Aobosi TY-A220BCLG User manual

Air Fryer Oven
Instruction Manual
MODEL TY-A220BCLG
Suitable for family use
This product is an electric heating appliance. For your safety and convenience, please read
this User Manual carefully and follow the steps. Please keep it for future reference.

１
Contents
I. Before Use...................................................................................................................２
II. Labels and Function Description........................................................................... ３
III. Names of Main Parts..............................................................................................４
IV. User Guide................................................................................................................４
1. Accessories............................................................................................................. 5
2. General Steps.........................................................................................................5
3. Broil........................................................................................................................ 5
4. ♣Broil......................................................................................................................6
5. Toast........................................................................................................................6
6. Bake........................................................................................................................ 6
7. Airfry...................................................................................................................... 7
8. Dehydrate...............................................................................................................8
V. Cooking Guide.............................................................................................................8
VI. Clean and Maintenance......................................................................................... 10
VII. After-sales Service................................................................................................. 10
VIII. Special Statement............................................................................................ １０
IX. Specification ......................................................................................................10
X. Trouble Shooting....................................................................................................11
XI. Warranty...............................................................................................................11

２
I. Before Use
Please observe the following safety precautions before using this product:
1. Please read this User Manual carefully before using the product.
2. Do not immerse the power cord, plug and oven in water in case of electric shock.
3. Before using this oven, be sure to untie all the power cords wrapped around the back to avoid the
accident.
4. When the electric oven is working or after use, the external surface temperature is high, and touch is
not allowed to prevent burns.
5. Use this product with extra care when children are around. Children are not allowed to use this
product on their own or keep it out of reach of children
6. When the timer is on, do not swing the plug or socket to avoid strong currents and injuries by sparks.
7. Never hang the power cord on the edge of a cabinet/table or on a hot surface.
8. If the power cord or plug is damaged, or the oven fails, stop using it and seek a professional to repair
or replace it.
9. If the power cord is damaged, it shall be replaced by the manufacturer or a professional to avoid
danger.
10. Do not damage, bend, stretch, or twist the power cord; do not place heavy objects on the power cord
or clamp the power cord.
11. When the electric oven is not in use, the plug shall be pulled out of the socket to avoid electric shock
or electric leakage fire due to insulation aging.
12. The matching accessories shall be used correctly to avoid fire or injuries caused in operation.
13. The electric oven shall be placed in a dry environment and shall not be used outdoors.
14. During the use of the electric oven, it is necessary to keep a distance of at least 10 cm/3.94 inch.
15. Keep the electric oven in a stable place and keep it away from flammable materials.
16. Only consumable food can be baked in the oven. Do not put large pieces of food or metal objects in
the electric oven in case of fire or danger.
17. To bake greasy oily foods (such as meat), put a baking pan on the bottom layer to prevent the oil from
falling onto the bottom heating tube to cause a flame.
18. Do not place the following items in the oven for grilling, such as paper, cards, plastic, cloth, and
flammable items.
19. When moving or repairing the electric oven, unplug the power cord and wait for the electric oven to
cool before proceeding.
20. When the electric oven is working, do not open the oven door to move the baking tray or other
accessories to avoid burns caused by high temperature or high-temperature liquid.
21. Avoid sharp edges when using electric ovens.

３
22. Do not place anything on the electric oven. Do not cover or obstruct the heat dissipation position of
the electric oven.
23. No items are allowed on the glass door.
24. Baking trays or other items are not allowed to be put directly on the heating elements of the electric
oven.
25. Please watch out for starchy foods (such as bread) to avoid fire.
26. Do not use the timer if it cannot produce a beep sound.
27. This product is for home use only. Do not use this oven for any other purpose not specified.
28. All maintenance must be carried out by professional personnel.
29. This appliance cannot be operated with an external timer or a separate remote control.
30. This device cannot be used by children, mental patients, people with physical challenges and those
who are slow to respond unless guided by a person who is able to use it.
II. Labels and Function Description
Broil
Top baking: two heating tubes on both sides of the top row
♣Broil
Top baking + hot air: two heating tubes on both sides of the top row +
hot air (Rotisserie Fork)
Toast
Top and bottom baking: two heating tubes on both sides of the top row
+ heating of bottom row heating tubes at the same time
Bake
Top and bottom baking + hot air: two heating tubes on both sides of the
top row + heating of bottom row heating tubes + hot air (Rotisserie
Fork)
Airfry
Airfryer: all top row heating tubes + hot air (Rotisserie Fork)
Dehydrate
Top baking + hot air: two middle heating tubes of the top row + hot air
(Rotisserie Fork)
Note: the fork and hot air are in the same gear for the model with fork function.

