Applent Instruments AT5108 User manual

Manual Print History
The print history shown below lists the printing dates of all Revisions and Addenda
created for this manual. The Revision Level letter increases alphabetically as the manual
undergoes subsequent updates. Addenda, which are released between Revisions, contain
important change information that the user should incorporate immediately into the
manual. Addenda are numbered sequentially. When a new Revision is created, all
Addenda associated with the previous Revision of the manual are incorporated into the
new Revision of the manual. Each new Revision includes a revised copy of this print
history page.
Revision A January, 2013
Applent Instruments Ltd.
Address: 3 Floor, No. 61, Baolong International,
Zhonglou District, Changzhou, Jiangsu, China
Post Code: 213001
Telephone: [phone]
Fax：[phone]
http://www.applent.com
©2005-2016 Applent Instruments Inc.
English
Revision A2
FIRMWARE REVISIONS
This manual applies directly to instruments that
have the firmware Rev.C1.x
[AT5108/AT5110/AT5120 Multi-Channel Resistance Meter]
User’s Guide

2
AT5108/AT5110/AT5120 User's Guide
CERTIFICATION, LIMITED WARRANTY, & LIMITATION OF
LIABILITY
Applent Instruments, Inc. （shortened form Applent）certifies that this product met its published specifications
at the time of shipment from the factory. Applent further certifies that its calibration measurements are traceable to
the People’s Republic of China National Institute of Standards and Technology, to the extent allowed by the
Institution’s calibration facility or by the calibration facilities of other International Standards Organization
members.
This Applent instrument product is warranted against defects in material and workmanship for a period
corresponding to the individual warranty periods of its component products. The warranty period is 1 year and
begins on the date of shipment. During the warranty period, Applent will, at its option, either repair or replace
products that prove to be defective. This warranty extends only to the original buyer or end-user customer of a
Applent authorized reseller, and does not apply to fuses, disposable batteries or to any product which, in Applent’s
opinion, has been misused, altered, neglected or damaged by accident or abnormal conditions of operation or
handling.
For warranty service or repair, this product must be returned to a service facility designated by Applent. The buyer
shall prepay shipping charges to Applent and Applent shall pay shipping charges to return the product to the Buyer.
However, the Buyer shall pay all shipping charges, duties, and taxes for products returned to Applent from another
country.
Applent warrants that its software and firmware designated by Applent for use with an instrument will execute its
programming instruction when properly installed on that instrument. Applent does not warrant that the operation
of the instrument, or software, or firmware, will be uninterrupted or error free.
The foregoing warranty shall not apply to defects resulting from improper or inadequate maintenance by the
Buyer, Buyer-supplied software or interfacing, unauthorized modification or misuse, operation outside the
environmental specifications for the product, or improper site preparation or maintenance.
THIS WARRANTY IS BUYER’S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. APPLENT SHALL
NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR
LOSSES, INCLUDING LOSS OF DATA, WHETHER ARISING FROM BREACH OF WARRANTY OR
BASED ON CONTRACT, TORT, RELIANCE OR ANY OTHER THEORY.
Applent Instruments.Ltd
Changzhou,
Jiangsu,
China,
Rev.A2 January, 2005
Rev.B0 January, 2008

