ADTRAN OSU 300 User manual

OSU 300
User Manual
61200663L1-1B
May 2001
1200663L1 Single Mode SC
1200663L2 Multi-mode SC
1200663L4 Multi-mode ST
1200218L1 HSSI DTE Interface Card
1200219L1 V.35 DTE Interface Card
1200284L1 Quad DSX-1 Interface Card

Trademark Information
OpenView is a trademark of Hewlett-Packard Company.
Spectrum is a registered trademark of Cabletron.
Netview is a registered trademark of IBM.
901 Explorer Boulevard
P.O. Box 140000
Huntsville, AL 35806
[phone]
© 2001 ADTRAN, Inc.
All Rights Reserved.
Printed in U.S.A.

iii
The following conventions are used in this manual.
Important Safety Instructions
When using your telephone equipment, please follow these basic safety precautions
to reduce the risk of fire, electrical shock, or personal injury:
1. Do not use this product near water, such as near a bathtub, wash bowl, kitchen
sink, laundry tub, in a wet basement, or near a swimming pool.
2. Avoid using a telephone (other than a cordless-type) during an electrical storm.
There is a remote risk of shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord, power supply, and/or batteries indicated in the manual.
Do not dispose of batteries in a fire. They may explode. Check with local codes
for special disposal instructions.
Save These Important Safety Instructions
Notes provide additional useful information.
Cautions signify information that could prevent service interruption.
Warnings provide information that could prevent damage to the equip-
ment or endangerment to human life.

iv
Federal Communications Commission Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class A dig-
ital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in
a commercial environment. This equipment generates, uses, and can radiate radio fre-
quency energy and, if not installed and used in accordance with the instruction man-
ual, may cause harmful interference to radio frequencies. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at his own expense.
Shielded cables must be used with this unit to ensure compliance with Class A FCC
limits.
Change or modifications to this unit not expressly approved by the party re-
sponsible for compliance could void the user’s authority to operate the equip-
ment.

v
Limited Product Warranty
ADTRAN warrants that for five (5) years from the date of shipment to Customer, all
products manufactured by ADTRAN will be free from defects in materials and work-
manship. ADTRAN also warrants that products will conform to the applicable speci-
fications and drawings for such products, as contained in the Product Manual or in
ADTRAN's internal specifications and drawings for such products (which may or
may not be reflected in the Product Manual). This warranty only applies if Customer
gives ADTRAN written notice of defects during the warranty period. Upon such
notice, ADTRAN will, at its option, either repair or replace the defective item. If ADT-
RAN is unable, in a reasonable time, to repair or replace any equipment to a condition
as warranted, Customer is entitled to a full refund of the purchase price upon return
of the equipment to ADTRAN. This warranty applies only to the original purchaser
and is not transferable without ADTRAN's express written permission. This warranty
becomes null and void if Customer modifies or alters the equipment in any way, other
than as specifically authorized by ADTRAN.
EXCEPT FOR THE LIMITED WARRANTY DESCRIBED ABOVE, THE FOREGOING
CONSTITUTES THE SOLE AND EXCLUSIVE REMEDY OF THE CUSTOMER AND
THE EXCLUSIVE LIABILITY OF ADTRAN AND IS IN LIEU OF ANY AND ALL
OTHER WARRANTIES (EXPRESSED OR IMPLIED). ADTRAN SPECIFICALLY DIS-
CLAIMS ALL OTHER WARRANTIES, INCLUDING (WITHOUT LIMITATION),
ALL WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. SOME STATES DO NOT ALLOW THE EXCLUSION OF IMPLIED WAR-
RANTIES, SO THIS EXCLUSION MAY NOT APPLY TO CUSTOMER.
In no event will ADTRAN or its suppliers be liable to Customer for any incidental,
special, punitive, exemplary or consequential damages experienced by either Cus-
tomer or a third party (including, but not limited to, loss of data or information, loss
of profits, or loss of use). ADTRAN is not liable for damages for any cause whatso-
ever (whether based in contract, tort, or otherwise) in excess of the amount paid for
the item. Some states do not allow the limitation or exclusion of liability for incidental
or consequential damages, so the above limitation or exclusion may not apply to Cus-
tomer.