４
III. Names of Main Parts
IV. User Guide
Note before using electric oven for the first time:
1. Read the User Manual carefully;
Rotisserie Fork
Frying Basket
Baking Tray
Grill
Fork Handle
Function knob
Indicator
Light
Timer
Thermostat
Built-in light
Crumb Tray

５
2. Remove all accessories and parts from the oven or package;
3. Use warm water to clean accessories such as grills and pans. Wipe the inside of the oven with a
soft, soapy cloth and wait until it is completely dry;
4. There shall be enough space around the oven and make sure the surface of the oven is more than
10cm/3.94inch from the other objects. No objects shall be put on the top of the oven;
5. Before using the electric oven for the first time, set the temperature knob to the maximum (450
scale mark), preheat it for 10-15 minutes to remove the machine oil from the electric oven; It is
normal if smoke appears when used.
1. Accessories
Rotisserie Fork: used to fix and bake large-sized food.
Frying basket: used for small-sized food. When using it, place the frying basket on the grill or
baking tray.
Baking tray: used to bake food.
Grill: used to bake food.
Fork Handle: for the Rotisserie Fork.
Crumb Tray: used to hold the oil.
2. General Steps
➀Place the grill or baking tray on the appropriate rack, depending on the size of the food.
➁Place food on the grill or baking tray.
➂Use the Temperature knob to select the desired temperature.
➃Turn the Function knob clockwise to set the oven. Select the degree to which the food is
cooked according to personal preference.
➄Use the Time knob to set the baking time clockwise according to the size of the food and
baking color preferred.
➅When finished, turn the Function knob to "0", and the Time knob to "0".
➆Remove food with oven gloves.
Tips: Do not use flammable materials such as plastic or paper; do not use glass or ceramic plates or
lids; do not let the grease drip directly to the bottom of the oven. When baking foods with much
fat, place the baking tray on the grill and place the drip tray on the bottom rack; set the desired
temperature according to the recipe or personal preference.

６
3. Broil
This function is suitable for thawing all kinds of meat.
➀Place the grill or baking tray on the middle or top rack.
➁Place food that needs to be defrosted on a frill or baking tray.
➂Use the Temperature knob to set the desired temperature.
➃Set the function to Broil. After the power is turned on, the top two heating tubes will heat up
at the same time.
➄The indicator light will be on when the power is on. Use the Time knob to set the baking time
in a clockwise direction.
➅When you hear a “Ding”, the pre-set time is up and take the food out with special accessories.
4. ♣Broil
This function is suitable for baking various kinds of bread, pizza, biscuits,
steaks and so on.
➀Place the grill or baking tray on the middle or top rack.
➁Place the prepared food on a grill or baking tray.
➂Use the Temperature knob to select the desired temperature.
➃Turn the Function knob clockwise to ♣Broil, and the above two heating tubes will be heated
at the same time after the power is switched on.
➄The indicator light will be on when the power is on. Use the Time knob to set the baking time
in a clockwise direction.
➅When you hear a “Ding”, the pre-set time is up. Make sure the food is cooked enough and
take it out with special accessories.
5. Toast
This function is suitable for roasting fish, beef and vegetables.
➀Place the grill or baking tray on the middle or bottom rack.

７
➁Place the prepared food on a grill or baking tray.
➂Use the Temperature knob to select the desired temperature.
➃Turn the Function knob clockwise to Toast, and the top and bottom heating tubes will be
heated at the same time after the power is switched on.
➄The indicator light will be on when the power is on. Use the Time knob to set the baking time
in a clockwise direction.
➅When you hear a “Ding”, the pre-set time is up. Make sure the food is cooked enough and
take it out with special accessories.
6. Bake
This function is suitable for baking various kinds of bread, pizza, biscuits,
steaks and so on.
➀Place the grill or baking tray on the middle or bottom rack.
➁Place the prepared food on a grill or baking tray.
➂Use the Temperature knob to select the desired temperature.
➃Turn the Function knob clockwise to Bake. After the power is switched on, the two bottom
heating tubes will be heated at the same time.
➄The indicator light will be on when the power is on. Use the Time knob to set the baking time
in a clockwise direction.
➅When you hear a “Ding”, the pre-set time is up. Make sure the food is cooked enough and
take it out with special accessories.
7. Airfry
This airfryer function is suitable for roasting meat, casseroles, stewing and so
on.
➀Place the grill or baking tray on the top rack.
➁Place the food on the grill or baking tray (also for the food that requires the Rotisserie Fork).
➂Use the Temperature knob to set the desired temperature.

８
➃Turn the function knob clockwise to Airfry. When the power is on, the top and bottom heating
tubes will work at the same time.
➄After the power is on, turn the Time knob clockwise to set the baking time, and the power
indicator will be on.
➅When you hear a “Ding”, the pre-set time is up. Make sure the food is cooked enough and
take it out with special accessories.
8. Dehydrate
This function is suitable for drying various fruits and vegetables.
➀Place the grill or baking tray on the middle or top rack.
➁Place food on the grill or baking tray.
➂Use the Temperature knob to set the desired temperature.
➃Turn the Function knob clockwise to Dehydrate. When the power is on, the top and middle
heat tubes will work at the same time.
➄The indicator light will be on when the power is on. Use the Time knob to set the baking time
in a clockwise direction.
➅When you hear a “Ding”, the pre-set time is up. Make sure the food is cooked enough and
take it out with special accessories.
Note: The baking time is adjusted depending on the temperature and size
of the food. Frozen and chunky foods generally take longer to bake.
V. Cooking Guide
Cooking Guide
1. Cooking time and temperature is varies according to the temperature, quality and weight of the
food. Please refer to the recipe for adjustment.
2. For continuous cooking, since the starting temperature inside is high, cooking time can be
shorter than the time when used for the first time. Please make adjustment according to the
actual situation.
3. When the heating temperature in the oven is too high, the built-in thermostat will automatically
disconnect and the heating tube will stop working. After cooling, the oven will return to work.
If the food is taken out during this time, it might not be cooked enough.
Types of Food
Temperature
inside Oven
Cooking Time
Other information
Steak
230°C/446℉
10-15min
Place the tin foil on the baking
tray, place the food on top, and
set the oven to Airfry or
Toast.
Ribs
230°C/446℉
20-30 min
Place the tin foil on the baking
tray, place the food on top, and

