumant l'équipement, l'utilisateur est encouragé à essayer
de corriger les interférences par une ou plusieurs des mesures suivantes:
●Réorientez ou déplacez l'antenne de réception.
●Augmentez la distance entre l'équipement et le récepteur.
●Connectez l'équipement à une prise sur un circuit différent de celui auquel le récepteur est
connecté.
●Consultez le revendeur ou un technicien radio / TV expérimenté pour obtenir de l'aide.
CE Mark Warning
This is a Class-A product. In a domestic environment, this product may cause radio interference in which
case the user may be required to take adequate measures.
Avertissement de marque CE
Ceci est un produit de classe A. Dans un environnement domestique, ce produit peut provoquer des
interférences radio, auquel cas l'utilisateur peut être amené à prendre des mesures adéquates.

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
Industrial PoE++ Injector
Industrial Grade PoE++ Injector
Hardware Manual
Version 1.0 (November 2021)
The manual supports the following models:
●INJ-C201G-bt-100-24-T
This document is the current official release hardware manual. Please check our website
(www.antaira.com) for any updated manual or contact us by e-mail ([email protected]).

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
Table of Contents
1 Overview 1
1.1 Product Hardware Features 1
1.2 Package Contents 2
1.3 Safety Precaution 2
2 Hardware Description 4
2.1 Physical Dimensions 4
2.2 Front View Panel 5
2.3 Top View Panel 5
2.4 LED Indicators 6
2.5 DIP Switch 7
2.6 Relay Contact Alarm Warning 8
2.7 Ethernet Ports 8
2.8 Cabling 9
2.9 Wiring the Power Inputs 9
2.10 Wiring the Fault Alarm Contact 10
2.11 Grounding Note 11
3 Mounting Installation 12
3.1 DIN-Rail Mounting 12
3.2 Wall Mounting 13
4 Hardware Installation 15
4.1 Installation Steps 15
4.2 Maintenance and Service 16
4.3 Troubleshooting 16
5 Technical Specifications 17

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
1 Overview
Antaira Technologies’ INJ-C201G-bt-100-24-T, solves the problem simply by deploying data and power
from non-PoE switch and power input to the PD device. PoE injector is a brilliant low-cost solution for the
case that only one side of devices is supporting PoE function. Therefore, INJ-C201G-bt-100-24-T will be
your best choice to deal with the lack of PoE function cases.
INJ-C201G-bt-100-24-T supports low voltage 9VDC model with power booster technology, ensuring full
90W PoE output, for better usage in the automation industry. Moreover, for some special applications
which are eager for more PoE power from the PSE device, this model also supports Enhanced PoE mode
to offer up to 100W to the powered device. INJ-C201G-bt-100-24-T with fan-less design, besides
extending surely to various industrial applications, it works perfectly in polarized temperature from -40°C
to 75°C, and undoubtedly becomes your best option in the industrial market.
1.1 Product Hardware Features
System Interface and Performance
- Embedded 1*10/100/1000Tx RJ45 port (90W/Port) and 1*10/100/1000Tx RJ45 port
- Support IEEE 802.3af/at/bt Compliant PoE
- Support auto detection and classification for PoE application
- Support short-circuit and current-overloading protection for PoE application
- Dip-switch setting for PoE mode and dual PD check
Power Input
- Dual DC 9~55V redundant, with a 4-pin removal terminal block
- Max. current 8A (Included PoE power budget)
- Max. PoE output: 60W@9V, 90W@12V, 100W@24-55VDC
- The power input specification complies with the requirements of SELV (Safety Extra Low Voltage)
and the power supply should comply with UL 61010-1 & UL 61010-2-201
Operating Temperature
- Extended operating temperature model: -40°C to 75°C
Case / Installation
- IP30 protection metal housing
- DIN-Rail and wall-mount design
- Installation in a Pollution Degree 2 industrial environment
1

