Apator Metra E-ITN 10 Series Manual

ELECTRONIC HEAT COST ALLOCATOR
E-ITN 10
Installation and service manual
APATOR METRA s r o
Havlíčkova 919/24
787 64 Šumperk
Czech Republic
tel : [phone]
fax: [phone]
e-mail: prodej@metra - su cz
WWW: http://www metra - su cz

E-ITN 10
Installation and service manual M2015/04b [EN]
TABLE OF CONTENTS
1 INTRODUCTION 4
1 1 LC display 4
2 DEVICE DESCRIPTION 5
2 1 Type E-ITN 10 41 5
2 2 Type E-ITN 10 42 5
2 3 Type E-ITN 10 51 5
2 4 Type E-ITN 10 52 5
2 5 Type E-ITN 10 6 5
2 6 Type E-ITN 10 71 5
2 7 Type E-ITN 10 72 5
3 TECHNICAL SPECIFICATIONS 6
3 1 Construction 8
4 OPERATION MODES 9
4 1 Operation modes 9
4 2 Submenu navigation 9
4 3 Sleeping mode 9
4.3.1. Submenu structure in sleeping mode..............................................................................................9
4.3.1.1. Activation of working mode...................................................................................................................10
4.3.1.2. Allocator self test................................................................................................................................... 10
4.3.1.3. Setting of radiator type E-ITN 10.5x, 10.6, 10.7x only).......................................................................10
4 4 Mode of waiting for start date 10
4.4.1. Submenu structure in mode of waiting for start date......................................................................11
4 5 Working mode 11
4.5.1. Menu structure in working mode.................................................................................................... 11
4.5.1.1. Value for current billing period .............................................................................................................11
4.5.1.2. Value for the last billing period..............................................................................................................12
4.5.1.3. Alphanumerical code............................................................................................................................ 12
4.5.1.4. Serial number E-ITN 10.4x, 10.5x, 10.7x only)....................................................................................12
4.5.1.5. Temperature of the radiator sensor E-ITN 10.4x, 10.5x, 10.7x only)...................................................12
4.5.1.6. Temperature of the surroundings sensor E-ITN 10.4x, 10.5x, 10.7x only)..........................................12
4.5.1.7. Date of the billing period beginning......................................................................................................12
4.5.1.8. Current date.......................................................................................................................................... 12
4.5.1.9. Current time E-ITN 10.4x, 10.5x, 10.7x only)......................................................................................12
4.5.1.10. Display test E-ITN 10.6 only)............................................................................................................. 12
4.5.1.11. Average surroundings temperature for the last billing period E-ITN 10.6 only).................................12
4.5.2. Month consumption values............................................................................................................ 13
4.5.2.1. Activation of the submenu with month values E-ITN 10.4x, 10.5x, 10.7x only)...................................13
4.5.2.2. Activation of the submenu with month values E-ITN 10.6 only)..........................................................13
4.5.2.3. Structure of submenu with month values..............................................................................................13
4.5.3. Menu structure in service mode E-ITN 10.6 only)........................................................................13
4.5.3.1. Number of measuring cycles in single-sensor mode............................................................................14
4.5.3.2. Max. temperature of radiator sensor in last billing period.....................................................................14
4.5.3.3. Date when the max. temperature of radiator sensor in last billing period was reached.......................14
4.5.3.4. Min. temperature of radiator sensor in last billing period......................................................................14
4.5.3.5. Date when the min. temperature of radiator sensor was reached in last billing period........................14
4.5.3.6. Value in penultimate billing period........................................................................................................14
4.5.4. Last year of battery life.................................................................................................................. 14
4 6 Error mode 14
5 OTHER INFORMATIONS 15
5 1 Allocator parameters setting 15
5 2 Transportation 15
5 3 Storage 15
5 4 Application and disposal 15
5 5 Defects and their elimination 15
5 6 Warranty 15
2 / 39

E-ITN 10
Installation and service manual M2015/04b [EN]
6 ACCOMPANYING DOCUMENTATION 16
6 1 Ordering 16
6 2 Packing 16
7 INSTALLATION METHODS 19
7 1 Allocator installation 19
7 2 Allocator back plate 19
7 3 List of installation material 20
7 4 E-ITN 10 mounting place on segmented and panel radiators 21
7.4.1. Vertical position: ........................................................................................................................... 21
7.4.2. Horizontal position:........................................................................................................................ 21
7 5 Installation on segmented radiators 22
7.5.1. Description of installation .............................................................................................................. 22
7.5.2. Installation differences .................................................................................................................. 23
7 6 Installation on panel radiators 24
7.6.1. Installation on panel radiators........................................................................................................ 24
7 7 Installation on horizontal and vertical registers 26
7.7.1. Installation on horizontal and vertical registers..............................................................................26
7.7.2. Proper E-ITN 10 installation on different register types.................................................................27
7 8 Model No 1 – Cast iron radiators 29
7 9 Model No 2 – Cast iron radiators with flat vertical front panel 30
7 10 Model No 3 – Cast iron radiators with distance pad 31
7 11 Model No 4 – Steel radiators 32
7 12 Model No 5 – Steel radiators with distance pad 33
7 13 Model No 6 – Panel radiators with shaped front side 34
7 14 Model No 7 – Panel radiators with a flat front panel 35
7 15 Model No 8 – Tubular radiators - ladder 36
7 16 Model No 10 – Radiators made from smooth or ribbed tubes - register 37
7 17 Model No 12 – Aluminium radiator with vertical ribs 38
7 18 Model No 14 – Tubular radiator with alluminum front desk 39
3 / 39