vi
Customer Service, Product Support Information, and Training
ADTRAN will replace or repair this product within five years from the date of ship-
ment if the product does not meet its published specification, or if it fails while in ser-
vice.
A return material authorization (RMA) is required prior to returning equipment to
ADTRAN. For service, RMA requests, training, or more information, see the toll-free
contact numbers given below.
Presales Inquiries and Applications Support
Please contact your local distributor, ADTRAN Applications Engineering, or ADT-
RAN Sales:
Post-Sale Support
Please contact your local distributor first. If your local distributor cannot help, please
contact ADTRAN Technical Support and have the unit serial number available.
The Custom Extended Services (ACES) program offers multiple types and levels of ser-
vice plans which allow you to choose the kind of assistance you need. For questions,
call the ACES Help Desk.
Repair and Return
If ADTRAN Technical Support determines that a repair is needed, Technical Support
will coordinate with the Custom and Product Service (CAPS) department to issue an
RMA number. For information regarding equipment currently in house or possible
fees associated with repair, contact CAPS directly at the following number:
Applications Engineering [phone]
Sales [phone]
Technical Support (888) 4ADTRAN
ACES Help Desk [phone]
CAPS Department [phone]

vii
Identify the RMAnumber clearly on the package (belowaddress), and returnto the fol-
lowing address:
ADTRAN Customer and Product Service
901 Explorer Blvd.
Huntsville, Alabama 35806
RMA # _____________
Training
The Enterprise Network (EN) Technical Training Department offers training on our
most popular products. These courses include overviews on product features and func-
tions while covering applications of ADTRAN's product lines. ADTRAN provides a va-
riety of training options, including customized training and courses taught at our
facilities or at your site. For more information about training, please contact your Terri-
tory Manager or the Enterprise Training Coordinator.
Training - phone [phone], ext. 7500
Training - fax [phone]
Training - email [e-mail]

viii

61200663L1-1 OSU 300 User Manual ix
Table of Contents
List of Figures .....................................................................................................................xv
List of Tables .................................................................................................................... xvii
Chapter 1. Introduction
Product Overview ...............................................................................................................1-1
Optical Interface Port .......................................................................................................... 1-2
SNMP .................................................................................................................................... 1-3
Telnet ..................................................................................................................................... 1-4
Interface Option Cards ....................................................................................................... 1-4
HSSI Card.......................................................................................................................1-4
V.35 Card........................................................................................................................ 1-5
Quad DSX-1 Card ......................................................................................................... 1-5
Chapter 2. Installation and Operation
Receiving Inspection ...........................................................................................................2-1
Shipping Contents ............................................................................................................... 2-1
Customer Provides ..............................................................................................................2-1
Installing the Unit ................................................................................................................ 2-2
Rackmount Installation................................................................................................ 2-2
Desktop Installation...................................................................................................... 2-3
Reviewing the Rear Panel ..................................................................................................2-3
Strain Relief....................................................................................................................2-5
DC Terminal Block........................................................................................................ 2-5
DTE Ports 2-4 (Expansion Slots)................................................................................. 2-5
DTE Port 1 (HSSI Interface).........................................................................................2-6
Alarm Connector........................................................................................................... 2-6
LAN Port........................................................................................................................2-6
Optical Interface Port.................................................................................................... 2-7
Single-Mode ........................................................................................................... 2-7
Multi-Mode ............................................................................................................ 2-7

