AquaCure AC50 User manual

AquaCure Model AC50 Operation Manual"
11"
Keep AquaCure and it’s generated HydrOxy away from open flames or
any item(s) that generate static electrical sparks.
(Except when properly and appropriately igniting torch).
The HydrOxy mixture is easily ignited when it is ‘pure’ but becomes
non-combustible when mixed with enough air.
As long as the percentage of hydrogen in the air is less than 4%, the mixture is NON-
combustible.
AquaCure Assembly Instructions
Items you will need:
- Philips screwdriver
- 1 quart (or 1 liter) wide mouth glass container (mason jar or large measuring cup).
It’s OK to mix in smaller batches if you only have a smaller container.
- Stainless steel table knife (or equivalent for stirring)
- 1 ounce (or 30 gram) measuring spoon
- About 4 ounces (112 grams) of lye (the exact amount isn’t critical)
- Rubber dishwashing gloves
- Safety glasses or goggles
- 1 gallon (4 liters) of distilled water (we recommend buying a home distiller, to make
your own distilled water).
Mix Electrolyte Solution
Put on rubber gloves and safety glasses.
Place the glass mixing container in a well-ventilated area (I
prefer outdoors) and on a surface that won’t be damaged by
lye spills (a stainless steel sink, plastic tray or plastic
tablecloth are examples). Don’t use a plastic jar for
mixing; the heat might melt it.
Fill your glass container with about 3 cups (750ml) of
distilled water and slowly pour 4 to 5 ounces (about 100
grams or 8 to 9 tablespoons) of Lye into the distilled water,
while stirring the water* with a metallic stirring item**.
You stir so that the lye doesn’t fall to the bottom and stick
there like concrete. If this happens, stir until it dissolves.

12"
AquaCure Model AC50 Operation Manual"
The exact amount of lye isn’t critical. It should be at least 100 grams and not more than
about 150 grams. Adding more than about 100 grams does not significantly affect
(improve) performance and might be a detriment (too much lye can plug things up).
Continue to stir until the lye is completely dissolved. It will heat up somewhat*, which is
one reason to use glass as the mixing container, not plastic (plastic might melt).
Set the solution aside to cool until transparent (may take an hour or so).
DON’T add Citric Acid as previous instructions optionally allowed; use ONLY lye.
Impurities (oils) in Citric Acid can cause foaming and excessive sludge formation that
causes plugging issues inside the machine.
DON’T use any other electrolyte in the AquaCure (only lye). ALL other electrolytes
either cause health issues and/or damage the AquaCure.
The AquaCure is designed exclusively to use lye as the catalyst (based on thousands of
tests and experiments since 1986).
*The solution may become hot and turn cloudy. It may also emit noxious fumes for a few
minutes as the lye pre-conditions the water. The fumes will irritate your throat if
breathed.
**Do not use aluminum utensils or containers! Lye will dissolve aluminum.
Additional Notes:
Having a handy container (spray bottle) of vinegar or lime or lemon juice, to spray on
and neutralize lye spills, is a good idea.
Don’t use the 1 liter Drinking Water Bubbler that came with your AquaCure to mix your
lye solution, because you don’t want to contaminate it and heat could cause it to melt.
Which reminds me to mention that while ALL the containers and tubes we use are FOOD
SAFE, they are NOT dishwasher safe. They’ll melt in a dishwasher.
DON’T replace the plastic Drinking Water Bubbler with a glass jar. The problem is
the explosive potential of the HydrOxy. If the gas explodes in a plastic container, it’s like
a loud balloon pop. If it explodes in a glass container, glass shards can fly everywhere.
Be SAFE, use PLASTIC.
To clean the lye from all containers, utensils, gloves, surfaces, etc. just wash with warm
tap water until the ‘slippery’ feeling is gone. They’ll be REALLY clean because lye used
to be a main ingredient in soap, for thousands of years.