E-ITN 10
Installation and service manual M2015/04b [EN]
1 INTRODUCTION
E-ITN 10 is modern electronic device intended for ratio based allocation of heat cost in buildings with central
heating system
The heat cost allocator E-ITN 10 4 uses one (E-ITN 10 41) or two temperature sensors with surrounding
temperature sensor is used for start only (E-ITN 10 42) Allocators E-ITN 10 5x, E-ITN 10 6 and E-ITN 10 7x
are based on the two-sensor measuring principle Using this principle, allocator ensures measurement of
consumption value only when the radiator really emits heat (i e it does not measure in the summer)
E-ITN 10 is intended to be installed in one-tube horizontal/vertical and two-tube heating systems with the
lowest mean design heating medium temperature ≥ 35 °C or 55 °C (depending on type of the allocator, see
chapter 3 Technical specifications) and mean design heating medium temperature ≤ 90 °C
Each radiator in billing (account) unit with common invoicing heat meter must be equipped with a heat cost
allocator of the same type Technical conditions of heating system must be fulfilled when using heat cost
allocators E-ITN 10
E-ITN 10 is not intended for heat cost allocation for floor heating systems, ceiling radiant heating, flap
controlled radiators, radiators with fan, systems with steam heating medium, air heaters and single tube
radiators if exceeds the scope of one user It must not be also used for heating elements that shape and
design does not allow reliable transfer of heat to heat cost allocators
1 1 LC DISPLAY
Basic allocator status and measured values can be displayed on LCD LCD can display five alphanumeric
characters These values are highlighted by underline and overline in following text, e g 395
Meaning of some values may be different if the additional symbol „SM“ at the right bottom corner is
displayed These values are mentioned with „SM“ symbol in text , e g 385 SM
The last symbol on the display indicate end of the battery life, see chapter 4 5 4 Last year of battery life
To save the battery, after longer period of inactivity (approx 1 min ), energy-saving mode is activated and
display is switched off Display can be activated by pushing the button (Illustration 1: E-ITN 10)
When pushing the button briefly, notice ----- on the display will appear If the button is not pushed in 1 minute,
the display will switch off
The data displayed on the LCD display may vary depending on the type of the allocator and also on the
active operating mode For more information, see below
4 / 39
Illustration 1: E-ITN 10
mechanical seal
push-button
IR diode for infra-red reading ( E-ITN 10 6
and E-ITN 10 7 only)
serial number and bar code
LC display
type of the allocator
Illustration 2: LC display

E-ITN 10
Installation and service manual M2015/04b [EN]
2 DEVICE DESCRIPTION
Installation of allocator consists of mounting of base plate made from aluminium alloy on the radiator, placing
of allocator on the base plate, attaching with screw M3x8 and securing with mechanical seal
The device is resistant against cheating If any cheating is detected (fully two-sensor types E-ITN 10 5x, E-
ITN 10 6 and E-ITN 10 7) allocator switches to the one-sensor mode inconvenient for the user – when
cheating is finished, the allocator switches to standard mode
2 1 TYPE E-ITN 10 41
Allocator uses the one-sensor measuring principle and is equipped with unified scale No parameters (e g
parameters related to radiator type, nominal output or coefficient KC) are set before installation on the
radiator Billing period is year Allocator can be read only visually
2 2 TYPE E-ITN 10 42
Allocator uses the two-sensor measuring principle (sensor of surrounding temperature is used for start only,
measuring is based only on data from sensor of radiator temperature) and is equipped with unified scale
Conditions for registration start (e g parameters related to radiator type, nominal output or coefficient KC)
are set before installation on the radiator Billing period is year Allocator can be read only visually
2 3 TYPE E-ITN 10 51
Allocator uses the two-sensor measuring principle and is equipped with unified scale For proper evaluation
of measured data, it is necessary to set radiator type (in production or manually) Billing period is year
Allocator can be read only visually
2 4 TYPE E-ITN 10 52
Allocator uses the two-sensor measuring principle and is equipped with unified scale For proper evaluation
of measured data, it is necessary to set radiator type (in production or manually) Billing period is month
Allocator can be read only visually
2 5 TYPE E-ITN 10 6
Allocator is equipped with individual scale For proper evaluation of measured data, it is necessary to set:
•radiator type (Kc)
•radiator nominal output (M)
•evaluation coefficient (KCHF) describing heat contact with sensor of radiator temperature
Parameter can be set by manufacturer or before installation with Programming unit for changing allocator
parameters of E-ITN 20.x, 30.x connected to PC Radiator type (Kc) can be set in sleeping mode by pressing
the button E-ITN 10 6 can be ordered after agreement with manufacturer only
Billing period is year
2 6 TYPE E-ITN 10 71
Allocator uses the two-sensor measuring principle and is equipped with unified scale For proper evaluation
of measured data, it is necessary to set radiator type (in production or manually) Billing period is year
Allocator can be read visually or using infra-red reading device
2 7 TYPE E-ITN 10 72
Allocator uses the two-sensor measuring principle and is equipped with unified scale For proper evaluation
of measured data, it is necessary to set radiator type (in production or manually) Billing period is month
Allocator can be read visually or using infra-red reading device
5 / 39