Table of Contents
x OSU 300 User Manual 61200663L1-1
Powering the Unit ...............................................................................................................2-8
Reviewing the Front Panel .................................................................................................2-9
Control Port....................................................................................................................2-9
VT-100 Terminal Connection ..............................................................................2-9
Navigating Within the Menus ...........................................................................2-11
OSU 300 Main Menus .........................................................................................2-11
Status .............................................................................................................2-11
Statistics .........................................................................................................2-11
Configuration ...............................................................................................2-11
Diagnostics ....................................................................................................2-11
Remote Login ...............................................................................................2-12
Logout ............................................................................................................2-12
Remote Active LED.....................................................................................................2-12
Optical Interface LEDs................................................................................................2-12
In Service ..............................................................................................................2-12
In Test ...................................................................................................................2-12
Alarm ....................................................................................................................2-12
LOS ........................................................................................................................2-12
DTE Port LEDs.............................................................................................................2-13
Chapter 3. Configuration
DS3 Network ........................................................................................................................3-2
DS3 Timing.....................................................................................................................3-2
Remote Auto-Configuration........................................................................................3-2
XCV Threshold..............................................................................................................3-2
Multiplexing Mode .......................................................................................................3-3
DTE Ports ..............................................................................................................................3-3
Port Selections 1-4 .........................................................................................................3-4
Configuration Selections for HSSI and V.35 Interfaces ...................................3-5
Transmit Clock ...............................................................................................3-7
Configuration Selections for DSX-1 Interfaces .................................................3-8
Timed Profiles..............................................................................................................3-10
Bandwidth Profiles 1 and 2 ...............................................................................3-10
Profile Switch Time (1 and 2) ............................................................................3-11
Active Profile .......................................................................................................3-11
System Management .........................................................................................................3-11
Local IP Address .........................................................................................................3-12
Gateway IP Address...................................................................................................3-12
Subnet Mask.................................................................................................................3-12
Read Community Name ............................................................................................3-12
Write Community Name ...........................................................................................3-13
Trap Community Name.............................................................................................3-13

Table of Contents
61200663L1-1 OSU 300 User Manual xi
Trap IP Addresses....................................................................................................... 3-13
Trap Generation .......................................................................................................... 3-13
Toggle All Traps ..................................................................................................3-15
Password...................................................................................................................... 3-16
Terminal Timeout ....................................................................................................... 3-16
IP Security .................................................................................................................... 3-16
IP Hosts......................................................................................................................... 3-16
Master Control Port .................................................................................................... 3-16
Slave Control Port....................................................................................................... 3-16
Circuit ID......................................................................................................................3-16
Date/Time.................................................................................................................... 3-17
Alarm Relay................................................................................................................. 3-17
Utilities ................................................................................................................................ 3-17
Save Configuration ........................................................................................................... 3-18
Chapter 4. Status
Network: State ..................................................................................................................... 4-2
Network: Alarm .................................................................................................................. 4-2
Remote Status: Alarm .........................................................................................................4-3
Remote Status: Data Link ...................................................................................................4-3
DTE Ports .............................................................................................................................. 4-4
Interface Type................................................................................................................ 4-4
Port Status...................................................................................................................... 4-4
Bandwidth...................................................................................................................... 4-4
DTE Leads...................................................................................................................... 4-4
T1 Status .........................................................................................................................4-5
HSSI Interface Leads ............................................................................................ 4-6
TA (terminal available) ................................................................................. 4-6
CA (communications equipment available) .............................................. 4-6
LA (loopback circuit A) ................................................................................ 4-6
LB (loopback circuit B) ..................................................................................4-6
LC (loopback circuit C) ................................................................................. 4-6
TM (test mode) ............................................................................................... 4-6
V.35 Interface Leads ............................................................................................. 4-7
RS ..................................................................................................................... 4-7
CS ..................................................................................................................... 4-7
CD ....................................................................................................................4-7
TR ..................................................................................................................... 4-7
SR ..................................................................................................................... 4-7
LL ..................................................................................................................... 4-7
RL ..................................................................................................................... 4-7
TM ....................................................................................................................4-7