3
Contents
Contents
CERTIFICATION, LIMITED WARRANTY, & LIMITATION OF LIABILITY ..................................................2
Contents............................................................................................................................................................3
Figure Contents .................................................................................................................................................6
Table Contents...................................................................................................................................................7
1. Unpacking and Preparation.........................................................................................................................8
1.1 Incoming Inspection....................................................................................................................8
1.2 Setting up Fuse ...........................................................................................................................8
1.3 Environmental Requirements.......................................................................................................8
1.4 Cleaning.....................................................................................................................................9
1.5 How to Remove the Handle.........................................................................................................9
2. Overview................................................................................................................................................. 11
2.1 Introduction .............................................................................................................................. 11
2.2 Main Specifications and Features............................................................................................... 11
2.2.1 Ranging............................................................................................................................. 11
2.2.2 Measurement Speed........................................................................................................... 11
2.2.3 Trigger Mode .................................................................................................................... 11
2.2.4 Basic Accuracy.................................................................................................................. 11
2.2.5 Correction .........................................................................................................................12
2.3 Main Functions .........................................................................................................................12
2.3.1 Correction Function...........................................................................................................12
2.3.2 Comparator Function (Sorting)...........................................................................................12
2.4 Measurement Assistance Functions............................................................................................12
2.4.1 Key Lock ..........................................................................................................................12
2.4.2 Interface............................................................................................................................12
3. Startup.....................................................................................................................................................13
3.1 Front panel................................................................................................................................13
3.2 Rear Panel ................................................................................................................................13
3.3 Power On/Off ...........................................................................................................................14
3.3.1 Line Power Connection......................................................................................................14
3.4 Warm-up Time..........................................................................................................................14
3.5 Connect to Device under Test (DUT) .........................................................................................14
4. [Meas] Key..............................................................................................................................................16
4.1 <MEAS DISPLAY> Page .........................................................................................................16
4.1.1 Trigger Mode [TRIG] ........................................................................................................16
4.1.2 Channel Setup ...................................................................................................................17
5. [Setup] Key .............................................................................................................................................18
5.1 <SETUP> Page.........................................................................................................................18
5.1.1 Trigger Mode [TRIG] ........................................................................................................18
5.1.2 Range [RANGE] ...............................................................................................................19
5.1.3 Measurement Speed [RATE]..............................................................................................20
5.1.4 Turn the Comparator ON/OFF [COMP] .............................................................................20
5.1.5 [SCAN] mode....................................................................................................................21
5.1.6 Turn Temperature Compensation ON/OFF .........................................................................21
5.1.7 Temperature [COEFFICIENT] α ........................................................................................21
5.1.8 Reference Temperature [REFER TEMP] ............................................................................22
5.2 Short Correction........................................................................................................................22
5.3 <Comparator> Page ..................................................................................................................23
5.3.1 Turn the Comparator ON/OFF [COMP] .............................................................................23
5.3.2 Comparator limit mode [MODE]........................................................................................23
5.3.3 Nominal value for tolerance mode......................................................................................24
5.3.4 【Beep】..........................................................................................................................24
5.3.5 Lower and upper Limits.....................................................................................................25
6. System Configurations .............................................................................................................................26

4
AT5108/AT5110/AT5120 User's Guide
6.1 <SYSTEM CONFIG> Page.......................................................................................................26
6.1.1 To change system【LANGUAGE】..................................................................................26
6.1.2 Setting the system date and time.........................................................................................27
6.1.3 Account Setting.................................................................................................................27
6.1.4 Beep Feature .....................................................................................................................28
6.1.5 RS-232 Baud Rate [BAUD]...............................................................................................28
6.1.6 RS-232 Shake Hand [SHAKE HAND]...............................................................................29
6.1.7 RS-232 Result Send Mode [RESULT SEND] .....................................................................29
6.1.8 Data format and EOC mode [DATA/EOC]..........................................................................30
6.2 <SYSTEM INFO> Page............................................................................................................30
7. Handler Interface .....................................................................................................................................31
7.1 Pin Assignment.........................................................................................................................31
7.2 Connection ...............................................................................................................................33
8. Remote Control........................................................................................................................................35
8.1 About RS-232C ........................................................................................................................35
8.1.1 RS232C Connection ..........................................................................................................36
8.2 Handshake Protocol ..................................................................................................................36
8.3 SCPI Language.........................................................................................................................37
9. SCPI Command Reference.......................................................................................................................38
9.1 Terminator ................................................................................................................................38
9.1.1 Terminator Rules ...............................................................................................................38
9.1.2 Notation Conventions and Definitions ................................................................................38
9.1.3 Command Structure ...........................................................................................................39
9.2 Header and Parameters..............................................................................................................39
9.2.1 Header ..............................................................................................................................39
9.2.2 Parameter..........................................................................................................................40
9.2.3 Separator...........................................................................................................................40
9.3 Command Reference.................................................................................................................41
9.4 DISPlay Subsystem...................................................................................................................41
9.4.1 DISP:PAGE.......................................................................................................................41
9.4.2 DISP:LINE........................................................................................................................42
9.5 FUNCtion Subsystem................................................................................................................42
9.5.1 FUNCtion:RANGe ............................................................................................................42
9.5.2 FUNCtion:RANGe:MODE................................................................................................42
9.5.3 FUNCtion:RATE...............................................................................................................43
9.5.4 FUNCtion:TC....................................................................................................................43
9.5.5 FUNCtion:TC: COEFficient ..............................................................................................43
9.5.6 FUNCtion:TC: REFErence ................................................................................................43
9.5.7 FUNCtion:SCAN ..............................................................................................................43
9.6 COMParator Subsystem ............................................................................................................44
9.6.1 COMParator:STATe...........................................................................................................44
9.6.2 COMParator:MODE..........................................................................................................44
9.6.3 COMParator:BEEP............................................................................................................44
9.6.4 COMParator:NOMinal ......................................................................................................44
9.6.5 COMParator:CH................................................................................................................45
9.7 TRIGger Subsystem..................................................................................................................45
9.7.1 TRIGger[:IMMediate] .......................................................................................................45
9.7.2 TRIGger:SOURce .............................................................................................................45
9.7.3 TRG..................................................................................................................................46
9.8 FETCh Subsystem ....................................................................................................................46
9.8.1 FETCh?.............................................................................................................................46
9.9 SYSTem subsystem...................................................................................................................47
9.9.1 SYSTem:LANGuage .........................................................................................................47
9.9.2 SYSTem:SENDmode.........................................................................................................47
9.9.3 SYSTem:DATAmode.........................................................................................................47
9.10 CORRection Subsystem ............................................................................................................47
9.10.1 CORRection:SHORt..........................................................................................................47
9.11 IND? Subsystem .......................................................................................................................48
10. Specification.....................................................................................................................................49

