Aqua PRO AS10000DF User manual

DATE
MAY 2021 v1.0
MODEL
02AS020
WWW.AQUAPROONLINE.COM.AU
HOTLINE    PHONE +   
EMAIL [e-mail]
AS10000DF
SUBMERSIBLE SUMP PUMP
- INSTRUCTIONS -
AQUAPRO AS10000DF Instructions.indd 1AQUAPRO AS10000DF Instructions.indd 1 3/5/2022 11:53 am3/5/2022 11:53 am

HOTLINE [phone] PHONE [phone] EMAIL [e-mail] WEB WWW.AQUAPROONLINE.COM.AU
CONGRATULATIONS ON YOUR PURCHASE
OF THIS PRODUCT BY AQUAPRO.
TECHNICAL SPECIFICATIONS
• This product is not suitable for use with drinking (potable) water and is not continuous rated.
• An automatic float switch turns the pump on and o as water levels rise and fall.
• The pump has a convenient carry handle for easy positioning.
CLEANING THE PUMP & BASE
• Use a damp cloth to clean the outside of pump housing. Allow to dry thoroughly before storing in a
dry location that is protected from the elements. Hose down gently with low pressure water. Allow to
dry thoroughly before storing.
POWER CABLE
• Damage to, and tampering with the cable voids warranty.
DESCRIPTION AS10000DF
VOLTAGE* 220 - 240V
POWER 550W
MAX HEAD HEIGHT 7.0M
MAX FLOW 10000L/H
MAX IMMERSION DEPTH 7.0M
MAX SOFT SOLID PARTICAL SIZE 35MM
INLET / OUTLET 25 / 32MMØ
CABLE LENGTH 10M
Please read these instructions and familiarise yourself with the equipment before placing it in service. Correct and safe use of the
system requires strict compliance with the safety instructions. For safety reasons persons less than 16 years of age or people that are
not familiar with these instructions should not use this equipment.
FEATURES
MAINTENANCE
YOUR AQUAPRO SUMP PUMP HAS BEEN MANUFACTURED WITH ADVANCED TECHNOLOGY TO
PROVIDE YOU WITH THE BEST QUALITY PUMP FOR EXTRACTING DIRTY WATER FROM PONDS,
TANKS AND DRAINS.
BEGIN BY ENSURING THAT THE MAINS POWER SUPPLY IS DISCONNECTED BEFORE
ATTEMPTING ANY MAINTENANCE OR ADJUSTMENT OF THE UNIT OR THE WATER BODY. THE
PUMP DOES NOT REQUIRE ANY MAINTENANCE UNDER NORMAL OPERATING CONDITIONS.
AQUAPRO AS10000DF Instructions.indd 2AQUAPRO AS10000DF Instructions.indd 2 3/5/2022 11:53 am3/5/2022 11:53 am

HOTLINE [phone] PHONE [phone] EMAIL [e-mail] WEB WWW.AQUAPROONLINE.COM.AU
AS10000DF PUMP
INSTRUCTIONS
INSTALLATION
• Screw the 90° elbow connector into the pump housing in a clockwise direction. Tighten the elbow
firmly to prevent leakage.
• Prepare the Multiple Hosetail Outlet; it is designed to fit various hoses, pipes and fittings. Three
options are detailed below.
1. To fit a 25mm (1”) tap adaptor (temporary application only) Cut o the first 25mm barbed
section with a hacksaw directly in front of the threaded section. It is now ready to be fitted with a
25mm (1”) tap adaptor (not included).
2.To fit a 25mm hose. No cutting is required; hose or tube is now ready to be fitted.
3.To fit a 32mm hose. Cut o the 25mm barbed and threaded sections with a hacksaw leaving the
32mm barbed section only; hose or tube is now ready to be fitted.
• Screw the prepared Multiple Hosetail Outlet clockwise onto the elbow, tightening firmly to Prevent
leakage. Tubing or hose not to be connected at this stage.
• Fit hose or tube to the prepared Multiple Hosetail Outlet and secure with hose clamp (not supplied).
• Unwrap the power cable and ensure the plug is clear of wet damp locations.
• If required the pump can be immersed in deep water by using a rope secured to the carry handle.
• Adjusting the Float Switch. The float switch allows you to adjust the switching On and O depending
on the application requirements. The float switch can also be set to run continuously.
AUTOMATIC MODE
• In automatic mode float heights can be adjusted between 500 and
150mm. To control the automatic on/o switching at various water
levels, simply reduce or increase the length of the float switch
cable by inserting the cable into the circular groove (Float Switch
Adjuster) on the side of the carry handle.
MANUAL MODE
• CAUTION: The pump is to be observed at all times during manual
mode. Prolonged use in manual mode may result in a shorter
motor life or burnout. Set the float switch cable into the
circular groove with the float as close to the pump as
possible. To turn on, position the float above horizontal. The
pump will now run continuously until turned o. Turn o by
tilting the float down 30° or switching o at the power point
(GPO).
AQUAPRO AS10000DF Instructions.indd 3AQUAPRO AS10000DF Instructions.indd 3 3/5/2022 11:53 am3/5/2022 11:53 am

