APW Wyott APWF-15C User manual

1
DESIGNED SMART. BUILT SOLID.®
FOR YOUR SAFETY: Do not store or use gasoline or other ammable vapors and
liquids in the vicinity of this or any other appliance.
WARNING: Improper installation, operation, service or maintenance can cause
property damage, injury or death. Read and understand these instructions
thoroughly before positioning, installing, maintaining or servicing this equipment.
Initial heating of appliance may generate smoke or fumes and must be done in a well ventilated area.
Overexposure to smoke or fumes may cause nausea or dizziness.
APW Wyott® cooking equipment has been engineered to provide you with year-round dependable
service when used according to the instructions in this manual and standard commercial kitchen
practices.
APW Wyott Food Service Equipment Company
1307 N. Watters Road, Suite 180 • Allen, TX 75013
APW Wyott Food Service Equipment Company is a wholly owned subsidiary of Standex International Corporation.
972.908.6100 Phone [phone]
214.565.0976 Fax www.apwwyott.com
INSTALLATION AND OPERATING INSTRUCTIONS
Countertop Fryer
Models: APWF-15C, APWF-25C
INTENDED FOR OTHER THAN HOUSEHOLD USE
P/N 300361 09/18
WARNING: California Residents Only. This product can expose you to chemicals including
chromium which is known to the State of California to cause cancer and birth defects or
other reproductive harm. For more information go to www.P65Warnings.ca.gov.

2
TABLE OF CONTENTS
ITEM ........................................................................ PAGE
Installation Instructions ..............................................................2
Operating Instructions...............................................................3
Maintenance Instructions ............................................................4
Warranty .........................................................................9
IMPORTANT
Installing, Operating and Service Personnel:
• Installation of the equipment should be performed by qualied, certied, licensed and/or authorized
personnel who are familiar with and experienced in state/local installation codes.
• Operation of the equipment should be performed by qualied or authorized personnel who have
read this manual and are familiar with the functions of the equipment.
• Service of the equipment should be performed by qualied personnel who are knowledgeable with
APW Wyott equipment.
SHIPPING DAMAGE CLAIM PROCEDURE
The equipment is inspected & crated carefully by skilled personnel before leaving factory. The
transportation company assumes full responsibility for safe delivery upon acceptance of this
equipment. If shipment arrives damaged:
Visible loss or damage: Note on freight bill or express delivery and have signed by the person
making delivery.
File claim for damages immediately: Regardless of the extent of damages.
Concealed loss or damage: If damage is noticed after unpacking, notify the transportation company
immediately and le ‘Concealed Damage’ claim with the transportation carrier. This should be done
within fteen (15) days from the date delivery and receipt of goods. Retain container for inspection.
INSTALLATION INSTRUCTIONS
The area around the appliance must be kept free and clear of combustibles such as solvents, cleaning
liquid, broom, rags, etc.
Proper clearances must be provided at the front of the appliance for servicing and proper operation.
Provisions shall be incorporated in the design of the kitchen, to ensure adequate supply of fresh air
and adequate clearance for air openings into the combustion chamber, for proper combustion, and
ventilation.
For proper operation of the appliance, do not obstruct the ow of combustion and ventilation air.
The installation must conform with local codes, or in the absence of local codes, with the national fuel
gas code, ANSI Z223.1 - 1988 (or latest addenda), National gas installation code, CAN/CGA - B 149.1,
or the propane installation code, CAN/CGA - B 149.2 as applicable.

3
CLEARANCES
Location Combustible Non-combustible
Sides 6” 0”
Rear 6” 0”
Floor 6” 0”
Installation on non-combustible oor shall be with factory supplied legs or casters.
OPERATING INSTRUCTIONS
WARNING: Hot oil and hot surfaces can cause severe burns. Use caution when
operating the fryer. Do not attempt to move the fryer lled with hot oil or shortening.
Do not go near the area directly above the ue when fryer is in operation. Severe
burns may be caused. Drain hot oil in metal containers, do not use plastic buckets
or glass containers.
LIGHTING INSTRUCTIONS
1. Set the thermostat and the gas cock dial on the combination gas valve to the “OFF” position.
2. Wait for ve minutes.
3. Turn gas cock dial on the combination gas valve to “Pilot” position.
4. Depress the gas cock dial and apply a lighted match or taper to the pilot.
5. Hold the gas cock dial depressed for about 30 seconds or until pilot stays lit before releasing.
6. If the pilot does not stay lit, repeat step 4 and 5.
BURNERS / THERMOSTAT OPERATION
1. After the pilot is lit, turn the gas cock dial to “ON” position.
2. Turn the thermostat dial to any temperature setting and observe the burners ignition. It should
ignite within four seconds.
CAUTION: Main burners shall not be “ON” when the vessel is empty. During
testing, ll the vessel with liquid (oil or water) till above the heat transfer tubes.
The appliance and its individual shut o valve must be disconnected from the gas supply piping
system during any pressure testing of that system in excess of 1/2 PSI.
The appliance must be isolated from the gas supply piping system by closing its individual manual shut o
valve during any pressure testing of the gas supply piping system at test pressures equal to or less than
1/2 PSI.
The gas supply line must be at least the same size as the gas inlet of the appliance.

