AnthroDesk MDESK-ADC01 User manual

SSEMBLY INSTRUCTIONS
MODEL:MDESK- DC01
Manual Crank Standing Desk
WWW. NTHRODESK.C 1-800-267-1783
Step5.Install andadjustthehexbar tothe requiredwidthtoengagecrankdrive.
Hexbar1pcs 6
4
Step6.Attach selectedtable top.
M3*81pcs 13
Crank handle1pcs
11

ASSEMBLYINSTRUCTIONS
Left leg1pcs Rightleg1pcs Long tube1pcs Sideframe1pcs
Hexbar 1pcs Base2pcs M8*10 8pcs M8*25 8pcs
Glide4pcs
M8*8+washer2pcs
Crank handle 1pcs
Leversupport
+Side frame1pcs
Step1.Loosen the fourscrewsasshowntoextendthe longsupporttube.
Do notthreadboltsintothe
threeholes’atthisstep
threeholes threeholes
fourscrews
1 2 3 4 5
678 9 10
11 12
2
13
M3*8 1pcs
M8*8+washer2pcs
M8*10 4pcs
Length
Leftleg1pcs 1
Rightleg 1pcs 2
Longtube1pcs 3
Side frame1pcs 4
M8*10 4pcs
5
Step2.Connectthe longsupporttubetothe legs asshown.
Step3.Adjust the longsupporttubetoappropriatelength(basedonthe table topsize)
andtighten the fourtubescrewsfrom Step1.Next,attach the sideframesupportbars.
Step4.Attach the basesupportsandscrewin the Glide’levelerpads.Withassistance,
turnthedeskupright.
M8*25 8pcs 9
Glide4pcs 12
Base2pcs 7
8
10
8
3
Leversupport
+Side frame1pcs
