Aqara G2H User manual

Camera Hub G2H User Manual
Camera Hub G2H使用說明書
Camera Hub G2H Bedienungsanleitung
Camera Hub G2H Manuel d’utilisation
Camera Hub G2H Manual de uso
Camera Hub G2H Manuale di istruzioni
Умная Камера G2H: Руководство по Эксплуатации
Camera Hub G2H取扱説明書
Camera Hub G2H 사용 설명서
· 01
· 10
· 16
· 25
· 33
· 41
· 49
· 57
· 64

Indicator light
Micro SD card slot
Lens
Microphone
Reset button
Long press the button for 5s:
restore to factory settings
Product introduction
The Aqara Camera Hub G2H is an intelligent hardware product that integrates dual
functions of a camera and a hub. It has functions such as video intercom, motion
detection, sound detection, and Micro SD card recording. It can also be used as a Zigbee
hub in collaboration with other sensors, controllers and other child-devices to realize
functions such as home guard, data reporting and smart control. It also supports
HomeKit Secure Video. Activity detected by supported cameras is privately analyzed by
your home hub using device intelligence to determine if people, pets, or cars are
present.
01

Speaker
Micro USB slot
Function button
Long press the button for 5s:
Leave a video message
Warnings
* This product is NOT a toy. Please keep children away from this product.
* This product is designed for indoor use only. Do NOT use in humid environments or
outdoors.
* Beware of moisture, do NOT spill water or other liquids onto the product.
* Do NOT place this product near a heat source. Do NOT place it in an enclosure unless
there is normal ventilation.
* Do NOT attempt to repair this product by yourself. All repairs should be performed by
an authorized professional.
* This product is only suitable for improving the convenience of your home life and
reminding you about the status of your devices.It should NOT be used as security
equipment for home, building, warehouse or any other places. If a user violates the
product use instructions, the manufacturer will NOT be liable for any risks and
property losses.
* The base of this product has been designed with strong magnetic properties, which
02

Quick Setup
1. Download the App
Scan the QR code, or search for "Aqara Home" on the App Store，
or on Google Play. Download and install the Aqara Home app.
2. Power on and start up
Find the power jack on the back of the product and connect the USB power cable.
Then power on the power adapter. Aer the camera starts up successfully, the red
indicator light of the camera will flash.
* If the red indicator light does not flash, please long press the reset button and try again.
03
can ensure that the product will not fall off when it is installed on the wall. In order to
prevent the product falling off and possibly causing personal injury, we recommend
that the installation height of the device should be less than 2 meters.

3. Add camera
Connect to Aqara Home
Open the Aqara Home app, and click “+” on the upper right corner of the homepage.
Select “Camera Hub G2H”, and operate it as the app prompts. Aer the device is
connected successfully, the blue indicator light will be steady on.
Connect to Apple HomeKit
Open Apple Home app, click “+” on the upper right corner, and then enter the “Add Accessory”
page. Scan or manually enter the HomeKit Setup Code at the bottom of the camera to bind the
camera to HomeKit.
If the device failed to be added, please check the following steps:
Failed to add to HomeKit guide:
* “Failed to add accessory”. Due to multiple adding failures, the error information of iOS cache cannot be
removed. Please restart the iOS device and reset the camera.
* “Accessory already added”. Aer restarting the iOS device and reset the camera, you can manually enter
the HomeKit setup code and add it again.
* Please make sure the camera is connected with the 2.4GHz Wi-Fi network.
* Wi-Fi name or password may not contain special characters or spaces. Please replace them with ordinary
characters and try again.
* Please make sure the phone is not less than 4 inches away. The camera can't scan the QR code under
back-lighting.
* Please check whether the router turns on the Wi-Fi connection watcher function, which causes the
network connection failures.
* Please check whether the router turns on the AP isolation function, which causes the phone cannot
search the camera within LAN.
* It is recommended not to connect it to a bridge network.
04

