Aqua PRO AP1000F User manual

DATE
NOV 2019 v1.0
MODEL
02AF009
02AF010
WWW.AQUAPROONLINE.COM.AU
HOTLINE    PHONE +   
EMAIL [e-mail]
AP1000F / AP2400F
POND & FOUNTAIN PUMP
- INSTRUCTIONS -
AQUAPRO AP1000F/AP2400F Instructions.indd 1AQUAPRO AP1000F/AP2400F Instructions.indd 1 22/9/21 9:00 am22/9/21 9:00 am

HOTLINE [phone] PHONE [phone] EMAIL [e-mail] WEB WWW.AQUAPROONLINE.COM.AU
CONGRATULATIONS ON YOUR PURCHASE
OF THIS PRODUCT BY AQUAPRO.
TECHNICAL SPECIFICATIONS
• AQUAPRO Fountain & Pond pumps are suitable
either submersible or inline.
• AQUAPRO Fountain & Pond pumps are a
magnetically driven centrifugal pump, therefore they
cannot suck from a water level that is below the inlet
level when used inline.
• Your AQUAPRO Fountain & Pond pump has a single
moving part (an impellor set) enabling easy cleaning
and maintenance.
• The motor and electrical components are
encapsulated in epoxy resin, ensuring safe operation
under water.
• The pump has a robust bearing and shaft design so no
oil/grease lubrication is required.
• AQUAPRO pumps that have plastic impellor parts
and ceramic shafts, with no exposed metal, can be
used in salt water applications.
• AQUAPRO fountain pumps are fitted with suction
cup feet, enabling use on both horizontal and vertical
surfaces.
• AQUAPRO Fountain & Pond Pumps are continuous
rated therefore are designed to operate 24/7.
DESCRIPTION AP1000F AP2000F
VOLTAGE* 220-240V 220-240V
POWER 36W 92W
MAX HEAD HEIGHT 2.00M 2.80M
MAX FLOW 1200L/H 2600L/H
IP RATING IP68 IP68
FREQUENCY 50HZ 50HZ
INLET Ø BSP FEMALE THREAD 3/4 IN 1 IN
OUTLET Ø BSP FEMALE THREAD 1/2 IN 3/4 IN
CABLE LENGTH 10M 10M
* SUBJECT TO VARIATION ACCORDING TO LOAD.
Please read these instructions and familiarise yourself with the equipment before placing it in service. Correct and safe use of the
system requires strict compliance with the safety instructions. For safety reasons persons less than 16 years of age or people that are
not familiar with these instructions should not use this equipment.
FEATURES
THE AQUAPRO FOUNTAIN AND POND PUMP HAVE BEEN MANUFACTURED WITH ADVANCED
TECHNOLOGY TO PROVIDE YOU WITH THE BEST QUALITY PUMP FOR YOUR POND OR WATER
FEATURE.
AQUAPRO AP1000F/AP2400F Instructions.indd 2AQUAPRO AP1000F/AP2400F Instructions.indd 2 22/9/21 9:00 am22/9/21 9:00 am

