Endress+Hauser Cerabar S PMP72 User manual

BA271P/00/EN/05.10
71111792
valid from Software version:
02.10.zz
Operating Instructions
Cerabar S PMC71, PMP71, PMP72, PMP75
Process pressure measurement

Overview documentation Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART
2Endress+Hauser
Overview documentation
Device Documentation Content Remarks
Cerabar S
4 to 20 mA HART
Technical Information TI383P
(PMC71, PMP71, PMP75)
Technical Information TI438P
(PMP72)
Technical data
– The documentation is located on the supplied
documentation CD.
– The documentation is also available via the
Internet. See: www.endress.com 
Download
Operating Instructions BA271P – Identification
– Installation
– Wiring
– Operation
– Commissioning, Description of Quick Setup menus
– Maintenance
– Trouble-shooting and spare parts
– Appendix: Illustration of menu
Operating Instructions BA274P – Examples of configuration for pressure and level
measurement
– Description of parameters
– Trouble-shooting
– Appendix: Illustration of menu
Brief Operating Instructions
KA1019P
– Installation
– Wiring
– Operation on-site
– Commissioning
– Description of Quick Setup menus
Brief Operating Instructions
KA218P
– Wiring
– Operation without on-site
display
– Description of Quick Setup menus
– Operation HistoROM®/M-DAT
Functional Safety Manual
SD190P
– Safety function with Cerabar S
– Behaviour in operation and failure
– Commissioning and iterative tests
–Settings
– Technical safety characteristic quantities
– Management Summary
– The documentation is valid for devices
showing version "E" in feature 100 "Additional
options 1" or in feature 110 "Additional
options 2".
See also Technical Information TI383P,
chapter "Ordering information".

Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART Table of contents
Endress+Hauser 3
Table of contents
1 Safety instructions . . . . . . . . . . . . . . . . 4
1.1 Designated use . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Installation, commissioning and operation . . . . . . . . 4
1.3 Operational safety and process safety . . . . . . . . . . . . 4
1.4 Notes on safety conventions and icons . . . . . . . . . . . 5
2 Identification . . . . . . . . . . . . . . . . . . . . 6
2.1 Device designation . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.3 CE mark, declaration of conformity . . . . . . . . . . . . . 9
2.4 Registered trademarks . . . . . . . . . . . . . . . . . . . . . . . 9
3 Installation . . . . . . . . . . . . . . . . . . . . . 10
3.1 Incoming acceptance and storage . . . . . . . . . . . . . . 10
3.2 Installation conditions . . . . . . . . . . . . . . . . . . . . . . 10
3.3 Installation instructions . . . . . . . . . . . . . . . . . . . . . 10
3.4 Post-installation check . . . . . . . . . . . . . . . . . . . . . . 19
4 Wiring . . . . . . . . . . . . . . . . . . . . . . . . 20
4.1 Connecting the device . . . . . . . . . . . . . . . . . . . . . . 20
4.2 Connecting the measuring unit . . . . . . . . . . . . . . . 22
4.3 Potential matching . . . . . . . . . . . . . . . . . . . . . . . . 26
4.4 Overvoltage protection (optional) . . . . . . . . . . . . . . 27
4.5 Post-connection check . . . . . . . . . . . . . . . . . . . . . . 27
5 Operation . . . . . . . . . . . . . . . . . . . . . . 28
5.1 On-site display (optional) . . . . . . . . . . . . . . . . . . . . 28
5.2 Operating elements . . . . . . . . . . . . . . . . . . . . . . . . 29
5.3 On-site operation –
on-site display not connected . . . . . . . . . . . . . . . . . 32
5.4 On-site operation –
on-site display connected . . . . . . . . . . . . . . . . . . . . 35
5.5 HistoROM®/M-DAT (optional) . . . . . . . . . . . . . . 37
5.6 Operation via HART handheld terminal . . . . . . . . . 41
5.7 FieldCare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.8 Locking/unlocking operation . . . . . . . . . . . . . . . . . 42
5.9 Factory setting (reset) . . . . . . . . . . . . . . . . . . . . . . 43
6 Commissioning. . . . . . . . . . . . . . . . . . 45
6.1 Function check . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
6.2 Selecting language and measuring mode . . . . . . . . 45
6.3 Position adjustment . . . . . . . . . . . . . . . . . . . . . . . . 47
6.4 Pressure measurement . . . . . . . . . . . . . . . . . . . . . . 48
6.5 Level measurement . . . . . . . . . . . . . . . . . . . . . . . . 50
7 Maintenance. . . . . . . . . . . . . . . . . . . . 54
7.1 Exterior cleaning . . . . . . . . . . . . . . . . . . . . . . . . . 54
8 Trouble-shooting . . . . . . . . . . . . . . . . 55
8.1 Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
8.2 Response of outputs to errors . . . . . . . . . . . . . . . . . 62
8.3 Confirming messages . . . . . . . . . . . . . . . . . . . . . . . 64
8.4 Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
8.5 Repair of Ex-certified devices . . . . . . . . . . . . . . . . . 65
8.6 Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
8.7 Returning the device . . . . . . . . . . . . . . . . . . . . . . . 67
8.8 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
8.9 Software history . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
9 Technical data . . . . . . . . . . . . . . . . . . . 70
10 Appendix. . . . . . . . . . . . . . . . . . . . . . . 70
10.1 Operating menu for on-site display, FieldCare and HART
handheld terminal . . . . . . . . . . . . . . . . . . . . . . . . . 70
10.2 Patents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Safety instructions Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART
4Endress+Hauser
1 Safety instructions
1.1 Designated use
The Cerabar S is a pressure transmitter for measuring pressure and level.
The manufacturer accepts no liability for damages resulting from incorrect use or use other than that
designated.
1.2 Installation, commissioning and operation
The device has been designed to operate safely in accordance with current technical, safety and EU
standards. If installed incorrectly or used for applications for which it is not intended, however, it is
possible that application-related dangers may arise, e.g. product overflow due to incorrect
installation or calibration. For this reason, the instrument must be installed, connected, operated
and maintained according to the instructions in this manual: personnel must be authorised and
suitably qualified. The manual must have been read and understood, and the instructions followed.
Modifications and repairs to the device are permissible only when they are expressly approved in
the manual. Pay particular attention to the technical data on the nameplate.
1.3 Operational safety and process safety
Alternative monitoring measures must be taken to ensure operational safety and process safety
during configuration, testing and maintenance work on the device.
1.3.1 Hazardous areas (optional)
Devices for use in hazardous areas are fitted with an additional nameplate (see Page 6). If the
device is to be installed in an explosion hazardous area, then the specifications in the certificate as
well as all national and local regulations must be observed. The device is accompanied by separate
"Ex documentation", which is an integral part of this Operating Instructions. The installation
regulations, connection values and Safety Instructions listed in this Ex document must be observed.
The documentation number of the related Safety Instructions is also indicated on the additional
nameplate.
• Ensure that all personnel are suitably qualified.
1.3.2 Functional Safety SIL3 (optional)
If using devices for applications with safety integrity, the Functional Safety Manual (SD190P) must
be observed thoroughly.

Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART Safety instructions
Endress+Hauser 5
1.4 Notes on safety conventions and icons
In order to highlight safety-relevant or alternative operating procedures in the manual, the following
conventions have been used, each indicated by a corresponding icon in the margin.
Symbol Meaning
#Warning!
A warning highlights actions or procedures which, if not performed correctly, will lead to personal
injury, a safety hazard or destruction of the instrument.
"Caution!
Caution highlights actions or procedures which, if not performed correctly, may lead to personal
injury or incorrect functioning of the instrument.
!Note!
A note highlights actions or procedures which, if not performed correctly, may indirectly affect
operation or may lead to an instrument response which is not planned.
0Device certified for use in explosion hazardous area
If the device has this symbol embossed on its nameplate, it can be installed in an explosion
hazardous area or a non-explosion hazardous area, according to the approval.
-Explosion hazardous area
Symbol used in drawings to indicate explosion hazardous areas.
– Devices used in hazardous areas must possess an appropriate type of protection.
.
Safe area (non-explosion hazardous area)
Symbol used in drawings to indicate, if necessary, non-explosion hazardous areas.
– Devices used in hazardous areas must possess an appropriate type of protection. Lines used in
hazardous areas must meet the necessary safety-related characteristic quantities.
%Direct voltage
A terminal to which or from which a direct current or voltage may be applied or supplied.
&Alternating voltage
A terminal to which or from which an alternating (sine-wave) current or voltage may be applied
or supplied.
)Grounded terminal
A grounded terminal, which as far as the operator is concerned, is already grounded by means of
an earth grounding system.
*Protective grounding (earth) terminal
A terminal which must be connected to earth ground prior to making any other connection to the
equipment.
+Equipotential connection (earth bonding)
A connection made to the plant grounding system which may be of type e.g. neutral star or
equipotential line according to national or company practice.
Safety instruction
For safety instructions refer to the manual for the appropriate instrument version.