4
FLEXIBLE COUPLINGS, CONNECTORS AND CASTERS
If the unit is to be installed with casters, the installation shall be made with a connector that complies
with the Standard for Connectors for Movable Gas Appliances, ANSI Z21.69 or Connectors for
Moveable Gas Appliances, CAN/CGA-6.16, and a quick-disconnect device that complies with the
Standard for Quick-Disconnect Devices for Use With Gas Fuel, ANSI Z21.41, or Quick Disconnect
Devices for Use with Gas Fuel CAN1-6.9. Locking front casters are provided to limit the movement of
the appliance without depending on the connector or associated piping. A suitable strain relief must
be installed with the exible connector.
Restraining device may be attached to the back frame/panel of the unit.
All connections must be sealed with a joint compound suitable for LP gas and all connections must be
tested with a soapy water solution before lighting pilots.
PREPARATION FOR USE
New units have a coating of oil on the interior of the vessel. Remove this coating with hot soapy water,
washing soda, or any other grease dissolving liquid. Rinse thoroughly and drain until all residues are
removed. Wipe dry.
Clean the baskets, crumb screen.
PILOT OPERATION
Check and make sure the pilot is lit. If not, refer to previous section for lighting the pilot.
BEFORE TURNING THE BURNERS ON
Fill the vessel with liquid shortening or oil up to the “oil level” marking.
Block of solid shortening should not be melted by setting it on top of tubes. This will damage the
vessel and scorch fat. Either melt it rst on another appliance or cut into small pieces and pack tightly
below, between and above the burner tubes, without leaving any air spaces around the tubes. Turn the
burners “ON” for about 10 seconds and turn “OFF” for about a minute. Repeat this “ON-OFF” cycle
until all the shortening is melted. If scorching occurs, lower the “ON” time.
Do not overll the vessel.
MAIN BURNER OPERATION
After the vessel is lled with liquid shortening or oil, set the gas cock dial on the combination gas valve
to the “ON” position.
Turn the thermostat to desired temperature setting.
DAILY SHUT-DOWN
At the end of the day, turn the gas cock dial on the combination gas valve and the thermostat to OFF
position. Where applicable turn the power switch to OFF position. Filter the oil in all fryers.

5
MAINTENANCE INSTRUCTIONS
CLEANING
For continued performance eciency and longevity of your fryer it is essential to carry out a good
maintenance program.
DAILY
1. Remove and wash thoroughly all “loose” parts (basket hanger, baskets, crumb screen, etc.).
2. Wipe clean all exterior and interior accessible surfaces and parts.
3. Filter the liquid oil/shortening at the end of the day, replace if necessary. If fryer is under heavy use,
lter more often during the day.
WEEKLY
1. Shut down the fryer by turning o the gas cock dial and power supply, where applicable.
2. Drain the fryer in a lter pan or steel container. Flush out sediments at the bottom of the vessel with
liquid oil.
3. Close the drain valve and ll the vessel with a mixture of boil-out solution and water.
4. Relight the pilot and turn on the burners.
5. When the solution starts to boil, turn o the thermostat and let the vessel soak to soften the deposit
and/or carbon spots. (Approximately 1 hour).
6. Drain o solution, scrub the insides with brush and rinse thoroughly.
7. Repeat the cleaning procedure, if necessary.
8. Wipe dry with soft towels and rell with clean oil/shortening.
WARNING: All water must be removed before adding oil or shortening. Not doing so
can result in splattering of hot oil.
STAINLESS STEEL PARTS
Do not use steel wool, abrasive cloths, cleansers or powders to clean stainless steel surfaces. All
stainless steel parts should be wiped regularly with hot soapy water during the day and a stainless
steel liquid cleaner at the end of the day. To remove encrusted materials, soak in hot water to loosen
the material, then use a wood or nylon scraper. NOT USE a metal knife, spatula, or any other metal tool
to scrape stainless steel. Scratches are almost impossible to remove.
WARNING: A factory authorized agent should handle all maintenance and repair.
Before doing any maintenance or repair, contact APW Wyott.