HOTLINE [phone] PHONE [phone] EMAIL [e-mail] WEB WWW.AQUAPROONLINE.COM.AU
AP1000F / AP2400F PUMP
INSTRUCTIONS
BEGIN BY ENSURING THAT THE MAINS POWER SUPPLY IS DISCONNECTED BEFORE
ATTEMPTING ANY MAINTENANCE OR ADJUSTMENT OF THE UNIT.
INSTALLATION
CLEANING INSTRUCTIONS
• Once a fountain nozzle has been selected, assemble
the fountain kit as per the diagram on next page.
• Screw the T-piece onto the pump outlet and adjust
the telescopic riser to the desired height and align
vertically. On the Dual Control Flow Adjuster, on the
T-piece, you can vary the flow between the fountain
head and the waterfall outlet. Close the second outlet
of the T-piece if this is not required for an optional
waterfall or water spout.
• Place the pump in desired location, ensure the pump
is on a stable surface that is free of sludge, sand and
other debris, and connect tubing to the outlet or
attach fountain kit.
• Position the device in the pond horizontally, on a solid
base, in such a way that it is fully covered with water
and the fountain nozzle protruding out of the water.
• Push the plug into the power supply outlet and switch
on.
• Remove the unit from the water. The filters and
sponges in this unit will clog over time. Please clean
regularly (at least once a month) to ensure strong
water flow. Failure to maintain the unit will result in a
burnt out motor and other damage.
• All AQUAPRO Pond & Fountain pumps are water
cooled, if pump becomes restricted, or blocked, it
will overheat and could cause permanent damage.
The motor unit of the pump is encapsulated with
epoxy resin and does not need lubrication. Regular
inspections, cleaning and maintenance of impellor is
necessary to ensure longer impellor life.
• Take o the fountain set first. Unscrew the fountain
kit from the top of the unit. Examine the nozzles to
ensure all ports are unblocked. Clean with a suitable
brush if necessary.
• Maintain the filter sponge regularly according to how
quickly the sponge gets clogged up. When the flow
starts to be reduced, check and clean if necessary.
• Unclip the front filter cage from the front of the
pump and take out the filter sponge and clean. If
using an optional prefilter block sponge, slide the
sponge o the threaded core and wash out. It is
recommended that this is done in a bucket of pond
water to ensure the good bacteria that are present in
the sponge are not killed by the Chlorine in tap water.
Check for wear and tear of the sponges. Replace if
necessary.
• To maintain the impellor of the pump, turn the
Impellor cover locking ring in an anti-clockwise
direction to the stop position and lift o. Then you
can separate the impellor cover from the pump body.
Take out the impellor. (Take care not to break ceramic
shaft because it is brittle.)
• Clean the impellor with clean water and a suitable
brush. Inspect for signs for wear and tear. If the
impellor set becomes worn or damaged it should be
replaced (available from your dealer or special orders).
Failure to do so may cause serious damage to pump.
The impellor set is a wearing consumable part.
• Once the cleaning and inspection process is
completed, reassemble in the revers manner. Reinstall
the shaft into the motor body, and then carefully slide
the impellor onto the shaft. The impellor will pull itself
in by magnetic force, this is normal (take care not to
pinch your fingers or break the shaft).
• Replace the impellor cover, making sure the shaft is
located properly on the impellor cover. You may need
to place rubber impellor locator (Grommet) on end of
shaft to locate into impellor cover properly. Reattach
the locking ring.
• Replace the internal sponge and front cage or foam
block sponge prefilter.
• Re-attach fountain kit and/or tubing, relocate in
water, connect to power supply and turn on.
AQUAPRO AP1000F/AP2400F Instructions.indd 3AQUAPRO AP1000F/AP2400F Instructions.indd 3 22/9/21 9:00 am22/9/21 9:00 am

HOTLINE [phone] PHONE [phone] EMAIL [e-mail] WEB WWW.AQUAPROONLINE.COM.AU
NOTE: PARTS MAY DIFFER SLIGHTLY FROM SHOWN
or
1. FRONT FILTER CAGE 2. BIOSPONGE
3. IMPELLOR COVER LOCKING RING
4. INLET HOSE TAIL  1IN BSP TO 25MM
5. INTAKE SCREEN 6. IMPELLOR COVER
7. IMPELLOR 8. MOTOR BODY
9. THREADED NIPPLE  1/2IN TO 1/2IN
10. 20MM  1/2IN BSP HOSE TAIL
11. OUTLET HOSE TAIL  1/2IN BSP TO 20MM
12. TPIECE & FOUNTAIN RISER
13. FOUNTAIN NOZZLE MOUNT
14. FOUNTAIN HEADS
PART DESCRIPTION
NOTE:
PLEASE CONSULT YOUR RETAILER FOR QUALITY ORIGINAL
AQUAPRO REPLACEMENT PARTS FOR YOUR AQUAPRO PRODUCT.
VISIT WWW.AQUAPROONLINE.COM.AU FOR NEAREST STOCKISTS.
11
9
3
1
13
7
5
12
10
4
2
14
8
6
AQUAPRO AP1000F/AP2400F Instructions.indd 4AQUAPRO AP1000F/AP2400F Instructions.indd 4 22/9/21 9:00 am22/9/21 9:00 am