5
Contents
10.1 General Specification ................................................................................................................49
10.2 Dimensions...............................................................................................................................50

6
AT5108/AT5110/AT5120 User's Guide
Figure Contents
Figure 1-1 How to remove the handle..................................................................................................10
Figure 3-1 Front panel........................................................................................................................13
Figure 3-2 Rear Panel.........................................................................................................................13
Figure 3-3 Test Terminal of Each Channel...........................................................................................14
Figure 4-1 AT5110 <MEAS DISPLAY> Page .....................................................................................16
Figure 5-1 < SETUP> Page ................................................................................................................18
Figure 5-2 Residual Resistance ...........................................................................................................22
Figure 5-3 <COMPARATOR> Page....................................................................................................23
Figure 6-1 <SYSTEM CONFIG> Page ...............................................................................................26
Figure 6-2 <SYSTEM INFO> Page ....................................................................................................30
Figure 7-1 Pin Assignment..................................................................................................................31
Figure 9-2 DISP Command Tree.........................................................................................................41
Figure 9-3 FUNCtion Subsystem Tree................................................................................................. 42
Figure 9-4 COMParator Subsystem Command Tree.............................................................................44
Figure 9-5 TRIGger Subsystem Command Tree ..................................................................................45
Figure 9-6 FETCh Subsystem Command Tree.....................................................................................46
Figure 9-7 SYSTem............................................................................................................................47
Figure 9-8 CORRection Subsystem Command Tree.............................................................................47
Figure 10-1 Dimensions .......................................................................................................................50

7
Contents
Table Contents
Table 3-1 Front panel description.......................................................................................................13
Table 3-2 Rear panel description........................................................................................................14
Table 5-1 Range Mode ....................................................................................................................19
Table 5-2 Effective measurement range ............................................................................................. 19
Table 7-1 Description of Handler Interface Signals ............................................................................31

8
AT5108/AT5110/AT5120 User's Guide
1. Unpacking and Preparation
This chapter describes how to set up and start the AT5108/AT5110/AT5120
Multi-Channel Resistance Meter.
•Incoming Inspection
•Power Requirements
•Setting up the Fuse
•How to Remove the Handle
•Environmental Requirements
•Cleaning
1.1 Incoming Inspection
After you receive the instrument, carry out checks during unpacking according to the
following procedure.
WARNING
If the external face of the instrument (such as the cover, front/rear panel, LCD screen,
power switch, and port connectors) appears to have been damaged during transport, do
not turn on the power switch. Otherwise, you may get an electrical shock.
Make sure that the packing box or shock-absorbing material used to package the
instrument has not been damaged.
Referring to <Packing List> in the packing box, check that all packaged items supplied
with the meter have been provided as per the specified optioned.
NOTE
If an abnormality is detected, contact the company and transport the meter to your
nearest Applent Instruments sales or service office. For inspection by the transport
company, save the packing box, shock-absorbing material, and packaged items as you
received them.
1.2 Setting up Fuse
~Line: 110VAC/220VAC, 50Hz/60Hz
Fuse: 250V 1A Slow Blow
Please use the following fuse type.
UL/CSA type, Slow-Blow, 5×20-mm miniature fuse, 1A, 250 V
When you need a fuse, contact your nearest Applent Instruments sales or service office.
To verify and replace the fuse, remove the power cable and pull out the fuse holder.
1.3 Environmental Requirements
Set up the AT5108/AT5110/AT5120 where the following environmental requirements
are satisfied.
Operating Environments
Ensure that the operating environment meets the following requirements.
Temperature: 0C to 55C

