AnyTone AT-318P User manual

A1.140822
Qixiang Electron Science & Technology Co., Ltd.
www.qxdz.cn

AT-318P
TWO WAY RADIO

THANK YOU!
transceiver will provide you with reliable, clear and efficient communication service. The
transceiver introduces innovative DSP digital signal processing technology, high level integration,
it is including kinds of professional function, best stability and great reliability as well as exterior
smooth lines, novel, fashionable, let it meet the instant communication technology and become a high
performance transveiver, It boasts high power (5W), long distance, loud and clear timbre, high capacity
battery (7.4V 1500mAh), It is best suit for property, building, shopping mall, outdoor work place with
noisy surroundings. For your full comprehension of the varous excellent functions and maintenance,
please read the user manual before use.
NOTE:
When programming the transceiver, read the factory initial data first, then rewrite the frequency and
signaling etc., otherwise errors may occur because of different frequency band etc.
User Manual Applied to: AT-318P UHF FM Transceiver
VHF FM Transceiver
Programming Software: QPS318P_1.00

SAFETY INFORMATION FOR USER
transceiver is excellently designed with advanced technology. Please observe the following
precautions to perform your obligation, prevent personal injury and ensure the safety of transceiver
usage.
Keep the transceiver and accessories away from children.1.
Please do not try to open or modify the transceiver without permission, non-professionals process2.
may also cause damage.
Please use assorted battery and charger to avoid damage.3.
Please use assorted antenna to ensure the communication distance.4.
Please do not expose the transceiver to long period of direct sunlight, nor place it close to heat5.
appliances.
Please do not put the transceiver in excessively dusty or humid areas.6.
Do not use harsh chemicals, cleaning solvents to clean the transceiver.7.
Do not transmit without antenna.8.
When using this transceiver, we recommend transmitting for 1 minute then receiving for 4 minutes.9.
Continuous transmitting for long time or working in high power will heat the back of the transceiver.
Do not place the transceiver’s hot back close to any surface of plastic.
If any abnormal odor or smoke detected coming from the transceiver, turn off the power and take10.
off the battery pack and its case. Then contact local dealers.

Professional
FM Transceiver I
UNPACKING .........................................................................................................................................1
Supplied Accessories .........................................................................................................................1
STANDARD ACCESSORIES/OPTIONAL ACCESSORIES .................................................................2
Standard Accessories................................................................................................................................................2
Optional Accessories .................................................................................................................................................2
BATTERY INFORMATION....................................................................................................................3
How to Charge...........................................................................................................................................................3
PREPARATION.....................................................................................................................................4
Installing / Removing the Battery...............................................................................................................................4
Installing / Removing the Antenna .............................................................................................................................5
Installing / Removing the Belt Clip.............................................................................................................................5
Installing the Additional Speaker/ Microphone (Optional) .........................................................................................6
GETTING ACQUAINTED......................................................................................................................7
Indicator Status and Beep ........................................................................................................................................9
[PF1] & [PF2] Key Default .........................................................................................................................................9
Auxiliary Functions ....................................................................................................................................................10
BASIC OPERATIONS...........................................................................................................................11
Switch on / off Transceiver ........................................................................................................................................11
Battery Capacity Enquiry ...........................................................................................................................................11
Adjusting Volume.......................................................................................................................................................11
Channel Selection .....................................................................................................................................................12
Receiving...................................................................................................................................................................12
Monitor.......................................................................................................................................................................12
CONTENTS

Professional
FM Transceiver
II
Transmitting ...............................................................................................................................................................13
Power Switch.............................................................................................................................................................13
ON/OFF VOX ............................................................................................................................................................13
ON/OFF Highlight Torch ............................................................................................................................................14
Emergency Alarm ......................................................................................................................................................14
Battery Save Setup....................................................................................................................................................14
CTCSS / DCS Encode and Decode ..........................................................................................................................14
Time-out Timer...........................................................................................................................................................15
Resume Factory Default............................................................................................................................................15
Maintaining and Cleaning ..........................................................................................................................................15
TECHNICAL SPECIFICATIONS...........................................................................................................16
TROUBLE SHOOTING GUIDE.............................................................................................................17
CONTENTS

Professional
FM Transceiver 1
UNPACKING
Carefully unpack the transceiver. We recommend you to identify the items listed in the following
table before discarding the packing material. If any items are missing or have been damaged during
shipment, please contact dealers immediately.
Supplied Accessories
Item Number Quantity
Antenna QA06V(136-174MHz)
QA06U(400-480MHz) etc 1
Li-ion Battery Pack QB-43L 1
Battery Charger QBC-42L 1
AC Adaptor QPS-07 1
Belt Clip BC06 1
Instruction Manual 1
Qualication 1