Table of Contents
xii OSU 300 User Manual 61200663L1-1
Chapter 5. Statistics
Viewing Statistical information .........................................................................................5-1
Alarm History................................................................................................................5-2
Performance Parameters..............................................................................................5-4
Chapter 6. Diagnostics
DS3 ..................................................................................................................................6-2
Data Mode ..............................................................................................................6-2
DS3 Payload Loopback ........................................................................................6-3
BERT .......................................................................................................................6-3
Remote DS3 Loopback .........................................................................................6-3
Remote DS3 Loopback with BERT .....................................................................6-3
DTE Ports 1-4.................................................................................................................6-3
HSSI and V.35 Diagnostic Options .....................................................................6-4
Data Mode .......................................................................................................6-4
Payload Loopback .........................................................................................6-4
Payload BERT .................................................................................................6-5
DTE Loopback ................................................................................................6-5
Payload and DTE Loopback .........................................................................6-6
Remote Port Payload Loopback ..................................................................6-7
Remote Payload Loopback with BERT .......................................................6-7
Quad DSX-1 Diagnostic Options ........................................................................6-7
Data Mode .......................................................................................................6-7
#x Payload Loopback ....................................................................................6-8
#x Framer Loopback ......................................................................................6-8
#x Local Loopback .........................................................................................6-9
#x Line Loopback ...........................................................................................6-9
Payload Loopback .......................................................................................6-10
DTE Loopback ..............................................................................................6-10
Payload and DTE Loopback .......................................................................6-11
Remote Port and Payload Loopback .........................................................6-12
BERT Configuration....................................................................................................6-12
Pattern ...................................................................................................................6-12
Invert Pattern .......................................................................................................6-13
BERT Information Fields ....................................................................................6-13
Port .................................................................................................................6-13
Direction ........................................................................................................6-13
State ................................................................................................................6-13
Errors .............................................................................................................6-14
Current Err/Sec ............................................................................................6-14
Insert Error ...........................................................................................................6-14
Clear Errors ..........................................................................................................6-14

Table of Contents
61200663L1-1 OSU 300 User Manual xiii
Reset All Tests .....................................................................................................6-14
Chapter 7. Applications
Single Port Full T3 Bandwidth .......................................................................................... 7-1
Point-to-Point Multiport Application .............................................................................. 7-2
Fractional T3 Carrier Application ..................................................................................... 7-4
Remote SNMP Management Application ....................................................................... 7-6
Voice Application ................................................................................................................ 7-7
Appendix A. Pinouts ....................................................................................................... A-1
Appendix B. Specifications Summary.......................................................................... B-1
Appendix C. Acronyms/Abbreviations........................................................................ C-1
Appendix D. Glossary..................................................................................................... D-1
Index ........................................................................................................................... Index-1