HOTLINE [phone] PHONE [phone] EMAIL [e-mail] WEB WWW.AQUAPROONLINE.COM.AU
AP1000F / AP2400F PUMP
INSTRUCTIONS
• Be sure the equipment is submerged completely in the water. The depth should not be greater than 2m.
• Do not operate the pump if the appliance or any components of the system, such as the power cable, have been
damaged.
• The pump is designed to be used in a Garden pond or Aquarium environment. It is not to be used in any other
manner or purpose.
• The pump should only be used in clean water. Do not use the pump in, or with, any chemicals such as a solvent or
gasoline.
• All AQUAPRO Fountain & Pond pumps are water cooled. If the pump flow becomes restricted it will overheat
and could cause permanent damage. The pump needs to be cleaned regularly to prevent the pump becoming
blocked, thus causing the pump to overheat and burn out. This is not a warrantable event.
• For your own safety, disconnect from the power supply before any maintenance of any equipment is attempted on
the tank or water body.
• Be sure the equipment is submerged completely in the water. The depth should not be greater than 2m.
• Do not operate the pump if the appliance or any components of the system, such as the power cable, have been
damaged.
• Always use a properly grounded power supply that is connected to an RCD with a rated residual operating current
not exceeding 30mA. As per AS/NZS 3350.2.41:1997
• The drip loop method should be used to prevent water from traveling down the cable and onto the plug or power
supply. If the plug does get wet, do not unplug the cable. Disconnect the circuit breaker that supplies power to the
power supply point. Then unplug and examine the plug and power supply point for presence of water. If the power
point has become wet, you should consult an electrician before using the power point again.
• Always unplug the pump from the power supply when not in use or before performing any maintenance on the
pump or in the pond. Never pull the cable to disconnect the plug from the power supply. Grasp the plug and pull to
disconnect.
• Use of extension cords outdoors is not recommended.
• If required, have a qualified electrician install a weatherproof power supply point near to the pond or water-feature
(within the cable length of the appliance).
• Do not install or store the appliance where it will be exposed to extreme hot or cold temperatures. Do not use in
water above 35°C.
• Do not cut the cable as this will result in voiding your warranty.
• Care should be taken to arrange the power cable so that it cannot be accidentally tripped over or pulled.
• Do not attempt to repair the electrical appliance yourself. Return to an authorized service centre or place of
purchase if a fault occurs, (regular maintenance is not considered repair and is required by user).
• The power cord cannot be replaced. If the cord is damaged, the pump must be discarded.
SAFEGUARDS
DISCONNECT POWER CORD FROM THE POWER SUPPLY BEFORE PERFORMING
MAINTENANCE. NEVER LIFT THE PUMP BY THE POWER CORD.
AQUAPRO AP1000F/AP2400F Instructions.indd 5AQUAPRO AP1000F/AP2400F Instructions.indd 5 22/9/21 9:00 am22/9/21 9:00 am

HOTLINE [phone] PHONE [phone] EMAIL [e-mail] WEB WWW.AQUAPROONLINE.COM.AU
PROBLEM REASON SOLUTION
WATER PUMP NOT
WORKING NO POWER CHECK THAT THE PLUG IS CONNECTED
AND TURNED ON
SPONGES AND FILTER MEDIA
BLOCKED WITH SLUDGE CLEAN THE SPONGES AND FILTERS
IMPELLOR IS BLOCKED WITH
SLUDGE OR LIMESCALE
CLEAN THE IMPELLOR AS PER
THE INSTRUCTIONS
RUNNING WITHOUT SUFFICIENT WATER SUBMERSE THE EQUIPMENT UNDERWATER
THEN PLUG IN. REFILL IF NECESSARY.
BLOCKED IMPELLOR CHAMBER OR CERAMIC
SHAFT IS BROKEN
CLEAN THE IMPELLOR. CHECK FOR WARE.
REPLACE IF NECESSARY.
WATER PUMP IS NOISY BLOCKAGE IN PUMP CLEAR THE BLOCKAGE
IMPELLOR & SHAFT WORN OUT REPLACE IMPELLOR & SHAFT
IMPELLOR BROKEN REPLACE IMPELLOR
WATER VALVE CLOSED ON THE OUTLET OPEN THE VALVE AND ALLOW
WATER TO FLOW
UNIT INLET IS BLOCKED OR THE WATER PUMP
INLET IS BLOCKED CLEAR ALL BLOCKAGES
KIT NAME DESCRIPTION
AQUAPRO AP1000F v.2019 IMPELLOR COVER KIT 11AI041
AQUAPRO AP2400F v.2019 IMPELLOR COVER KIT 11AI042
AQUAPRO AP1000F v.2019 INTERNAL SPONGE KIT 11AI174
AQUAPRO AP2400F v.2019 INTERNAL SPONGE KIT 11AI175
AQUAPRO AP1000F v.2019 COMPLETE FOUNTAIN KIT 11AQ411
AQUAPRO AP2400F v.2019 COMPLETE FOUNTAIN KIT 11AG411
TROUBLESHOOTING
SPARE PARTS NOTE: THESE ARE THE MOST USED
AQUAPRO AP1000F/AP2400F Instructions.indd 6AQUAPRO AP1000F/AP2400F Instructions.indd 6 22/9/21 9:00 am22/9/21 9:00 am

