Apacer Technology AP-SRFD255AXXXXR-G User manual

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
1
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
RoHS Compliant
Serial ATA RAID Flash Drive
Specifications for SRFD
April 25, 2008
[Preliminary]
Apacer Technology Inc.
9/F, No. 100, Hsin Tai Wu Rd., Hsic i , Taipei Hsien 221, Taiwan
Tel: [phone] Fax: [phone]
www.apacer.com

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
2
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
Features:
 Interface
– Serial ATA 2.5 (Gen. 2)
– SATA II, 3.0 Gbps
– ATA command set compatible
 Performance
– Burst read/write: 300 MB/sec
 Capacities
– 1 GB+ for eac slot wit Ultra DMA
mode support
 Expansion
– 50-pin CF slot x 2
 Mode
- FAST(RAID-0)
- SAFE (RAID-1)
 OS Support
- Microsoft Windows 2000 and XP
 Auto Standby and Sleep modes
supported
 Temperature ranges
– 0°C ~ 70°C for operation
– -40°C ~ 100°C for storage
 Supply voltage
– 5.0 V ± 5%
 Form factor
– 2.5 inc
– 7-pin SATA male connector
– 15-pin SATA power connector
 Low power consumption
– 510 mA (typical)
 RoHS compliant

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
3
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
Table of Contents
1 General Description 4
1.1 Functional Block Diagram .............................................................................................................................. 4
1.2 Appearance ..................................................................................................................................................... 5
1.3 Mode Configuration ........................................................................................................................................ 6
1.3.1 Definition ................................................................................................................................................. 6
1.4 L D Mode ...................................................................................................................................................... 7
2 Functions 8
2.1 Overview......................................................................................................................................................... 8
2.2 Intelligent SATA RAID Processor Unit.......................................................................................................... 8
2.3 SATA .............................................................................................................................................................. 8
2.4 Architecture..................................................................................................................................................... 8
2.5 Applications .................................................................................................................................................... 8
2.6 Virtualization .................................................................................................................................................. 9
2.7 Modes.............................................................................................................................................................. 9
2.7.1 Fast (RAID-0) Mode ................................................................................................................................ 9
2.7.2 Safe (RAID-1) Mode................................................................................................................................. 9
2.8 RAID-1 Racing ............................................................................................................................................. 10
2.9 Sector Recovery and Disk Rebuild ............................................................................................................... 10
2.9.1 Sector Recover ...................................................................................................................................... 10
2.9.2 Disk Rebuild........................................................................................................................................... 11
2.9.3 Disk Verif .............................................................................................................................................. 11
3 Pin Assignments 12
4 Environmental Specification 14
5 Physical Characteristics 15
5.1 Dimension ..................................................................................................................................................... 15
6 Product Ordering Information 16
6.1 Product Code Designations......................................................................................................................... 16

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
4
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
1.
..
. General Description
T e Apacer 2.5” SRFD is t e first SATA RAID Flas Drive introduced to t e market. SRFD increases data
reliability and security by utilizing an SATA interface and saving data into two CompactFlas cards. It offers
capacity expansion, ultimate performance, reliability and simplicity wit a variety of ardware RAID modes.
1 1 Functional Block Diagram
T e Functional Block SATA RAID Flas Drive (SRFD) contains a SATA RAID Processor Unit, two CF media
slots wit PATA interfaces and a SATA interface to t e Host.
Figure 1-1: Functional block diagram

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
5
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
1 2 Appearance
T is section describes t e appearance of t e SRFD. It contains t e LED indication, mode configurations,
expansion slots, and interfaces.
SATA connector
Power connector
R/W LED (D2)
Link LED (D1)
RAID Mode
Configuration
Table
CF Slot 2