9
Unpacking and Preparation
Temperature range at calibration: 23C±5C (<1C deviation from the temperature
when performing calibration)
Humidity: 15% to 85% at wet bulb temperature ≤40 °C (non-condensation)
Altitude: 0 to 2,000m
Vibration: Max. 0.5 G, 5 Hz to 500 Hz
1.4 Cleaning
To prevent electrical shock, disconnect the AT5108/AT5110/AT5120 power cable from
the receptacle before cleaning.
Use a dry cloth or a cloth slightly dipped in water to clean the casing.
Do not attempt to clean the AT5108/AT5110/AT5120 internally.
WARNING: Don’t Use Organic Solvents (such as alcohol or gasoline) to clean the
Instrument.
1.5 How to Remove the Handle
A handle kit is attached to the AT5108/AT5110/AT5120:

10
AT5108/AT5110/AT5120 User's Guide
Figure 1-1 How to remove the handle
1 Retracted

3 Carrying Position

2 Extended
Remove Handle（Lift the handle perpendicular to the unit while pulling it in the direction of 1.）

11
Overview
2. Overview
This chapter contains general information about AT5110 .The information is organized
as follows
⚫Introduction
⚫Main Specifications
⚫Feature overview
2.1 Introduction
Thank you for purchasing AT5108/AT5110/AT5120 Multi-Channel Resistance Meter.
AT5108/AT5110/AT5120 is a high-precision wide-range, high-performance ARM
microprocessor-controlled multi-channel resistance meter. Its measurement range of
1Ω～300kΩ, the maximum display number 30000.
Computer remote control commands compatible with SCPI (Standard Command for
Programmable Instrument Programmable Instruments standard command set), complete
and efficient remote control and data acquisition functions.
With its built-in comparator, the AT5108/AT5110/AT5120 can output
comparison/decision results for sorting components into a maximum of ten channels.
Furthermore, by using the handler interface, the AT5108/AT5110/AT5120 can be easily
combined with a component handler, and a system controller to fully automate
component testing, sorting, and quality-control data processing.
AT5108/AT5110/AT5120 measures of high, medium and low-value resistor; various
switch contact resistance; connector contact resistance; relay line package and the
contact resistance; transformers, inductors, motors, deflection coil winding resistance;
wire resistance; cars, boats, aircraft riveting metal resistance; printed version of the line
and pore of resistance and so on.
2.2 Main Specifications and Features
2.2.1 Ranging
Auto, Hold and Nominal range. Total 8 Ranges.
About Nominal ranges: (Applent new definition): The AT5108/AT5110/AT5120 will
automatically select the best range according to the nominal value.
2.2.2 Measurement Speed
Slow: 3.4s/10-Channel
Medium: 830ms/10-Channel
Fast: 350ms/10-Channel
Ultra: 230ms/10-Channel
2.2.3 Trigger Mode
Include Internal, Manual, External and Bus Trigger.
2.2.4 Basic Accuracy
Slow Speed: 0.05%
Medium、Fast and Ultra：0.2%

12
AT5108/AT5110/AT5120 User's Guide
2.2.5 Correction
Zero correction for all ranges to eliminate lead resistance’s effect.
2.3 Main Functions
2.3.1 Correction Function
SHORT correction:
Eliminates measurement errors brought about by stray parasitic impedance in the test
fixtures.
2.3.2 Comparator Function (Sorting)
The primary parameter can be sorted into ten NG Bin: CH1-CH20
The sequential mode or tolerance mode can be selected as the sorting mode.
Limit Setup
Absolute value, deviation value, and % deviation value can be used for setup.
2.4 Measurement Assistance Functions
2.4.1 Key Lock
The front panel keys can be locked.
2.4.2 Interface
RS-232 remote control
Support MAX 115200bps baud rate, Compatible with SCPI, ASCII transmission.
Handler Interface
Full opto-isolator、built-in pull-up resistor input and output port.
Support internal 5V and 24V external power supply.
Input：trigger signal
Output：output all sorting comparator result signal; measuring synchronizing signal
（EOC）.

