LNX-C800G Series
8-Port Compact Industrial Unmanaged Gigabit Ethernet Switch,
with 8*10/100/1000Tx
Version 1.0
User Manual

Antaira Technologies - Industrial Ethernet Switches
LNX-C800G Series User Manual V1.0
ii
© Copyright 2020 Antaira Technologies, LLC.
All Rights Reserved
This document contains information, which is protected by copyright. Reproduction, adaptation or translation
without prior permission is prohibited, except as allowed under the copyright laws.
Trademark Information
Antaira is a registered trademark of Antaira Technologies, LLC, Microsoft Windows and the Windows logo are the
trademarks of Microsoft Corp. NetWare is the registered trademark of Novell Inc. WMM andWPA are the
registered trademarks of Wi-Fi Alliance. All other brand and product names are trademarks or registered
trademarks of their respective owners.
Notice: Copyrights © 2020 by Antaira Technologies, LLC. All rights reserved. Reproduction, adaptation, or
translation without prior permission of Antaira Technologies, LLC. is prohibited, except as allowed under the
copyright laws.
Disclaimer
Antaira Technologies, LLC. provides this manual without warranty of any kind, expressed or implied, including but
not limited to the implied warranties of merchantability and fitness for a particular purpose. Antaira Technologies,
LLC. may make improvements and/or changes to the product and/or specifications of the product described in
this manual, without prior notice. Antaira Technologies, LLC. will not be liable for any technical inaccuracies or
typographical errors found in this guide. Changes are periodically made to the information contained herein and
will be incorporated into later versions of the manual. The information contained is subject to change without prior
notice.

Antaira Technologies - Industrial Ethernet Switches
LNX-C800G Series User Manual V1.0
iii
FCC Notice
This equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant to Part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy. It may cause
harmful interference to radio communications if the equipment is not installed and used in accordance with the
instructions. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the grantee of this device could void the user's
authority to operate the equipment.
CE Mark Warning
This is a Class-A product. In a domestic environment this product may cause radio interference in which case the
user may be required to take adequate measures.
Industrial Ethernet Switches
Industrial Grade Unmanaged Gigabit Ethernet Switches
User Manual
Version 1.0 (March 2020)
This manual supports the following models:
•LNX-C800G
•LNX-C800G(-T)
This document is the current official release manual. Please check our website (www.antaira.com) for any
updated manual or contact us by e-mail ([e-mail]).

Antaira Technologies - Industrial Ethernet Switches
LNX-C800G Series User Manual V1.0
iv
Table of Contents
1.Overview..................................................................... 1
1.1Key Features..................................................... 1
1.2 Package Contents............................................. 2
1.3 Safety Precaution.............................................. 2
2.Hardware Description................................................ 3
2.1Physical Dimensions......................................... 3
2.2 Front Panel....................................................... 3
2.3 Top View........................................................... 4
2.4 LED Indicators.................................................. 5
2.5 GigEthernet Ports ............................................. 5
2.6 Cabling............................................................. 6
2.7 Wiring the Power Inputs.................................... 7
3.Mounting Installation................................................. 8
3.1 DIN-Rail Mounting............................................. 8
3.2 Wall Mounting................................................... 9
4.Hardware Installation............................................... 10
4.1 Installation Steps ............................................ 10
5.Trouble Shooting ..................................................... 11
6. Technical Specifications......................................... 12

Antaira Technologies - Industrial Ethernet Switches
LNX-C800 Series User Manual V1.0
1
1. Overview
Antaira Technologies’ LNX-C800G series is a compact 8-port industrial Ethernet switch. The
small form factor of this metal IP30 rated industrial switch is 30% smaller allowing for a more
versatile implementation. The LNX-C800G is equipped with 8*10/100/1000Tx RJ45 Ethernet
ports; with a backplane speed of 16gbps. The industrial-grade design and compact size of the
LNX-C800G series makes this ideal unit for integration into projects or other applications that
need a small footprint.
The LNX-C800G series supports reverse polarity and overload current protection. This product
series supports DIN-rail as well as wall mountable orientations and provides operating
temperature range models in STD: -10°C to 65°C and EOT: -40°C to 75°C. This is an industrial
grade unit applicable for networking applications in factory automation, ITS, power/utility, water
wastewater treatment plants, or any application that needs a compact solution.
1.1 Key Features
◼System Interface/Performance
•All RJ-45 ports support the auto MDI/MDI-X function
•Embedded 8*10/100/1000Tx
•Store-and-forward switching architecture
•4K MAC address table
◼Power Input
•DC 12~48V redundant power with a 6-pin removal terminal block
◼Operating Temperature
•Standard operating temperature model: -10°C ~ 65°C
•Extended operating temperature model (–T): -40°C ~ 75°C
◼Case/Installation
•IP30 protection
•DIN-Rail and wall mount design

Antaira Technologies - Industrial Ethernet Switches
LNX-C800G Series User Manual V1.0
2
1.2 Package Contents
➢1 - LNX-C800G(-T): 8-port industrial compact unmanaged Gigabit Ethernet switch
with 8*10/100/1000Tx
➢2 - Wall mounting brackets and screws
➢1 - DC cable –18 AWG & DC jack 5.5x2.1mm
➢1 - Quick Installation Guide
➢1 –RJ45 dust cover set
1.3 Safety Precaution
Attention: If the DC voltage is supplied by an external circuit, please use a protection
device on the power supply input. The industrial Ethernet switch’s
hardware specs, ports, cabling information, and wiring installation will be
described within this user manual.