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
6
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
1 3 Mode Configuration
Apacer SRFD supports 4 static pins t at can be used to program a normal operating state. T e configuration
of eac node uses a combination of t e Configuration pins and t e Pus button (Reset) pin.
Table 1-1: Mode Configuration
1 3 1 Definition
T e following met od can be used to define t e configurations.
Configuration pins set to FAST (RAID-0), SAFE (RAID-1):
A. W ile t e system is powered-up
I. Any configuration c ange is ignored
II. P ysical drive c ange rules: no drivers accepted; in SAFE (RAID-1) mode, a single driver c ange
will be accepted wit normal driver rules (larger or equal to existing drive)
B. Upon power-up, but wit no pus button (reset) press
I. Any configuration c ange is ignored
II. P ysical drive c ange rules: no drivers accepted; in SAFE (RAID-1) mode, a single driver c ange
will be accepted wit normal driver rules (larger or equal to existing drive w ic must be present)
C. Upon power-up and momentary pus button (reset) pressed
I. Only new configuration c anges are explicitly accepted (if possible) and all new drives are explicitly
accepted if t ere is a new configuration
Configuration Pin
1 2 3 4 Mode Example
0100 0 1 0 0 RAID 0
1100 1 1 0 0 RAID 1

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
7
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
1 4 LED Mode
T e following table s ows LED Mode status and descriptions.
Table 1-2: LED Status
H/D Signal Color Indication Description
D1 Red SATA Link SATA Link ready
Host
D2 Green Read/Write Host/device Access (active)
D3 Yellow LED_D0_N1
CF 1
D4 Green LED_D0_N0
See table as below
D5 Yellow LED_D1_N1
CF 2
D6 Green LED_D1_N0
See table as below
Table 1-3: CF 1 and CF 2 LED
Description LED_Dx_N1
(D3/D5)
LED_Dx_N0
(D4/D6)
Device Unplugged / No Power Blink Blink
Device Plugged (Idle) On Off
Device Plugged (Activity) On Flas (On)
Disk Rebuild (A P ysical Partition is being Rebuilt; Safe
Mode (RAID-1)) Blink On
Disk Rebuild-Verify (A P ysical Partition is being Verified;
Safe Mode (RAID-1)) On Flas (ON)
Will appear as On
Error State: Incorrect Serial Number Blink Blink

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
8
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
2. Functions
2 1 Overview
 Compatible wit SATA Gen1 and Gen2 ost controllers
 OS independent, Driverless, Auto Configuration
 FAST (RAID 0), SAFE (RAID 1) support
 Embedded fast RAID Processor
 Virtualization engine to simplify and improve utilization of storage devices
 Ultra-fast 3Gbps ost and device port capability
2 2 Intelligent SATA RAID Processor Unit
 Automatic Failover in RAID 1 mode
 Automatic Rebuild in RAID 1 mode
 Automatic RAID mode configuration
 100GB/ r Rebuild speed wit out Host CPU loading
 Hig performance, reliability and simplicity wit ardware RAID 0, 1 options
 Virtualized multiple storage devices into one or many storage units, e.g. multi-drive spanning, drive
partitioning
 Hig -speed, native SATA II connection to ost and device
 Device-to-device(s) copy to off-load ost during rebuild
 LED drivers for status reporting
 Drive Splitting for multi-RAID partitions on a single volume wit PM Aware Host
2 3 SATA
 1x2 Port Multiplier Functionality
 1.5Gpbs or 3Gpbs link rate wit auto-negotiation
 Supports ot plug, drive roaming
 Supports ost control of ard disk drive staggered spin-up
 Host side NCQ support
2 4 Architecture
 Features independent 8-KByte FIFO per Device Serial ATA c annel for reads and writes
 Hig Performance data movement between all SATA Generation 2 ports
 Greater t an 110MBps sustained reads in RAID 1 mode (limited by drives)
 Support store and forwarding
2 5 Applications
 PC
 DVR
 PVR
 Video Editing Systems
 eSATA Storage Target/Host