Professional
FM Transceiver
2
STANDARD ACCESSORIES/OPTIONAL ACCESSORIES
Standard Accessories
Antenna*1
QA06V (136-174MHz)
QA06U (400-480MHz) etc.
Li-ion Battery Pack
(1300mAh)
QB-43L
Charger
QBC-42L
Belt Clip
BC06
AC Adaptor
QPS-07
Instruction
Manual
Qualication
* Note: For frequency of antenna, please refer to label
indicated in the bottom of the antenna.
Optional Accessories
USB Programming
Cable PC03
Programming Software
QPS318P_1.00
Earpiece
HS03
Li-ion Battery Pack
(1500mAh)

Professional
FM Transceiver 3
BATTERY INFORMATION
How to Charge
Plug the AC adaptor into the AC outlet(100V-240V), the1.
indicator light will light green.
Plug the battery or transceiver into the charger.2.
A: Make sure that the battery terminals are in contact with
charging terminals well.
B: The indicator turns into red during charging process.
NOTE: It takes approximately 4 hours to fully charge the battery. Charging time depends on the
battery capacity. Not charge for too long, which will shorten the life of battery and reduce the battery
performance. For the first time charging, please not make the battery reach the usual capacity
after purchasing or storing for long term(more than 2 months). The battery should be charged and
discharged for 2or 3 times repeatedly and then to make it reach the usual capacity.
AC input

Professional
FM Transceiver
4
Installing / Removing the Battery
■ Installing the Battery
Lay the battery to face the back of the radio.1.
Press the button of battery, the latch in button of transceiver locks will release. After hearing a2.
"click" sounds, the battery has been locked.
PREPARATION
■ Removing the Battery
According to “ ” to push the battery lock to removing the battery.

Professional
FM Transceiver 5
PREPARATION
Installing / Removing the Antenna
■ Installing the Antenna:
Screw the antenna into the connector on the top of the
transceiver by holding the antenna at its base and turning it
clockwise until secure.
■ Removing the Antenna:
Turn the antenna anticlockwise till the antenna separates
the connector of the transeceiver to remove it.
Installing / Removing the Belt Clip
■ Installing the Belt Clip:
Place the belt clip to the grooves on the back of the
transceiver, and then clockwise screw it.
■ Removing the Belt Clip:
Anticlockwise turn the screws to remove the belt clip.

Professional
FM Transceiver
6
PREPARATION
Installing the Additional Speaker/ Microphone (Optional)
Unveil the MIC-SP jack cover and then insert the
Speaker/Microphone plug into MIC-SP jack.
Note:
The transceiver is not completely waterproof while
using the Speaker/Microphone.

Professional
FM Transceiver 7
GETTING ACQUAINTED
1
2
3
9
4
6
5
7
8
10
12
11

Professional
FM Transceiver
8
GETTING ACQUAINTED
1Antenna
2POWER / VOLUME Switch:
Turn clockwise to switch on the transceiver, and turn anticlockwise till hearing “Click” to switch
off the transceiver. After switching on the transceiver, turn clockwise to increase the volume and
anticlockwise to decrease the volume.
3Indicator light
4Highlight Torch
5LAMP Key
6PTT Key
When you are making a call, please press and hold this key to speak into the microphone. Release
the key to receive.
7PF1 Key
It can realize different functions by programming.
8PF2 Key
It can realize different functions by programming.
9Channel Selector Knob
Turn the selector knob to select desired channel. Turn clockwise to increase channel, anticlockwise
to decrease channel.
10 Additional Microphone / Speaker Jack、Reading / Writing frequency Jack
11 Belt Clip
12 Battery Lock

Professional
FM Transceiver 9
GETTING ACQUAINTED
Indicator Status and Beep
Warning on low voltage The red light twinkles.
Transmitting Lighten the red light.
Receiving Lighten the green light.
Reading/Writing Frequency Reading Frequency: Red light twinkles
Writing Frequency: Green light twinkles
Key Operation Voices "DU" into any function, "DU DU" to exit any function.
[PF1] & [PF2] Key Default
Press [PF1] Battery Capacity Enquiry
Press [PF2] Squelch off
Press [PF1] 1 second Monitor
Press [PF2] 1 second Switch H/L Power
Press [PF1] 3 seconds On/Off VOX Function
Press LAMP Key On/Off Highlight Torch
Press LAMP Key 3 seconds Emergency alarm

