AnyTone AT-D868 User manual

A1.140922

DMR DIGITAL TWO WAY RADIO
AT-D868

THANK YOU!
Thank you very much for choosing our transceiver. transceiver provides you with
reliable, clear and efcient communication service.
The transceiver introduces innovative DMR digital processing system to achieve high-fidelity voice
processing and with multiple groups communication encryption. It boasts novelty, best stability, great
reliability, nice timbre and long distance communication as well as fashionable design and smooth exterior
lines. AT-D868 is a cost-effective and multi-functional professional DMR digital transceiver . It is convinced
that you will be satised with this transceiver’s quality and functions. For your full comprehension of the
various excellent functions and maintenance, please read the user manual before use.
NOTE:
When programming the transceiver, read the factory initial data first, then rewrite the frequency and
signaling etc., otherwise errors may occur because of different frequency band etc.
User Manual Applied to: AT-D868 UHF FM Transceiver
VHF FM Transceiver
Programming Software: QPSD868

SAFETY INFORMATION FOR USER
transceiver is excellently designed with advanced technology. Please observe the following
precautions to perform your obligation, prevent personal injury and ensure the safety of transceiver
usage.
Keep the transceiver and accessories away from children.1.
Please do not try to open or modify the transceiver without permission, non-professionals process2.
may also cause damage.
Please use assorted battery and charger to avoid damage.3.
Please use assorted antenna to ensure the communication distance.4.
Please do not expose the transceiver to long period of direct sunlight, nor place it close to heat5.
appliances.
Please do not put the transceiver in excessively dusty or humid areas.6.
Do not use harsh chemicals, cleaning solvents to clean the transceiver.7.
Do not transmit without antenna.8.
When using this transceiver, we recommend transmitting for 1 minute then receiving for 4 minutes.9.
Continuous transmitting for long time or working in high power will heat the back of the transceiver.
Do not place the transceiver’s hot back close to any surface of plastic.
If any abnormal odor or smoke detected coming from the transceiver, turn off the power and take10.
off the battery pack and its case. Then contact local dealers.
ATTENTION:
All tips above apply to accessories of your transceiver. If any device can not work normally,
please contact local dealers.
If you use any accessories made by other companies, Company does not guarantee the
operability and safety of the transceiver.

Professional
FM Transceiver
I
UNPACKING ....................................................................................................................... 1
Supplied Accessories .........................................................................................................................1
STANDARD/OPTIONAL ACCESSORIES .......................................................................... 2
Standard Accessories .........................................................................................................................2
Optional Accessories ..........................................................................................................................2
BATTERY INFORMATION.................................................................................................. 3
Charging Operation.............................................................................................................................3
Charger Applied ..................................................................................................................................3
Notice for Charging Battery.................................................................................................................3
How to Charge .................................................................................................................................... 4
Normal Charging Tips ......................................................................................................................... 6
How to Store the Battery.....................................................................................................................6
PREPARATION................................................................................................................... 8
Installing / Removing the Battery ........................................................................................................8
Installing / Removing the Antenna ......................................................................................................8
Installing / Removing the Belt Clip ......................................................................................................9
Installing the Additional Speaker/ Microphone (Optional) ..................................................................9
Installing/ Removing the Hand Strap (Optional)..................................................................................10
CONTENTS

Professional
FM Transceiver II
GETTING ACQUAINTED.................................................................................................... 11
BASIC OPERATIONS......................................................................................................... 13
Switch on / off Transceiver..................................................................................................................13
Adjusting Volume ................................................................................................................................13
Channel Selection...............................................................................................................................13
Group Selection ..................................................................................................................................14
Receiving ............................................................................................................................................14
Transmitting ........................................................................................................................................14
Digital Communication Mode .............................................................................................................. 15
Scan List .............................................................................................................................................17
The Mode To Start Scan .....................................................................................................................17
ADVANCED OPERATIONS................................................................................................ 18
All Alert Tones On/Off..........................................................................................................................18
Emergency On ....................................................................................................................................18
Emergency Off .................................................................................................................................... 18
Switch High/Low Power ......................................................................................................................19
Monitor ................................................................................................................................................19
Fast Access Key 1-6 ..........................................................................................................................19
Repeater/ Talk Around ........................................................................................................................ 20
CONTENTS

Professional
FM Transceiver
III
Scan On/Off ........................................................................................................................................ 20
Tight/ Normal Squelch.........................................................................................................................20
Encryption On/Off ..............................................................................................................................20
VOX On/Off.........................................................................................................................................21
Battery Capacity Enquiry .................................................................................................................... 21
Lone Work...........................................................................................................................................21
TECHNICAL SPECIFICATIONS......................................................................................... 22
CONTENTS