4. Add child-device
Aer the camera is added successfully, please open the Aqara Home app and add the
child-devices as the user manual shows.
5. Product installation
Please make sure the camera is added successfully, and then install it onto the wall.
You can place the camera on the horizontal surface, such as desk, table, bookcase,
etc.
The base of the camera contains a magnet, which can be attached to a metal
surface, such as a refrigerator, iron door etc. Do not place it near the main unit of the
computer or hard disc.
You can use the 3M double-sided tape to attach the metal plate to a smooth, non-
metal surface, such as glass, tile, latex wall, etc. and then attach the magnetic
camera base to the metal plate.
05
* “Accessory not found”. Please wait for 3 minutes aer resetting the camera. You can manually enter the
HomeKit setup code and add it again.
* Use of the Works with Apple badge means that an accessory has been designed to work specifically with
the technology identified in the badge and has been certified by the developer to meet Apple
performance standards. Apple is not responsible for the operation of this device or its compliance with
safety and regulatory standards.
* A 10-day recording history from your Camera Hub G2H is securely stored in iCloud and available to view
in the Apple Home app on your iPhone, iPad, or Mac. You can add one camera to your 200GB plan or up
to five cameras to your 2TB plan at no additional cost. Camera recordings don’t count against your
iCloud storage limit.
* Communication between iPhone, iPad, Apple Watch, HomePod, or Mac and the HomeKit- enabled
Camera Hub G2H is secured by HomeKit technology.
1
2
3
4

Indicator Light Status
* Please make sure the installation position is within the coverage range of the Wi-Fi.
* Do not place it near strong electromagnetic interference sources.
* The product is only meant to be used indoors. Please do not use it in humid environment or outdoors.
* Please make sure there is no obstacle around the device.
Indicator Light Status
Blue light is steady on
Blue light flashes
Red light is steady on
Red light flashes
Off
Status Description
Connected successfully / works normally
Connecting to network / network is abnormal
Starting up / Live streaming / recording
Waiting for connection
Sleep mode / the indicator light is off
06

Basic Parameters
Model: CH-H01
Resolution: 1080p
Lens: 140° wide angle
Video Code: H.264
Input Power: 5V 1A
Power Consumption: 5W(MAX)
Wireless Protocol: Wi-Fi IEEE 802.11 b/g/n 2.4 GHz, Zigbee
Local Storage: Micro SD card (CLASS 4 or above is supported, up to 32GB storage)
Supported device: Android 4.0 or iOS13.2 and above
Operating Temperature: -10℃～40℃
07
Hereby, [Lumi United Technology Co., Ltd] declares that the radio equipment
type [Camera Hub G2H, CH-H01] is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
https: //www.aqara.com/DoC
Wi-Fi Operation Frequency 2412-2472 MHz
≤ 20 dBm
2405-2480 MHz
≤ 13 dBm
Wi-Fi Maximum Output Power
Zigbee Operation Frequency
Zigbee Maximum Output Power
Under normal use of condition, this equipment should be kept a separation distance of
at least 20cm between the antenna and the body of the user.

08
All products bearing this symbol are waste electrical and electronic equipment
(WEEE as in directive 2012/19/EU) which should not be mixed with unsorted
household waste. Instead, you should protect human health and the environment
by handing over your waste equipment to a designated collection point for the recycling of
waste electrical and electronic equipment, Appointed by the government or local authori-
ties. Correct disposal and recycling will help prevent potential negative consequences to the
environment and human health. Please contact the installer or local authorities for more
information about the location as well as terms and conditions of such collection points.
FCC ID: 2AKIT-G2H
Federal Communications Commission (FCC) compliance statement:
1. This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communi-
cations. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following measures: -Reorient or
relocate the receiving antenna. -Increase the separation between the equipment and
receiver. -Connect the equipment into an outlet on a circuit different from that to which the

Online Customer Service: www.aqara.com/support
Manufacturer: Lumi United Technology Co., Ltd.
Address: 8th Floor, JinQi Wisdom Valley, No.1 Tangling Road, Liuxian Ave, Taoyuan
Residential District, Nanshan District, Shenzhen, China.
09
receiver is connected. -Consult the dealer or an experienced radio/TV technician for help.
RF Exposure statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance of
20 cm between the radiator and your body. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
IC: 22635-G2H
IC NOTICE TO CANADIAN USERS
This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation,
Science and Economic Development Canada’ s license-exempt RSS(s). Operation is subject
to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES‐003.
This device complies with RSS‐247 of Industry Canada. Operation is subject to the
condition that this device does not cause harmful interference.
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance of
20 cm between the radiator and your body. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.