Professional
FM Transceiver
10
Users can setup the key [PF1] and [PF2] to be one of the optional functions as bellows :
Squelch off•
Monitor•
Current Channel Power Enquiry•
Frequency Reverse•
Talk Around•
Battery Capacity Enquiry•
TX Power Switch•
Please download the detailed operation on our website(www.qxdz.cn) or call the after-sales to consult.
AUXILIARY FUNCTIONS
GETTING ACQUAINTED

Professional
FM Transceiver 11
BASIC OPERATIONS
Switch on / off Transceiver
Switch on Transceiver: Under power-off state, turn [POWER / VOLUME] clockwise till hearing
"Click" to switch on the transceiver. The transceiver will announce "welcome to use" when power-
on and announce the current channel.
Switch off Transceiver: Under power-off state, turn [POWER / VOLUME] anticlockwise till hearing
"Click" to switch off the transceiver.
Adjusting Volume
Under power-on state, turn POWER / VOLUME switch to adjust the volume. Turn clockwise to
increase the volume, and anticlockwise to decrease the volume. You can press PF2 key to monitor
the current volume.
NOTE: You can press the programmed key of squelch off [PF2] to monitor the background noise and
meanwhile turn POWER / VOLUME to adjust the volume. Under the communicating state, you can
adjust volume as per your need more accurately.
Battery Capacity Enquiry
Under the standby conditions, press the programmed key of "Battery Capacity Enquiry" [PF1],
transceiver announce current battery capacity. There are 10 grades in total. Grade 10th means full
battery capacity.
When the battery state is grade 1st (6.1V), the LED lights red. The transceiver will voice prompt
users each 30 seconds to charge timely and also enter automatically the state of no transmission.

Professional
FM Transceiver
12
Receiving
You can hear the transmitting party's calling when the channel you are operating is called and the
LED light turns green.
NOTE:
You may not receive the calling if you set a high squelch off level of the transceiver.
If current channel has been programmed with signaling, you can only hear the call from a same
signaling, other calls can not be heard.
Channels Selection
Under the standby conditions, turn channel selector knob to choose the desired channel, and
the transceiver will announce the adjusted channel. Turn clockwise to increase the channel,
anticlockwise to decrease the channel.
NOTE: The transceiver will emit "DiDi" beep when current channel is blank.
BASIC OPERATIONS
Monitor
Pressing the programmed key of Monitor [PF1], the transceiver emits "DU" beep and then comes
into the monitor state. Under these conditions, transceiver will ignore CTCSS/DCS decode and
monitor signal of the other party as long as receiving the matched carrier wave. Press this key again,
transceiver emits "Du Du" beep and exits the monitor.

Professional
FM Transceiver 13
Transmitting
Before transmitting, make sure that the channel you want to use is not in busy state through monitoring
for a while by pressing the programmed Squelch off [PF2] key. Under these conditions, press the [PTT]
key and speak into microphone. Please keep around 2.5-5cm distance between microphone and your
lip. And please speak in normal tone to make the receiver obtain best tone quality.
ON/OFF VOX
When turn on this function, it's not necessary to press the [PTT], through the appropriate voice can
star emission.
In standby, press and hold [PF1] more than 3 seconds, the transceiver will send a prompt voice and
turn on VOX function. Repeat the above operation or restart will be closed the VOX function.
NOTE: It needs to program the VOX in valid status firstly if you want to turn on this function,
otherwise, the above operation is invalid.
Note:Press [PTT] Red LED lighting means transmitting. Release [PTT] to receive signal.
BASIC OPERATIONS
Power Switch
Under the standby conditions, press the programmed key of [PF2] 1 second, transceiver change the
current channel power and announces.

Professional
FM Transceiver
14
Battery Save Setup
The transceiver will automatically switch on Battery Save Function when not receiving a signal or not
making any operations for 10 seconds. The programming software can set whether allow to use the
function and energy saving ratio.
CTCSS / DCS Encode and Decode
When the transceiver is edited with this function, the transceiver hear the calling of the other party.
when receive matching CTCSS/DCS signaling. Transceiver with matched CTCSS/DCS or without
signaling both can hear your call.
BASIC OPERATIONS
ON/OFF Highlight Torch
Under standby condition, press LAMP key and the transceiver will emit "DU' beep, and then turn on
the Highlight Torch. Repeating the above operation will turn off the Highlight Torch.
Emergency Alarm
Under standby condition, press and hold LAMP Key for 3 seconds, the transceiver will start the
emergency alarm function. Switching off the transceiver will exit the function.
NOTE: The purpose of the CTCSS/DCS is to prevent to disturb, but it doesn't mean your call is in
secret. The transceiver can be edited non standard CTCSS encode/decode by computer.