Identification Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART
6Endress+Hauser
2 Identification
2.1 Device designation
2.1.1 Nameplate
!Note!
• The MWP (maximum working pressure) is specified on the nameplate. This value refers to a
reference temperature of 20°C (68°F) or 100°F (38 °C) for ANSI flanges.
• The pressure values permitted at higher temperatures can be found in the following standards:
– EN 1092-1: 2001 Tab. 18 1)
– ASME B 16.5a – 1998 Tab. 2-2.2 F316
– ASME B 16.5a – 1998 Tab. 2.3.8 N10276
– JIS B 2220
• The test pressure corresponds to the over pressure limit (OPL) of the device = MWP x 1.5 2).
• The Pressure Equipment Directive (EC Directive 97/23/EC) uses the abbreviation "PS". The
abbreviation "PS" corresponds to the MWP (maximum working pressure) of the measuring
device.
Aluminium and stainless steel housing (T14)
P01-PMx7xxxx-18-xx-xx-xx-001
Fig. 1: Nameplate for Cerabar S
1 Order code
See the specifications on the order confirmation for the meanings of the individual letters and digits.
2 Serial number
3 Degree of protection
4 MWP (Maximum working pressure)
5 Symbol: Note: pay particular attention to the data in the "Technical Information"!
6 Minimum/maximum span
7 Nominal measuring range
8 Electronic version (output signal)
9 Supply voltage
10 Wetted materials
11 ID number of notified body with regard to Pressure Equipment Directive (optional)
12 ID number of notified body with regard to ATEX (optional)
13 GL-symbol for GL marine certificate (optional)
14 SIL-symbol for devices with SIL3/IEC 61508 Declaration of conformity (optional)
15 Layout identification of the nameplate
1) With regard to their stability-temperature property, the materials 1.4435 and 1.4404 are grouped together under 13EO
in EN 1092-1 Tab. 18. The chemical composition of the two materials can be identical.
2) The equation does not apply for PMP71 and PMP75 with a 40 bar (600 psi) or a 100 bar (1500 psi) measuring cell.
Mat.
MWP
Span
Ser.-No.:
Order Code:
P
U=
Cerabar S
Made in Germany,
D-79689 Maulburg
1
23
456
7
8 9
10 11
12
14
13 15 14
26
23,5
2,5
55
R1
2,1 -0,1

Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART Identification
Endress+Hauser 7
Devices for use in hazardous areas are fitted with an additional nameplate.
P01-xMD7xxxx-18-xx-xx-xx-002
Fig. 2: Additional nameplate for devices for hazardous areas
1 EC type examination certificate number
2 Type of protection e.g. II 1/2 G EEx ia IIC T4/T6
3 Electrical data
4 Safety Instructions number e.g. XA235P
5 Safety Instructions index e.g. A
6 Device manufacture data
Devices suitable for oxygen applications are fitted with an additional nameplate.
P01-xxxxxxxx-18-xx-xx-xx-000
Fig. 3: Additional nameplate for devices suitable for oxygen applications
1 Maximum pressure for oxygen applications
2 Maximum temperature for oxygen applications
3 Layout identification of the nameplate
Dat.:
3
6
5
1
2
4
Pmax
Tmax
for oxygen service
Bei Sauerstoffeinsatz/
3
12

