APEKX BE1033 User manual

TWIN WIRELESS EARBUDS
Please read this manual carefully before using the product
WITH CHARGING CASE
and keep it in a safe place.
USER MANUAL
MODEL: BE1033

1
PACKING LIST
User manud X1
X1
(Size M is preinstalled on earbuds)
X1
X1
X1
S
L
Quick Guide X1

2
DIAGRAM
Charging Pins
ar Caps
/R logo
LED light charging port
E
L
MFB
LED lndicator
Microphone
Type-C

3
CHARGING
• Remove the protective film from the earbuds when using
for the first time.
• Fully charge both the earbuds and the charging case before
the first-time using.
•
•
To prevent damage, use the provided cable.
Fully dry off the earbuds and the USB port before charging.
• Close fully the charging case cover to charge the earbuds.
Type-C

4
POWER ON
• In the shutdown status and when the earbuds are not in the
charging case. Simultaneously click and hold the MFB of both
earbuds for 3 seconds to power on and go into pairing mode
(with the blue LED light flashing).
x 3s
Mode 2
Mode 1
ON
ON


POWER OFF
•If the earbuds are not in the charging case. Pause music first,
click and hold the MFB of both earbuds for 4 second to turn
them off.
• Put the earbuds back to the charging case and close the
case to turn them off.
• Note: Earbuds will not turn off automatically if charging case is
out of battery.
x 4s
Mode2
Mode1
OFF
OFF
5

Note : The earbud will reconnect to the paired device
by priority. If you want to pair to the second smartphone.
Please disconnect wireless on the paired smartphone.
Mode
1
Mode2
1.Open the charging case, they will automatically enter the
pairing mode in which the LED light flashes blue, and then
select " ”.
If the earbuds are not in the charging case. Click and hold
the MFB button for 6 seconds, they will automatically enter
the pairing mode and then select " " on your phone.
6
PAIRING
Voice Prompt: pairing
x 6s
BE1033
Bluetooth
Bluetooth
12:00
Settings
MY DEVICES
Connected
12:
0
0
BE1033
Bluetooth
Bluetooth
12:00
Settings
MY DEVICES
Connected
12:
0
0
BE1033
BE1033

7
RESET
Delete the connection name in wireless list of your phone. Turn off both
earbuds and then triple-click the MFB button of both earbuds, the LED lights
flash light blue three times to indicate that the earbuds have been reset
successfully.
to turn
to turn
Volume UP / Down
Volume+: Click and hold the MFB button of Left earbud
up the volume increasingly.
Volume-: Click and hold the MFB button of Right earbud
down the volume.
Next / Previous Track
Next Track: Double click the MFB of Right earbud.
Previous Track: Double click the MFB of Left earbud.
Play / Pause
Click the MFB of either earbud once.
Answer /
Click the MFB of either earbud once.
Reject
Double click the MFB button of either earbud when there is an
incoming call
Activate Siri
Click and hold the MFB button for 2 seconds.
TOUCH CONTROL
Hang Up

8
Earbuds
SPECIFICATION
Charging case
Earpiece weight: 7.6g
Weight: 56.8g
Wireless version: V 5.0 dual mode
Working time: 6 hours (50% volume)
Battery: 50mAh
Working distance: 10M (barrier-free)
Charging time: 1.5hous
2 hou rsChaging times：
Battery:
5V 1AInput:
5V 100 mAOut put:
Li-battery 650 mAh (Extra 4 times full charge for earbuds)

FCCWarningStatement
Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecould
voidtheuser’sauthoritytooperatetheequipment.Thisequipmenthasbeentestedandfoundto
complywiththelimitsforaClassBdigitaldevice,pursuanttoPart15oftheFCCRules.These
limitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceinaresidential
installation.Thisequipmentgeneratesusesandcanradiateradiofrequencyenergyand,ifnot
installedandusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradio
communications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticular
installation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,
whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotryto
correcttheinterferencebyoneormoreofthefollowingmeasures:
‐‐ Reorientorrelocatethereceivingantenna.
‐‐ Increasetheseparationbetweentheequipmentandreceiver.
‐‐Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris
connected.
‐‐ Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowing
twoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and
(2) this device must accept any interference received, including interference that may
cause undesiredoperation.
The device has been evaluated to meet general RF exposure requirement.