HOTLINE [phone] PHONE [phone] EMAIL [e-mail] WEB WWW.AQUAPROONLINE.COM.AU
AP1000F / AP2400F PUMP
INSTRUCTIONS
NOTES
AQUAPRO AP1000F/AP2400F Instructions.indd 7AQUAPRO AP1000F/AP2400F Instructions.indd 7 22/9/21 9:00 am22/9/21 9:00 am

IMPORTANT SAFEGUARDS WARRANTY
WARRANTY COVERS ONLY APPLIANCE
DEFECTS, FAULTY MATERIAL AND
WORKMANSHIP WITHIN A 2 YEAR PERIOD.
IMPORTANT: IF USED IN MARINE OR
SALTWATER, DUE TO THE HARSH
CONDITIONS THE WARRANTY IS VOID.
• Faults arising due to; accidents, misuse, not
following manufacturer’s guidelines/ instructions, or
power surges/spikes/ brownouts will not be covered.
• The impellor set is a consumable item and is
therefore not covered under warranty.
• Warranty will be void if any tampering, removal of
warranty labels, or electrical circuitry is evident.
• Warranty will be void if the power cord is cut or
damaged in any way.
• Warranty will be void if any visible signs of
overheating are present.
• Loss of livestock, damage to property or personal
injury caused by this product will not be covered.
• Warranty claims caused by installation faults will not
be covered.
• It is the customer’s responsibility to return the faulty
appliance for any warranty claim to Aquatec.
• For any warranty to be valid, an original proof of
purchase must be provided.
• Our goods come with guarantees that cannot be
excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a
major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure
does not amount to a major failure.
FOR MORE INFORMATION AND THE
COMPLETE AQUAPRO RANGE
VISIT WWW.AQUAPROONLINE.COM.AU
To guard against injury, basic safety precautions should
be observed including, but not limited to the following:
• The pump should only be used in clean water. Do
not use the pump in any solvent or gasoline that is
flammable.
• Do not operate the pump without water at any time,
permanent damage may occur.
• Do not operate the pump if the pump or any of the
components of the pump, such as the power cable,
have been damaged.
• The drip loop method should be used to prevent
water from traveling down the cord onto the plug
or power point. If the plug does get wet, do not
unplug the cord. Disconnect the circuit breaker
that supplies power to the power point. Then unplug
and examine the plug and power point for presence
of water. If the power point has become wet, you
should consult an electrician before using the power
point again.
• Always use a properly grounded power supply
that is connected to an RCD with a rated residual
operating current not exceeding 30mA. As per AS/
NZS 3350.2.41:1997.
• Always unplug the pump from the power supply
when not in use or before performing any
maintenance on the pump. Never pull the cord to
disconnect the plug from the power supply. Grasp
the plug and pull to disconnect.
• Do not install or store the pump where it will be
exposed to extreme hot or cold temperatures.
• Do not cut the cord as this will result in voiding your
warranty.
• Care should be taken to arrange the power cord so
that it cannot be accidentally tripped over or pulled.
• Do not attempt to repair the pump yourself. Return
to an authorised service centre o place of purchase
if a fault occurs.
• Do not use in water above 35°C.
WWW.AQUAPROONLINE.COM.AU
HOTLINE    PHONE +   
EMAIL [e-mail]
AQUAPRO AP1000F/AP2400F Instructions.indd 8AQUAPRO AP1000F/AP2400F Instructions.indd 8 22/9/21 9:00 am22/9/21 9:00 am