13
Startup
3. Startup
This chapter describes names and functions of the front panel, rear panel, and screen
display and provides the basic procedures for operating AT5108/AT5110/AT5120.
⚫Front panel summary
⚫Rear panel summary
⚫Power On/Off
⚫Connect to Device under Test
3.1 Front panel
Figure 3-1 Front panel
2
3
1
456
8
9
7
10
Table 3-1 Front panel description
No.
Description
1
USB Disk Port (USB-Host)
2
Trigger Key
3
Power Switch
4
System Key (Include File, System and Key Lock)
5
Soft Key
6
Menu key
7
UNKNOWN Terminal
8
Entry Key
9
Cursor Key
10
LCD Display
3.2 Rear Panel
Figure 3-2 Rear Panel

14
AT5108/AT5110/AT5120 User's Guide
Table 3-2 Rear panel description
No.
Description
1
Test Terminal
2
RS-232C Interface
3
Handler Interface
4
Temperature Compensation Interface
5
AC Power Cord Receptacle
3.3 Power On/Off
3.3.1 Line Power Connection
Power ON. Power OFF.
3.4 Warm-up Time
AT5108/AT5110/AT5120 is ready to be used as soon as the power-up sequence has
completed. However, to achieve the accuracy rating, warm up the instrument for 15
minutes.
3.5 Connect to Device under Test (DUT)
The test terminals of all channels are on the rear panel.
Please insert test plug into the terminal along the rabbet direction.
Figure 3-3 Test Terminal of Each Channel

15
Startup
Warning:
No putting current source, voltage source directly access to test side. Energy storage device
access to testing after discharging.

16
AT5108/AT5110/AT5120 User's Guide
4. [Meas] Key
4.1 <MEAS DISPLAY> Page
When press the [Meas] key, the <MEAS DISPLAY> page appears.
The following measurement controls can be set.
•TRIG –Trigger Mode
•01-20 –Set up the corresponding channel
Figure 4-1 AT5110 <MEAS DISPLAY> Page
Figure 4-2 AT5120 <MEAS DISPLAY> Page
4.1.1 Trigger Mode [TRIG]
SCPI Command: TRIGger:SOURce {INT,MAN,EXT,BUS}
AT5110 supports four trigger modes: INT (internal), EXT (external), MAN (manual)
and BUS (RS-232).
Trigger Mode
Description
INT
Continuously repeats the measurement cycle.
MAN
Performs one cycle of measurement each time you press the [Trig] key.
EXT
Performs one cycle of measurement each time a rising pulse is input to
the handler external trigger input pin on the rear panel.

17
[Meas] Key
Please refer to the Handler section.
BUS
Performs one cycle of measurement each time it receives a trigger
command sent via RS-232.
Procedure for choosing trigger mode [TRIG]
Step 1.
Press the [Meas] key
Step 2.
Use the cursor key to select [TRIG] field
Step 3.
Use the soft keys to select desired trigger mode.
Soft key
Function
INT
Internal Trigger Mode
MAN
Manual Trigger Mode
EXT
External Trigger Mode
BUS
BUS Trigger Mode
4.1.2 Channel Setup
SCPI Command: FUNCtion:SCAN {ON,OFF,<channel no>}
Each channel can be turned ON/OFF or fixed to single channel measurement.
Procedure for setting the channel
Step 1.
Press the [Meas] key
Step 2.
Use the cursor key to select [01]~[10] field
Step 3.
Use the soft keys to select desired working mode of corresponding channel.
Soft key
Function
OFF
This channel will be turned off.
ON
Turn on this channel
SCAN
Change to scan mode
SINGLE
Only measure this channel.

18
AT5108/AT5110/AT5120 User's Guide
5. [Setup] Key
This section includes the following information:
•SETUP page
•Temperature Compensation Setup
•SHORT Correction
•Comparator Setup
Every time or everywhere you can press the [Setup] key to open the <SETUP> page.
5.1 <SETUP> Page
NOTE
In <SETUP> page, the Instrument does not display test result and sorting result, and
testing is continuing.
Figure 5-1 < SETUP> Page
In the <SETUP> Page, you can configure each of the following measurement controls
with the cursor placed in the corresponding field.
•Trigger Mode [TRIG] *1
•Comparator ON/OFF [COMP]
•[RANGE]
•Measurement Speed [SPEED]
•[SCAN] mode
•Temperature Compensation ON/OFF [TEMP]
•Temperature Coefficient [COEFFICIENT]
•Reference Temperature [REFER TEMP]
NOTE: *1. These two settings can be set in <MEAS DISPLAY> page.
Please refer Sector 4.1 <MEAS DISPLAY> Page to set.
5.1.1 Trigger Mode [TRIG]
SCPI Command: TRIGger:SOURce {INT,MAN,EXT,BUS}
AT5110 supports four trigger modes: INT (internal), EXT (external), MAN (manual)