HOTLINE [phone] PHONE [phone] EMAIL [e-mail] WEB WWW.AQUAPROONLINE.COM.AU
OPERATION
• The pump is now ready for use; ensure the pump is not immersed in water deeper than 7m and that
the discharge point is not higher than 7m above the water surface.
• Ensure the area being pumped out is large enough to allow the float switch to move freely and
function eectively.
• Place the pump on a flat surface and check there are no obstructions to the suction base.
• When the float switch is 30° higher than horizontal or above the handle, the pump will turn on and
operate.
ATTENTION: The pump starts up as soon as the float switch reaches start-up level. ie: Above the
handle or higher than 30°.
• The pump will turn o when the float switch is lower than the handle or is lower than 30° from
horizontal. Alternatively, you can manually turn the pump o at the mains power.
• If you wish to use the pump down to the minimum water depth of 50mm, the float switch will need
to be operated manually. The pump can be manually turned “on” by lifting the float to activate the
internal switch.
NB: If you manually turn the pump o, be aware of the location of your hose or tube. If it is at a lower
point than the pump, the water will continue to siphon out, unless a non-return valve (not included) is
fitted to the hose or tube.
TURNING ON AND OFF
• Insert the plug into the mains power socket (GPO). Avoid using extension cords as this can lead to a
voltage drop which may cause power loss and overheating.
• Switch on the mains power to commence operation.
• To cease operation, turn o the mains power. The pump will also stop automatically once the float
switch reaches 30° below horizontal.
HINTS FOR OPERATION
• To maximise pump flow use the largest diameter hose or tube possible. Smaller diameter hose or
tube will reduce the flow rate relative to their size. Where possible use discharge pipes having a larger
diameter than the discharge outlet.
• Do not run the pump without water flowing through it. This leads to increased wear and possible burn
out. Immediately unplug the pump as soon as water supply or flow stops.
NB: The built in thermal overload protector will automatically switch o the pump in the event of
overheating. The motor automatically
AQUAPRO AS10000DF Instructions.indd 4AQUAPRO AS10000DF Instructions.indd 4 3/5/2022 11:53 am3/5/2022 11:53 am

HOTLINE [phone] PHONE [phone] EMAIL [e-mail] WEB WWW.AQUAPROONLINE.COM.AU
AS10000DF PUMP
INSTRUCTIONS
NOTE:
PLEASE CONSULT YOUR RETAILER FOR QUALITY ORIGINAL AQUAPRO
REPLACEMENT PARTS FOR YOUR AQUAPRO PRODUCT.
VISIT WWW.AQUAPROONLINE.COM.AU FOR NEAREST STOCKISTS.
PART DESCRIPTION
FLOW SWITCH CABLE
FLOAT SWITCH ADJUSTOR
AUTOMATIC FLOAT SWITCH
INTEGRAL CARRY HANDLE
10M POWER CABLE
PUMP HOSTING
25MM HOSETAIL
25MM 1” BSP THREAD
32MM HOSETAIL
90° ELBOW
INTAKE/SUCTION BASE
1
2
3
4
5
6
7
8
9
10
11
1 5
6
7
8
9
10
11
2
3
4
AQUAPRO AS10000DF Instructions.indd 5AQUAPRO AS10000DF Instructions.indd 5 3/5/2022 11:53 am3/5/2022 11:53 am