E-ITN 10
Installation and service manual M2015/04b [EN]
3 TECHNICAL SPECIFICATIONS
Application min temperature of the heating medium tmin ≥ 55 °C (E-ITN 10 4x)
min temperature of the heating medium tmin ≥ 35 °C (E-ITN 10 5x,
10 6, 10 7x)
max temperature of the heating medium tmax ≤ 90 °C
Measuring principle one-sensor measuring principle (E-ITN 10 41)
one-sensor measuring principle with starting sensor (E-ITN 10 42)
two-sensor measuring principle (E-ITN 10 5x, 10 6, 10 7x)
Conditions for registration temperature of the sensor of the radiator temperature ≥ 28 °C (E-ITN
10 41)
temperature of the sensor of the radiator temperature ≥ 20 °C,
difference of mean temperature of heating medium and surroundings
temperature ≥ 4 °C (E-ITN 10 42)
temperature of the sensor of the radiator temperature ≥ 23 °C,
difference of mean temperature of heating medium and surroundings
temperature ≥ 4 °C (E-ITN 10 5x, 10 6, 10 7x)
Note: For E-ITN 10.41 and E-ITN 10.42 conditions for registration
can be set differently depending on values in setting protocol
Billing period year (E-ITN 10 4x, 10 51, 10 6, 10 71)
month (E-ITN 10 52, E-ITN 10 72)
Resulting rating factor K unified scale, K = 1 (E-ITN 10 4x, E-ITN 10 5x, E-ITN 10 7x)
individual scale (E-ITN 10 6)
Calendar functions E-ITN 10 4x, E-ITN 10 5x
•consumption value in the last billing period
•for last 24 moths: month values
E-ITN 10 6
•for the last billing period: consumption value, average
surroundings temperature, number of measuring cycles in
single-sensor mode, max radiator temperature, max tempe-
rature date, min radiator temperature, min temperature date
•for last 12 months: month values
E-ITN 10 71
•consumption value in the last billing period
•for last 12 months: month values, min , aver and max
radiator temperature, average surroundings temperature,
number of heating days
E-ITN 10 72
•consumption value in the last billing period
•for last 12 months: month values
•for last 6 months: min , aver and max radiator temperature,
number of heating days
6 / 39

E-ITN 10
Installation and service manual M2015/04b [EN]
Display 5 digits LCD + 2 special symbols
Protection against cheating mechanical seal with billing company label
continuous control, when thermal influence is detected, allocator is
switched to single-sensor mode (E-ITN 10 5x, 10 6, 10 7x)
Data reading visual
infra-red (E-ITN 10 6, 10 7x only)
Data backup daily backup of measured values including real time
Function control automatic, can be activated and controlled by user
Dimensions 97 x 37 x 23 mm
Power supply lithium battery 3,0 V
Material ABS / Al – F22
IP code IP 42
Conformity ČSN EN 834
Data available via infra-red
interface (for exact data structure
see manual for decoding software)
E-ITN 10 6
•reading date
•serial number
•date of billing period beginning
•value for the last billing period
•alphanumeric code for the last billing period
•month values in last 11 months
•average surroundings temperature for the last billing period
•number of measuring cycles in single-sensor mode for the last
billing period
•max radiator temperature in last billing period
•day when the max temperature was achieved
•min radiator temperature in last billing period
•day when the min temperature was achieved
E-ITN 10 71
•reading date
•serial number
•date of billing period beginning
•value for the last billing period
•alphanumeric code for the last billing period
•monthly values in last 11 months
•actual value
•max radiator temperature in last 11 months
•min radiator temperature in last 11 months
•average radiator temperature in last 11 months
•average surroundings temperature in last 11 months
•number of days in month when conditions for measuring were
fulfilled in last 11 months
7 / 39

