AOODOR 800-052 Installation guide
Assembly&Instruction Manual
SKU:800-052
Save this manual for future reference
3 SEAT SWING BED
wing
Guide
Installation
S
INTRODUCTION
2
Thank you for purchasing ' ! We hope you will find joy in our Aoodor s Patio Swing Bed products for many
years to come.
To ensure your personal safety during installation and to get the most out of your investment, please read this entire
manual before beginning the installation process. If you feel that this process is too di cult to do on your own, we advise ffi
that you seek assistance from a local building or home improvement contractor.
We believe that installation can be a simple, streamlined process if you follow the instructions in this manual.
Please contact our customer support line for help any step of the way. If you need assistance with assembly, have
missing or defective parts, or any other issues, please email us at customerservice aoodor@ .com
INTRODUCTION
CARE AND MAINTENANCE
WARNING
FRAMES
Cleaning- Use mild soap and warm water. Do not use abrasive materials, cleansers or bleach products.
Rinse with clean water and dry thoroughly.
Maintenance- Periodically clean and dry thoroughly. Be sure to drain any water
accumulated inside the frames. To thoroughly drain frames, remove foot caps and tilt the
frames, if necessary, to remove all water. This is critical. Water allowed to accumulate
inside the frames and then exposed to sub-freezing temperatures can cause damage to
the frame tubing. Such damage is not covered under warranty. Always clean, drain and
dr y thoroughly before storing for the winter. For best results, always store or cover your
furniture when not in use. We recommend commercially available outdoor furniture covers.
** When cleaning or moving large or heavy items, always have two people work
together. Never drag furniture.
FABRICS (CUSHIONS/SLINGS)
Cleaning - Maintenance Wipe minor spills immediately. Clean with mild soap, warm clean water and a soft cloth.
Do not use abrasive materials and cleansers. Although fabric has been treated to resist stains, occasional use of
commercially available fabric cleaners may be necessar y. Follow manufacturer's instructions.
Maintenance- The best way to
maintain the beauty of cushions and slings is to store
them in a dry area and out of the elements when not in use, or cover with commercially
available outdoor furniture covers.
THIS ITEM IS INTENDED FOR OUTDOOR DOMESTIC USE ONLY, NOT FOR COMMERCIAL USE.
Do not discard any of the packaging until you have checked that you have all the parts and pack of fittings.
Keep children away during assembly. This item contains small parts which can be swallowed by children.
Children should always be under direct adult supervision while using the product.
Retain the assembly instructions for future reference.
This swing must be installed on level ground.
● Assemble 6 feet or more away from obstruction such as fence, garage, house, hot grills, overhanging branches,
laundr y wires and electrical wires...etc.
● Tighten all nuts, bolts and components during assembly and periodically during usage,fail to do so will be on your own risk
● Lubricate all moving parts during usage season.
● It is advisable to wear goggles during assembly.
● It is recommended that two or more person assemble this swing.
● Use with proper cautions especially accompany with young children. Gentle swing action is recommended for both
adult and young children. Younger children should not be left alone without adult accompany on the swing.
● Maximum weight capacity 600 pound.
● Make sure to have help when removing seat from the frame or when moving the swing.
● No machine wash or dry clean for all the fabric materials, use hand wash with care only.
Parts Desc Qty Ref No
A2800 052 001- -
B2800-052-002
C1800-052-003
D1800-052-004
E2800-052-005
E1 4800-052-006
F1800-052-007
G1800-052-008
H2800-052-009
I1800-052-010
I1 1800-052-011
J1800-052-012
K1800-052-013
L1800-052-014
Parts Desc Qty Ref No
M1800 052 015- -
N 3 800-052-016
O9800-052-017
P2800-052-018
R8800-052-019
S12 800-052-020
T2800-052-021
U2800-052-022
V800-052-023
W800-052-024
Y2800-052-025
Z800-052-026
3800-052-027
3
M6
M8
17
8
M6
M8
17
8
M6
M8
17
8
M6x1
M8x1
4
1
2
Assembly
Step2:Insert the top cross beam into the upright supports(A)(B) and fasten them by using bolt(R),washer(W),
nuts(V),plastic cap(Z)
Step1:Joint the top cross beam together and fasten them by using bolt(P),washer(W),nuts(V),plastic cap(Z)
D
C
P
Z
V
W
AB
RWVZ
Assembly
5
3
4
Step3:Joint the rear cross brace together and fasten them by using bolt(O),washer(W),nuts(V),plastic cap(Z)
Step4.1:Fasten the rear cross brace to the rear upright supports by using bolt(R),washer(W) nuts(V),
plastic cap(Z).
4.2:Fasten the lateral cross braces to the upright supports by using bolts (Q),washer(W),nuts(V),
plastic cap(Z)
F
G
Z
V
W
O
W
V
Z
R
W
VZ
E
O
Assembly
6
5
6
K
I
LI1
S
J
T
W
V
ZU
Step5:Joint the arm(I)and(I1)with beam(K)and(L) fasten them by using bolt(S).Pay attention to
the beam(L),there are two locks for locking the seat back.
Step6:Assembly the seat(J) with the bed frame and fasten them by using bolt(T),
plastic washer(U),washer(W),nuts(V) and plastic cap(Z)
Noted:There are two latches to locking the seat to the bed frame.
Locking the seat
Assembly
7
7
8
H
E1 H
S
W
V
Z
H
Step7.1:Assembly the tube(E1) to the arm and fasten them by using bolt(S) washer(W) nuts(V) and
plastic cap(Z).
7.2:Assembly the hanging springs to the tube(E1).
Step8:Hanging the seat frame onto the swing.
Assembly
8
9
10
M
Y
N
Step9:Assembly the canopy(M) to the swing using the plastic bolt(Y).
Step10:Place the cushions on the bed and insert the latches to locking the bed.
Assembly
9
Pleasedon’thesitatetocontactusforanyfurther questions,
yoursatisfactionisguaranteed.
customerservice@aoodor.com
https://www.aoodor.com/
11
Step10:released the latches and insert the cushion back support to the locking system
to becoming a swing chair
