APURO FS498-A User manual

Model:
FS498-A / FS499-A
Fryer
Instruction manual
FS498-A_FS499-A_A5_v2_20230619.indb 1FS498-A_FS499-A_A5_v2_20230619.indb 1 2023/6/19 10:412023/6/19 10:41

2
EN Telephone Helpline: 1300225960
Safety Instructions
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- Fire Precautions
- Wiring Regulations
- Building Regulations
• ALWAYS ensure oil levels are within the ‘MIN’ and ‘MAX’
levels. Failure to do so could result in fire.
• ALWAYS use a suitable cooking oil.
• ALWAYS remove excess moisture/water from food before
frying to avoid excess foaming and spitting of the oil.
• Change oil regularly. The flashpoint of oil (the point at which it
ignites) gradually reduces the more it is used.
• DO NOT cover the oil pan when frying.
• DO NOT immerse the appliance in water.
• Some surfaces become hot during operation - take
care when using the appliance.
• Always switch off and disconnect the power supply to the
appliance when not in use.
• Not suitable for outdoor use.
• This appliance must only be used in accordance with these
instructions and by persons competent to do so.
• Keep all packaging away from children. Dispose of the
packaging in accordance to the regulations of local authorities.
FS498-A_FS499-A_A5_v2_20230619.indb 2FS498-A_FS499-A_A5_v2_20230619.indb 2 2023/6/19 10:412023/6/19 10:41

3
EN
Telephone Helpline: 1300225960
• If the power cord is damaged, it must be replaced by an
Apuro agent or a recommended qualified technician in order
to avoid a hazard.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience or knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
• Apuro recommend that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection,
Polarity Test, Earth Continuity, Insulation Continuity and
Functional Testing.
• This is an Attended Appliance and must be supervised when in
use.
• Switch off and unplug after use.
• If Oil begins to Smoke or Overheat then Switch Off Immediately.
Product Description
• FC258 - Single 5 litre fryer
• FC259 - Double 5 litre fryer
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your Apuro product.
Pack Contents
The following is included:
• Apuro fryer
• Basket (FS499-A x 2)
• Element guard (FS499-A x 2)
• Lid (FS499-A x 2)
• Instruction manual
Apuro prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your Apuro dealer immediately.
FS498-A_FS499-A_A5_v2_20230619.indb 3FS498-A_FS499-A_A5_v2_20230619.indb 3 2023/6/19 10:412023/6/19 10:41

4
EN Telephone Helpline: 1300225960
Operation
Element
Power switch
Heat indicator
light
Thermal Cut-out reset switch
Reset switch cover
Thermostat
Safety switch
Timer
Connecting the head unit
The head unit is supplied as a single detachable part to aid
in cleaning the appliance.
To connect the body of the appliance with head unit:
1. Put the head unit onto the main body of the appliance,
using the pin (A).
2. Rotate the head unit until the safety switch (C) on the
bottom touches the pin (D) on the main body.
Using the timer
The digital timer with audible alarm can be set from 1 second to 15 minutes. The timer provides an
audible alarm only; after the set time expires unit will continue to operate at set temperature.
• START/STOP: Press START/STOP to start timer, press again
to stop. The timer will provide an audible alarm after the
set time. The alarm will beep 10 times and the display will
continue to flash until timer is reset (press the START/STOP
button).
• UP: Press UP to add extra time.
• DOWN: Press DOWN to reduce time.
• PROGRAM: There are a total of 6 programmable timer settings. The default factory program settings
are given below.
Program 1 2 3 4 5 6
Factory preset time 00:30 01:00 01:30 02:00 02:30 03:00
FS498-A_FS499-A_A5_v2_20230619.indb 4FS498-A_FS499-A_A5_v2_20230619.indb 4 2023/6/19 10:412023/6/19 10:41