E-ITN 10
Installation and service manual M2015/04b [EN]
E-ITN 10 72
•reading date
•serial number
•date of billing period beginning
•value for the last billing period
•alphanumeric code for the last billing period
•monthly values in last 11 months
•value for the last year
•max radiator temperature in last 5 months
•min radiator temperature in last 5 months
•average radiator temperature in last 5 months
•number of days in month when conditions for measuring were
fulfilled in last 5 months
•alphanumeric code for the penultimate billing period and 5
previous billing periods
3 1 CONSTRUCTION
Electronic heat cost allocator E-ITN 10 complies with ČSN EN 834:1995
Allocator consist of cover and printed circuit board with spring and push-button Cover is made from plastic
material There are marked values of the lowest and highest heating medium temperature, manufacturer's
mark, type of the allocator, serial number (both as number and bar code) and optionally the partner's mark
on the cover The base plate is made of aluminium alloy to ensure of a good thermal contact with the
radiator
To install the heat cost allocator, place it at the lower end of the aluminium back plate, push up so that the
locks in the housing fit in the aluminium back plate and fix allocator with bolt M3x8 in this position Then
secure the device with seal (marked seal should be inserted into the holes in the upper part of the allocator)
against unauthorized manipulation Now the heat cost allocator can only be uninstalled after breaking the
seal
Devices are equipped with a 16-bit microprocessor with extremely low current consumption and powered by
lithium battery The accuracy of the measuring circuit is independent of the battery voltage The LCD-display
has 5 large main digits separated by dots and two special symbols
Warning!
Spring on the printed board circuit is intended to maintain the good contact between temperature
sensor and base plate Do not change the temperature sensor position or prestress of the spring
8 / 39

E-ITN 10
Installation and service manual M2015/04b [EN]
4 OPERATION MODES
4 1 OPERATION MODES
The allocator can be in four operation modes:
•sleeping mode
•mode of waiting for start date
•working mode
•error mode
4 2 SUBMENU NAVIGATION
The allocator contains a simple submenus (depending on current operation mode), that allow to obtain
additional informations or perform other activities
To switch between individual items of menu, push the button briefly To enter the submenu, choose relevant
item and hold the button (approximately 2 seconds) until --A-- appears on LCD When you release the
button, designation of the 1st submenu item appears Move in menu by short presses of the button If the
button is not pushed for 10 seconds, the LCD returns to the main menu
Activation process of item is the same as entering the submenu Find the relevant item and hold the button
(for approximately two seconds), till notice --A -- on the LCD appears
Movement in options is the same – briefly press the button Selected option confirmation as well – by long
(approx 2 s) press of the button, till notice --A-- appears on LCD
4 3 SLEEPING MODE
Allocator consumption is reduced to a minimum since no measuring and no calculations are carried out and
furthermore allocator does not transmit the data Sleeping mode is suitable for prolonged storage prior to
allocator use The storage period should not exceed one year
In sleeping mode allocator allows the following operations:
•displaying of set radiator type (E-ITN 10 5x, 10 6, 10 7x only)
•setting of radiator type (E-ITN 10 5x, 10 6, 10 7x only)
•activation of working mode
•allocator self test
Sleeping mode is indicated with notice uPr on the display If the display does not show any value or notice
(due power saving), press the button briefly to switch LCD on
4.3.1. Submenu structure in sleeping mode
When notice uPr appears, hold the button till notice --A - - is displayed and indicates sub menu activation
Submenu activation and navigation in the items is described in chapter 4 2 Submenu navigation
Table 1: Submenu structure in sleeping mode, type E- ITN 10.4x
Allocator self test ti
Activation of working mode Act
Table 2: Submenu structure in sleeping mode, type E- ITN 10.5x, 10.6, 10.7x
Radiator type (e g 2) tot 2
Setting of radiator type ntt
Activation of working mode Act
Allocator self test ti
9 / 39

