Assembly Instructions for
7ft QR Module.
QR-7
Fasteners.
Tools Needed:
(I) Hammer
(I) Power drill
(I) Level
*Suggested 18
guage Brad Gun
with 1-1/4 brad
nails will make
install easier.
Parts
List:
(8) 2-1/2” Phillps
screws for attaching
to wall.
(6) 1-1/4” Joining
Screws to attach to
other modules.
(36) 1-1/4” Shelf
screws.

QR-7
Assembly Instructions
for 7ft QR Module.
Front
Quarter
Round
Pieces
1 x 2
Vertical
Pieces
(1) Side
Panel
1-1/4”W
x 84-
13/16”
Angled
ends on
front.
Square
ends on
back
(1) Back
Panel
11-15/16”W
x 84-13/16”
10-7/8
(6) Quarter Round
Shelves

Step 1
Step 1: (Attaching Side panel to
back panel)
Join the back panel to the
side panel using the screws
provided so that the back panel
overlaps the side panel. Apex
has predrilled the holes on the
back of the rack panel for ease
of attaching the two panels
together. Tighten securely.
Side Panel
Back Panel
Step 2
Step 2: (Attaching the Shelves)
Place each quarter round shelf
on top of the IxI rails that are
fastened to the panels. Note: The
grain pattern should be going
in the same direction on all the
shelves. From the back side use
the prednailed holes and screw
the shelves into place with the
screws provided.
Side Panel
Quarter Round
Shelf
Back Panel
Step 3
Step 3-Optional: (Attaching the 1
x 2 x 84 13/16” Trim)
Since the QR-6 is not as deep as
the other Apex Modular Racks,
Apex has provided a 1 x 2 x 84
13/16” trim board as an optional
piece when mounting the QR-7
to another modular rack. The trim
board is used to ll in the gap
between the QR-7 and the wall.
1 x 2 x 84
13/16” Trim
Side Panel
Quarter Round
Shelf
Back Panel
Step 4
Step 4: (Finish)
If attaching to another module
screw through the panel into the
end ladder of the other module
just underneath the shelves. Use
a level to make sure the rack is
mounted square to the wall or
other rack.
QR-7

Fastener Placement Guide (8) screws for attaching the
panels to each other
(36) screws for attaching the
shelves to the panels.
-Screw through backside of
panels wherever there is a
pre-drilled hole.
A2
Closeup A2
A1
A1 Closeup