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
9
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
2 6 Virtualization
Virtualization is a mec anism, w ere t e HBA can ave an alternate view of t e p ysical drives. T e RAID
Processor allows various access strategies to t e connected Hard Disks and may be configured to represent
n-drives as m-drives to t e user. T is provides t e user wit a simple way of partitioning storage resources
according to use. For example, t e processor could represent one drives as a single, large drive. Anot er
option would be to make virtual storage resources according to reliability or performance requirements. One
virtual target could be a mirrored set consisting of drives 1 and 2, or could be a striped set consisting of drives
1 and 2. Representing multiple device targets may only be performed wit port multiplier aware ost
controllers.
2 7 Modes
SRFD supports 2 modes: Fast (RAID-0) and Safe (RAID-1).
2 7 1 Fast (RAID-0) Mode
RAID 0 - RAID Level 0 is not redundant, ence does not truly fit t e "RAID" acronym. T is met od splits t e
data over numerous drives but is seen as one drive by t e operating system. If one drive fails t oug , all data
becomes inaccessible. T is level is commonly referred to as striping.
T e RAID Processor supports a definition of Fast (RAID-0) set. T e stripe size (c unk size) is set to 8 KB. T e
HBA (Host Bus Adapter) does not need to know anyt ing about t e p ysical arrangement of t e data. To t e
HBA, t e virtualized drive be ind RAID Processor is a simple (normal) drive t at just appens to be faster. All
error andling etc. is managed by t e Processor. T e advantage of striping is double t e data transfer
t roug put of a single p ysical drive. T is applies to bot read and write operations.
2 7 2 Safe (RAID-1) Mode
RAID 1- Mirrored Set (2 disks minimum) wit out parity. RAID-1 set is a combination of two p ysical partitions,
w ere t e data is “mirrored” among t em. Provides fault tolerance from disk errors and single disk failure.
Increased read performance occurs w en using a multi-t readed operating system t at supports split seeks,
very small performance reduction w en writing. Array continues to operate so long as at least one drive is
functioning.

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
10
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
T e RAID Processor supports a definition of Safe (RAID-1) set. T e HBA (Host Bus Adapter) does not need
to know anyt ing about t e p ysical arrangement of t e data. To t e HBA, t e virtualized drive be ind RAID
Processor is a normal drive t at just appens to be safer (fault tolerant). All error andling and Data rebuild is
managed by t e RAID Processor. T e two p ysical partitions used for mirroring must reside on two different
p ysical disks, as t ere is no benefit of mirroring t e data on t e same drive. T e advantage of mirroring is
essentially safeguarding t e data in case of a single p ysical drive failure. For a read operation, t e RAID
Processor decides w ic p ysical partition to read from and for write, t e data is written to bot drivers. Note:
T ere is no benefit of performance due to mirroring. Often t e performance may suffer slig tly, as t e data will
be transferred to t e least common denominator of t e two p ysical drives. T e two p ysical partitions used
for mirroring must reside on two different p ysical disks, as t ere is no benefit of mirroring t e data on t e
same drive.
2 8 RAID-1 Racing
T e Storage Processor improves t e speed of RAID 1 (SAFE) mode by introducing RAID 1 drive racing.
W en reading a sector, bot mirrored drives race and t e first one to get t e data supplies t e information,
lowering t e average seek time.
2 9 Sector Recovery and Disk Rebuild
For Safe (RAID-1) volumes, t e firmware implements t ree additional features to make t e data more reliable,
Sector Recovery, Disk Rebuild and Disk Verify.
2 9 1 Sector Recovery
For Safe (RAID-1) volumes, at any time, if t e Storage Processor detects any read or write error, it
automatically (wit out ost intervention):
 Take t e P ysical Partition Off-line
 Attempt to copy t e respective data from t e ot er mirrored Partition (if available).
 If t e re-write is successful, t en t e problem is solved before it got to be catastrop ic.
 Bring t e P ysical Partition On-Line.
In case t e problem still persists after re-write (Read-Verify fails), t en it is assumed t at P ysical Partition on
t e P ysical Disk is bad (and all spare sectors implemented by t e HDD itself are depleted). In t is event, t is
P ysical Partition (wit Error) will stay off-line. Ot er P ysical Partitions on t is HDD are still good and stay
on-line. In addition, t at HDD’s LED will s ow t e Error State. In t e rare case, if t ere is anot er sector