E-ITN 10
Installation and service manual M2015/04b [EN]
4.3.1.1. Activation of working mode
If the allocator is in a sleeping mode, working mode can be activated using button For activation of working
mode, sub menu item Act is used
Working mode activation:
1 Switch to sub menu in sleeping mode
2 When notice Act appears, press and hold the button till notice --A - - is displayed When you release
the button, first menu item is displayed: chapter 4 5 1 Menu structure in working mode
4.3.1.2. Allocator self test
Allocator self test is used for control of all LCD segments and to test A/D converter for temperature
measurement We can run the test in sleeping mode, working mode and also in mode of waiting for start
date Option is located in sub menu whose activation was described above
To start the test:
1 Switch to submenu item marked as ti (allocator test) with brief press of the button
2 While ti is displayed, press and hold the button, till notice --A - - appears
3 Allocator self test has three phases 1st phase: all segments are turned on 2nd phase:
radiator temperature is displayed, e g 36 4°C and in 3rd phase surrounding temperature appears
e g 25 4°C SM (or --°C SM for one sensor allocator E-ITN 10 41) Every value is displayed for 2
seconds and LCD is automatically switched into the main menu when self test is completed
If A/D converter malfunction is detected, allocator switches to fault mode and notice Error is displayed on
LCD
4.3.1.3. Setting of radiator type E-ITN 10.5x, 10.6, 10.7x only)
Switch to the submenu in sleeping mode Switch to submenu on 2nd item marked as ntt (radiator type setting)
with button short presses While ntt is displayed, press and hold the button, till notice --A - - appears After
button release, notice ot x is displayed (number „x“ indicates the selected type of radiator)
Press the button briefly to browse in radiator types and than choose the right one Confirm selected type of
radiator with long press (hold the button till --A - - is displayed) After button release submenu item tot x
appears (number „x“ gives us selected type of the radiator)
Table 3: Radiator setting – options
Steel plate radiator with vertical offsets ot 0
Steel plate radiator with smooth front panel ot 1
Steel segmented radiator ot 2
Cast iron segmented radiator ot 3
Universal, average value 0 to 3
( E-ITN 10 6 only)
ot 4
4 4 MODE OF WAITING FOR START DATE
This mode is suitable when you require to start multiple allocators on the same date In this mode, the
allocator regularly updates real time and compares current date with start date When the start date is
reached, the allocator will start measuring (switch to working mode)
Mode of waiting for start date is indicated with notice: e g o 1 12 (date indicates the date of start) If the
display does not show any indication (because of power saving), press the button briefly to switch it on
In mode of waiting for start date, following actions can be performed:
• displaying of set radiator type (E-ITN 10 5x, 10 6, 10 7x only)
•allocator self test
10 / 39

E-ITN 10
Installation and service manual M2015/04b [EN]
4.4.1. Submenu structure in mode of waiting for start date
For submenu activation and navigation between items see chapter 4 2 Submenu navigation Allocator self
test activation is described in chapter 4 3 1 2 Allocator self test Radiator type selection for E-ITN 10 5x,
10 6, 10 7x is described in chapter 4 3 1 3 Setting of radiator type ( E-ITN 10 5x, 10 6, 10 7x only)
Table 4: Submenu structure in mode of waiting for start date, type E-ITN 10.4x
Allocator self-test ti
Table 5: Submenu structure in mode of waiting for start date, type E-ITN 10.5x, 10.6, 10.7x
Radiator type (e g 2) tot 2
Allocator self-test ti
4 5 WORKING MODE
In working mode allocator performs temperature measurement, calculates the increase of value (if
measurement conditions are met), transmits measured data, updates real-time and makes some other
actions in regular intervals
4.5.1. Menu structure in working mode
If nothing is displayed press the button briefly
Table 6: Submenu structure in working mode, type E-ITN 10.4x, 10.5x, 10.7x
Value for current billing period 245
Value for last billing period 458 SM
Alphanumerical code for last billing period A 0 i h t
Serial number – first part -0700
Serial number – second part 0060-
* Radiator temperature 53 3°C
* Surroundings temperature – E-ITN 10 42, 10 5, 10 6, 10 7x
– E-ITN 10 41
26 7°C SM
--°C SM
* Date of billing period beginning – E-ITN 10 4x, 10 51, 10 71
– E-ITN 10 52, 10 72
u 1 12
dF 1
* Current date 10 12
* Current time 12-45
Note: menu items marked as * are optional, see chapter 5 1 Allocator parameters setting
Table 7: Submenu structure in working mode, type E- ITN 10.6
LCD test
Current date 10 12
Start of the billing period u 1 2
Value for last billing period 458 SM
Alphanumerical code A 0 i h t
Average surroundings temperature for last billing period 23 7°C SM
Value for current billing period 245
4.5.1.1. Value for current billing period
Value for current billing period is displayed as 389 (without insignificant zeros) It is calculated from the
beginning of the current billing period
11 / 39