Identification Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART
8Endress+Hauser
Hygenic stainless steel housing (T17)
P01-PMx7xxxx-18-xx-xx-xx-003
Fig. 4: Nameplate for Cerabar S
1 Order code
See the specifications on the order confirmation for the meanings of the individual letters and digits.
2 Serial number
3 MWP (Maximum working pressure)
4 Symbol: Note: pay particular attention to the data in the "Technical Information"!
5 Minimum/Maximum span
6 Nominal measuring range
7 Electronic version (output signal)
8 Supply voltage
9 Wetted materials
10 Degree of protection
Optional:
11 ID number of notified body with regard to Pressure Equipment Directive
12 ID number of notified body with regard to ATEX
13 3A-symbol
14 CSA-symbol
15 FM-symbol
16 SIL-symbol for devices with SIL3/IEC 61508 Declaration of conformity
17 GL-symbol for GL marine certificate
18 Ex-symbol
19 EC type examination certificate
20 Type of protection e.g. II 1/2 G EEx ia IIC T4/T6
21 Approval number for WHG overspill protection
22 Temperature operating range for devices for use in hazardous areas
23 Electrical data for devices for use in hazardous areas
24 Safety Instructions number e.g. XA283P
25 Safety Instructions index e.g. A
26 Device manufacture data
27 Maximum temperature for devices suitable for oxygen applications
28 Maximum pressure for devices suitable for oxygen applications
2.1.2 Identifying the sensor type
See parameter "Sensor Meas.Type" in Operating Instruction BA274P. The Operating Instruction
BA274P can be found on the supplied documentation CD.
15 Pmax
Tmax
Bei Sauerstoffeinsatz/for oxygen service:
Cerabar S
Made in Germany, D-79689 Maulburg
Order Code:
Ser.-No.:
MWP
Span
p
U=
Mat.
12
34
6
78
9
10
11
12 13 14
5
16
17
-
Dat.:
18
19
21
20
22
23
24 25
26
27 28

Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART Identification
Endress+Hauser 9
2.2 Scope of delivery
The scope of delivery comprises:
• Cerabar S pressure transmitter
• For devices with the "HistoROM/M-DAT" option:
CD-ROM with Endress+Hauser operating program and documentation
• Optional accessories
Documentation supplied:
• The Operating Instructions BA271P and BA274P, the Technical Information TI383P and the
Safety Instructions, Functional Safety Manual and brochures can be found on the supplied
documentation CD.
See also Page 2, "Overview documentation" chapter.
• Brief Operating Instructions KA1019P
• Leporello KA218P
• Final inspection report
• Also Safety Instructions with ATEX, IECEx and NEPSI devices
• Optional: factory calibration form, test certificates
2.3 CE mark, declaration of conformity
The device is designed to meet state-of-the-art safety requirements, has been tested and left the
factory in a condition in which it is safe to operate. The device complies with the applicable
standards and regulations as listed in the EC declaration of conformity and thus complies with the
statutory requirements of the EC Directives. Endress+Hauser confirms the successful testing of the
device by affixing to it the CE mark.
2.4 Registered trademarks
KALREZ, VITON, TEFLON
Registered trademarks of E.I. Du Pont de Nemours & Co., Wilmington, USA
TRI-CLAMP
Registered trademark of Ladish & Co., Inc., Kenosha, USA
HART
Registered trademark of the HART Communication Foundation, Austin, USA.
GORE-TEX®
Registered trademark of W.L. Gore & Associates, Inc., USA

Installation Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART
10 Endress+Hauser
3 Installation
3.1 Incoming acceptance and storage
3.1.1 Incoming acceptance
• Check the packaging and the contents for damage.
• Check the shipment, make sure nothing is missing and that the scope of supply matches your
order.
3.1.2 Storage
The device must be stored in a dry, clean area and protected against damage from impact
(EN 837-2).
Storage temperature range:
• PMC71, PMP71, PMP75:
– –40 to +90°C (–40 to +194°F)
– On-site display: –40 to +85°C (–40 to +185°F)
– Separate housing: –40 to +60°C (–40 to +140°F)
• PMP72:
– see TI438P
3.2 Installation conditions
3.2.1 Dimensions
For dimensions, please refer to the Technical Information for Cerabar S TI383P (PMC71,
PMP71, PMP75); TI438P (PMP72), "Mechanical construction" section. See Page 2, "Overview
documentation".
3.3 Installation instructions
!Note!
• Due to the orientation of the Cerabar S, there may be a shift in the measured value, i.e. when the
container is empty, the measured value does not display zero. You may correct this zero point
shift either directly on the device using the "E"-key or by remote operation. See Page 30,
Section 5.5.2 "Function of the operating elements – on-site display not connected" or Page 47,
Section 6.3 "Position adjustment".
• For PMP75, please refer to Section 3.3.2 "Installation instructions for devices with diaphragm
seals – PMP75", Page 13.
• To ensure optimal readability of the on-site display, it is possible to rotate the housing up to 380°.
See Page 19, Section 3.3.5 "Rotating the housing".
• Endress+Hauser offers a mounting bracket for installing on pipes or walls. See Page 16, Section
3.3.4 "Wall and pipe mounting".

Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART Installation
Endress+Hauser 11
3.3.1 Installation instructions for devices without diaphragm seals –
PMP71, PMP72, PMC71
!Note!
• If a heated Cerabar S is cooled during the cleaning (e.g. by cold water), a vacuum develops for a
short time, whereby water can penetrate the sensor through the pressure compensation (1). If this
is the case, mount the sensor with the pressure compensation (1) pointing downwards.
• Keep the pressure compensation and GORE-TEX®filter (1) free from contaminations and water.
• Cerabar S without diaphragm seal are mounted as per the norms for a manometer
(DIN EN 837-2). We recommend the use of shut-off devices and siphons. The orientation
depends on the measuring application.
• Do not clean or touch process isolating diaphragm seals with hard or pointed objects.
Pressure measurement in gases
P01-PMx7xxxx-11-xx-xx-xx-001
Fig. 5: Measuring arrangement for pressure measurement in gases
1 Cerabar S
2 Shut-off device
• Mount Cerabar S with shut-off device above the tapping point so that any condensate can flow
into the process.
1
1
1
FIELD TERMINALSFIELD TERMINALS
FIELD TERMINALSFIELD TERMINALS
➀
➁

Installation Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART
12 Endress+Hauser
Pressure measurement in steams
P01-PMx7xxxx-11-xx-xx-xx-002
Fig. 6: Measuring arrangement for pressure measurement in steams
1 Cerabar S
2 Shut-off device
3 U-shaped siphon
4 Circular siphon
• Mount Cerabar S with siphon below the tapping point.
The siphon reduces the temperature to almost ambient temperature.
• Fill the siphon with fluid before commissioning.
Pressure measurement in liquids
P01-PMx7xxxx-11-xx-xx-xx-003
Fig. 7: Measuring arrangement for pressure measurement in liquids
1 Cerabar S
2 Shut-off device
• Mount Cerabar S with shut-off device below or at the same level as the tapping point.
➂
➀
➁
➃
➀
➁
➀
➁

Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART Installation
Endress+Hauser 13
Level measurement
P01-PMP75xxx-11-xx-xx-xx-000
Fig. 8: Measuring arrangement for level
• Mount Cerabar S below the lowest measuring point.
• Do not mount the device at the following positions:
In the fill flow, in the tank outlet or at a point in the container which could be affected by pressure
pulses from an agitator.
• Do not mount the device in the suction area of a pump.
• The calibration and functional test can be carried out more easily if you mount the device after a
shut-off device.
PVDF adapter
!Note!
For instruments with PVDF adapter, a maximum torque of 7 Nm (5.16 lbs ft) is permitted. The
thread connection may become loose at high temperatures and pressures. This means that the
integrity of the thread must be checked regularly and may need to be tightened using the torque
given above. Teflon tape is recommended for sealing with the 1/2 NPT thread.
3.3.2 Installation instructions for devices with diaphragm seals –
PMP75
!Note!
• The Cerabar S with diaphragm seal is screwed in, flanged or clamped, depending on the type of
diaphragm seal.
• The diaphragm seal and the pressure sensor together form a closed an calibrated system which is
filled with filling fluid through a hole in the upper part. This hole is sealed and not to be opened.
• Do not clean or touch process isolating diaphragm of the diaphragm seals with hard or pointed
objects.
• Do not remove the protection of the process isolating diaphragm until shortly before installation.
• When using a mounting bracket, sufficient strain relief must be ensured for the capillaries in order
to prevent the capillary bending down (bending radius 100 mm (3.94 in)).
• Please note that the hydrostatic pressure of the liquid columns in the capillaries can cause zero
point shift. The zero point shift can be corrected. See also Page 47, Section 6.3 "Position
adjustment".
• Please note the application limits of the diaphragm seal filling oil as detailed in the Technical
Information for Cerabar S TI383P, Section "Planning instructions for diaphragm seal systems". 
See also Page 2, "Overview documentation".
In order to obtain more precise measurement results and to avoid a defect in the device, mount the
capillaries as follows:
• vibration-free (in order to avoid additional pressure fluctuations)
• not in the vicinity of heating or cooling lines
• insulate if the ambient temperature is below ore above the reference temperature
• with a bending radius of 100 mm (3.94 in).