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
1.2 Package Contents
- INJ-C201G-bt-100-24-T
- Quick Installation Guide
- Wall mounting bracket set with screws
- DC cable - 18AWG & DC jack 5.5 x 2.1mm **Wire: White (+) / Black (-)
- Dust cover set
1.3 Safety Precaution
Attention: If the DC voltage is supplied by an external circuit, please use a protection device on the power
supply input. The industrial PoE injector’s hardware specs, ports, cabling information, and wiring
installation will be described within this hardware manual.
Attention: Si la tension CC est fournie par un circuit externe, veuillez utiliser un dispositif de protection sur
l'entrée d'alimentation. Les spécifications matérielles, les ports, les informations de câblage et
l'installation du câblage de l'injecteur PoE industriel seront décrits dans ce manuel du matériel.
2

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
Warning Labels
The caution label means that you should check certain information on the user manual when working
with the device. (Shown in Figure 1.1)
Étiquettes d'avertissement
L'étiquette d'avertissement signifie que vous devez vérifier certaines informations du manuel d'utilisation
lorsque vous travaillez avec l'appareil. (Illustré à la figure 1.1)
Figure 1.1 - Caution Label
Figure 1.1 - Étiquette de mise en garde
Figure 1.2 - Hot Surface Warning Label
Figure 1.2 - Étiquette d'avertissement de surface chaude
3

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
2 Hardware Description
2.1 Physical Dimensions
Figure 2.1, below, shows the physical dimensions of this product series:
(W x D x H) is 30mm x 75mm x 95mm
Figure 2.1 - Physical Dimensions
4

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
2.2 Front View Panel
Figure 2.2, below, shows the front panel of the product series:
Figure 2.2 - Front View Panel
2.3 Top View Panel
Figure 2.3, below, shows the top panel of the product series:
Figure 2.3 - Top View Panel
5

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
2.4 LED Indicators
There are LED light indicators located on the front panel of the industrial PoE injector that display the
power status and network status. Each LED indicator has a different color and has its specific meaning,
see below in Table 2.1.
LED
Color
Description
Power
Green
On
Power input 1 or 2 is active
Red
On
Power input 1 or 2 is inactive, trigger relay
-
Off
Power input 1 and 2 is inactive
PoE
Amber
On
The PoE output port is supplying power to the
powered-device over 2 pairs
Green
On
The PoE output port is supplying power to the
powered-device over 4 pairs
Amber
Flashing
The PoE output port is supplying power to the
powered-device over 2 pairs after the Dual PD Check
event happens.
(only occurs when Dual PD Check function is disabled)
Green
Flashing
The PoE output port once supplied power to the
powered-device over 2 pairs and now recovers to
supply power over 4 pairs.
-
Off
No powered-device attached or power supplying fails
P/L
-
Off
Actual Consumption ≦30W
Blue
On
31W≦ Actual Consumption ≦60W
Red
On
61W≦ Actual Consumption ≦90W
Red
Flashing
91W≦ Actual Consumption ≦100W
(only occurs when PoE enhanced mode is enabled)
Table 2.1 - LED Indicators
6

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
2.5 DIP Switch
There is a 2-set DIP switch in the front panel that can be used for setting the PoE Mode and Dual PD
Check functions. The default setting for all DIP switches is “OFF”. See Table 2.2 and description below for
more details.
ON
OFF (Default)
DIP Switch 1
Enhanced PoE Mode
Standard PoE Mode
DIP Switch 2
Dual PD Check Enabled
Dual PD Check Disabled
Table 2.2 - DIP Switch Setting for INJ-C201G-bt-100-24 Series
DIP Switch 1
OFF: Enable “Standard PoE Mode” function.
The PoE Output will be activated following IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt PoE Standard
ON: Enable “Enhanced PoE Mode”
The PoE Output will be activated based on the used pairs. If the PSE output is over 2 pairs, the max. PoE
budget is 50W; If the PSE output is over 4 pairs, the max. PoE budget is 100W.
DIP Switch 2
OFF: Disabled “Dual PD Check” function
When Dual PD Check is disabled, the port will detect, classify and service power on request for either
channel regardless of the detection result on the other channel.
ON: Enabled “Dual PD Check” function
When Dual PD check is set, if an invalid detection signature is discovered on either channel, the port will
not perform classification or grant power on requests.
*Note:
1. When Dual PD Check is disabled in Standard PoE Mode and one of the channels fails, the PoE budget will
be based on the classification of the valid channel.
2. When Dual PD Check is disabled in Enhanced PoE Mode and one of the channels fails, the PoE budget
will become max.50W over 2 pairs.
7

