AQUASOL AB-T-TDS User manual

AB-T-TDS
TDS/CONDUCTIVITY METER
Instruction Manual
Warranty Card*
AB-T-TDS

Content
1. Introduction .............................................................................. 3
2. Technical parameter .................................................................. 4
3. Instrument structure ................................................................. 4
3.1. LCD Display ...................................................................... 4
3.2. Operation ......................................................................... 5
3.3. Interface ............................................................................ 6
4. Instrument Measurement ......................................................... 6
4.1. Preparation work .............................................................. 6
4.2. Instrument calibration ....................................................... 7
4.3. Conductivity solution measurement ................................. 7
5. Instrument Setting .................................................................... 8
6. Warranty ................................................................................. 12
1. Brief Instruction :
Thanks for buying and using the model AB-T-TDS Conductivity Meter (the
following called “meter” in short. Before using this meter, please read the
operation manual carefully in order to help use and maintain it correctly. On
the basis of improving instrument of performance constantly, we reserve the
right of changing the content of this manual and accessories in case of not
notifying in advance. This meter is a perfect combination with the most
advanced electronic technology, sensor technology and software design. This
meter can measure the parameters of conductivity and temperature for high
accuracy solution.
This meter has the following prominent features:
Built-in microprocessor chip, with the intelligent functions of automatic
calibration, automatic/manual operation temperature compensation, data
storage, function setting and data export. Adopts digital filter and step slipping
technology to intelligently improve meters' response speed and result
accuracy will appear when reading to be stable.
With the new type of conductivity electrode and temperature electrode, the
conductivity measurement mode has the function of automatic temperature
compensation. At the same time, it can measure RES, TDS and SAL more
conveniently and accurately.
32

3.1.1. Display
3. Instrument Structure
①--- Parameter mode icon ⑤---Temperature Value
②---Measuring value ⑥---Operation reminder
③---Time ⑦---Stable symbols
④
①--- Parameter mode icon
②--- Measuring value ⑤--- Temperature Value
③--- Time ⑥--- Operation reminder
④--- Measurement unit ⑦--- Stable symbols
3.2. Operation Key
The meter has 8 operation keys.
3.2.1. ON/OFF – Switch On/Off meter
3.2.2. CAL/LEFT – Calibration Key / Left Direction Key.
(a) When measuring state, press this button to enter the calibration
setting interface of the instrument.
(b) When in system time & manual temperature compensation status,
the key is a Left direction key.
3.2.3. SAVE/RIGHT – Save Record Key / Right direction key
(a) Under measurement status short press ”SAVE” key can save
measurement data in the corresponding mode (the lower right
corner of screen will display serial number M+).
(b) Under measurement status, long press ”SAVE” key can recall saved
data in the corresponding mode (RM and serial number will be
displayed in search operation).
(c) Under system setting and manual temperature compensation mode,
it is used as the right direction key
1.1 Product Packing
a) AB-T-TDS – Meter – 1 Unit
b) AME-CN-LG – Conductivity Electrode – 1 Unit
c) AME-T-T10 – Temperature Electrode – 1 Unit
d) Supply Adapter – 12V/1A
e) Operating Manual
Model No AB-T-TDS
Parameter Conductivity TDS Salinity Temp
Range 0.0 to 200.0 0.0 to 100
mS/cm PPT PPT Deg C
Accuracy ±1% FS ±1% FS ±1% FS ±0.2 + 1 Digit
Resolution 0.1µS/cm 0.1 PPM 0.1 PPM 0.1 Deg C
0.1mS/cm 0.1 PPT 0.1 PPT
ATC 0 to 60 0 to 60 0 to 60 NA
Deg C Deg C Deg C
Power 12V / 1A
Size 240 × 170 × 80 mm
Weght 550 Gms
0.0 to 100 0 to 100
2. Technical Parameters :
54
°C MTC
25.0
MESSAGE :
•Press SET to enter system parameter settings.
•Press CAL to enter calibration mode.
•Press SAVE to save current reading.
• Long-time press SAVE to retrieve the stored data.
00:08
2000/ 1/4
µS/cm
COND
5
4
23
6
7
1
• Press or to select the measurement mode.

