Aquaox OXL5600-8 User manual

WATER FILTRATION SYSTEM
MODEL # OXL5600-8
PRODUCT SPECIFICATION
Model No.
Height
Diameter
Weight
Maximum Service Flow (gpm)
Inlet/Outlet Connection
Temperature
pH
Fleck Head Digital
Pre-sediment Filter
Pre-sediment Filter Connection
Backwash Cycle
# oxl5600-8
64 in
13 in
175 lbs
37
1 1/4” male threaded or 1 1/4” PVC Glue
41° - 100°
6.5 - 8.5
Requires regular 110 Outlet
30 gpm Stainless Steel
Screen Backwashable
1 1/2” male threaded fittings
AQUAOX CONNECTIONS:
Connections Height From Floor 56”
Backwash Drain Connection 3/4” male threaded
PRODUCT SPECIFICATION
Height
Diameter
Weight
Maximum Service Flow (gpm)
Inlet/Outlet Connection
Temperature
pH
Fleck Head Digital
64 in
13 in
175 lbs
37
1 1/4” male threaded or 1 1/4” PVC Glue
41° - 100°
6.5 - 8.5
Requires regular 110 Outlet
H
D
W
Connections Height From Floor 56”
Backwash Drain Connection 3/4” male threaded
Gallons used During Backwash Between 40 and 50
Backwash Cycle 20 minutes every 3 days
The System comes with two options: 1 1/4” glue fitting and a
1 1/4” male threaded NPT fitting.

INSTALLATION
AquaOx Protected Home
Caution: Diagram shown is for
reference purposes only. Read
installation and operation manual
prior to installing the unit.
SYSTEM INSTALLATION INSTRUCTIONS
*PLEASE READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING
Prior to Installation:
1. Find the point of entry of the main water line.
2. Determine where the drainage line will travel for the backwash process.
3. A 120-volt electrical outlet will be needed in order to plug in the Fleck 5600. Electricity is required to run
the timer only. Normal water pressure manually runs the backwash.
4. Place the filter where you want to install the unit. Be sure the tank is on a level solid base. Note: the system
cannot be tilted beyond a 70-degree angle. The system must be upright at all times.
5. Take care not to drop the system; the riser is sensitive to the weight of the media.
6. Perform all plumbing according to local plumbing codes.
7. It is important to use only Teflon tape on the by-pass valve.
Installation Steps:
1. Connect proper fittings to both sides, inward arrow and outward arrow on the bypass valve.
2. Turn both knobs on the by-pass valve clockwise until they are all the way open.
3. Ensure that the main water shuto valve to the house is in the OFF position.
4. Cut the point of entry line to the house and install cuto (A) as seen in the illustration.
5. From cuto (A) connect line to the inward arrow on the bypass valve.
6. Install a hose bib on the line that runs from the outward arrow to the main line of the house.
7. From the hose bib install another cuto (B) as see in the illustration.

8. Make sure both cutos (A) and (B) are in the OFF position.
9. Install a garden hose to the hose bib and run the hose either outside or into utility sink/open drain.
10. Place the hose bib valve to the ON position.
11. Make sure that the bypass valve is in the SERVICE position, and slowly turn on cuto (A).
12. Fill the tank slowly so not to disturb the media bed. NOTE: the water flowing from the hose is cloudy and/or
contains media fines as well as air.
13. When steady flow comes from the hose, TURN OFF hose bib and cuto (A) and allow the media bed to
soak & settle for 30 minutes. Note: 30 minutes is minimal requirement. Longer is better 45-60 minutes.
Typically this is done while the backwash pipes are being assembled and positioned to drainage.
14. During pre-soak, attach the backwash piping to empty into the drain line. Install to code for your area.
15. Makes sure the hose bib is in the o position and the bypass valve is in the IN SERVICE position.
16. Turn cuto (A) to the ON position.
17. The system is now ready to run through the backwash cycle.
18. Plug in the power cord.
19. Set the time by pushing down and holding the down arrow for 3 seconds. This will put it in clock mode. Set
the time by pressing the up or down arrows until you have the correct time displayed and press the next
button at the bottom left once to lock in the time.
20.The time should be displayed on the screen.
21. There will be a number “3” that will flash up. That is just the number of days until the next backwash.
22. Now you are ready for the initial backwash. Press the regeneration button and hold for 3 seconds. This will
take around 20 minutes. NOTE: backwashing regularly is absolutely vital to the performance of this water
system.
23. When the wash is complete, the time will display.
24. Turn the hose bib back on and let the water run until it is clear. We recommend that you run water into a 5
gallon white bucket to insure the clarity of the water before you run it into the house.
25. When the water is clear, turn o the hose bib and turn cuto (B) to the ON position.
26. Remember that the hot water tank has old water in it. It may take up to a week to replace the old water with
purified water.
INSTALLATION QUESTIONS? CALL [phone] OR VISIT HTTPS://WWW.AQUAOXFILTERS.COM