Table of Contents
xiv OSU 300 User Manual 61200663L1-1

61200663L1-1 OSU 300 User Manual xv
List of Figures
Figure 2-1. OSU 300 Rear Panel Description.................................................................. 2-4
Figure 2-2. Moving the Optical Interface Door..............................................................2-4
Figure 2-3. DC Power Connector ..................................................................................... 2-5
Figure 2-4. OSU 300 Front Panel ......................................................................................2-9
Figure 2-5. OSU 300 Main Menu.................................................................................... 2-10
Figure 3-1. Configuration Main Menu ............................................................................ 3-1
Figure 3-2. DS3 Network Configuration Menu..............................................................3-2
Figure 3-3. DTE Ports Menu .............................................................................................3-3
Figure 3-4. Port Configuration Menus for V.35 and HSSI Interface Cards ................ 3-4
Figure 3-5. Port Configuration Menu for Quad DSX-1 Interface Card.......................3-8
Figure 3-6. Timed Profiles Screen...................................................................................3-10
Figure 3-7. Example of a Profile Configuration Menu................................................ 3-11
Figure 3-8. System Management Configuration Menu ..............................................3-12
Figure 3-9. Trap Generation Menu................................................................................. 3-13
Figure 3-10. System Utilities Menu..................................................................................3-18
Figure 4-1. Status Menu..................................................................................................... 4-1
Figure 5-1. Main Local Statistics Menu Screen...............................................................5-1
Figure 5-2. Current Alarm Count..................................................................................... 5-3
Figure 5-3. 24-Hour Alarm History .................................................................................5-3
Figure 5-4. 24-Hour Alarm Totals .................................................................................... 5-4
Figure 5-5. Quad DSX-1 24 Hour Alarm History.......................................................... 5-4
Figure 5-6. Network Statistics Menu for Current 15-Minute Interval........................ 5-5
Figure 5-7. Network Port Statistics 24-Hour History.................................................... 5-5
Figure 5-8. Network Port Statistics Menu (24-Hour Totals)......................................... 5-6
Figure 6-1. Diagnostics Main Menu................................................................................. 6-2
Figure 6-2. DS3 Diagnostics Menu................................................................................... 6-2

List of Figures
xvi OSU 300 User Manual 61200663L1-1
Figure 6-3. DS3 Payload Loopback Test..........................................................................6-3
Figure 6-4. HSSI or V.35 Port Diagnostics Menu............................................................6-4
Figure 6-5. Payload Loopback Test ..................................................................................6-5
Figure 6-6. Payload BERT Test..........................................................................................6-5
Figure 6-7. DTE Loopback Test.........................................................................................6-6
Figure 6-8. Payload and DTE Loopback Test..................................................................6-6
Figure 6-9. Quad DSX-1 Diagnostics Menu....................................................................6-7
Figure 6-10. T1 Payload Loopback Test.............................................................................6-8
Figure 6-11. Framer Loopback Test....................................................................................6-8
Figure 6-12. T1 Local Loopback Test..................................................................................6-9
Figure 6-13. Line Loopback Test.........................................................................................6-9
Figure 6-14. Payload Loopback Test ................................................................................6-10
Figure 6-15. DTE Loopback Test.......................................................................................6-11
Figure 6-16. Payload and DTE Loopback Test................................................................6-11
Figure 6-17. Remote Port Payload Loopback Test .........................................................6-12
Figure 6-18. BERT Pattern Menu......................................................................................6-13
Figure 7-1. Single Port Application..................................................................................7-1
Figure 7-2. Multiport Application....................................................................................7-3
Figure 7-3. Fractional Application....................................................................................7-5
Figure 7-4. Remote Management Application ...............................................................7-6
Figure 7-5. Voice Application............................................................................................7-7

61200663L1-1 OSU 300 User Manual xvii
List of Tables
Table 2-1. Alarm Connector Terminal Block Description...........................................2-6
Table 3-1. HSSI and V.35 Configuration Selections..................................................... 3-5
Table 3-2. Additional V.35 Interface Port Configuration Selections ......................... 3-6
Table 3-3. DSX-1 Interface Port Configuration Selections ..........................................3-8
Table 3-4. Near End Alarm Trap Descriptions........................................................... 3-14
Table 3-5. Far End Alarm Trap Descriptions..............................................................3-14
Table 3-6. MIB II Standard Trap Descriptions............................................................3-15
Table 3-7. Network Test Trap Descriptions................................................................3-15
Table 3-8. DTE Port Trap Description.......................................................................... 3-15
Table 3-9. Quad DSX-1 Port Trap Description ........................................................... 3-15
Table 4-1. LA and LB Leads ............................................................................................ 4-6
Table 7-1. Single Port Full T3 Bandwidth Application Example .............................. 7-2
Table 7-2. Multiport Application Configuration Example .........................................7-3
Table 7-3. Fractional T3 Application Configuration Example .................................. 7-5
Table 7-4. Configuration Example for Remote SNMP Management Application.. 7-6
Table 7-5. Local OSU 300................................................................................................. 7-6
Table 7-6. Configuration Example for a Voice Application .......................................7-7
Table A-1. Control Port Pin Assignments.....................................................................A-1
Table A-2. HSSI Interface Pin Assignments..................................................................A-2
Table A-3. LAN Port Pin Assignments..........................................................................A-3
Table A-4. V.35 Interface Card Pin Assignments.........................................................A-3
Table A-5. Quad DSX-1 Interface Card Pin Assignments...........................................A-4