AquaCure Model AC50 Operation Manual"
13"
There’s no need to worry about mold in the tubes. Oxygen and lye are natural
preventatives to mold. In all the decades I’ve used my electrolyzers I’ve never had mold
form in the tubes or containers.
Filling the Electrolyzer with electrolyte solution
While the AquaCure AC50 as a whole is often called an electrolyzer or a Water Gas
Generator; technically the ACTUAL electrolyzer (that splits the water into HydrOxy) is a
plastic block located in a stainless steel tank inside the machine.
The actual electrolyzer needs a catalyst to make the electrolysis (water splitting) work.
We choose lye (NaOH) as the most practical catalyst (out of thousands of tests since
1986) to find the most practical electrolyte solution.
Do NOT use KOH, Baking Soda, Sodium Chloride, Citric Acid, etc. as a catalyst
Lye has the best balance of catalytic efficiency, minimal sludge formation, no poisonous
gas formation, low cost, easy availability, purity, caustic safety, etc.
Once the lye solution has cooled enough, remove the ‘Black Fill Cap’ from the top of the
machine. Then, using the appropriate funnel and protecting the AquaCure from spills (I
use a towel), carefully pour the electrolyte solution into the ‘water-fill’ pipe.
It is OK to have the main power switch on, so the sight tube light is turned on as you fill
the machine, to help you see the liquid level.
The initial fill of lye solution will not quite be enough to see the liquid level, float the
ball or shut off the low level alarm. While occasionally checking the sight tube,
SLOWLY add another 500 mL (about 2 cups) of distilled (pure) water (no more lye).
This still won’t fill the machine but is enough to get you started.
I recommend NOT filling the AquaCure to more than 80% of full to start the first time.
Don’t ever fill the machine all the way up because when the machine turns on, the gas
bubbles need room and will ‘raise’ the liquid level more. If the liquid level is too high,
the high liquid level alarm will sound and the gas production will shut off.
We added the blue LED and a floating ball to make it easier to see
the liquid level, but the ball can (usually temporarily) get stuck.
So look for and pay attention to the ACTUAL liquid level (the liquid
level ‘meniscus’ or liquid level line in the tube).
The ball getting stuck often happens when the machine is shipped
(after being drained) and the lye crystals (formed by drying) can
‘glue’ the ball to the tube. It usually comes free (starts floating) after
the lye crystals dissolve (it may take a few days).

14"
AquaCure Model AC50 Operation Manual"
The ball getting stuck is NOT a warranty repair issue.
While inconvenient, it does not affect the performance of the machine.
What to do in case of an accidental overfill
An alarm will sound and the red light will light up. Your AquaCure will not produce gas
if it is overfilled. This is a SAFETY FEATURE unique to the AquaCure (prevents lye
from being ejected).
If this happens, please carefully follow these steps.
Turn the AquaCure off and remove the power cord from the back of the unit.
Remove all the tubes and the humidifier.
Unscrew the Tower Cap (if installed).
Place a glass or plastic container into the sink and slowly pour out a little lye solution.
Set the machine upright and wait 30 seconds. If the liquid level is still above the full
mark, then repeat the above process until the liquid level is below the full mark.
We recommend saving the excess lye solution that was poured out (pour it into a sealable
jar or plastic container) and using it the next time the AquaCure needs liquid. The
REASON for this is that you also poured out some of the lye (catalyst) that your
AquaCure needs to make gas.
Lye used to be a main ingredient in soap. Lye is a main ingredient in drain cleaner. It is
safe for your plumbing and the environment to dispose of it down the drain if necessary.
Do not use the syringe with concentrated lye solution!
Do not put concentrated lye solution through the Tower Cap check valve!
The reason for this is that lye crystals can cause the check valve to malfunction, either
holding it closed (causing back-filling) or open (causing gas leak).
Lye solution should only be put in the machine using the provided funnel. Yes,
you’ll need to remove the Tower Cap. But only for initial fill of lye and for maintenance.
Tower Cap:
The Tower Cap is your first line of defense against lye contamination of the HydrOxy
gas. The height of the Tower Cap allows most of the lye mist to separate from the
HydrOxy and settle back into the electrolyzer.
Also the Tower Cap clear tube allows you to see if you have a foaming issue. If you see
foam in the clear tube, stop the AquaCure and completely clean it (rinse it out). Dump

