Apacer Technology AUDIO STENO AU840 User manual

1

2
For your Safety
Warning
 To prevent electric shock or other injury, please do not disassemble or repackage
this product.
 To prevent a fire, electric shock, or device malfunction, please do not use this
product in a wet environment such as a bathroom.
If the product gets wet, do not turn it on. Contact a Service Center.
 Do not leave the player in areas above 40oC (104 oF). Such as inside a sauna or
parked car.
 This product is an electronic device; please avoid dropping it or subjecting it to
other severe shock.
 For your safety and the safety of others, do not use headphones while driving,
cycling or conducting any other similar activities.
 Avoid using your player at high volume levels, as it may result in permanent
hearing damage. If you experience ringing in your ears while using the earphones,
remove the earphones immediately and lower the volume.
Notice
 Do not knock or hit the player. Be especially careful not to shake TFT screen to
avoid damaging or causing abnormal functioning of the TFT display.
 Do not dismantle the player personally or use alcohol, thinner or benzene to clean
the surface of the player.
 Do not disconnect the player while formatting, uploading or downloading,
otherwise it may cause a program error
 When transferring files, do not turn the power off or restart this device. No
responsibility is provided for any damage to or loss of any program, data, or other
information stored on any media or any part of this device serviced hereunder.
 Battery service life may vary according to actual using conditions, manufacturer
and manufacturing date.
 The player begins recharging once it is connected to the USB port of a standard
computer, whether it is powered on or not.
 Please recharge the device when:
A. Battery electricity icon displays no electricity.
B. Player refuses to power on.
C. Player functions normally, but it quickly powers off automatically.
D. There is no response when pressing the keys.

3
Table of contents
For your Safety
Chapter 1. Introduction.......................................................................................5
Chapter 2. Product Features..............................................................................5
Chapter 3. Diagram of the player.......................................................................6
Chapter 4. Package Contents ............................................................................6
Chapter 5. Screen Description...........................................................................6
Music Playing Mode ...................................................................................... 6
REC Mode.......................................................................................................6
Video Playing.................................................................................................7
FM Mode.........................................................................................................7
Picture Browsing...........................................................................................7
Chapter 6. Basic Functions................................................................................7
Power On/Off..................................................................................................7
Hold On/Off.....................................................................................................7
Charging the Battery.....................................................................................8
Connect to Computer and Data File Transmission..................................... 9
A-B Repeat Function ..................................................................................... 9
Volume Control.............................................................................................. 9
Chapter 7. System Menu ..................................................................................10
Main Menu....................................................................................................10
Settings ........................................................................................................10
Music ............................................................................................................10
FM Radio ...................................................................................................... 10
Record ..........................................................................................................10
Display..........................................................................................................10
System..........................................................................................................10
Power Off Timer........................................................................................... 11
Language...................................................................................................... 11
Chapter 8. Listening to Music..........................................................................11
Play/Stop ......................................................................................................11
Lyrics Display .............................................................................................. 11
Music Settings .............................................................................................11
Repeat Mode ................................................................................................12
Play Mode..................................................................................................... 12
EQ Select......................................................................................................12
User EQ ........................................................................................................ 12
Chapter 9. FM ....................................................................................................13
FM Radio ...................................................................................................... 13
Manual Search .............................................................................................13
Auto Search..................................................................................................13
Listen to FM..................................................................................................13
Deleting a channel.......................................................................................13
FM settings...................................................................................................14

4
Chapter 10. Picture ...........................................................................................14
Picture Browsing.........................................................................................14
Chapter 11. Text................................................................................................14
Download TXT File....................................................................................... 14
Read File.......................................................................................................14
Bookmark Setup..........................................................................................15
Chapter 12. Recording......................................................................................16
Recording Mode........................................................................................... 16
REC settings ................................................................................................16
Chapter 13. Navigation .....................................................................................16
Navigation ....................................................................................................16
Open folders and Play or Delete files ........................................................ 17
Chapter 14. DRM-9 Function............................................................................17
DRM-9 Transfer Instructions....................................................................... 17
Operation introduction:...............................................................................17
Chapter 15. Convert and Play Video File ........................................................17
Install the AVI converter..............................................................................17
Conversion:.................................................................................................. 19
Chapter 16. Upgrading Player Firmware.........................................................19
Chapter 17. Troubleshooting ...........................................................................20
Chapter 18. Service and Support.....................................................................21
Chapter 19. Product Specifications.................................................................21