Antaira Technologies - Industrial Ethernet Switches
LNX-C800G Series User Manual V1.0
3
2. Hardware Description
2.1 Physical Dimensions
Figure 2.1, below, shows the physical dimensions of Antaira Technologies’ LNX-C800G series: 8-
port compact industrial unmanaged Gigabit Ethernet switch with 8*10/100/1000TxRJ45 ports.
(W x D x H) is 40mm x 70mm x 95mm
Figure 2.1
LNX-C800G Series Physical Dimensions

Antaira Technologies - Industrial Ethernet Switches
LNX-C800G Series User Manual V1.0
4
2.2 Front Panel
The front panel of the LNX-C800G series: 8-port industrial compact unmanaged Gigabit Ethernet
switch with 8*10/100/1000Tx. See Figure 2.2.
2.3 Top View
Figure 2.3, below, shows the top panel of the LNX-C800G series switch that is equipped
with one 6-pin removal terminal block connector for dual DC power inputs (12-48 VDC).
Figure 2.3
Top Panel View of LNX-C800G Series
Figure 2.2
Front Panel of the LNX-C800G Series
6-pin Removal Terminal Block
(Dual Power Input)
LED for Power 1, Power 2, and Fault
LAN Port # 1~8 –10/100/1000Tx
LAN#1 LED for Link/Activity Status 1000Mbps
LAN#1 LED for Link/Activity Status 10/100Mbps
Grounding Screw

Antaira Technologies - Industrial Ethernet Switches
LNX-C800G Series User Manual V1.0
5
2.4 LED Indicators
There are LED light indicators located on the front panel of the industrial Gigabit Ethernet
switch that display the power status and network status. Each LED indicator has a different
color and has its own specific meaning, see below in Table 2.4.
LED
Color
Description
Power
Green
On
Power input is active
Off
Power input is inactive
LAN Port 1 ~ 8
(Left LED)
Green
On
Connected to network, 100Mbps
Flashing
Networking is active
Off
Not connected to network
LAN Port 1 ~ 8
(Right LED)
Green
On
Connected to network at 10Mbps
Flashing
Networking is active
Off
Not connected to network
2.5 Ethernet Ports
◼RJ-45 Ports
RJ-45 Ports (Auto MDI/MDIX): The RJ-45 ports(LAN 1~8) are auto-sensing for 10/100/1000Base-
T, or 1000Base-Tx devices connections. Auto MDI/MDIX means that the switch can connect to
another switch or workstation without changing the straight-through or crossover cabling. See the
figures shown below for straight-through and crossover cabling schematics.
◼RJ-45 Pin Assignments (Table 2.5)
Pin Number
Assignment
1
Rx+
2
Rx-
3
Tx+
6
Tx-
Table 2.4
LED Indicators for LNX-C800G Series
Table 2.5
RJ45 Pin Assignments

Antaira Technologies - Industrial Ethernet Switches
LNX-C800G Series User Manual V1.0
6
All ports on this industrial Ethernet switch support automatic MDI operations. Users can use
straight-through cables (see figure below) for all network connections to PCs, servers, and other
switches or hubs. With straight-through cable, pins 1, 2, 3, and 6, at one end of the cable, are
connected straight through to pins1, 2, 3 and 6 atthe other end of the cable. Thetable below shows
the 10BASE-T/100BASE-TX MDI port pin outs.
The following figures show the cabling schematics for straight-through and crossover cables.
2.6 Cabling
◼Twisted-pair segments can be connected with an unshielded twisted pair (UTP) or shielded
twisted pair (STP) cable. The cable must comply with the IEEE 802.3u 1000Base TX standard
(e.g. Category 5, 5e, 6, or 6a). The cable between the equipment and the link partner (switch,
hub, workstation, etc.) must be less than 100 meters (328 ft.) long.
Note:
The “+” and “-” signs represent the polarity of the wires that make up each wire pair.
Pin MDI-X
Signal Name
MDI Signal Name
1
Receive Data plus (RD+)
Transmit Data plus (TD+)
2
Receive Data minus (RD-)
Transmit Data minus (TD-)
3
Transmit Data plus (TD+)
Receive Data plus (RD+)
6
Transmit Data minus (TD-)
Receive Data minus (RD-)
Table 2.5
Ethernet Signal Pin Outs
Figure 2.4 Figure 2.5
Straight-Through Cables Schematic Crossover Cables Schematic
