aoyue Int883 User manual

12
BASIC TROUBLESHOOTING GUIDE
PROBLEM 1: THE UNIT HAS NO POWER
1. Check if the unit is switched ON.
2. Check the fuse. Replace with the same type if fuse is blown.
3. Check the power cord and ensure there are no disconnections.
4. Verify that the unit is properly connected to the power source.
PROBLEM 2: PANEL DISPLAYS “Err” MESSAGES
DESCRIPTION: Display show “SEnS” “Err” messages. \
ERR0 — First external temperature probe not detected
ERR1 — Second external temperature probe not detected
ERR2 — Internal temperature probe not detected
ERR3 — First external temperature probe not attached.
SOLUTION: Turn off power and back on.
If err messages shows err0 or err1 check the connection of sensor to
its receptacle. Check if the temperature probe tip is still intact.
If err messages shows err2 internal temperature connector might have
come loose or needs to be replaced.
If err messages shows err3, the first external temperature probe was
not detected, secure the external temperature on the underside of the
board to be worked on.
PROBLEM 3: DISPLAY AND OTHER DEVICE OPERATION
ISSUES
SOLUTION: Turn off power and back on.
OTHER PROBLEMS NOT MENTIONED:
Contact the vendor.
IR-Preheating System
Int883
INSTRUCTION MANUAL
Thank you for purchasing Aoyue Int 883 IR-Preheating System.
It is important to read the manual before using the equipment.
Please keep manual in accessible place for future reference.
This manual is designed to familiarize the technician with
the proper operation and maintenance of the equipment.
The “Care and Safety Precautions” section explains the
hazards of using any type of soldering or reworking device.
Please read carefully and observe the guidelines in order to
maximize usage and minimize the risk of injury or accidents .

TABLE OF CONTENTS
CARE & SAFETY PRECAUTIONS ……………...…….. 3
PRODUCT DESCRIPTION …………………….……… 4
FUNCTIONS & FEATURES …………….……………… 4
PACKAGE INCLUSION ……………….…………….. 5
SPECIFICATIONS ………………………..……………. 5
OPERATING PROCEDURES ………………...…... 6-11
BASIC TROUBLESHOOTING GUIDE …………….... 12
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
The specific instructions related to the safe operation of this appliance (as given in 7.12 of this
standard) shall be collated together in the front section of the user instructions.
The height of the characters, measured on the capital letters, shall be at least 3 mm.
These instructions shall also available in an alternative format, e.g. on a website.
A fire may result if the appliance is not used with care, therefore:
→ be careful when using the appliance in places where there are combustible materials ;
→ do not apply to the same place for a long time;
→ do not use in presence of an explosive atmosphere;
→ be aware that heat may be conducted to combustible materials that are out of sight;
→ place the appliance on its stand after use and allow it to cool down before
storage;
→ do not leave the appliance unattended when it is switched on.
Rohs
Correct Disposal of this product
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm
to the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the return
and collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe
recycling.
11
OPERATING PROCEDURES
Note:There is a built in protection feature to automatically limit the
temperature rising slope to no more than 3 degrees per second. Therefore
based on your set time, the maximum temperature may not reach 250C.
Sample Profile analysis:
SEG1 SEG2 SEG3 SEG4 SEG5 SEG6
050t 060t 080t 050t 040t 60t
100C 150C 180C 190C 195C 100C
Segment one is set to 50 seconds to reach 100C. Which means after
50seconds at the end of segment one the temperature should reach 100C.
Then Segment two is set to 60 seconds to reach 150C, which means by
the end of 60 seconds the set temperature should reach 150C, so on and
so forth.
To check the slope from segment Two :
● 150C - 100C =50C
● Time to reach 150C is set to 60seconds.
● Therefore the slope is 50/60= 0.833 degrees per second increase.
To determine the slope if it is declining as seen in segment six:
● 195C - 100C =95C
● Time to reach 100C is set to 60seconds.
● Therefore the slope is 95/60= 1.58 degrees per second decline.
Recommended Working Profile :
SEG1 SEG2 SEG3 SEG4 SEG5 SEG6
060t 060t 060t 050t 040t 30t
100C 130C 150C 172C 180C 180C