5
W
e ma
k
e no represen
t
a
ti
on
f
o
r
th
eer
r
ors, om
i
ss
i
ons o
r
up
d
a
t
es o
f
thi
s
d
ocumen
t
.
We
also make no representation for the data or music files lost of the player.
Microsoft Windows Media and Windows are trademarks of Microsoft Corporation.
Trademarks of other products mentioned in this user's manual are owned by their
respective companies or organizations.
λ Chapter 1. Introduction
Congratulations on your purchase of the Apacer Audio Steno MP4 Player.
Before operating the unit, please read this manual thoroughly and keep it for future
reference. This manual will help you learn to use many of the exciting features of
this device and make your experience more enjoyable.
This manual contains important safety measurements and operational information,
so please read all the information carefully before you use the device in order to
avoid any unexpected accidents.
λ Chapter 2. Product Features
 Full-featured MP4 player with large 2.2" TFT display
 Smooth video playback
 Built-in high-quality stereo speakers, dual earphone output jacks
 Rubber surface finish is comfortable to the touch
 Built-in high-performance Li-battery for continuous playing for up to 8 hours

6
 Chapter 3. Diagram of the player
λ Chapter 4. Package Contents
 Audio Steno AU840 MP4 Player x 1
 Earphones x 2
 USB cable x 1
 Installation CD x 1
 Quick Start Guide x 1
 Carrying Bag x 1
λ Chapter 5. Screen Description
 Music Playing Mode
 REC Mode
VOL -
REC State
File name
Progress ba
r
Remain Recordin
g
time
Recorded Time
REC Mode
Battery Level
REC Qualit
y
Mode key
Displa
y
Earphone jac
k
Power On/Off/Play/Pause
VOL +
F.FWD/NEXT
Ear
p
hone
j
ac
k
REC ke
y
F.REV/PREV
Power switch
USB
p
ort
Exterior-sound speaker
Microphone
Total Time
Track number/Total numbe
r
Playing State
Frequency Display/Lyrics Display/ID3 Info
Song Info
Playback Time
Play Mode Battery level
Bit rate
Volume Indicato
r
Progress bar
Repeat Mode
EQ
Locked Symbol

7
 Video Playing
 FM Mode
 Picture Browsing
λ Chapter 6. Basic Functions
 Power On/Off
Power On:
Push the power switch of player to the ON position
Press and hold key for 3 seconds, Power is turned on.
Power Off:
Press and hold key for 3 seconds, Power is turned off.
 Hold On/Off
Follow the below steps to enable the Hold function to avoid accidental key
presses and operation.
Hold On :hold press and key to lock the player.
Hold Off :hold press and key again to unlock the player.
Volume Indicato
r
Video Pla
y
Battery Level
Progress Bar
Total Time
TrackPlaying State
Playback Time
Folde
r
Files
Battery
FM Mode
Setting option
FM Band Indicato
r
Volume Ba
r
Current Frequenc
y
Battery Level

8
Locked Unlocked
 Charging the Battery
1. Connect the USB cable to your MP4 player, then connect the other end of
the USB cable to the USB port on your PC.
2. Computer and USB cable image appears on the screen display of the MP4
player to confirm USB power supply.
3. The battery icon will display total charge. After charging, the battery icon
will display a full bar. (This picture can’t be seen in the On-line mode).
4. It takes about 3 hours to fully charging the battery. Do not overcharge the
battery (more than 10 hours) . Excessive charging or discharging may
shorten the battery’s life.
Note: Fully charge the rechargeable battery before using the player for the
first time or after it has not been used for a while.

9
 Connect to Computer and Data File Transmission
1. Connect the USB cable to your MP4 player, then connect the other end of
the USB cable to the USB port on your PC.
2. Computer and USB cable image appears on the screen display of the MP4
player to confirm USB power supply and USB data transmission connection.
3. Select and organize files and folders in preparation for transfer to your MP4
player.
Note: Make sure the power switch is on the “Off” position before
connecting to the PC. The “ON/OFF” switch ceases to function after being
connected to a PC.
 A-B Repeat Function
1. Play a file of your choice
2. Press the [REC] key at the beginning of the section you want to repeat.
The starting point is set and the “ A- ” icon will appear in the screen display
window.
3. Press the [REC] key again to set the ending of the section you want to
repeat. “A-B” will appear in the screen and the specified section will begin
to play repeatedly.
4. Press the [REC] key again during the section to cancel the section repeat
function.
 Volume Control
In Music, Voice or Video mode, short press the [+] or [-] keys to increase or
decrease the volume. Hold the key to continually increase or decrease the
volume.