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
11
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
recovery is needed, w ile t e first one is not complete, t en t e new request is converted to a Disk Rebuild
Request.
2 9 2 Disk Rebuild
First of all, t e Disk Rebuild is really a P ysical Partition Rebuild. Only t en t e P ysical Partition spans t e
entire P ysical Disk, t e entire P ysical Disk is rebuilt. Disk Rebuild is a procedure, to copy all of t e contents
from t e “Good” P ysical Partition to t e “Broken” or “New” P ysical Partition.
T is is typically initiated on one of t e following t ree events:
 Power Up (Scan if anyt ing is pending)
 P ysical Disk insertion (Assume, t e inserted P ysical Disk is good and ready to use).
 Anot er Sector Recovery or Disk Rebuild completes. During Disk Rebuild, t e P ysical Partition is
not read from, but all writes are propagated to t e drive.
2 9 3 Disk Verify
In addition to t e Sector Recovery and Disk Rebuild, t e Storage Processor also implements a Data
Verification sc eme. For sector Recovery, t e Data Verification performed by Read-Verify Commands is
automatically and always performed to make sure, t e data is written correctly. In case of Disk Rebuild, t is
Data Verification is optional (selectable by GPI [1]). T e firmware will read t e status of t is GPI pin and if “1”,
it will perform a Verification cycle. Note: T e drive is fully available for reads and writes, during t e data
verification process.

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
12
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
3. in Assignments
Table 3-1: Signal segment
Pin Signal Description
S1 Ground
S2 RxP
S3 RxN
Serial Data Receiver
S4 Ground
S5 TxN
S6 TxP
Serial Data Transmitter
S7 Ground

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
13
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
Table 3-2: Power segment
Pin Signal / Description
P1 Not Used (3.3V)
P2 Not Used (3.3V)
P3 Not Used
P4 Ground
P5 Ground
P6 Ground
P7 5V Pre-c arge
P8 5V
P9 5V
P10 Ground
P11 Ground
P12 Ground
P13 Not Used
P14 Not Used (12V)
P15 Not Used (12V)

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
14
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
4. Environmental Specification
T e environmental specification follows t e US Military Standard MIL-STD-801F.
Table 4-1: Environmental Specifications (Plan)
0°C ~ 70°C for operation
Temperature
-40°C ~ 100°C for Storage
Humidity 5% ~ 95%R.H (non-condensing)
Vibration
A) Sine wave: 5~55~5Hz , X,Y,Z axes
B) Random: 10~2000Hz, 16.3g, X, Y, Z 3 axes.
Shock - Operating
A) Acceleration 1,500G , 0.5ms
B) Peak acceleration 50G ,11ms

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
15
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
5. hysical Characteristics
5 1 Dimension
Unit: mm
Tolerance: ± 0.2

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
16
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
6. roduct Ordering Information
6 1 Product Code Designations
A P – SRFD 25 5 A XXXX R – G
Housing/OEM
Device
RoHS
Blank = Standard
Product Type
SATA RAID Flash Drive
Apacer Product Code
2 5 inch

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
17
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
Revision History
Revision Description Date
0.1 Initial release. Preliminary specification. Jan. 07, 2008
0.2 Updated features and function modes Apr. 25, 2008

Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
18
© 2008 Apacer Technology Inc Rev 0.2 (Preliminary)
Global resence
Taiwan (Headquarters)
Apacer Technology Inc
9F, 100, Sec. 1, Hsin Tai Wu Rd.,
Hsic i , 221 Taipei Hsien
Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
[email protected]
U S A
Apacer Memory America, Inc
386 Fairview Way, Suite102,
Milpitas, CA 95035
Tel: [phone]
Fax: [phone]
[email protected]
Japan
Apacer Technology Corp
5F, Matsura Bldg., S iba, Minato-Ku
Tokyo, 105-0014, Japan
Tel: [phone]
Fax: [phone]
[email protected]
Europe
Apacer Technology B V
Europalaan 89
5232 BC 'S-Hertogenbosc
T e Net erlands
Tel: [phone]
Fax: [phone]
[email protected]
China
Apacer Electronic (Shanghai) Co , Ltd
1301, No.251,Xiaomuqiao Road, S ang ai,
200032, C ina
Tel: [phone]
Fax: [phone]
[email protected]m.cn
India
Apacer Technologies Pvt Ltd
#143, 1st Floor, Ra eja Arcade,
5t Block Kormangala Industrial Layout,
Bangalore - 560095, India
Tel: [phone]
[email protected]