E-ITN 10
Installation and service manual M2015/04b [EN]
4.5.1.2. Value for the last billing period
Value for the last billing period is displayed as 3258 SM Transfer of measured value for actual billing period
to value for the last billing period is performed, when new billing period is achieved in 00:00:00
4.5.1.3. Alphanumerical code
5 digit alphanumeric code comprises from numbers and letters mentioned from following set: 0, 1, 2, 3, 4, 5,
6, 7, 8, 9, A, b, c, d, E, F, h, i, J, L, n, o, P, r, t, u
On LCD it is displayed e g A 0 i h t Alphanumerical code is created when transfer of measured value for
actual billing period to measured value for last billing period is performed If transfer of measured value was
never done before, - - appears on the display (alphanumeric code value is not available)
Alphanumerical code is generated for every consumption value in last billing period and every code is
unique Code is also different for every billing period even for the same allocator
This can be useful if measured values are reported by tenant directly without entering billing company
employee Further check of consumption values can be done with decoding software EITN-10 For more
information refer to Installation and service manual for decoding software EITN-10
4.5.1.4. Serial number E-ITN 10.4x, 10.5x, 10.7x only)
Serial number is 8 digit figure and it is also labelled on the cover Serial number is divided in two parts E g
serial number „32000015” is displayed as figure -3200 and 0015- Symbol „ - “ distinguish between first and
second part of the serial number
4.5.1.5. Temperature of the radiator sensor E-ITN 10.4x, 10.5x, 10.7x only)
Temperature of the radiator sensor is displayed as 45 9°C with accuracy of one decimal place
4.5.1.6. Temperature of the surroundings sensor E-ITN 10.4x, 10.5x, 10.7x only)
Temperature of the surroundings sensor is displayed as 26 7°C SM with accuracy of one decimal place
One sensor allocator E-ITN 10 41 display --°C SM only
4.5.1.7. Date of the billing period beginning
Beginning of the billing period is displayed as u 1 2 (year versions) or as dF 15 (month versions) After the
date is reached, allocator transfers value for current billing period to value for last billing period and
alphanumeric code is generated at 00:00:00
Beginning of the year billing period can be set by manufacturer or with Programming unit for changing
allocator parameters of E-ITN 10.4, 10.5, 10.6, 10.7 connected to PC or notebook to any required date
4.5.1.8. Current date
Current date is displayed as 3 12 Calendar takes leap years into account
4.5.1.9. Current time E-ITN 10.4x, 10.5x, 10.7x only)
Current time is displayed in 24 cycle, e g 8-56 (8:56 AM) Summer time is not distinguished
4.5.1.10. Display test E-ITN 10.6 only)
During display test all segments are turned on The test is important when the measured values
are read visually
4.5.1.11. Average surroundings temperature for the last billing period E-ITN 10.6 only)
Average surroundings temperature is displayed as 24 4°C SM with accuracy of one decimal place
12 / 39

E-ITN 10
Installation and service manual M2015/04b [EN]
4.5.2. Month consumption values
Month consumption values (value at the end of the month) can be displayed for E-ITN 10 4 and 10 5 up to
23 month back from current date, for E-ITN 10 6 and 10 7 up to 11 month back from current date, for more
information see chapter 3 Technical specifications
4.5.2.1. Activation of the submenu with month values E-ITN 10.4x, 10.5x, 10.7x only)
Enter submenu from the main menu When the display is on and 1st menu item is displayed (value for the
current billing period, e g 389), press and hold the button, till notice --A--, is displayed After button release,
1st submenu item du is displayed (month values)
Table 8: Submenu structure in working mode, type E-ITN 10.4x, 10.5x, 10.7x
Month values du
Type of the radiator (e g 2), 10 5x, 10 7x only tot 2
Allocator self-test ti
To switch between the submenu items, press the button shortly If the button is not pressed in 20 seconds,
allocator switches back to the main menu and the 1st item is displayed
When submenu item „month value“ du is displayed, press and hold the button till –A-- appears After
release, current month number e g 10 07 (10 – month number, 07 – last two digit of the year) is be
displayed
Procedure how to run allocator test is described in chapter 4 3 1 2 Allocator self test
4.5.2.2. Activation of the submenu with month values E-ITN 10.6 only)
Enter submenu from the main menu When the display is on and menu item „value for the last billing period“
is displayed (e g 3258 SM) press and hold the button, till notice –A-- is displayed After release, current date
e g 10 07 (10 – month 07 – last two digits of the year) is displayed
4.5.2.3. Structure of submenu with month values
Except current moth, values correspond with measured values at the end of the month from the beginning of
the billing period
Table 9: Structure of submenu with month values
m0 – current moth, r0 - last two digits of the year „m0 r0“
x0 – value for current billing period „x0“
m1 – last month, r1 - last two digits of the year „m1 r1“
x1 – value at the end of the last month „x1“
… …
m11 - x month back, r11 - last two digits of the year „m11 r11“
x11 – value at the end of the xth month back „x11“
Total number of displayed items is 24 (E-ITN 10 4x, 10 5) or 12 (E-ITN 10 6, 10 7x)
To switch between submenu items, press the button shortly To end this submenu, do not press the button for
20 seconds, allocator will switch back to the main menu Also the long button press can be used to exit
Press and hold the button till --A-- appears Then 1st menu item „du“ (E-ITN 10 4x, 10 5x, 10 7x) or item
„display test“ (E-ITN 10 6) will appear
4.5.3. Menu structure in service mode ( -ITN 10.6 only)
Allocator can be switched into service mode by following procedure: when item „LCD test“ ( ) is
displayed, press and hold the button, till notice –A-- appears After release allocator will switch into the
service mode
13 / 39