AquaCure Model AC50 Operation Manual"
15"
the contaminated electrolyte down the drain. Impurities (like oils) cause the foaming, so
if you have foaming your electrolyte has become contaminated and needs to be replaced.
If foam rises to the gas outlet of your Tower Cap, you will quickly lose your lye (it rides
out on the foam). Foam looks like the bubbles formed in a sink when you put in
dishwashing detergent to wash dishes.
So one way or another, the Tower Cap helps keep the lye inside your machine.
Install Tower Cap
Screw the Tower Cap onto the electrolyzer water-fill pipe.Tighten until it’s sealed
enough to prevent gas leaks and condensation from leaking down the stem… but not so
tight that you break the plastic ring inside the tower.
Once the Tower Cap is installed, you should not remove it unless you are doing the 200
hour maintenance cleaning or if you need to see inside the electrolyzer (for diagnostic
purposes). So seldom remove it. Fill pure water through the tower check valve.
The reasons for this are:
1. The Tower Cap has plastic threads, so to make them last for 20+ years I don’t want
them unscrewed very often. This would be considered user abuse.
2. Squirting pure water into / through the check valve keeps the check valve clean and
functional (prevents lye crystal formation and plugging).
3. The fewer times the Tower Cap is removed, the fewer times care needs to be taken not
to break the inner plastic ring as you tighten it.
Note: If the Tower Cap leaks (gas and/or fluid) out the bottom threads, it means that
the inner rubber sealing ring isn’t sealing properly.
You can then use several wraps of Teflon Tape to seal the threads. Depending on the
thickness of the tape, it takes about 12 wraps. You want enough to seal but not so much
you can’t screw the cap on.
Wrap the tape in clockwise direction, so that screwing the Tower Cap on tightens the tape
into the threads.
Note that ‘condensation’ liquid droplets that are in the Tower Cap can pour down the
electrolyzer stem when you unscrew the tower, another reason not to remove it too often.
If liquid drips down the stem, then it can get past the fill stem collar and drip into the
machine, where it will cause issues. So wrap a cloth around the stem when removing the
tower, to catch the drips.
After the first fill (of catalyst solution) poured directly into the fill stem (not through the
Tower Cap), you will only fill the AquaCure with pure water using the syringe through
the check valve mounted on the top of the Tower Cap. Do Not ever plug or cap this
check valve or it won’t be able to mitigate the electrolyzer vacuum.

16"
AquaCure Model AC50 Operation Manual"
NOTE: Squirt SLOWLY into the check valve or water will spit back at you.
Sometimes the water doesn’t go down into the electrolyzer immediately when you are
squirting it into the tower, causing it to LOOK like the machine is over-filled. It is not.
If this is happening, stop filling and run the machine. As the gas comes up into the tower,
it’ll cause the water to drop down to where it’s supposed to be. And it’s OK to run the
AquaCure as you squirt in the water.
Note: The electrolyte (lye) solution is a catalyst and stays in the machine. You do NOT
add more lye or replace the lye unless you’ve somehow lost your lye or it’s gotten
contaminated.After the initial fill, add ONLY pure distilled water to the AquaCure
through the Tower Cap, using the supplied syringe.
Save the black ‘water fill’ cap and store it in place where it won’t get lost so you’ll have
it in case you need to ship the machine.
Install Humidifier Holding Bracket and Humidifier
•Remove the screw on the right of the AquaCure.
•Install the Humidifier holder using the same screw.
•The Humidifier bracket has two holes for screws. We use
the upper one.
•The rubber tape helps hold the bracket from swinging but
it IS permissible to drill another hole in the AquaCure and
install another screw in the lower hole.
Fill the Humidifier up to at LEAST 80% full (90%
recommended). Yes this will be far ABOVE the MAX fill
line with distilled water.
The Humidifier is your second line of defense against lye
contamination of the HydrOxy gas. Assuming the humidifier
water is pure, it will reliably trap any residual lye (scrub the
lye out of the gas).
Reinstall the humidifier lid (don’t cross-thread)
Thread the humidifier input tube to the top of the lid.
Place the humidifier in the holder.
Install the Humidifier output tube from the output on the side of the Humidifier lid to the
small nipple on the drinking water bubbler (the one leading to the bubbling stone in the
bubbler).

AquaCure Model AC50 Operation Manual"
17"
NOTE: When putting on tubes, ONLY push on tight enough to seal. Some people have
been pushing the tubes on so far that they are impossible to remove without cutting them
off with a razor… You should only need to gently rock the tube to have it come free.
Change out the Humidifier water about every 10 hours of use at 100% operation.
The AquaCure has about 10 hours of run time between full and low (assuming 100% gas
production) so change the Humidifier water when the AquaCure needs water...
And since you use pure (distilled) water in the Humidifier it’s the PERFECT water to
put into the AquaCure… Because if there was any lye trapped, you are now putting it
back into the AquaCure. Another way to prevent lye loss.
Fill the AquaCure with what you need from the Humidifier and then discard any excess
water down the drain.
We do not recommend using the Humidifier water for health purposes or for feeding to
plants, animals, etc. (it may have lye in it).
Use this water to refill the AquaCure.
Drinking Water Bubbler
FILL the 1 liter (1 quart) drinking water
Bubbler container at least 80%
(recommend 90%) full of water. Leave
enough room so that the bubbles bursting
up out of the liquid don’t splash water up
into the gas out tube. It’s not dangerous to
have water in the tubes, but liquid squirting
from the tube will tickle your nose.
Note that it is normal to have some water in
the tubes because the HydrOxy gas has a
very high humidity, which condenses in the
tubes.
The Drinking Water Bubbler liquid level
needs to be high so you make full volume
of drinking water AND because the
Drinking Water Bubbler is the final water
to make sure you have NO LYE in your
breathing gas.
ALWAYS fill the Humidifier and Drinking Water Bubbler to at least 80% (90%
recommended), less than that isn’t safe.