5
EN
Telephone Helpline: 1300225960
• To change the length of a program select the program you want to change by scrolling using the
PROGRAM button.
• Adjust the program time by using the UP and DOWN buttons. Press START/STOP to commence the
count-down. The new program time will be automatically stored.
• If the unit is left without power for more than 24hrs the timer settings will revert to the factory
defaults.
Cooking
1. Connect the appliance to the mains power supply.
2. Set the thermostat to the desired temperature. The amber power indicator light turns On.
• Note: 170°C to 180°C is suitable for general cooking.
3. The appliance begins to heat the oil.
Note: The green Heat indicator light turns On during heat-up. When the oil is at
the set temperatures the light turns Off.
4. Once the oil is at the set temperature lower the food into the oil using the basket supplied.
5. Remove the basket from the oil once the food is cooked. Shake gently above the oil tank to remove
any excess oil.
WARNING: The food and oil are very hot! Take care when removing the basket
as oil may drip.
Thermal Cut-out Reset
Apuro Fryers are fitted with a Thermal Cut-Out safety feature. Should the temperature exceed safe levels
the appliance will automatically cut off power.
To reset the appliance after a sufficient cool-down
period:
1. Unscrew the cover of the Safety Cut-Out reset
switch.
2. Press the small reset switch down until it clicks,
using a blunt pointed instrument.
3. The appliance is now reset and can be used as
normal. Reset switch
Cleaning, Care & Maintenance
• Always turn Off the appliance and disconnect from the power supply before cleaning.
• Always allow the oil to cool before cleaning, ideally for at least 6 hours.
• Check the temperature with a suitable probe thermometer; 40ºC is the MAXIMUM temperature at
which oil should be removed.
• For best performance, Apuro recommend that the appliance is cleaned after each day of operation.
FS498-A_FS499-A_A5_v2_20230619.indb 5FS498-A_FS499-A_A5_v2_20230619.indb 5 2023/6/19 10:412023/6/19 10:41

6
EN Telephone Helpline: 1300225960
Note: Failure to clean the appliance regularly may result in premature activation
of the thermal cut-out switch.
• Remove the head unit for ease of cleaning.
• Empty the oil to clean the appliance thoroughly.
Warning: Do not remove the oil pan until AFTER it has been emptied.
• If the oil is to be reused then filtering it before refilling will extend the oil’s cooking life.
• Use a suitable detergent to clean the interior of the appliance.
• Use warm, soapy water and a damp cloth to clean the exterior of the appliance.
• Dry thoroughly after cleaning, ensure there is no water left in the fryer.
Troubleshooting
A qualified technician should carry out repairs if required.
Fault Probable Cause Solution
Appliance not
working
The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug or lead is damaged Replace plug or lead
Mains power supply fault Check mains power supply
Safety switch not located
properly
Refit head unit
Appliance does
not reach set
temperature
Faulty thermostat Consult a qualified technician
Faulty element Consult a qualified technician
Build-up of fat on the element Clean the appliance
Appliance heats up
but indicator light
does not come on
Indicator light has expired Consult a qualified technician
Power indicator
light comes on but
appliance does not
heat up
Faulty element Consult a qualified technician
Faulty thermostat Consult a qualified technician
Thermostat set incorrectly Check thermostat
Appliance slow to
heat up
Faulty element Consult a qualified technician
Build-up of fat on the element Clean the appliance
Oil overheats or
starts to smoke
Thermostat damaged Switch off immediately. Consult a qualified
technician
No power Thermal cut-out activated Please check your machine is safe with no
obvious damage and then press the re-set
switch
FS498-A_FS499-A_A5_v2_20230619.indb 6FS498-A_FS499-A_A5_v2_20230619.indb 6 2023/6/19 10:412023/6/19 10:41