6
EXPLODED VIEW – APWF – 15C APWF-25C
Item Part # Description
2 300360 FRYER BASKET- LARGE – OPTIONAL
3 300510 FRYER BASKET- SMALL
4 390151 FILTER SCEEN MESH APWF-15C OPT
390152 FILTER SCREEN MESH APWF-25C OPT
5 300432 REGULAR-CRUMB SCREEN APWF-15C
300511 REGULAR-CRUMB SCREEN APWF-25C
6 300329 PILOT BRACKET
7 300231 PILOT BURNER - //26 (NAT)
8 300227 ORIFICE BELL - //26 (NAT)
300226 ORIFICE BELL - //16 (LP)
9 300157 THERMOPILE
10 300424 LANDING LEDGE 15C
300327 LANDING LEDGE 25C

7
Item Part # Description
11 300422 FRONT PANEL 15C
300339 FRONT PANEL 25C
12 390153 DOOR ASSY 15C
390154 DOOR ASSY 25C
13 2065847 APW Wyott NAMEPLATE
14 300232 THERMOSTAT
15 300229 KNOB, THERMOSTAT
16 300425 BRACKET, THERMOSTAT/HI-LIMIT
300328 BRACKET, THERMOSTAT/HI-LIMIT
17 300228 HI-LIMIT SWITCH
18 370110 LEG-COUNTER (4”) – OPTIONAL
300362 LEG-COUNTER 2-1/2” – OPTIONAL
19 300413 BOTTOM PANEL 15C
300313 BOTTOM PANEL 25C
20 300188 GAS VALVE (NAT)
300225 GAS VALVE (LP)
22 301040 ORIFICE HOOD- //40 NAT
301054 ORIFICE HOOD- //54 LP
23 300411 BURNER (SHEET METAL)
24 300416 BURNER BRACKET
300312 BURNER BRACKET
25 300319 DOOR HINGE- BOTTOM
26 300320 DOOR HINGE- TOP
27 300310 DRAIN VALVE
28 300452 DRAIN EXTENSION PIPE
29 300332 SIDE PANEL-R/H
30 300331 SIDE PANEL-L/H
31 300434 VESSEL WELD ASSY 15C
300355 VESSEL WELD ASSY 25C
32 300114 PROBE HOLDER (THERMOSTAT-HI-LIMIT) / T-STAT
33 N/A FLUE ASSY 15C
N/A FLUE ASSY 25C
34 300415 BASKET HANGER
300311 BASKET HANGER
35 300462 UPPER FRONT PANEL 15C
300439 UPPER FRONT PANEL 25C
36 390156 VESSEL COVER W/HANDLE
390147 VESSEL COVER W/HANDLE
N/S CALL FACTORY CONVERSION KIT TO NAT GAS
N/S 390149 CONVERSION KIT TO LP GAS
N/S 300447 DIFFUSER WELDMENT

8
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this manual for the life of the equipment.
For Warranty Service and/or Parts, this information is required.
Model Number Serial Number Date Purchased
Notes
APW Wyott takes pride in the design and quality of our products. When used as intended and with
proper care and maintenance, you will experience years of reliable operation from this equipment.
To ensure best results, it is important that you read and follow the instructions in this manual carefully.
Installation and start-up should be performed by a qualied installer who thoroughly read,
understands and follows these instructions.
If you have questions concerning the installation, operation, maintenance or service of this product,
contact APW Wyott Foodservice Equipment Company’s “Technical Service Department”.