10
OPERATING PROCEDURES
D. TYPE “2” OPERATION
Before proceeding with this type of operation, attach the first external
temperature probe (Marked “B”) to the underside of the PCB to be worked
on. The second probe can be placed near areas of interest. Such as near
the component to be worked on.
This type of operation utilizes the first external temperature sensor to
control the heat. Type “2” operation uses the profile to slowly control the
rise and fall of the temperature at board level. While the second external
temperature probe can be attached for additional monitoring.
1. To enter type “2” mode. Select 2 at the initial screen then press the
select button. The display would change to “run Prof”. This signifies
we are now in the type “2” mode.
2. To adjust the time and temperature profile of each segment press the
selection button. The top display will show which segment “SEG1”we
are currently adjusting while the bottom display shows whether we are
adjusting the time (suffix “t”) or temperature (suffix “C”).
3. Press the increase or decrease button to adjust the desired time and
temperature. The set temperature is adjustable from 50 to 250 C and
time 5 to 200 seconds.
4. To start preheating with the profile, repeatedly press the selection
button until the display shows the word “Run Prof” then press the
increase button. A 3 second countdown will commence before
automated reworking starts.
5. To see the running time, or current segment the system is processing
or the temperature of the external temperature probes. repeatedly
press the selection button to switch between different views. Follow
the suffix guide to determine displayed temperature.
6. After the process is finish the display will show “End”, press the
increase button to save the profile and exit to profile adjustment
mode.
7. To exit before the process is finished press the increase button while
the profile is running. The system would exit and return to profile
adjustment mode.
3
CARE and SAFETY PRECAUTIONS
CAUTION: Improper usage can cause injury and physical damage.
For your own safety, please observe the following precautions.
● Temperature may reach as high as 500°C when turned ON.
- Do not touch the heating element inside the pre-heater.
- Do not expose skin to infra-red light for long periods.
- Prolonged exposure may damage the skin tissue.
● Handle with care
- Never drop or sharply jolt the unit.
- Contains delicate parts such as IR tubes that may break if the
unit is dropped.
- Do not spill any liquid to the system.
● Do not tamper the electrical control unit or any wiring inside the
device.
● Disconnect plug from main power source if the device will not be
used for a long period.
- Turn off power during breaks, if possible.
● Allow ample time for the equipment to cool down before
commencing maintenance.
● Use only genuine replacement parts. Turn-off power and let the unit
cool down before replacing any component.

4
The Aoyue Int883 IR-Preheating System is a reworking equipment
that combines infrared (IR) heating technology, enhanced pre-heating
area, versatile board holder, and profile control of heating in one
sophisticated package. It is designed for reworking double-sided, diverse
technology printed circuit boards (PCB) which utilizes traditional or lead
free solder.
The system is equipped with a high powered IR-heating elements
combined with multiple types of preheating operation with built in
safety control of heat and over heat protection. Finally, the unique,
innovative design with digital control panel offers precision, safety, and
ease of use to meet all reworking.
PRODUCT DESCRIPTION
FUNCTIONS and FEATURES
● Microprocessor-controlled ESD safe unit.
● Utilizes infrared heat wave technology.
● Versatile board holder to fit various board types.
● Enhanced pre-heating area to fit large PCBs.
● Widely used for reworking BGAs, micro BGAs, QFPs, PLCCs, SOICs,
small SMD, and other circuit board components.
● Large pre-heating area minimizes board warping
● Easy-to-adjust pre-heat temperatures with digital display.
● Built in extra temperature sensor for more accurate monitoring of board
temperature.
● Built-in temperature sensor for stable (temperature) measurements.
● Closed loop system for precise temperature control.
● Profile adjustment functionality for automating reworking tasks under
user defined temperature and time settings.
● Three modes of operation to suite different reworking requirements.
● Temperature and Profile settings are stored into CPU memory for easy
configuration.
● Compatible for use with either hot air or IR top heating systems.
9
OPERATING PROCEDURES
D. TYPE “1” OPERATION
Before proceeding with this type of operation, attach the first external
temperature probe to the underside of the PCB to be worked on. The
second probe can be placed near areas of interest.
This type of operation utilizes the first external temperature sensor
(Marked “B”) to control the heat. Using this type of operation allows us to
closely control the temperature at board level. While freeing up the second
external temperature probe for additional monitoring.
1. To set the desired temperature press the selection button repeatedly
until the top display shows “Set”. The bottom display would show the
current set temperature followed by a suffix “A”.
2. Press the increase or decrease button to adjust the set temperature
level. The set temperature is adjustable from 50 to 280 C in this type
of operation.
3. For this type of operation we must closely monitor the actual
temperature of the first external temperature probe. To view the
actual temperature readout of this probe repeatedly press the
selection button until the top display shows the word “Act1”, and the
bottom display shows the actual temperature of first external
temperature probe followed by a suffix “b”.
4. To view the temperature of the second external temperature probe or
simultaneously view both external temperature probe's temperature:
● Repeatedly press the selection button until the top display shows
“Act 2” and bottom’s suffix shows “c” this displays the second
temperature probe.
● Repeatedly press the selection button until the top shows the first
temperature probe with suffix “b” and the bottom shows the second
temperature probe with suffix “c”.
5. Under type “1” mode of operation it is not necessary to monitor the
internal temperature sensor’s read out.