19
[Setup] Key
and BUS (RS-232).
Trigger Mode
Description
INT
Continuously repeats the measurement cycle.
MAN
Performs one cycle of measurement each time you press the [Trig] key.
EXT
Performs one cycle of measurement each time a rising pulse is input to
the handler external trigger input pin on the rear panel.
Please refer to the Handler section.
BUS
Performs one cycle of measurement each time it receives a trigger
command sent via RS-232.
Procedure for choosing trigger mode [TRIG]
Step 1.
Press the [Meas] key
Step 2.
Use the cursor key to select [TRIG] field
Step 3.
Use the soft keys to select desired trigger mode.
Soft key
Function
INT
Internal Trigger Mode
MAN
Manual Trigger Mode
EXT
External Trigger Mode
BUS
BUS Trigger Mode
5.1.2 Range [RANGE]
SCPI Command: FUNCtion:RANGe {<range number>,min,max}
SCPI Command: FUNCtion:RANGe:MODE {AUTO,HOLD,NOMinal}
Table 5-1 Range Mode
Mode
Function overview
Advantage
Disadvantage
Auto
range
Sets the optimum range
automatically.
You don’t need to
select range.
The measurement
time is longer due
to the ranging time
Hold
range
Measurement is performed
with a fixed range
No ranging time is
required
You need to select
a proper range
depending on the
value of the DUT.
Nominal
Range
Sets the optimum range
depending on the nominal
value.
You don’t need to
select range. No
ranging time is
required
Table 5-2 Effective measurement range
Range No.
Range
Measurement range
Up
Down
0
10mΩ
0.0000mΩ~30.000mΩ

30mΩ

300m

3


29mΩ

290m

2.9

1
100m
29.000mΩ~300.00mΩ
2
1
290.00mΩ~3.0000Ω
3
10
2.9000Ω~30.000Ω

20
AT5108/AT5110/AT5120 User's Guide
4
100
29.000Ω~300.00Ω
30

300

3k

30kΩ

300kΩ
29

290

2.9k

29kΩ

290kΩ
5
1k
290.00Ω~3.0000kΩ
6
10k
2.9000kΩ~30.000kΩ
7
100kΩ
29.000kΩ~300.00kΩ
Procedure for setting the range [RANGE]
Step 1.
Press the [Setup] key
Step 2.
Use the cursor key to select [RANGE] field
Step 3.
Use the soft keys to select the range mode or range.
Soft key
Function
AUTO RANGE
HOLD RANGE
NORMINAL RANGE
INCR +
Increments the range in the HOLD mode
DECR -
Decrements the range in the HOLD mode
5.1.3 Measurement Speed [RATE]
SCPI Command: FUNCtion:RATE {SLOW,MED,FAST,ULTRA}
SLOW, MED, FAST, ULTRA can be selected for AT5110.
SLOW mode will result in more stable and accurate measurement result.
When in Range-Hold mode:
Slow: 3.4s/10-Channel
Medium: 830ms/10-Channel
Fast: 350ms/10-Channel
Ultra: 230ms/10-Channel
Procedure for setting measurement speed mode
Step 1.
Press the [Setup] key
Step 2.
Use the cursor key to select [RATE] field
Step 3.
Use the soft keys to set measurement speed
Soft key
Function
SLOW
3.4s/10-Channel
MED
830ms/10-Channel
FAST
350ms/10-Channel
ULTRA
230ms/10-Channel
5.1.4 Turn the Comparator ON/OFF [COMP]
The comparator feature can be turned OFF. After the comparator feature is turned OFF,
the comparator result won’t be displayed on <MEAS DISPLAY> screen and all handler
functions will be turned off.
Procedure for turning ON/OFF the comparator [COMP]
Step 1.
Press the [Setup] key
Step 2.
Use the cursor key to select [COMP] field