9
APW Wyott EQUIPMENT LIMITED WARRANTY
APW Wyott Foodservice Equipment Company warrants its equipment against defects in materials and workmanship, subject to the
following conditions:
This warranty applies to the original owner only and is not assignable.
Should any product fail to function in its intended manner under normal use within the limits dened in this warranty, at the option of APW
Wyott such product will be repaired or replaced by APW Wyott or its Authorized Service Agency. APW Wyott will only be responsible for
charges incurred or service performed by its Authorized Service Agencies. The use of other than APW Wyott Authorized Service Agencies
will void this warranty and APW Wyott will not be responsible for such work or any charges associated with same. The closest APW Wyott
Authorized Service Agent must be used.
This warranty covers products shipped into the 48 contiguous United States, Hawaii, metropolitan areas of Alaska and Canada. There will be
no labor coverage for equipment located on any island not connected by roadway to the mainland.
Warranty coverage on products used outside the 48 contiguous United States, Hawaii, and metropolitan areas of Alaska and Canada may
vary. Contact the international APW Wyott distributor, dealer, or service agency for details.
Time Period
One year for parts and one year for labor, effective from the date of purchase by the original owner. The Authorized Service Agency may, at
their option, require proof of purchase. Parts replaced under this warranty are warranted for the un-expired portion of the original product
warranty only.
Exceptions
* Gas/Electric Cookline: Models GCB, GCRB, GF, GGM, GGT, CHP-H, EF, EG, EHP. Three (3) Year Warranty on all component parts,
except switches and thermostats. (2 additional years on parts only. No labor on second or third year.)
* Broiler Briquettes, Rock Grates, Cooking Grates, Burner Shields, Fireboxes: 90 Day Material Only. No Labor.
* Heat Strips: Models FD, FDL, FDD, FDDL. Two (2) Year Warranty on element only. No labor second year.
* Glass Windows, Doors, Seals, Rubber Seals, Light Bulbs: 90 Day Material Only. No Labor.
In all cases, parts covered by extended warranty will be shipped FOB the factory after the rst year.
Portable Carry In Products
Equipment weighing over 70 pounds or permanently installed will be serviced on-site as per the terms of this warranty. Equipment weighing
70 pounds or under, and which is not permanently installed, i.e. with cord and plug, is considered portable and is subject to the following
warranty handling limitations. If portable equipment fails to operate in its intended manner on the rst day of connection, or use, at APW
Wyott’s option or its Authorized Service Agency, it will be serviced on site or replaced.
From day two through the conclusion of this warranty period, portable units must be taken to or sent prepaid to the APW Wyott Authorized
Service Agency for in-warranty repairs. No mileage or travel charges are allowed on portable units after the rst day of use. If the customer
wants on-site service, they may receive same by paying the travel and mileage charges. Exceptions to this rule: (1) countertop warmers and
cookers, which are covered under the Enhanced Warranty Program, and (2) toasters or rollergrills which have in store service.
Exclusions
The following conditions are not covered by warranty:
* Equipment failure relating to improper installation, improper utility connection or supply and problems due to ventilation.
* Equipment that has not been properly maintained, calibration of controls, adjustments, damage from improper cleaning and water damage
to controls.
* Equipment that has not been used in an appropriate manner, or has been subject to misuse or misapplication, neglect, abuse, accident,
alteration, negligence, damage during transit, delivery or installation, re, ood, riot or act of god.
* Equi pment that has the model number or serial number removed or altered.
If the equipment has been changed, altered, modied or repaired by other than an Authorized Service Agency during or after the
warranty period, then the manufacturer shall not be liable for any damages to any person or to any property, which may result
from the use of the equipment thereafter.
This warranty does not cover services performed at overtime or premium labor rates. Should service be required at times which
normally involve overtime or premium labor rates, the owner shall be charged for the difference between normal service rates
and such premium rates. APW Wyott does not assume any liability for extended delays in replacing or repairing any items
beyond its control.
In all cases, the use of other than APW Wyott Authorized OEM Replacement Parts will void this warranty.
This equipment is intended for commercial use only. Warranty is void if equipment is installed in other than commercial
application.
Water Quality Requirements
Water supply intended for a unit that has in excess of 3.0 grains of hardness per gallon (GPG) must be treated or softened before
being used. Water containing over 3.0 GPG will decrease the efciency and reduce the operation life of the unit.
Note: Product failure caused by liming or sediment buildup is not covered under warranty.
“THE FOREGOING WARRANTY IS IN LIEU OF ANY AND ALL OTHER WARRANTIES EXPRESSED OR
IMPLIED INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR PARTICULAR
PURPOSES AND CONSTITUTES THE ENTIRE LIABILITY OF APW WYOTT. IN NO EVENT DOES THE
LIMITED WARRANTY EXTEND BEYOND THE TERMS STATED HEREIN.”
9/05