8
OPERATING PROCEDURES
3. To view the actual temperature read by the internal temperature
probe, repeatedly press the selection button until the top display
shows the word “Act3”, and the bottom display shows the actual
temperature of internal temperature probe followed by a suffix “d”.
4. To view the actual temperature read by the first external temperature
probe, repeatedly press the selection button until the top display
shows the word “Act1”, and the bottom display shows the actual
temperature of first external temperature probe followed by a suffix
“b”.
5. To view the actual temperature read by the Second external
temperature probe, repeatedly press the selection button until the top
display shows the word “Act2”, and the bottom display shows the
actual temperature of second external temperature probe followed by
a suffix “c”.
6. To simultaneously view the actual temperature read by the first and
Second external temperature probe, repeatedly press the selection
button until the top display shows the actual temperature of first
external temperature probe followed by a suffix “b”. and the bottom
display shows the actual temperature of second external temperature
probe followed by a suffix “c”.
Note: External temperature probes have stickers attached to
differentiate each other. The first probe is marked with “B” while
the second is marked with “C”
5
SPECIFICATIONS
Power Input: Available in 110V / 220V
Dimensions: 520(l) x 370(w) x100(h) mm
Power Consumption: 1500W (maximum)
Temperature Range: 50°C - 400°C (^maximum)
Heating Element: IR Heating
Pre-Heating Area: 310mm x 310mm
PACKAGE INCLUSION
^Depends on type of operation
*Specifications subject to change without prior notice
Instruction Manual
883 Main Station Temperature probe

6
CONTROL PANEL GUIDE
A - Set temperature for type 0 and 1 operation.
b - Actual Temperature of Sensor 1 (Marked B)
c - Actual Temperature of Sensor 2 C
D - Actual Temperature of Internal Sensor
C - Set Temperature for profile.
t - Set duration/time (seconds) for profile.
1.a 5
4
3
2
6
7
Front Panel
Back Panel 9
8
1.b
1 — Digital Display
1.a Top Display
1.b Bottom Display
2 — Selection button.
3 — Increase Button/ Enter button.
4 — Decrease Button.
5 — Status LED.
6 — External Sensor connector
7 — Main Power switch.
8 — Power cord attachment.
9 — Fuse holder.
LEGEND:
Suffix guide:
7
OPERATING PROCEDURES
A. INITIAL PROCEDURES
1. Make sure all switches are deactivated.
2. Attach external sensor probes to the three pin socket. (#6 on control
panel guide)
3. Attach power cord to the power cord attachment (#8 on control panel
guide)
4. Plug the device to the main power source.
5. To turn the unit ON. Toggle the main power switch to ON position (#7
on control panel guide)
B. OPERATION TYPE(MODE) SELECTION
1. Follow initial procedures, “A. INITIAL PROCEDURES”.
2. The display would show “TYPE 0”, which means Type 0 operation will
be used. To select between types 0 to 2. Press the increase or
decrease buttons (#3 & #4 of control panel guide).
3. To confirm selection and enter into operation mode using the selected
type. Press the selection button.(#2 of control panel guide)
C. TYPE “0” OPERATION
This type of operation utilizes the internal temperature sensor to control
the heat. Using this type frees up the two extra external temperature
probes for additional monitoring. Attach the two extra temperature probes
to areas of interest such as the bottom of the board and top of the board
near the components to be worked on for monitoring.
1. To set the desired temperature press the selection button repeatedly
until the top display shows “Set”. The bottom display would show the
current set temperature followed by a suffix “A”.
2. Press the increase or decrease button to adjust the set temperature
level. The set temperature is adjustable from 50 to 400 C in this type
of operation.