10
λ Chapter 7. System Menu
 Main Menu
1. In the Main menu, press or key to select
your desired option among [Music] / [Video] /
[FM] / [Picture] / [Text] / [Record] / [Navigation] /
[Settings]
2. Press or key, and press the [MODE] key
to enter the option submenu, hold press the
[MODE] key to exit the submenu and return to the Main menu.
 Settings
1. In the Main menu, press or key to select
the “Settings” option, press the [MODE] key to
enter “Settings” submenu.
2. Press or to select a sub-option, press
[MODE] key to enter the settings interface,
press [MODE] key again to save the settings.
3. Hold press the key to return to the “Settings” submenu.
 Music
There are 4 sub-options for this setting: “Repeat Mode”, “Play Mode”, “EQ
Select”, and “User EQ Set”.
For details, please see the section: ”Music settings” in chapter “Listen to Music“.
 FM Radio
There are 2 sub-options for this setting: “Stereo SW” and “FM Region”.
For details, please see the section: ”FM”.
 Record
There are 2 sub-options for this setting: “REC Quality” and “REC Volume”.
For details, please see the section: “Record settings” in chapter ”Record”.
 Display
Blight Time (Backlight time) : 6 options: 5 sec., 10 sec., 15 sec., 20 sec., 30
sec., and Always On.
Lum (luminance) : 5 options: 5, 4, 3, 2 and1. The higher level, the brighter the
luminance.
Blight mode (Backlight mode) : 2 options: Normal and Power Save.
 System
3 sub-options: About, Update, and Default Set.

11
About: Displays player firmware version, version date, total memory /
remaining memory. Press [MODE] key to exit.
Upgrade: A “Warning window” will pop up to confirm whether you want to
upgrade the firmware. Select “Yes” and press [MODE] key to upgrade, select
“No” to Exit.
Default settings: A “Warning window” will pop up to confirm whether you to
restore the factory default settings, Select “Yes” and press [MODE] key to
restore or select “No” to Exit.
 Power Off Timer
There are 6 options: OFF, 10 Minutes, 15 Minutes, 30 Minutes, 60 Minutes and
120 Minutes.
 Language
This MP4 player supports multiple languages.
λ Chapter 8. Listening to Music
 Play/Stop
1. Connect the earphones, then turn on the player, and check the battery.
2. Press the or key to select the “Music” option in the Main menu, press
[MODE] key to enter into music playing mode.
3. Press key to pause music, press key again to unpause music.
4. In playing mode, press the or key to select previous or next track.
5. In playing mode, hold press the or key to rewind or fast forward this
track.
6. Hold press the [REC] button to switch between the frequency display and
ID3 Info/lyric display.
 Lyrics Display
1. Save the lyrics files into your MP4 player with same name as the music file,
in *.LRC format.
2. Refer to the above operation to operate the Lyric Synchronous Display.
The player only supports the Lyric Synchronous Display of files that share the
same name as the MP3 format file, e.g., the music file is named “Angel.mp3”,
the LRC file must be named “Angel.Irc”, they must also be in the same directory.
 Music Settings
1. Select the “Settings” option in the main menu, press or key to select
the “Music” option, Press [MODE] key to enter into the “Music” submenu.
2. There are 4 sub-options: Repeat Mode, Play Mode, EQ Select, and User
EQ Set.

12
 Repeat Mode
7 options listed as below.
1. Once : only play current track once
2. Repeat 1 : Repeat a single song
3. Folder Once : Play every song in the folder once
4. Folder Repeat : Repeatedly play every song in the folder
5. All Once : Play every song once
6. All Repeat: Repeatedly play every song
7. Intro: Play the first 10 seconds of every song
 Play Mode
Order: play the songs in sequence.
Shuffle : play the songs in a random order.
 EQ Select
There are 7 EQ selections including: Normal, 3D, Rock, Pop, Classic, Bass,
Jazz.
 User EQ
In this mode, you can manually optimize your EQ.
1. Press [+] or [-] key to shift horizontally, press or key to adjust
vertically.
2. Select “Yes” to save the setting.