List of Tables
xviii OSU 300 User Manual 61200663L1-1

61200663L1-1 OSU 300 User Manual 1-1
Chapter 1 Introduction
PRODUCT OVERVIEW
The OSU 300 is a multiport DSU/CSU (data service unit/channel
service unit) that provides access to high-speed services over
single-mode or multi-mode fiber. The unit provides a cost-effective,
versatile approach for delivering high-speed frame relay and
dedicated digital services at data rates from 75.18 kbps to
44.2 Mbps. The TDM (time division multiplexer) multiport design
allows you to share the cost of the fiber link between multiple
applications. This unit maximizes the use of high-speed services,
providing up to four data ports capable of transmitting and
receiving high-capacity, realtime data.
The OSU 300 contains a built-in HSSI (high speed serial interface)
port and three expansion slots which accept additional HSSI, V.35,
or Quad DSX-1 interface cards. The HSSI interfaces support rates
between 75 kbps and 44.2 Mbps in 75-kbps increments. The high-
speed V.35 interface option card supports rates up to 10 Mbps in
increments of 75 kbps. The Quad DSX-1 interface card provides
four DSX-1 lines. Each DSX-1 port supports rates up to 1.544 Mbps.
Embedded SNMP (simple network management protocol) and
Telnet are available through either a SLIP/PPP or a 10BaseT
Ethernet port. Through the Management Information Base II (MIB
II), and RFC 1213 and 1407 standards, and an ADTRAN Enterprise
MIB, the OSU 300 can be configured, monitored, and diagnosed
using standard SNMP network management programs such as
Hewlett Packard’s HP OpenView™, IBM’s Netview™, Cabletron’s
Spectrum™, and MACS.

Chapter 1. Introduction
1-2 OSU 300 User Manual 61200663L1-1
Complete configuration, diagnostics, and performance monitoring
are available through SNMP, Telnet, or a VT-100 terminal interface.
This connection can be made via Ethernet or a local EIA-232 link.
The OSU 300 is designed for either desktop use or for installation in
a 19-inch rack.
The major features of the OSU 300 are as follows:
• Full feature multiport optical DS3 DSU/CSU
• Maximum of four user data ports: one integrated HSSI port
and three additional slots for optional HSSI, high-speed V.35,
or Quad DSX-1 cards
• Automatic or manual remote configuration
• Embedded SNMP and Telnet management through 10BaseT
Ethernet or SLIP/PPP
• Detailed performance monitoring for local and remote units
• Simplified configuration through detailed VT-100 terminal
menu structure
OPTICAL INTERFACE PORT
• The optical interface of the OSU 300 consists of either a single-
mode or a multi-mode transceiver module comprised of a
transmitter, a receiver, and an SC or ST receptacle.
• The optical interface port supports angled SC type optical
connectors (1200663L1 and L2 only).
• The optical interface port operates in the 1280 nm to 1335 nm
wavelength range (1310 nm nominal).
• The total output power is 8 mW, as defined by IEC with a
50 mm aperture at 10 cm distance.
• The optical interface uses two fibers, one for each direction of
transmission.
• The transceiver optical budgets for the optical transceivers are
28dB (single-mode) and 9 dB (multi-mode). See the Optical
Interface Port section on page 2-7 for calculations.
• The optical interface complies with the physical interface
parameters listed in ITU-T recommendation G 957.