Professional
FM Transceiver
1
UNPACKING
Carefully unpack the transceiver. We recommend you to identify the items listed in the following
table before discarding the packing material. If any items are missing or have been damaged during
shipment, please contact dealers immediately.
Supplied Accessories
Item Number Quantity
Antenna
QA01V(136-174MHz)
QA01V(350-390MHz)
QA01U(400-480MHz) etc
1
Li-ion Battery Pack QB-44L 1
Battery Charger QBC-44L 1
AC Adaptor QPS-01 1
Belt Clip BC09 1
Instruction Manual 1
Qualication

Professional
FM Transceiver 2
STANDARD/OPTIONAL ACCESSORIES
Standard Accessories
Antenna*1
QA01V (136-174MHz)
QA01V (350-390MHz)
QA01U (400-480MHz) etc.
Li-ion Battery Pack
QB-44L
Charger
QBC-44L
AC Adaptor
(12V/500mA) QPS-01
Belt Clip
BC09
Instruction
Manual
* Note: For frequency band of antenna, please refer to label
indicated in the bottom of the antenna.
* Note: Car Charger and QBC-44L Charger should be used
together.
Optional Accessories
USB Programming
Cable
Programming Software
QPSD868
Earphone
Hand Strap
GS01
Car Charger CPL01*2

Professional
FM Transceiver
3
BATTERY INFORMATION
Charging Operation
The battery pack is not charged at the factory; please charge it before use.
Charging the battery pack for the rst time after purchase or extended storage (more than 2 moths)
may not bring the battery pack to its normal operating capacity. After fully charging/ discharging cycle
for two or three times, the operating capacity will reach its best performance. The battery pack life
is over when its operating time decreases even though it is fully and correctly charged. Replace the
battery pack.
Charger Applied
Please use the specic charger appointed by our company. Other models may cause explosion and
personal injury. After installing the battery pack, if the radio displays low battery with red ashing
lamp or voice prompt, please charge the battery.
Notice for Charging Battery
Do not short the battery terminals or▼throw the battery into re. Never attempt to remove the
casing from the battery pack, we show no responsibility on any results caused by modifying
freely without permission of our factory.
The ambient temperature should be between 5▼℃and 40℃while charging is in progress.
Charging outside this range may not fully charge the battery.
Always switch OFF the transceiver equipped with a battery pack before charging. Otherwise, it ▼
will interfere with correct charging.
To avoid interfering the charging, please do not cut off the power or take out the battery during▼
charging.

Professional
FM Transceiver 4
BATTERY INFORMATION
Do not recharge the battery pack if it is already fully charged. This may shorten the life of the▼
battery pack or damage the battery pack.
Do not charge the battery or transceiver if it is damp. Dry it before charging to avoid danger.▼
WARNING:
When keys, ornamental chain or other electric metals contact with the battery terminal, the battery
may cause damage or hurt bodies. If the battery terminal short circuit it will generate a lot of heat.
Take care when carrying and using the battery. Remember to put the battery or radio into insulated
container.Do not put it into metal container.
How to Charge
Plug the AC adaptor into the AC outlet, and then1.
plug the cable of the AC adaptor into the DC jack
located on the back of the Charger. The Indicator
lights orange (1s) and then goes out----waits to
charge.
Plug the battery or transceiver into the charger.2.
Make sure that the battery terminals are in contact
with charging terminals well. The Indicator turns
into twinkling red-----Pre-charging begins.
After pre-charging for about 5 minutes, the3.
indicator will stop twinkling----charging begins.
It takes approximately 4 hours to fully charge the battery. When the lamp lights green, the charging4.
is nished. Remove the battery or the transceiver equipped with battery from socket.
Ac Input

Professional
FM Transceiver
5
BATTERY INFORMATION
NOTE: when charging a power-on transceiver equipped with battery, the indicating lamp will not
turn into green to show the fully charged status. Only when the transceiver is switched off, can the
lamp indicate normally. The transceiver consumes energy when it is power-on, and the charger can
not detect the voltage when the battery has been fully charged. So the charger will charge battery in
constant voltage and fail to indicate correctly whether the battery has been charged fully.
Charging Process5.
Charging Status Indicator Status
Standby (Self-examine lights orange 1second when power on) None
Pre-charging (Pre-charging stage) Red light twinkles for about 5 minutes
Charging (Charge in a constant current) Lights red for about 4 hours
Fully charged (Charge in a constant voltage) Lights green
LED Indicator:6.
STATUS Self-Examine
When Power on No Battery Pre-charging Charge Normally
Fully
Charged Trouble
LED Orange
(for 1 second) None
Red Light
Twinkles
for 5 Minutes
Red Green Red twinkles
for a long time
NOTE: Trouble means battery heating, battery short-circuit or charger short-circuit.