13
λ Chapter 9. FM
 FM Radio
1. Select the “FM” option in the Main Menu.
2. There are 5 options: Manua (manual), Auto (automatic), Mem (memory),
Prese (preset), and Del (delete).
Note: If these 5 options not appear, please press the [MODE] key again to
open submenu.
 Manual Search
1. In “FM” mode, press or key and press [MODE] key to select the
“Manua” option,
2. Press or key to manually seclect frequency channels.
 To save the channel:
1. Press [MODE] key to open FM submenu,
2. Select “ mem ” and press [MODE] to open “Save Channel” window
3. Press [+ ] or [-] key to select any of “Empty ” preset channels, press key
to select “Yes” to save the channels in sequence, select “No” to cancel
4. Press [MODE] to exit.
Note: This player can save a maximum of 30 channels.
 Auto Search
1. In “FM” mode, press or key and press [MODE] key to select “Auto”
option.
2. The MP3 player will search and save channels automatically in sequence.
3. After a total of 30 channels have been saved, the player will automatically
switch to “preset“ mode and play channel 01.
 Listen to FM
1. In “FM” mode, press or key and press [MODE] key to select “Prese”
option.
2. Press or key to select the saved channels to listen.
Note: There is must more channels saving for selecting.
 Deleting a channel
1. In “FM” mode, press or key and press [MODE] key to select “Del”
option.
2. Press [+] or [-] key to select the channel you want to delete.
3. Press key to select “Yes” to confirm the deletion or “No” to cancel.

14
 FM settings
1. Select the “Settings” option in the main menu, press or key to select
“FM Radio” option and press [MODE] key, there are two sub options:
Stereo SW: Press [MODE] key to select Stereo ”On” or “Off” .
FM Region: There are several options: China, Europe, Japan and U.S.A. From
87MHz to 108MHz, and from 76 MHz to 90 MHz for the Japan band.
λ Chapter 10. Picture
 Picture Browsing
1. In the Main menu, press the or key to select the “Picture” option, then
press [MODE] key to enter into Picture mode, shown as follows:
2. Press the or key to select a picture, then press
[MODE] key to
display, now you can press or key to browse through other pictures.
3. Press
[MODE] key again to exit.
Note: this player supports JPEG pictures.
λ Chapter 11. Text
 Download TXT File
1. Connect the player to your computer, select the desired file to download
and save the file as TXT format in the MP4 player.
 Read File
1. In the Main menu, press the or key to select “Text” option, then
press [MODE] key to enter into the “Text” window.
2. Press the or key to select the desired file to be read, and then press
[MODE] key to read.
3. Press the or key to turn the page. Hold press or key to quickly
rewind or fast forward through the pages.

15
Note:
1. This player only supports “ANSI” format TXT files, other file formats
are not supported.
2. If file size is over 400KB, it may display slowly. We suggest you store
file sizes around 400KB or less.
 Bookmark Setup
1. You can set bookmarks in reading mode, press or or [+] or [-] keys to
select bookmark location on the first line of the screen.
2. Press key to set, press [MODE] key to save.
3. Select another bookmark, press [REC] to open the bookmark window,
press [+] or [-] key to select desired bookmark, press [MODE] key to
confirm.
Note: Specified bookmarks can be overwritten, but not deleted.

16
λ Chapter 12. Recording
 Recording Mode
1. In the Main menu, press the or key to select “Record” option, and
then press [MODE] key to enter into the “Record” window.
2. For “MIC REC” record mode, enter the “MIC REC” window; “Prepare…”
is displayed on the screen.
3. Press [REC] key to start recording, press [REC] key again to pause,
“Recording” or “REC PAUSE” is displayed on the screen.
4. Hold press the [REC] key to save the recorded file and it will display
“Saving File” while saving, then prepare to record the next file.
5. Hold press the [MODE] key to exit REC mode.
 REC settings
1. Select the “Settings” option in the main menu, press or key to select
“Record” option and press [MODE] key, there are 2 sub options: “REC
Quality” and “High Quality” .
REC Quality: the “High Quality” option produces larger REC file sizes with
better quality, while “General Quality” produces smaller file sizes with lower
quality sound.
REC Volume: 5 options: +1, +2, +3, +4 and +5. The higher level has the higher
recorded volume.
Note:
You can also find and play the recorded files in the Music Play menu.
If the screen displays “Full Space”, it indicates that there is no memory
remaining for new recording files, please delete some files to free up
some memory.
λ Chapter 13. Navigation
 Navigation
1. Navigation is one function.
2. In the Main menu, press the or ] key to select “Navigation” option, then
press [MODE] key.
3. Navigation allows you see file types, structure and contents more clearly, it
is useful for file management and searching for file content types.