HOTLINE [phone] PHONE [phone] EMAIL [e-mail] WEB WWW.AQUAPROONLINE.COM.AU
To guard against injury, basic safety precautions should
be observed including, but not limited to the following:
• Always use a properly grounded power supply that is
connected to an RCD with a rated residual operating
current not exceeding 30mA. As per AS/NZS
3350.2.41:1997.
• Always unplug the pump from the power supply when
not in use or before performing any maintenance on
the pump.
• Do not install or store the pump where it will be
exposed to extreme hot or cold temperatures.
• Do not attempt to repair the pump yourself. Return
to an authorised service centre or place of purchase if
a fault occurs (regular maintenance is not considered
repair and is required by user).
• This product comes with a warranty against defects
and motor failure (Warranty). The benefits provided
in this Warranty are in addition to other rights
and remedies available to you under the Australia
Consumer Law. The Warranty is provided to the
original purchaser of the product on the following
terms:
• The warranty is given by Aquatec Equipment Pty Ltd
trading as Aquatec Equipment: 37 Edison Circuit,
Forrestdale WA 6112; contactable by phone 1300
552 202 or email [email protected].
• To make a claim under warranty you must return the
faulty product to the place of purchase with a valid
receipt or proof of purchase.
• A warranty claim must be made within 1 Year of the
date of purchase.
• If your claim complies with the above terms and the
product is not an exhaustible item and no Voiding
Events have occurred, we will (at our sole discretion):
- repair the product, if possible; or
- provide a replacement product; or
- if a replacement product is not available, provide a
refund for the purchase price paid.
• You will bear the cost associated with claiming under
the warranty such as the cost of transportation and
delivery of the productto and from the place of
purchase.
• The product contains a mechanical seal and O rings.
These items are exhaustible (Exhaustible Items) and
are not covered under the Warranty.
• The warranty will be void if any of the following events
occur, as determined by us, at our sole discretion
(Voiding Events):
- any tampering/removal of warranty/ identification
labels or electrical components is evident;
- the defect has arisen due to: an accident, incorrect
or inadequate installation, misuse or abuse of the
product (including improper maintenance and
service), excessive wear and tear, not following
manufacturer’s guidelines/instructions, or the product
has been used in a manner contrary to the purpose or
suitability of the product;
- the product has been modified without our
authority;
- the defect is caused by power surges / spikes /
brownouts.
• Loss of livestock, damage to property or personal
injury caused by the improper use or abuse of the
product will not be covered and the manufacturer
excludes all liability for such events, to the extent
permitted by law.
• In addition to the warranty set out above, our goods
come with guarantees that cannot be excluded under
the Australian Consumer Law.
• You are entitled to a replacement or refund for a
major failure and for compensation for any other
reasonably foreseeable loss or damage.
• You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality
and the failure does not amount to a major failure.
SAFEGUARDS & WARRANTY
DISCONNECT POWER CORD FROM THE POWER SUPPLY BEFORE PERFORMING
MAINTENANCE. NEVER LIFT THE PUMP BY THE POWER CORD.
FOR MORE INFORMATION AND THE
COMPLETE AQUAPRO RANGE
VISIT WWW.AQUAPROONLINE.COM.AU
AQUAPRO AS10000DF Instructions.indd 6AQUAPRO AS10000DF Instructions.indd 6 3/5/2022 11:53 am3/5/2022 11:53 am

HOTLINE [phone] PHONE [phone] EMAIL [e-mail] WEB WWW.AQUAPROONLINE.COM.AU
AS10000DF PUMP
INSTRUCTIONS
PROBLEM REASON SOLUTION
THE PUMP DOES NOT
START, OR PUMP WATER
Pump is not connected to the mains power supply Check that the pump is connected to the mains power
supply
Float switch has not been activated, water level too low Manually raise the position of the float switch
The thermal overload protection is activated Wait for the motor to cool and it will automatically
start operation
The motor is damaged Contact AQUAPRO customer service
THE PUMP DOES
NOT SUPPLY WATER
WHEN THE MOTOR IS
RUNNING WHEN THE
MOTOR IS RUNNING
The suction base is obstructed/blocked Clean the suction base of any foreign matter and debris
Air lock in the hose/tube and/or pump (air bubbles)
Perform several start-ups in order to remove all the
air or lift and tilt the pump slightly while the pump is
running
Discharge hose/tube (not included) is kinked or damaged Un-kink the discharge hose/tube. Or replace matter
and debris
THE PUMP FLOW RATE
IS REDUCED
The suction base is partially obstructed/blocked Clean the suction base of any foreign matter and debris
The hose/tube is obstructed Remove the obstructions
Air leak in the suction line or joints Check the suction line connections for air leaks and
tighten or fix where found
Incorrect assembly leads to air and water leakage
in the discharge lines
Ensure the discharge lines are the correct length and all
assembly instructions are adhered to
PUMP WILL NOT TURN
OFF, EVEN THOUGH
THE WATER LEVEL IS
LOW
The float switch is stuck in the "on" position
Ensure that the float switch is free to operate normally.
Contact AQUAPRO customer service if the problem
still occurs
HOSE / TUBE DOES
NOT STAY ON THE
UNIVERSAL ADAPTOR
WHEN WATER IS
TRAVELLING THROUGH
The hose/tube is slightly wider than the
dimension of the universal adaptor
An adhesive can be used inside the hose/tube to prevent
this or teflon tape can be fixed around the universal
adopter or a hose clamp can be used
THE PUMP OPERATES
INTERMITTENTLY
The suction base is obstructed/blocked Clean the suction base of any foreign matter and debris
Incorrect voltage is being used Ensure the pump is connected into 240V power supply
The fluid contains particles thicker than 5mm Ensure the pump is not being used with particles thicker
than 5mm.
The motor is faulty or damaged Contact AQUAPRO customer service
The temperature of the fluid is too high Ensure that maximum permissible water temperature
(35°C) is not exceeded
The water level is below 50mm Ensure the water level is above 50mm
TROUBLESHOOTING
AQUAPRO AS10000DF Instructions.indd 7AQUAPRO AS10000DF Instructions.indd 7 3/5/2022 11:53 am3/5/2022 11:53 am

WWW.AQUAPROONLINE.COM.AU
HOTLINE    PHONE +   
EMAIL [e-mail]
AQUAPRO AS10000DF Instructions.indd 8AQUAPRO AS10000DF Instructions.indd 8 3/5/2022 11:53 am3/5/2022 11:53 am