Professional
FM Transceiver 6
BATTERY INFORMATION
Normal Charging Tips
Self- Examination:1. When charging, orange light twinkles for 1 second and goes out, which means
the charger has passed its self-examination and it can charge the battery normally. If the light
remains orange or the red light twinkles, it means the charger can not pass its self-examination or
charge the battery.
Trickle Pre-Charging:2. If red light twinkles when battery is inserted into the charger, it means the
remnant voltage is low and the charger is trickle-charging the battery (Pre-Charging Status). The
charger will automatically turn into normal charging when the battery reaches a certain electric
quantity, And if the red light stops twinkling, it means the remnant voltage meets a certain electric
quantity, the charger will charge the battery normally.
NOTE:
Trickle charging (Pre-Charging Status) time can not beyond 30 minutes. If the indicating lamp still
twinkles after 30-minute trickle-charging, it means that the charger can not charge the battery. Please
check whether the battery or charger is damaged.
How to Store the Battery
If the battery needs to be stored, keep it in status of 50% discharged.1.
It should be kept in low temperature and dry environment.2.
Keep it away from hot places and direct sunlight.3.

Professional
FM Transceiver
7
BATTERY INFORMATION
WARNING:
Do not short circuit battery terminals.▼
Never attempt to remove the casing from the battery pack.▼
Never assemble the battery in dangerous surroundings, spark may cause explosion.▼
Do not put the battery in hot environment or throw it into re, it may cause explosion.▼

Professional
FM Transceiver 8
PREPARATION
Installing / Removing the Battery
Match the two grooves of the battery pack with1.
the corresponding guides on the back of the
transceiver, and then push it.
Press the battery pack until the release latch on2.
the top of the transceiver locks. After hearing a
“click” sounds, the battery has been locked.
To remove the battery pack, slide up the release3.
latc h and remove t he pack away from the
transceiver.
Installing / Removing the Antenna
■ Installing the Antenna:
Screw the antenna into the connector on the top of
the transceiver by holding the antenna at its base
and turning it clockwise until secure.
■ Removing the Antenna:
Turn the antenna anticlockwise to remove it.

Professional
FM Transceiver
9
PREPARATION
Installing / Removing the Belt Clip
■ Installing the Belt Clip:
Place the belt clip to the corresponding grooves
on the back of the transceiver, and then clockwise
screw it.
■ Removing the Belt Clip:
Anticlockwise turn the screws to remove the belt
clip.
Installing the Additional Speaker/ Microphone (Optional)
Unveil the MIC-SP jack cover and then insert the
Speaker/Microphone plug into MIC-SP jack.

Professional
FM Transceiver 10
PREPARATION
Installing/ Removing the Hand Strap
Slide the loop of the hand strap through the eyelet on
the upper rear of the transceiver, then pull the entire
hand strap through the loop to secure the hands strap
in place and lastly tighten the hands strap.

Professional
FM Transceiver
11
GETTING ACQUAINTED
1
2
6
7
5
3
11
10
4
8
9

Professional
FM Transceiver 12
GETTING ACQUAINTED
1Antenna
2POWER / VOLUME Switch:
Turn clockwise to switch on the transceiver, and turn anticlockwise till hearing “Click” to switch
off the transceiver. After switching on the transceiver, turn clockwise to increase the volume and
anticlockwise to decrease the volume.
3Channel Selector Knob
Turn the selector knob to select desired channel. Turn clockwise to increase channel, anticlockwise to
decrease channel.
4Indicator
Indicate different working status
5Top Key
It can realize different functions by programming.
6MIC
7Speaker
8PTT Key
When you are making a call, please press and hold this key to speak into the microphone. Release
the key to receive.
9PF1 Key
It can realize different functions by programming.
10 PF2 Key
It can realize different functions by programming.
11 Additional Microphone / Speaker Jack, PC program Jack

Professional
FM Transceiver
13
BASIC OPERATIONS
Switch on / off Transceiver
Switch on Transceiver: Under power-off state, turn POWER / VOLUME clockwise till hearing
"Click" to switch on the transceiver. The transceiver will announce "Power on" and prompt current
channel number.
Switch off Transceiver: Under power-off state, turn POWER / VOLUME anticlockwise till hearing
"Click" to switch off the transceiver.
Adjusting Volume
Under power-on state, turn POWER / VOLUME switch to adjust the volume. Turn clockwise to
increase the volume, and anticlockwise to decrease the volume. If current communication channel is
with Analogue mode, you can press the programmed " Monitor" key to monitor current volume.
NOTE: It will be more accurately to adjust the desired volume when in communication status.
Channels Selection
Under the standby condition, turn channel selector knob to choose the desired channel, and the
transceiver will announce the channel number. Turn clockwise to increase the channel, anticlockwise
to decrease the channel.
NOTE: The transceiver will emit a voice prompt when current channel is blank.