指示燈
Micro SD卡槽
镜頭
麥克風拾音器
按鍵重置孔
長按5s: 恢復出厰設
產品簡介
Aqara Camera Hub G2H是一款集成攝像頭和網關雙重功能的智能硬件產品，具
有可視對講、移動偵測、聲音偵測、Micro SD卡錄像等功能，同時能作為Zigbee網
關協同其他傳感器、控制器等子設備聯動實現家庭看護、數據上報和智能控制的
功能，支持蘋果HomeKit平台連接，可通過蘋果“家庭”APP實現遠程控制。
10

喇叭放音區
Micro USB接口
功能按鍵
長按3s: 發起視頻留
* 本產品非玩具，請讓兒童遠離本產品。
* 本產品僅限室內使用，請勿在潮濕環境或室內使用。
* 注意防潮，請勿將水或液體潑灑在本產品上。
* 請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放在密閉位置中。
* 請不要嘗試自行維修本產品，應由授權的專業人士進行此項工作。
* 本產品僅適用於提升家居生活娛樂性、便捷度，以及用於設備狀態提醒，如有用戶違反
產品使用說明及本注意事項，製造商對因此造成的任何風險和財產損失不承擔責任。
* 本產品僅適用於提升家居生活娛樂性、便捷度，以及用於設備狀態提醒，不應做為家
居、樓宇、倉庫或其他任何場所的安防設備使用。如有用戶違反產品使用說明及本注意
事項，將產品用於安防領域，製造商對因此造成的任何風險和財產損失不承擔責任。
* 本產品的磁吸底座經過嚴格設計有較強吸附能力，可保證附牆安裝時產品不會脫落，
為避免有其他重物施壓導致產品脫落而產生人身傷害，我們仍建議您將設備的安裝高
度限制在2米以下。
11
警告

1、下載用戶端
在應用商店中搜索“Aqara Home”或者掃描
以下二維碼下載“Aqara Home”app。
2、攝像機通電開機
找到產品背部的電源接口並將USB電源線插入，接通電源適配器。攝像機啟動完
成後，攝像機狀態指示燈紅燈閃爍。
3、添加攝像機如果設備添加失敗，請確認以下幾點:
* 請確保攝像機連接2.4GHz的Wi-Fi網絡;
* Wi-Fi名稱或密碼包含不支持的特殊字符，導致無法連接路由器，請修改成常用的字符後再試；
* 攝像機無法識別手機生成的二維碼，請確保手機屏幕不小於4.0寸，並確保攝像機不要逆光拍攝
二維碼;
* 如狀態燈指示燈非紅色閃爍，請嘗試長按重置按鍵。
12
快速設定

13
* 檢查路由器是否開啟Wi-Fi防蹭設置，導致攝像機無法正常聯網;
* 檢查路由器是否開啟AP隔離，導致手機在局域網內無法搜索到攝像機;
* 建議不要連接橋接網絡。
接入Aqara Home
打開Aqara Home app，點擊首頁右上角“+”，選擇Camera Hub G2H，並且依
照app指示進行操作。成功連接後，設備狀態指示燈將藍燈長亮。
接入Apple HomeKit
打開Apple“家庭”app，點擊右上角“+ ”，進入添加配件頁面，掃描或手動輸
入攝像機底部的HomeKit設置代碼(請妥善保存)，將設備綁定至HomeKit。
常見的HomeKit添加失敗指引：
* 提示“無法添加配件”。由於反復多次添加失敗，導致iOS系統緩存的錯誤信息無法釋放，請重啟
iOS設備並重置攝像機後再試。
* 提示“配件已添加”。請重啟iOS設備並重置攝像機後，採用手動輸入HomeKit設置代碼方式重新
添加。
* 提示“未找到配件”。請重置攝像機後，等待3分鐘後，採用手動輸入HomeKit設置代碼方式重新
添加。
* 使用帶有Works with Apple的徽章，意味著該配件經過專門設計，可與徽章中所標識的技術配
合使用，並且已通過開發者認證，符合Apple性能標準，Apple不對此產品的操作或其符合的安
規標準負責。
* HomeKit安全視頻支持錄製長達10天的視頻並安全存儲在iCloud中，您可以在iPhone、iPad或
Mac上的Apple“家庭”App中查看。此外，您需要擁有200GB的iCloud 儲存方案來支持一個攝像
頭，2TB的儲存空間方案支持最多五個攝像頭。錄製視頻不會佔用您的iCloud存儲空間。
* 本產品與iPhone、iPad、Apple Watch、HomePod或Mac之間的通訊受HomeKit技術保護。

