Apollo Ultrasonic Visual User manual

DUN0708 Apollo Instructions 9-5396-02
QUICK GUIDE
First Stage
Step 1: Measure the tank height and from the height chart, set the relevant switches on the
receiver. Using a screwdriver or tip of ball point pen, flip the relevant switches upwards (=ON).
e.g. Tank height 850mm set switches 1, 4 & 8.
Step 2: Plug receiver into a suitable and convenient electrical socket and switch on. The display
screen on the front of the receiver will show a flashing top bar. This indicates that the receiver is
awaiting a unique code. The flashing top bar will last for 2 minutes during which time you can
match the transmitter to the receiver.
Step 3: Hold the Visual transmitter against/touching the receiver on the right hand side, so that
the black dots are aligned/touching each other, with the label side facing the receiver, as shown.
Hold together for about 20 seconds to allow the unique code to be transferred. The bars will
increase up the display screen. ONLY when all 10 bars are shown, will they flash to indicate that,
the unique code is transferred. For tanks of 1 metre in height, the matching is now complete.
Separate the Apollo Visual from the receiver and watch for double flash of red light on the Visual
transmitter. You may now fit to tank.
FOR TANKS OF 800mm AND MORE THAN 1 METRE IN HEIGHT – Continue Matching To Second Stage.
Second Stage – Tank Height Look Up Table For Apollo Visual – Bar Display
Visual
Transmitter
Reading
Set Measurement Visual
Transmitter
Reading
Set Measurement
If you hold Visual Transmitter until you see this, you
will have set it to measure tank height 800mm
NO BARS
If you hold Visual Transmitter until you see this, you
will have set it to measure tank height 1700mm
6 BARS
If you hold Visual Transmitter until you see this, you
will have set it to measure tank height 1000mm
1 BAR
If you hold Visual Transmitter until you see this, you
will have set it to measure tank height 2000mm
7 BARS
If you hold Visual Transmitter until you see this, you
will have set it to measure tank height 1100mm
2 BARS
If you hold Visual Transmitter until you see this, you
will have set it to measure tank height 2300mm
8 BARS
If you hold Visual Transmitter until you see this, you
will have set it to measure tank height 1200mm
3 BARS
If you hold Visual Transmitter until you see this, you
will have set it to measure tank height 2600mm
9 BARS
If you hold Visual Transmitter until you see this, you
will have set it to measure tank height 1300mm
4 BARS
If you hold Visual Transmitter until you see this, you
will have set it to measure tank height 2800mm to
3000mm
10 BARS
If you hold Visual Transmitter until you see this, you
will have set it to measure tank height 1400mm
5 BARS
Don’t forget that if you make a mistake, you can
simply continue to hold Visual transmitter in
matching position until the bars reset themselves
and start again.
YOU MAY NOW FIT THE TRANSMITTER TO YOUR TANK. Ensure the Visual transmitter is vertical on top of the
tank. Tighten on to the tank using the 2 screws supplied. Do not over tighten.