E-ITN 10
Installation and service manual M2015/04b [EN]
Table 10: Menu structure in service mode, type E- ITN 10.6
Number of measuring cycles in single-sensor mode 7526 SM
Max temperature of radiator sensor in last billing period 61 9°C SM
Date when max temperature of radiator sensor in last billing period was
reached
3 12 SM
Min temperature of radiator sensor in last billing period 25 4°C SM
Date when min temperature of radiator sensor in last billing period was
reached
12 12 SM
Value for penultimate billing period 3258 SM
Values are not displayed in 6 s intervals like in user mode, it is necessary to press the button shortly to see
next value If button is not pressed for 20 s, allocator switch back to the user mode Switching to user mode
can be speed up by button long press (press and hold the button till --A-- appear on the display
4.5.3.1. Number of measuring cycles in single-sensor mode
Number of measuring cycles is single-sensor mode in last billing period is displayed as e g 7526 SM
(without meaningless zeros) Maximal displayable value is 99 999 If this value is exceeded, E SM is
displayed
4.5.3.2. Max. temperature of radiator sensor in last billing period
Maximal temperature of radiator sensor in last billing period is displayed as e g 61 9°C SM with accuracy to
one decimal place
4.5.3.3. Date when the max. temperature of radiator sensor in last billing period was reached
Date when the maximal temperature of radiator sensor was reached is displayed as e g 3 12 SM
4.5.3.4. Min. temperature of radiator sensor in last billing period
Minimal temperature of radiator sensor in last billing period is displayed as e g 25 4°C SM with accuracy to
one decimal place
4.5.3.5. Date when the min. temperature of radiator sensor was reached in last billing period
Date when the minimal temperature of radiator sensor was reached is displayed as e g 12 12 SM
4.5.3.6. Value in penultimate billing period
Value in penultimate billing period is displayed as e g 3258 SM Value will be overwritten at 00:00:00 when
the new billing period begins
4.5.4. Last year of battery life
Battery lifetime is programmed in the microprocessor memory and the last year of battery lifetime is indicated
on LCD by blinking of the special symbol: BAT After finishing this time the symbol stays displayed
permanently Calculated battery lifetime is 10 years + 1 year reserve
4 6 ERROR MODE
In error mode the notice Error is permanently displayed and allocator does neither measure temperatures,
count the increase of consumption nor transmit measured data Allocator just actualizes real time Allocator
switches from working mode to error mode automatically after registration of serious error (e g fault in A/D
converter, when the power supply of microprocessor was interrupted and loss of data in RAM memory
occurred, etc )
Allocator backups important data to permanent memory daily Data in this memory are saved even if the
power supply is interrupted Even in the case of battery failure these data are not lost Saved data could be
read by special tools
14 / 39

E-ITN 10
Installation and service manual M2015/04b [EN]
5 OTHER INFORMATIONS
5 1 ALLOCATOR PARAMETERS SETTING
Basic settings as per Setting protocol is done by manufacturer. Parameters can be changed later with
Programming unit for changing allocator parameters of E-ITN 10.4, 10.5, 10.6, 10.7 connected to PC
Settings or parameters adjustment can be performed only via built-in interface that is available only when
allocator is opened (disassembled from back plate)
5 2 TRANSPORTATION
E-ITN 10 allocators can be transported under following conditions:
•devices can be transported by all usual covered means of transport
•devices must be in original package
•originally packed devices must be stored and secured to avoid mechanical damages during
transportation
•devices can not be transported together with aggressive substances
•temperature during transportation from -10 °C to +55 °C
•relative humidity from 45 % to 75 %
5 3 STORAGE
E-ITN 10 is an electrical device and can be stored under these conditions:
•devices must be originally packed by manufacturer and individually stored in antistatic bags
•storage temperature from +10 °C to +30 °C
•relative humidity from 45 % to 75 %
•devices must be stored in clean covered areas without aggressive substances and stored properly to
avoid mechanical damage
5 4 APPLICATION AND DISPOSAL
"This device is subject to a waste management in accordance with local legislation "
5 5 DEFECTS AND THEIR ELIMINATION
Any E-ITN 10 defect should be repaired by manufacturer only
5 6 WARRANTY
If device E-ITN 10 is installed and handled according to manufacturer instructions mentioned in Installation
and service manual, manufacturer provide warranty under the valid legislation unless agreed differently
The warranty is void if device was used contrary to Installation and service manual or damaged:
•during transport or storage by customer or reseller
•when mounted or dismantled to the customer device
•because of improper handling or installation into other device than agreed in manual
•if the product was exposed to different environment than agreed in manual
•if mechanically or in other way damaged by user
15 / 39