９
set the oven to Airfry or
Toast.
Prawn
180°C/356℉
10-12 min
Place the tin foil on the baking
tray, place the food on top, and
set the oven to Airfry or
Toast.
Sausages
180°C/356℉
12-15min
Place the tin foil on the baking
tray, place the food on top, and
set the oven to Airfry or
Toast.
Beef cake
230°C/446℉
15-17min
First set the oven to the top
and bottom pre-heat for 5
minutes, then put the beef
cake on the grill, set the oven
to ♣Broil, turn it over after
5 minutes, and cook for 7
minutes in ♣Broil.
Egg tart
230°C/446℉
18-20min
Place the tin foil on the baking
tray, place the food on top, and
set the oven to Toast.
Doughnuts
230°C/446℉
7-10min
Place the tin foil on the baking
tray, place the food on top, and
set the oven to Toast.
Chips
230°C/446℉
10-15min
Put 300g chips in airfryer
basket, setting on airfryer
function, 230°C/446℉, it
will take 10-15mins.
Toasts
230°C/446℉
5-8min
First set the oven to Toast for
5 minutes, then put the toasts
on the grill, and set the oven to
Bake for 3 minutes.
Chicken wings
230°C/446℉
10-15min
Place the food on the baking
tray, then place the baking tray
on the top rack. And set the
oven to Airfry.
Full Chicken
230°C/446℉
190°C/374℉
25-30min
40-45min
Put the full chicken on the
rotisserie, setting on airfryer
function with 230°C/446℉,
it will take 25-30mins;
However, if setting at
190°C/374℉, it will take
40-45 mins.

１０
VI. Clean and Maintenance
1. Unplug the power cord before cleaning the oven and allow the oven to cool down completely.
2. The inner and outer surfaces of the electric oven and baking trays can be cleaned with a soft
cotton cloth or sponge with a neutral detergent and cleaned with water.
3. Do not use hard brushes or articles for cleaning to avoid damaging the inner surface of the
electric oven and the protective layer of the baking tray.
4. Do not use toxic and corrosive cleaning agents such as gasoline, thinners, or polish.
5. The cleaned parts must be wiped dry before plugging in.
6. Please do not clean the heating tube, the heating tube cleans itself.
7. Do not immerse the electric oven in a liquid such as water.
VII. After-sales Service
1. The Company offers a one-year free warranty for the whole machine.
2. The start date of the warranty shall be the date on the purchase bill.
3. Any one or more of the following situations is not covered by the warranty:
Damage caused by improper use, storage and maintenance by consumers.
Damage caused due to disassembly and repair by the maintenance points not designated by
the Company.
Damage caused by force majeure.
4. The company's customer service center is still eager to serve you for the products that are not
covered by the warranty.
5.If the product is faulty, please contact our designated service point or customer service center :
[email protected]
VIII. Special Statement
1. All contents of this document have been carefully checked. If there is any misunderstanding of
print or content, the company reserves the right of final interpretation.
2. For the technical improvements of the product, they will be compiled into the new manual without
prior notice; if the appearance and color of the product are changed, the actual product shall
prevail.
3. This product is for home use only.
IX. Specifications
Product Name: Air Fryer Oven
Model No.: TY-A220BCLG
Rated Voltage: AC 120V
Rated Power:1700W
Rated Frequency: 60Hz
Capacity: 22L / 0.78 CUFT

１１
X. Trouble Shooting
XI. Warranty
Thank you for purchasing our product, which has been made to meet high quality standards. The
manufacturer's warranty covers the product for a period of 12 months from the date of purchase
against manufacturing faults.
All Aobosi warranties are automatically kept track of in our system, so there is no need to register
your product.
For 6 month extra free of charge warranty, please register at website www.iaobosi.com or fill in and
take picture of bellow Warranty Card sending to [email protected].
Problem
Possible Cause
Solution
The oven doesn't
work.
The oven is not connected to the power
supply.
Connect to the power supply.
The inside lamp
doesn't work.
The inside lamp is turned off.
Press the inside lamp button to
turn it on.
The food is burnt.
Cooking time is too long or the cooking
temperature is too high.
Reduce cooking time or
cooking temperature.
There is peculiar
smell when cooking.
There is oil on the surfaces oven and
accessories.
Clean the oven and accessories.

１２
Due to continuous product improvement, we reserve the right to change the product specification
without prior notice.