14
4、添加子設備
攝像機添加成功後，請打開Aqara Home app並參考子設備使用說明書進行添加
子設備的操作。
5、產品安裝
請確保攝像機成功添加後，再進行上牆安裝。
可以將攝像機擺放在寫字台，餐桌，書櫃，茶几等水平桌面使用。
攝像機底座為磁鐵底座，可以吸附在含有鐵物體表面，比如:冰箱，鐵門等。
切勿放置在電腦主機或者硬盤旁。
可用附件包中3M雙面膠將鐵塊粘貼在玻璃、瓷磚、乳膠牆面漆等光滑物體表
面，再將攝像機磁吸到鐵塊上。
1
2
3
4
* 攝像機放置位置確保在無線Wi-Fi信號覆蓋範圍內;
* 本產品僅限室內使用，請勿在潮濕環境或室外使用;
* 不要放置在強電磁干擾源附近;
* 確保設備周圍沒有近距離遮擋物。

基本參數
產品型號：CH-H01 視頻編碼：H.264
分 辨 率：1080p 電源輸入：5V 1A
鏡 頭：140°廣角 整機功耗：5W (Max)
無線連接：Wi-Fi IEEE 802.11 b/g/n 2.4GHz、Zigbee
本地存儲：Micro SD卡(支持CLASS4或以上產品，最大支持32GB)
支持設備：Android 4.0 或 iOS 13.0及以上版本設備
工作溫度：-10°C~+40°C(14°F~104°F)
指示燈狀態
藍燈常亮
藍燈閃爍
紅燈常亮
紅燈閃爍
熄滅
設備狀態
連接成功 / 正常使用
網絡連接中 / 網絡異常
開機過程 / 正在視頻直播 / 錄像
等待連接
休眠 / 已關閉指示燈顯示
15
狀態指示燈說明
服務網址： www.aqara.com/support
制 造 商： 深圳綠米聯創科技有限公司
地 址： 深圳市南山區桃源街道留仙大道塘嶺路1號金騏智谷大廈8樓

Indikator
Steckplatz für
Micro-SD-Karte
Objektiv
Mikrofon-Aufnahmeöffnung
Nachbohren-Taste
5s lang drücken, um die
Werkseinstellungen
wiederherzustellen
Produktbeschreibung
Aqara Camera Hub G2H ist ein intelligentes Hardware-Produkt, das die Doppelfunk-
tionen von Kamera und Hub integriert. Es verfügt über die Funktionen wie visuelle
Gegensprechanlage, Bewegungserkennung, Tonerkennung, Videoaufzeichnung auf
Micro SD-Karte usw. Gleichzeitig kann es als Zigbee-Hub verwendet werden, um mit
anderen Sensoren, Controllern und anderen Untergeräten zusammenzuarbeiten, um
die Funktionen der häuslichen Pflege, der Datenberichterstattung und der intelligenten
Steuerung zu realisieren. Es unterstützt die Anbindung der iPhone HomeKit-Plattform
und kann die Fernsteuerung durch iPhone Home APP realisieren.
16

17
Wiedergabebereich des
Lautsprechers
Micro USB-Schnittstelle
Funktionstaste
3s lange drücken, um eine
Videobotscha einzuleiten
Warnhinweise
* Dieses Produkt ist KEIN Spielzeug. Bewahren Sie das Produkt bitte außerhalb der
Reichweite von Kindern auf.
* Dieses Produkt ist ausschließlich für die Anwendung in Innenräumen bestimmt.
Verwenden Sie es NICHT in feuchten Umgebungen oder im Freien.
* Das Gerät darf nicht feucht werden; Wasser oder andere Flüssigkeiten dürfen KEINEN
Kontakt mit dem Produkt haben.
* Stellen Sie dieses Produkt NICHT nahe einer Heizquelle auf. Platzieren Sie das Gerät
ausschließlich Deutsch dann in einem Gehäuse, wenn für AUSREICHENDE Belüung
gesorgt wurde.
* Stellen Sie dieses Produkt NICHT nahe einer Heizquelle auf. Platzieren Sie das Gerät
ausschließlich Deutsch dann in einem Gehäuse, wenn für AUSREICHENDE Belüung
gesorgt wurde.
* Dieses Produkt eignet sich lediglich für die
Verbesserung von Unterhaltungsgeräten, es dient der Bequemlichkeit und verfügt