E-ITN 10
Installation and service manual M2015/04b [EN]
6 ACCOMPANYING DOCUMENTATION
6 1 ORDERING
Order must include Setting protocol that is available on the website for business partners In every order
following items must be specified:
•quantity
•type
•attach Setting protocol – if column "required value" is empty, default values are set
•spare parts (extra pieces)
•delivery date
•method of transport
Order example: 100 pcs E-ITN E-ITN 10 71, required delivery 28 2 2012, EXW + filled Setting protocol
6 2 PACKING
Allocators are disassembled and packed in the boxes, packing sheet is included in every box (see Illustration
3: Packing sheet) with mark of the producer, device type, number of items and their serial numbers, packing
date and the name of the operative who checked and packed the products The lids of boxes are marked
with label "THIS SIDE UP!" The boxes are non-returnable Boxes are stored always cover up on the
standard shipping pallets
Electronic heat cost allocator E-ITN 10 is sensitive to static electricity For this reason, each allocator is
shipped in antistatic packaging Antistatic package should be removed just before installation
16 / 39

E-ITN 10
Installation and service manual M2015/04b [EN]
17 / 39
Illustration 3: Packing sheet

E-ITN 10
Installation and service manual M2015/04b [EN]
E-ITN 10
INSTALLATION
18 / 39

E-ITN 10
Installation and service manual M2015/04b [EN]
7 INSTALLATION METHODS
7 1 ALLOCATOR INSTALLATION
The back plate is mounted on the radiator using mounting material in compliance with EN 834:1995 and with
Installation and service manual Mounting material is provided by manufacturer and supplied with allocator,
see chapter 7 3 List of installation material
Installation can be done only by person professionally trained by the manufacturer
Warning!
Static electricity is harmless for humans but can seriously damage electronic devices When
handling or installing the product follow these rules:
• discharge accumulated static electricity by touching the hand with a grounded metal object (e g
radiator) before installation,
• keep the product in antistatic package until installation,
• do not touch the PCB before or during installation,
• avoid PCB contact with other items, especially metallic,
• never remove PCB from the housing,
• do not touch metal parts when handle the product (e g temperature sensor body)
Use only original parts or parts approved by the manufacturer for installation, pay attention to the
tightening of mounting material specified torque
7 2 ALLOCATOR BACK PLATE
The back plate is made of aluminium alloy and designed to have the best heat transfer from the radiator to
the allocator It is necessary to install back plate to the radiator with recommended mounting material to
ensure the optimal thermal contact
The standard back plate is produced with mounting holes, see Illustration 4: Standard back plate
If agreed with manufacturer, custom back plate version can be produced, e g to install the allocators to
formerly installed welding bolts on panel radiators
19 / 39
Illustration 4: Standard back plate

E-ITN 10
Installation and service manual M2015/04b [EN]
7 3 LIST OF INSTALLATION MATERIAL
Mounting material is used to install allocator to the radiator Manufacturer does not guarantee the accuracy of
coefficient Kc when used a different installation material
Type Mounting accessories content
0001 bolt M4x25 + serrated lock washer + clamp III
0002 bolt M4x50 + serrated lock washer + clamp IV + spacer 45
0003 bolt M4x35 + serrated lock washer + clamp III
0004 bolt M4x115 + serrated lock washer + clamp III
0005 bolt M4x25 + serrated lock washer + clamp
0006 bolt M4x80 + serrated lock washer + clamp III
0007 bolt M4x115 + serrated lock washer + clamp III
0008 bolt M4x80 DIN 7985A 4 8 shape Z Zn + serrated lock washer + clamp III
0009 2pc nut M3 spec + 2pc serrated lock washer + 1pc clamp FONAL (8 mm)
0011 2pc nut M3 spec + 2pc serrated lock washer + 1pc clamp FONAL (10 mm)
0012 2pc nut M3 spec + 2pc serrated lock washer + 1pc clamp FONAL (12 mm)
0051 2pc bolt M3x6 type G DIN 32 501 AlMg3 + 2pc serrated lock washer + 2pc nut M3 spec
0052 2pc bolt M3x6 type G DIN 32 501 ST 36-2 + 2pc serrated lock washer + 2pc nut M3 spec
0053 2pc bolt M3x10 type G DIN 32 501 ST 36-2 + 2pc serrated lock washer + 2pc nut M3 spec
0054 2pc bolt M3x12 type G DIN 32 501 ST 36-2 + 2pc serrated lock washer + 2pc nut M3 spec
0055 2pc bolt M3x10 type G DIN 32 501 ST 36-2 + 2pc serrated lock washer + 2pc nut M3 spec +
1ks clamp
0056 1pc bolt M3x6 type G DIN 32 501 ST 36-2 + 2pcs bolt M4x8 + 1pc nut M3 + 1 pc spacer –
register
0057 2 pc bolt M3x8 type G DIN 32 501 ST 36-2 + 2 pc serrated lock washer + 2pcs nut M3
20 / 39