17
 Open folders and Play or Delete files
1. Open folders: In “Navigation” Mode, you can select a folder and press
[MODE] key to see its contents.
2. Play File : In “Navigation” Mode, you can select your own favorite music
or video files, then press [MODE] key to play them directly;
3. Delete File: In “Navigation” mode, hold press [REC] key to open the
“Delete” window, then select “Yes” to delete and “No” to exit.
Note: If the selected file format is not supported by this player, it will
display a “File Format Error” warning.
λ Chapter 14. DRM-9 Function
 DRM-9 Transfer Instructions
Warning : Download music with DRM 9 protection.
1. Music with DRM 9 should be transferred by Windows Media Player 9.0 or
10.0 version to the player.
2. Other download operations will probably cause the player to be unable to
read music files with DRM 9.
 Operation introduction:
The system may request to download a license if the user has not downloaded
the music file with DRM properly from a website. In this case, the user will need
to download the license from the music publisher.
1. Connect player to PC.
2. Choose the desired music file with DRM 9.
3. Right click the file and choose “Add to Sync list”.
4. On the open windows, choose “Sync” option.
5. On “Sync” window, choose the desired music file with DRM 9 selected in
step 2. and choose “Removable Disk”.
6. Click “start Sync“ to transfer the music file with DRM 9 to player.
7. Safely remove the player from PC.
λ Chapter 15. Convert and Play Video File
 Install the AVI converter
1. Insert the installation CD into the CD-ROM, select and click
“AVIConverter.exe” to setup the program.
2. Then click [Next] button to display as follows:

18
3. Choose “Only for Win 2K/XP” option, then click Next.
4. After selecting the installation routine, click the [Install] button until the
installation is completed (shown below)
5. After the installation, click the [Finish] button to finish the software
installation (shown below).

19
 Conversion:
This player can convert RM, VOB, DAT, and RMVB formats into AVI video
format via the attached video conversion software.
1. Run the “AVIConverter 2.0” program and click “Add”, then select your
desired video/audio file and AVI video file routine to be generated, shown
below:
2. Select and set your desired parameters, click “Save”, you can select other
files. After selections are finished, click “Close” to shut this window and
click “Convert Now”. The player will begin to convert the AVI file.
3. After the conversion has finished, click “Close” to exit.
4. The successfully converted AVI video file can be played in the MP4 player.
During the operation, enter Video Mode, select the corresponding file,
press [MODE] key to play video, hold down to exit (the Video Play interface
refers to the Screen Description).
λ Chapter 16. Upgrading Player Firmware
This function is reserved for professional technicians to upgrade the firmware if
your MP4 player sustains abnormal damage. Please contact our distributor or
our technical support center.

20
λ Chapter 17. Troubleshooting
If you experience a problem, please check the following chart for help.
Problem Causes
 Power will not turn on Power will not turn on if the battery is fully
discharged. Recharge the battery and turn the
power on again.
 Power automatically turs off The power is automatically turned off when the
batter is fully discharged. Recharge the battery.
 The screen will not turn on  The screen may not be visible under direct
sunlight.
 Check if you have selected the “Power Save”
setting.
 Playing is disabled  Check if the desired file has been saved in the
memory.
 Check if the music file is correct or the format is
not supported.
 Check if there is enough battery power.
 No music or sound  Check if the volume is not reduced to the 0 level.
 Check that the earphones are connected well
and keep the earphones clean.
 Corrupted music files may result in unplayability,
please confirm the integrity of the files. Re-
format the disk.
 Connection to PC is disabled  Insert the USB cable well after the power is
turned on, or plug in the player again via USB
cable.
 Correctly reinstall the driver again.
 Abnormal Play Time
Displayed while playing
Check if that the file is in VBR (Variable Bit Rate)
format
 Actual memory capacity is
different from what is listed
on package
Small discrepancies are due to different file formats
and algorithms used by various operating systems.
 Abnormal wording or file
name display
Make sure that you have selected the correct
language.
 The product is hot Heat may be generated during recharging. This has
no effect on product life or functions.
