APM ABR-1A+3G User manual

1 of 2
APM CO., LTD
ABR- 1a+3g
IEEE 802.11a
IEEE 802.3
IEEE 802.3u
Radio Frequency Type Direct Sequence Spread Spectrum ( DSSS )
5.15~5.35GHz
5.50~5.70GHz
5.725~5.850GHz
Operating Channel 9 non-iverlapping channels
Transmit output Power Up to 200mW (software provisionable)
Transmission Rate 108(Turbo mode)/54/48/36/24/18/12/9/6Mbps auto fallback
10/100 Base-TX; RJ-45
Radio Wave: Antenna N-Male
6Mbps:-88dBm;9Mbps:-87dBm;12Mbps:-86dBm;18Mbps:-84dBm;
24Mbps:-81dBm;36Mbps:-76dBm;48Mbps:-72dBm;
54Mbps:-68dBm;108Mbps:-64dBm
Antenna Type External high gain antenna
Security Systems 64-bit/128-bit/152-bit WEP encryption
Support DFS and TPC
SNMP network management interface
FTP
Windows "IpDiscover" program to help find IP
Web-based configuration via popular browser (MS IE, Netscape…)
Firmware upgrade and configuration backup via Web
Operating Environment Operating Temperature: -30 ~ +70°C
Power
() p p
supply
Regulatory Approval FCC Part 15 B (US); CE
Network Management
System OS Support
Warranty One year limited
Standards Compliance
Frequency Band
Physical Interfaces
Sensitivity (@PER10%)
5801a Specification
Software/Firmware
Windows 2000/XP
1F, No.49, Alley 24, Lane 75, Sec 3, Kang-Ning Rd, Nei-Hu Dist, Taipei 114, Taiwan, R.O.C.
www.apm.com.tw [email protected] Tel: [phone] Fax: [phone]

2 of 2
APM CO., LTD
ABR- 1a+3g
Standards Compliance IEEE802.11b/g; IEEE802.3af; IEEE802.3; IEEE802.3u
SDRAM 8 M Byte
Flash 2 M Byte
Radio Frequency Type Direct Sequence Spread Spectrum ( DSSS )
America/FCC ：2.412~2.462 GHz (11 channels)
Europe CE/ETSI ：2.412~2.472 GHz (13 channels)
Transmission Power IEEE802.11b/g: 30dBm
IEEE802.11b:1/2/5.5/11 Mbps
IEEE802.11b/g:6/9/12/18/24/36/48/54 Mbps
Super G: up to 108 Mbps
Auto MDI/MMDI-X Ethernet 10/100Base-TX: RJ-45
Radio Wave: Antenna N-Male
Sensitivity -88dBm @ 11Mbps,PER< 8%; -74dBm @ 54Mbps,PER< 10%
Antenna Type Reverse N-type Female
Security Systems 64-bit/128-bit/152-bit/ WEP encryption; Wi-Fi Protected
Access(WPA) and WPA2
Wireless Setting Operation Mode-AP/Wireless Client/Repeater/Bridge(WDS)PtP and
PtMP Mode
Site Survey
DHCP Client
Supressed SSID
Wireless access control by MAC address(deny or accept)
WPA Support(WPA personal and enterprise)
Web-based configuration via popular browser(MS IE, Netscape … )
Windows ”Locator” program to help find IP in DHCP client mode
Firmware upgrade and configuration backup via Web
Reset to default by WebUI
Operating Environment Operating Temperature: -30 ~ +70°C
Power DC 48Volt + 5%; 4A (Max.); AC adapter AC 100V ~ 240V
Regulatory Approval FCC Part 15 B (US); CE
Network Management
System OS Support
Warranty One year limited
Frequency Band
Transmission Rate
Access Point Interfaces
Software/Firmware
Windows 2000/XP
24005g*3 Specification
1F, No.49, Alley 24, Lane 75, Sec 3, Kang-Ning Rd, Nei-Hu Dist, Taipei 114, Taiwan, R.O.C.
www.apm.com.tw [email protected] Tel: [phone] Fax: [phone]