4. Instrument Measurement :
4.1 Preparation Work
4.1.1. Press “ON/OFF” key to turn on, press “UP” key, and press the "COND"
button to select the conductivity measurement mode.
4.1.2. Insert the conductivity electrode and the temperature electrode into the
corresponding interface of the instrument.
4.2. Instrument Calibration：(Standard Solution Method):
4.2.1. Press “CAL” key to enter the calibration mode, displays “CAL” on the
screen, indicating to enter the calibration mode.
4.2.2.Wash the Conductivity & Temperature Electrode in pure water and dry
it, then immerse them into the 1413µs/cm calibration solution, shake
the electrodes and place them statically, when the measurement value
is stable and show “ ”,then press the “OK” key, display 1413 µs/cm,
confirm the calibration is correct then press the “OK” key to complete
the calibration, and save the data press “OK” key to exit the calibration
mode, The icon “L M” will appear on the screen.
4.2.3. This instrument also has a unique single point calibration function. It
should be calibrated according to the conductivity of the water sample
and the calibration solution are as close as possible. The commonly
used calibration solution is 1413 µs/cm, using the K=1 electrode, it can
be used in measurement range less than 100ms /cm. Other calibration
points are (L) 84 µs/cm, (M) 1413 µs/cm, (H) 12.88ms/cm or (H)
111.9 ms/cm.
4.3. Instrument Measurement
4.3.1. Clean and dry the conductivity electrode, put it in sample solution with
the temperature electrode, stir it and place stable, when the
measurement value is stable and LCD appears the icon “ ” then
read it out, which is the measurement value of the conductivity solution.
4.3.2. Short press “DOWN” key can simultaneously display resistivity values,
TDS values and salinity values corresponding to conductivity values.
3.2.4. ESC/PRN – Return Key / Print Key
(a) Under measurement mode, it is used as printing key and can be
printed directly through Bluetooth printer.
(b) Under non - measuring mode, it is used as a return key.
3.2.5. SET – Enter System Setting
(a) Under measurement mode, system setting interface can be entered
through the key.
3.2.6. UP - Big switch mode, upwards key
(a) In the measurement status, short press (no more than 1s) is used as a
large handover mode, which enables to switch back and forth between
several functions.
(b) Under system setting and manual temperature compensation mode, it
is used as the upwards key.
3.2.7. DOWN - Small switch mode, downward direction key
(a) In the measurement mode, the key is used as a switching mode
CONDUCTIVITY / RESISTIVITY / TDS / SAL.
(b) Under system setting and manual temperature compensation mode, it
is used as the downwards direction key.
3.2.8. OK – To Confirm key
3.3. Interface picture
1 - Temperature electrode interface 4 - USB interface
2 – No Connection 5 - Data line interface
3 – Conductivity Electrode interface 6 - Power interface
76

98
5.2 Setting Parameter and its Functions
Code Parameter Setting
P1 Export Data to USB
P2 Date and Time
P3 Clear Stored Records
P4 Temperature Unit Selection
P5 Display Machine Code
P6 Android App Authorization Code
P7 Restore to Factory default
P8 Manual Temperature Compensation Value
P9 Bluetooth Mode Selection
P10 Electrode Coefficient Value
P11 Electrode Coefficient Range
P12 Standard Solution Selection
P13 Temperature Compensation Coefficient Value
P14 Datum Temperature Value
5. Instrument Settings :
5.1 Steps to Change Parameter Setting
Press “SET” to enter Setting Mode.
Press “UP” or “DOWN” to select parameter from P1 to P14.
Press “OK” to enter Parameter Setting.
Press “UP” or “DOWN” to select value and Press “OK” to confirm.
Press “ESC” to return to Measurement Mode
P1 - Export Data to USB
This setting will transfer Data from Meter to USB disk in Excel Format (If no
USB is detected Meter will prompt ERROR)
a) In Setting Mode select “P1” and press . Data Will be copied to
USB.
b) Press “ESC” and Exit settings.
P2 - Set DATE and TIME
This setting will set Date and Time
a) In Setting Mode select "P2" and press “OK” to change Date an Time.
b) Press “UP” or “DOWN” to change values, Press “LEFT” or “RIGHT”
to shift between variables.
c) Press “OK” to Confirm and “ESC” and Exit settings.
P3 - Clear Records
This setting will delete Stored values in the Meter
a) In Setting Mode select "P3" and press “OK” to Clean records.
b) Press “UP” or “DOWN” to select record and press “OK” to Clear
Value.
c) Press “ESC” and Exit settings.
P4 - Temperature Unit
This setting will select Temperature Unit Deg C or Deg F
a) In Setting Mode select "P4" and press “OK” to select unit.
b) Press “UP” or “DOWN” to select unit and press “OK” to confirm.
c) Press “ESC” and Exit settings.
P5 - Display Machine Code
This setting will display 4-digit Machine Code, used for Bluetooth paring.
a) In Setting Mode select "P5" and press “OK”. Machine Code will be
displayed.
b) Press “ESC” and Exit settings
“OK”