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
2.6 Relay Contact Alarm Warning
The relay contact alarm supports power redundancy failed, PoE total output watts >100% warning and
PoE over current or cable short warning. There are 5 key trigger events, please follow the below rules:
The relay contact alarm will be triggered when any of the listed events occurs.
Key trigger event 1: Power-1 or Power-2 is inactive
Key trigger event 2: PoE total loading >100% PoE output budget
Key trigger event 3: PoE over current per port
Key trigger event 4: Cable short per port
Key trigger event 5: One of the channels in Dual PD fail
[Notice] When the relay is triggered because of Event 2~5, the relay contact alarm will update the status
every 30 seconds. If there is no event happening for 30 seconds, the relay contact alarm will be turned off.
If the user disables the failed PoE port by removing the cable or Dip Switch manually, the relay will be
recovered immediately.
2.7 Ethernet Ports
●RJ45 Ports
RJ45 Ports (Auto MDI/MDI-X): The RJ45 ports are auto-sensing for 10Base-T, 100Base-TX, or
1000Base-T connections. Auto MDI means that the switch can connect to another switch or workstation
without changing the straight-through or crossover cabling. See the figures below for straight-through and
crossover cabling schematics.
●RJ45 Pin Assignments
Crossover Cable
Straight Through Cable
Pin Number / Signal
Pin Number / Signal
Pin Number / Signal
Pin Number / Signal
1 / RX+
3 / TX+
1 / RX+
1 / TX+
2 / RX-
6 / TX-
2 / RX-
2 / TX-
3 / TX+
1 / RX+
3 / TX+
3 / RX+
6 / TX-
2 / RX-
6 / TX-
6 / RX-
Table 2.3 - 10/100Base-T(X) RJ45 Pin Assignments
8

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
Crossover Cable
Straight Through Cable
Pin Number / Signal
Pin Number / Signal
Pin Number / Signal
Pin Number / Signal
1 / TP0+
3 / TP1+
1 / TP0+
1 / TP1+
2 / TP0-
6 / TP1-
2 / TP0-
2 / TP1-
3 / TP1+
1 / TP0+
3 / TP1+
3 / TP0+
4 / TP2+
7 / TP3+
4 / TP2+
4 / TP3+
5 / TP2-
8 / TP3-
5 / TP2-
5 / TP3-
6 / TP1-
2 / TP0-
6 / TP1-
6 / TP0-
7 / TP3+
4 / TP2+
7 / TP3+
7 / TP2+
8 / TP3-
5 / TP2-
8 / TP3-
8 / TP2-
Table 2.4 - 1000Base-T RJ45 Pin Assignments
Note: “+” and “-” signs represent the polarity of the wires that make up each wire pair.
2.8 Cabling
Use the four twisted-pair, category 5e, or the above cabling for the RJ45 port connections. The cable
between the injector and the link partner (switch, hub, workstation, etc.) must be less than 100 meters
(328 ft.) in length.
2.9 Wiring the Power Inputs
Caution: Please follow the steps below when inserting the power wire.
Attention: Veuillez suivre les étapes ci-dessous lors de l'insertion du câble d'alimentation.
1. Insert the positive and negative wires into the PWR1 (V1+, V1-) and PWR2 (V2+, V2-) contacts on the
terminal block connector as shown below in Figure 2.4.
Figure 2.4 - Power Terminal Block
9

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
2. Tighten the wire-clamp screws to prevent the wires from loosening, as shown below in Figure 2.5.
Figure 2.5 - Power Terminal Block
Caution:
Only use copper conductors, 125°C, tighten to 5 lbs.
The wire gauge for the terminal block should range between 18~20 AWG.
Attention:
Utilisez uniquement des conducteurs en cuivre, 125°C, serrez à 5 lb.
Le calibre des fils du bornier doit être compris entre 18 et 20 AWG.
2.10 Wiring the Fault Alarm Contact
The fault alarm contact is on the 2-pin terminal block connector as the picture shown below. By inserting
the wires, it will detect the fault status including power failure or port link failure (managed industrial
switch only) and form a normally open circuit. An application example for the fault alarm contact is
shown below in Figure 2.6.
Figure 2.6 - Fault Alarm Contact
10

