Apollo NEXX GATE KIT User manual

USB POWER
USB Type C connector
May be used to power
module if WIFI connection
is being setup prior to
connecting to control
board.
OPENER CONNECTING CABLES
To verify that your gate operator is compatible with
the Nexx Gate APP receiver:
Identify your control board.
•App ready control boards will have the
DB9 Connector shown here. (Plug and Go)
NEXX GATE KIT
CONTENTS AND
INFORMATION
COMPATIBILITY CHECK
WARNING
PRODUCT LIMITED WARRANTY
FCC WARNING: This equipment may generate or use radio frequency
energy. Changes or modifications to this equipment may cause harmful
interference unless the modifications are expressly approved in the
instruction manual. The user could lose the authority to operate this
equipment if an unauthorized change or modification is made. This device
complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Consult the dealer for help.
• The rating information is located at the bottom of the unit.
Warrants to the first retail purchaser of this product that it is free from
defects in materials and/or workmanship for a period of one (1) year
following the original purchase date of the product, this limited warranty
does not cover 1) normal wear and tear 2) failures due to a) improper
installation, operation, care, and maintenance b) misuse/unin-tended use
c) abuse, negligence d) accidental damage e) unauthorized repairs or
alternation f) use of improper voltage g) electrical outage short circuit 3)
acts of nature.
For products returned for warranty which are confirmed to be defective
and are covered by this limited warranty, we will replace or repair the
product at no extra cost to you. Products may be repaired or replaced by
refurbished parts or units or by different models of similar functionality at
our sole discretion. We will not cover any product installation costs or any
labor associated with other manufactures’ products or any repair or
replacement or damage costs related to other products and services.
Any warranty claim must be accompanied by the first retail proof of
purchase receipt showing the original first date of purchase, which is used
to determine the warranty period.
We do not warrant that the operation of the product will be error-free or
uninterrupted. Except to the extent set forth in this limited warranty, the
product is provided on an “as is” basis, and all implied warranties,
including bit not limited to any implied warranties of merchantability and
fitness for a particular purpose, are limited in duration to the applicable
limited warranty period set forth, and no implied warranties will exist or
apply after such period. No person or entity is authorized to assume for us
any other liability in connection with the sale of this product.
EXTERNAL ANTENNA
EXTERNAL ANTENNA
EXTENSION CABLE
If the gate operator battery is AC charged then you are
good to go.
If Solar charged it is recommended that the charging system
be upgraded to a 20 watt Solar panel to accommodate the
APP receiver.
RESET
In case you need to reset
the device, use a paper clip
or similar wire to press and
hold the factory reset
button until steady Activity
Orange Light is visible.
QUESTIONS:
Send email with your gate operator
control board serial number to
[email protected]
Continue the
installation.
APP RECEIVER MODULE
DB9 to flying leads cable
DB9 to DB9 cable
If installing in a metal control box extension
cable must be used.
Control box will have hole located in the
upper right corner of the control box on the
right side wall.
Older models might not have antenna hole.
Care should be taken to prevent metal
shavings from falling onto Control board
when drilling.
*Important Safety Considertions:
Nex Gate will allow gate to be opened or closed remotely. Only use this
device on gate operators that have entrapment prevention safety devices
installed, car detection safety devices installed and are properly
maintained and tested for obstruction and force testing.
POWER
WIFI
ACTIVITY
Powered by
www.ApolloGateOpeners.com | [phone] | [e-mail]

Compatibility check passed
2.4 GHz WiFi Internet Connection
WIFI signal at gate operator
location is strong
Mobile Device with enabled
Bluetooth
Gate Operator
Screwdriver
1. BEFORE YOU START CHECK LIST
5. CHECK STATUS OF NEXX GATE
6. ADD NEXX GATE TO NEXX HOME
7. MOUNT IN CABINET
2. INSTALL MOBILE APP
3. CREATE ACCOUNT
4. ASSEMBLE AND CONNECT TO POWER
B. NO Activity Orange Light
Press and hold the factory
reset button using a paper
clip or similar until steady
Activity Orange Light is
visible.
Download and install from
Apple App Store or Google
Play Store:
Nexx Home
Open Nexx Home app and
create an account with Nexx.
If you need help just send an email to
[email protected]
Log in to Nexx Gate app and tap to
add device.
Follow the configuration process.
A. Steady Activity Orange
Light is ON:
Continue to next step
APP ready control board - all models: Use the DB9
to DB9 cable
Nice Apollo control board
without DB9 connector:
Use the DB9 to flying lead
cable (5 wires) See chart
below for wiring instructions.
o
o
o
o
o
o
POWER
WIFI
ACTIVITY
Powered by
POWER
WIFI
ACTIVITY
Powered by
POWER
WIFI
ACTIVITY
Powered by
1
2
7
3
9
Control Board J2 pin 1
Control Board J2 pin 2 or J2 pin 7
Control Board J2 pin 2 or J2 pin 7
Apollo Actuator cable Close Limit
White Wire - Pull to Open Orange
Wire - Push to Open
Control Board J2 pin 3
Red
Black
Yellow
White
Green
DB9
Pin #
DB9
Wire
Gate Opener
Connections
Interface Cable Connections for Nice Apollo Control Board
Apollo control board cabinets are equipped
with mounting studs on the inside box wall on
the right side which can be used to securely
attach the Receiver module inside the control
box. Older models might not have these
mounting studs.
For plastic enclosures, the Receiver may be
attached to the shelf.