7
EN
Telephone Helpline: 1300225960
Technical Specifications
Note: Due to our continuing program of research and development, the specifications herein may be
subject to change without notice.
Model Voltage Power Current Capacity
(litres)
Max. single
load (kg)
Dimensions
H x W x D mm Weight
FS498-A 220-240V~,
50Hz
2200W 9.6A 5L 2 350 x 280 x 450 7.4kg
FS499-A 2 x 2200W 2 x 9.6A 2 x 5L 2 x 2 350 x 560 x 450 13.3kg
Electrical Wiring
The plug is to be connected to a suitable mains socket.
This appliance is wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The product must not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product correctly, contact the product
supplier, or the local authority responsible for waste disposal in your area.
Apuro parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
Apuro products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic, mechanical, photocopying,
recording or otherwise, without the prior written permission of Apuro.
Every effort is made to ensure all details are correct at the time of going to press, however, Apuro reserve the right to change specifications without
notice.
FS498-A_FS499-A_A5_v2_20230619.indb 7FS498-A_FS499-A_A5_v2_20230619.indb 7 2023/6/19 10:412023/6/19 10:41

DECLARATION OF CONFORMITY
• Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad • Declaração de conformidade
Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp
• Tipo di apparecchiatura • Tipo de equipo • Tipo de equipamento
Model • Modèle • Modell • Modello
• Modelo • Malli
Single Fryer - 5Ltr 2.2kW
Double Fryer - 2x5Ltr 2x2.2kW
FS498-A
FS499-A
Application of Territory Legislation &
Council Directives(s)
Toepassing van Europese Richtlijn(en) •
Application de la/des directive(s) du
Conseil • Anwendbare EU-Richtlinie(n) •
Applicazione delle Direttive
• Aplicación de la(s) directiva(s) del
consejo • Aplicação de directiva(s) do
Conselho
Electrical safety
AS/NZS 60335.1:2011 +A1:2012 +A2:2014 +A3:2015 +A4:2017
IEC 60335-2-37:2002 +A1:2008 +A2:2011
EN 62233:2008
Electro-Magnetic Compatibility
EN 55014-1:2017
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers
• Nome del produttore • Nombre del fabricante • Nome do fabricante
Apuro
I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation, Directive(s)
and Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande
Richtlijn(en) en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und
Norm(en) entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y
estándar(es) arriba mencionadas.
Eu, o abaixo-assinado, declaro que o equipamento anteriormente especificado está em conformidade com a(s) anterior(es)
Directiva(s) e Norma(s)
Date • Data • Date • Datum • Data •
Fecha • Data
21st May 2021
Signature • Handtekening • Signature
• Unterschrift Firma • Firma •
Assinatura
Full Name • Volledige naam • Nom et
prénom • Vollständiger Name • Nome
completo • Nombre completo • Nome
por extenso
Ashley Hooper
Josie Holt
Position • Functie • Fonction • Position
• Qualifica • Posición • Função
Technical & Quality Manager
Commercial Manager/ Responsible
Supplier
Producer Address • Adres fabrikant •
Adresse du producteur • Anschrift des
Herstellers • Indirizzo del produttore •
Dirección del fabricante • Morada do
fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
15 Bagdally Road,
Campbelltown
NSW 2560
DocuSign Envelope ID: AD52F341-7934-46D3-96D3-85DACAA38FF8
FS498-A_FS499-A_A5_v2_20230619.indb 8FS498-A_FS499-A_A5_v2_20230619.indb 8 2023/6/19 10:412023/6/19 10:41

FS498-A_FS499-A_A5_v2_20230619.indb 9FS498-A_FS499-A_A5_v2_20230619.indb 9 2023/6/19 10:412023/6/19 10:41

FS498-A_FS499-A_A5_v2_20230619.indb 10FS498-A_FS499-A_A5_v2_20230619.indb 10 2023/6/19 10:412023/6/19 10:41

FS498-A_FS499-A_A5_v2_20230619.indb 11FS498-A_FS499-A_A5_v2_20230619.indb 11 2023/6/19 10:412023/6/19 10:41

FS498-A_FS499-A_A5_v2_2023/06/19
FS498-A_FS499-A_A5_v2_20230619.indb 12FS498-A_FS499-A_A5_v2_20230619.indb 12 2023/6/19 10:412023/6/19 10:41