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
2.11 Grounding Note
Grounding and wire routing help limit the effects of noise due to Electromagnetic Interference (EMI). Run
the ground connection from the ground screw to the grounding surface before connecting devices. The
grounding screw symbol is shown below in Figure 2.7.
Figure 2.7 - Grounding Screw Symbol
Caution: Using a shielded cable achieves better electromagnetic compatibility.
Attention: L'utilisation d'un câble blindé permet une meilleure compatibilité électromagnétique
11

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
3 Mounting Installation
3.1 DIN-Rail Mounting
The DIN-Rail is pre-installed on the industrial PoE injector from the factory. If the DIN-Rail is not on the
industrial PoE injector, please see Figure 3.1 to learn how to install the DIN-Rail on the injector.
Follow the steps below to learn how to hang the industrial PoE injector:
1. Use the screws to install the DIN-Rail bracket on the rear side of the industrial PoE injector.
Caution: The torque for tightening the screws on the device is 3.5 in-lbs.
Attention: Le couple de serrage des vis sur l'appareil est de 3.5 pouces-livres.
2. To remove the DIN-Rail bracket, do the opposite from step 1.
3. After the DIN-Rail bracket is installed on the rear side of the injector, insert the top of the
DIN- Rail onto the track as shown below in Figure 3.2.
4. Lightly pull down the bracket onto the rail as shown below in Figure 3.3.
5. Check if the bracket is mounted tightly on the rail.
6. To remove the industrial PoE injector from the rail, do the opposite from the above steps.
Figure 3.1 - Rear View of the Injector and DIN-Rail
12

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
Figure 3.2 - Insert the Injector on the DIN-Rail Figure 3.3 - Stable the Injector on the DIN-Rail
3.2 Wall Mounting
Follow the steps below to mount the industrial PoE injector using the wall mounting bracket as shown
below in Figure 3.4.
Caution: “Wall” means industrial control panel wall
Attention: “Wall” signifie mur de panneau de commande industriel
1. Remove the DIN-Rail bracket from the industrial PoE injector by loosening the screws.
2. Place the wall mounting brackets on the top and bottom of the industrial PoE injector.
3. Use the screws to screw the wall mounting bracket on the industrial PoE injector.
Caution: The torque for tightening the screws on the device is 3.5 in-lbs.
Attention: Le couple de serrage des vis sur l'appareil est de 3.5 pouces-livres.
4. Use the hook holes at the corners of the wall mounting bracket to hang the industrial PoE injector
on the wall.
5. To remove the wall mount bracket, do the opposite from the steps above.
13

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
Figure 3.4 - Remove DIN-Rail bracket from the Injector
Below, in Figure 3.5 are the dimensions of the wall mounting bracket.
Figure 3.5 - Wall Mounting Bracket Dimensions
14

Antaira Technologies - Industrial Gigabit PoE++ Injector
INJ-C201G-bt-100-24-T - Hardware Manual - v1.0
4 Hardware Installation
4.1 Installation Steps
This section will explain how to install the industrial PoE injector:
Caution: This device is intended for indoor use.
Attention: Cet appareil est destiné à une utilisation en intérieur.
Caution: The device is intended to be installed in an industrial control enclosure and panel.
Attention: L'appareil est destiné à être installé dans une armoire de commande et un panneau
industriels.
Installation Steps
1. Unpack the industrial PoE injector from the original packing box.
2. Check if the DIN-Rail bracket is screwed on the industrial PoE injector.
●If the DIN-Rail is not screwed on the industrial PoE injector, please refer to the DIN-Rail
Mounting section for DIN-Rail installation.
●If it is required to wall mount the industrial PoE injector, please refer to the Wall Mounting
section for wall mounting installation.
3. To hang the industrial PoE injector on a DIN-Rail or wall, please refer to the Mounting Installation
section.
4. Power on the industrial PoE injector and then the power LED light will turn on.
●For the help on how to wire power, please refer to the Wiring the Power Inputs section.
●Please refer to the LED Indicators section for LED light indication.
5. Prepare the twisted-pair, straight-through category 5 cable for Ethernet connection.
6. Insert one side of the RJ45 cable into the injector’s Ethernet port and on the other side into the
networking device’s Ethernet port, e.g. switch PC or server.
7. When all connections are set, the installation is complete.
15