1110
P6 - Bluetooth App Code (Useful only when Bluetooth App is
Purchased)
This setting will enter Bluetooth App Authorization Code in the machine for
Android Bluetooth App and Meter Paring.
a) In Setting Mode select "P6" and press “OK” to enter code.
b) Press “UP” or “DOWN” to enter values, Press “LEFT” or “RIGHT” to
shift between variables.
c) Press “OK” to Confirm and “ESC” and Exit settings.
P7 - Restore Factory Setting
This setting will restore Meter to Factory Default Values.
a) In Setting Mode select “P7” and press “OK” Machine will display
“8888”
b) Press “OK” to Confirm and “ESC” and Exit settings.
P8 - Manual Temperature Compensation
(Default Value = 25 Deg C)
This setting will enter the manual temperature compensation value,
applicable only if Temperature Electrode is not connected.
a) In Setting Mode select “P8” and press“OK” to enter value.
b) Press “UP” or “DOWN” to enter values, Press “LEFT” or “RIGHT” to
shift between variable.
c) Press “OK” to Confirm and “ESC” and Exit settings.
P9 - Bluetooth Operation Mode
This setting will select Bluetooth Operation Mode
APP Mode - Use Android App to connect Meter
Bluetooth Mode - Use to print Meter reading on Bluetooth Printer
a) In Setting Mode select “P9” and press “OK” to select APP or
Bluetooth.
b) Press “UP” or “DOWN” to select Mode and press “OK” to confirm.
c) Press “ESC” and Exit settings.
P10 - Electrode Coefficient (K) Value setting
This setting will enter Conductivity Electrode (K=1.0) value as mentioned on
the electrode.
a) In Setting Mode select “P10” and press “OK” to select value.
b) Press “UP” or “DOWN” to select value and press “OK” to confirm.
c) Press “ESC” and Exit settings.
P11 – Electrode Coefficient (K) Range setting
This setting will select Conductivity Electrode (K=0.1/1.0/10) range as
mentioned on the electrode.
a) In Setting Mode select “P11” and press “OK” to select range.
b) Press “UP” or “DOWN” to select range and press“OK” to confirm.
c) Press “ESC” and Exit settings.
P12 - Standard Solution Selection (USA/NIST/CHINA)
This setting will select Standard Solution range as mentioned on the
electrode.
a) In Setting Mode select “P12” and press “OK” to select range.
b) Press “UP” or “DOWN” to select range and press “OK” to confirm.
c) Press “ESC” and Exit settings.
P13 - Temperature Compensation Coefficient
(Default = 2.00 % /Deg C)
This setting will enter Temperature Compensation Coefficient for Automatic
Temperature Compensation.
a) In Setting Mode select “P13” and press “OK” to enter value.
b) Press “UP” or “DOWN” to enter values, Press “LEFT” or “RIGHT” to
shift between variable.
c) Press “OK” to Confirm and “ESC” and Exit settings.
P14 - Datum Temperature Setting
This setting will select Datum Temperature (18 / 20 / 25) range as mentioned
on the electrode.
a) In Setting Mode select “P11” and press “OK” to select range (18 / 20
/ 25).
b) Press “UP” or “DOWN” to select range and press “OK” to confirm.
c) Press “ESC” and Exit settings.