18"
AquaCure Model AC50 Operation Manual"
Just to be safe, NEVER breathe gas that hasn’t gone through BOTH the Humidifier and
the Drinking Water Bubbler… And that both are FULL of water.
Water in the Drinking Water Bubbler can be safely drunk IF the gas first went through
the Humidifier and the Humidifier has been changed out regularly.
Water that is too impure will not absorb (aka trap or scrub) the residual lye out of the
HydrOxy. The Humidifier water needs to be refreshed regularly so that it retains it’s
‘absorption capability’. So, because the humidifier water has the ‘trapped lye’ it’s the
perfect water to refill the AquaCure water so I recommend using the Humidifier water to
refill the AquaCure.
Back in 1996 I once breathed the gas without first putting it through a bubbler and it had
lye mist in it and it HURT (burning in the lungs). It took over a week to heal.
So please be safe, bubble the gas through TWO FULL containers of pure water before
using it for any health application.
Tube attachments
1. Attach the Tower Cap to the Humidifier using the appropriate short connection tube.
2. Attach the Humidifier to the Bubbler using the 1/8” ID vinyl tube with the appropriate
adaptor(s). The 1/8” OD tube just slides tightly into the ¼” ID adaptors.
Make sure to attach Humidifier output to the Drinking Water Bubbler fitting that leads to
the bubbling stone in the Drinking Water Bubbler container.
Now you are ready to attach any accessory tube to the gas out fitting of the Drinking
Water Bubbler. Accessories like:
Tube from bubbler to nose cannula (for gas inhalation)
Tube from bubbler to bag (for general topical gas application)
Tube from bubbler to collapsible silicone funnel (for spot topical gas application)
Tube from bubbler to bubbling stone (for remote bubbling of water).
The AquaCure is now ready to be plugged in and started.
Check fluid levels (AquaCure 80%, Humidifier 90% and Drinking Bubbler 90% full).
Plug in the AquaCure into an appropriate electrical receptacle (outlet).
(you can safely leave it plugged in between uses).
Turn on the Main Power switch (you can safely leave the power switch on between uses).
Turning off the Main Power switch is pretty much the same as unplugging the AquaCure.

AquaCure Model AC50 Operation Manual"
19"
When Main Power is turned on, the below lights will come on.
1. The Main Power switch red internal
2. The Blue sight tube illumination light
3. The tiny yellow light on the bottom of the Timer switch (120 VAC version only)
Timer Switch
Once the timer is turned on, the Green ‘Gas Production’ light should shine, indicating
that gas is being produced. Actually it only indicates that electricity is going to the
electrolyzer so we ASSUME gas is being produced (more on that later).
Note that the 240 VAC version has a mechanical timer switch so doesn’t have indicator
lights on the timer. See below for 240 VAC specific details
Turn on the desired setting on timer switch (10*, 20, 30 or 60 minutes).
*The included 1 quart (1 liter) Drinking Water Bubbler’s water will be fully infused with
the hydrogen, oxygen and ExW in about 10 minutes (assuming 100% DUTY). Larger
volumes (bigger containers full of water) will require more time.
Calculate bigger containers at 10 minutes per liter, (so 4 liters = 40 minutes).
The (120 VAC) timer switch has:
1. A yellow LED under the stop button (bottom button) that indicates that the timer
switch is off.
2. A green LED to the left of each timing option that lights up when the timing option
is active
Note: as the timer counts down the next lower green button LED will light up.
3. You can shut off the timer anytime by pushing the bottom button.
4. Note: if you shut off the main power switch when the timer switch is still activated,
it will ‘remember’ the setting it was at and continue when you turn the power on
5. The yellow LED under the stop button will change color to RED when you put the
timer into ‘continuous mode’.
To turn on continuous mode, press and hold the top timing button for 5 seconds.
This continuous setting bypasses the timer function and the AquaCure AC50 will
stay ON (producing gas) until you shut it off manually (timer off button) or until it
runs low on water and the alarm sounds (after about 10 hours if water level starts at
the recommended 80% and the AquaCure is producing gas at 100%).