Installation Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART
14 Endress+Hauser
Vacuum application
For applications under vacuum, Endress+Hauser recommends mounting the pressure transmitter
underneath the diaphragm seal. A vacuum load of the diaphragm seal caused by the presence of
filling oil in the capillaries is hereby prevented.
When the pressure transmitter is mounted above the diaphragm seal, the maximum height
difference H1 in accordance with the illustration below on the left must not be exceeded. The
maximum height difference is dependent on the density of the filling oil and the smallest ever
pressure that is permitted to occur at the diaphragm seal (empty container), see illustration below,
on the right.
Mounting with temperature isolator
P01-PMx7xxxx-11-xx-xx-xx-005
Endress+Hauser recommends the use of temperature separators in the event of constant extreme
fluid temperatures which lead to the maximum permissible electronics temperature of +85°C
(+185°F) being exceeded. To minimise the influence of rising heat, Endress+Hauser recommends
the device be mounted horizontally or with the housing pointing downwards.
The additional installation height also brings about a zero point shift of approx. 21 mbar (0.315 psi)
due to the hydrostatic columns in the temperature isolator. You can correct this zero point shift. 
See also Page 30, Section 5.2.2 "Function of the operating elements – on-site display not connected"
or
Page 47, Section 6.3 "Position adjustment".
P01-PMx7xxxx-11-xx-xx-xx-008
Fig. 9: Installation above the diaphragm
seal
P01-PMP75xxx-05-xx-xx-xx-011
Fig. 10: Diagram of maximum installation height above the
diaphragm seal for vacuum applications dependent on
the pressure at the diaphragm seal
H1
FIELDTERMINALSFIELDTERMINALS
0.0
2.0
4.0
6.0
8.0
10.0
12.0
50 100 300 400 500 600 700 800 900 1000
200
Inert oil
Hightemperature
oil
Vegetableoil
Silicone oil
Pressure at diaphragm seal[mbarabs]
HeightdifferenceH1[m]
Lowtemperature oil
max. 115

Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART Installation
Endress+Hauser 15
3.3.3 Seal for flange mounting
P01-FMD7xxxx-11-xx-xx-xx-002
Fig. 11: Mounting the versions with flange or diaphragm seal
1 Process isolating diaphragm
2Seal
#Warning!
The seal is not allowed to press on the process isolating diaphragm as this could affect the
measurement result.
➁➀

Installation Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART
16 Endress+Hauser
3.3.4 Installation with heat insulation – PMC71 high temperature
version and PMP72/PMP75
The devices must only be insulated up to a certain height. The maximum permitted insulation
height is labelled on the devices and applies to an insulation material with a specific heat
conductivity and to the maximum permitted ambient and process temperature (see following
table). The data were determined under the most critical application "quiescent air".
P01-PMx7xxxx-11-xx-xx-xx-010
Fig. 12: Maximum insulation height, here e.g. PMC71 with flange
3.3.5 Wall and pipe-mounting (optional)
Endress+Hauser offers a mounting bracket for installing on pipes or walls.
P01-xMx5xxxx-06-xx-xx-xx-001
Please note the following when mounting:
• Devices with capillary lines: mount capillaries with a bending radius of 100 mm (3.94 in).
• In the case of pipe mounting, the nuts on the bracket must be tightened uniformly with a torque
of at least 5 Nm (3.69 lbs ft).
T
A
T
P
Insulation
material
PMC71 PMP75 PMP72
Ambient temperature (TA)70°C (158°F) 70°C (158°F) 50°C (122°F)
Process temperature (TP)150°C (302°F) 400°C (752°F) 1)
1) Depending on the diaphragm seal filling oil used (see Technical Information TI383P Cerabar S)
280 °C (536°F)
Heat conductivity
Insulation material 0,04 W/(m x K)
at 100°C (212°F): 0,04 W/(m x K)
at 300°C (572°F): linearly increasing to
0,072 W/(m x K)
52
133
119
70

Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART Installation
Endress+Hauser 17
3.3.6 Assembling and mounting the "separate housing" version
P01-PMx7xxxx-11-xx-xx-xx-011
Fig. 13: "Separate housing" version
1 In the "separate housing" version, the sensor is supplied with process connection and cable fitted.
2 Cable with connection jack
3 Pressure compensation
4Plug
5Lockingscrew
6 Housing fitted with housing adapter, included
7 Mounting bracket suitable for wall and pipe mounting, included
Assembly and mounting
1. Connect plug (item 4) into the corresponding connection jack of the cable (item 2).
2. Plug the cable into the housing adapter (item 6).
3. Tighten the locking screw (item 5).
4. Mount the housing on a wall or pipe using the mounting bracket (item 7). When mounting
on a pipe, tighten the nuts on the bracket uniformly with a torque of at least 5 Nm (3.69 lbs ft).
Mount the cable with a bending radius (r) 120 mm (4.72 in).
r³120 mm
1
2
3
4
5
6
7

Installation Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART
18 Endress+Hauser
3.3.7 PMP71, version prepared for diaphragm seal mount –
welding recommendation
P01-PMP71xxx-11-xx-xx-xx-000
Fig. 14: Version U1: prepared for diaphragm seal mount
1 Hole for filling fluid
2Bearing
3 Threaded pin
A1 see the following table "Welding recommendation"
Welding recommendation
For the "U1 Prepared for diaphragm seal mount" version in feature 70 "Process connection;
Material" in the order code of up to including 40 bar (600 psi)-sensors, Endress+Hauser
recommends welding on the diaphragm seal as follows: the total welding depth of the fillet weld is
1 mm (0.04 in) at an external diameter of 16 mm (0.63 in). Welding is performed according to the
WIG method.
ø2.5
5
➀➂➁
ø7.95
A1
Consecutive
seam no.
Sketch/welding groove
shape, dimension as per
DIN 8551
Base material
matching
Welding
process
DIN EN
ISO 24063
Welding
position
Inert gas,
additives
A1
for sensors
40 bar
(600 psi)
P01-PMP71xxx-11-xx-xx-xx-001
Adapter made of
1.4435 (AISI 316L)
to be welded to
diaphragm seal made of
1.4435 or 1.4404
(AISI 316L)
141 PB Inert gas
Ar/H 95/5
Additive:
1.4430
(ER 316L Si)
s1 a0.8

Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART Installation
Endress+Hauser 19
3.3.8 Rotating the housing
The housing can be rotated up to 380° by loosening the Allen screw.
P01-PMx7xxxx-17-xx-xx-xx-000
Fig. 15: Aligning the housing
– T14 and T15 housing: Loosen setscrew with a 2 mm (0.08 in) Allen key.
Hygenic T17 housing:Loosen setscrew with a 3 mm (0.12 in) Allen key.
– Rotate housing (max. up to 380°).
– Retighten setscrew.
3.3.9 Close cover on a hygenic stainless steel housing (T17)
P01-PMD75xxx-17-xx-xx-xx-000
Fig. 16: Close cover
The covers for the terminal and electronics compartment are hooked into the casing and closed with
a screw. These screws should be finger-tightened (2 Nm (1.48 lbf ft)) to the stop to ensure that the
covers sit tightly.
3.4 Post-installation check
After installing the device, carry out the following checks:
• Are all screws firmly tightened?
• Are the housing covers screwed down tight?
FIELD TERMINALSFIELD TERMINALS
max. 380°

Wiring Cerabar S PMC71, PMP71, PMP72, PMP75 with 4...20 mA HART
20 Endress+Hauser
4 Wiring
4.1 Connecting the device
!Note!
• When using the measuring device in hazardous areas, installation must comply with the
corresponding national standards and regulations and the Safety Instructions or Installation or
Control Drawings.
• Devices with integrated overvoltage protection must be earthed.
• Protective circuits against reverse polarity, HF influences and overvoltage peaks are installed.
• The supply voltage must match the supply voltage on the nameplate. (See also Page 6, Section
2.1.1 Nameplate.)
• Switch off the supply voltage before connecting the device.
• Remove housing cover of the terminal compartment.
• Guide cable through the gland. Preferably use twisted, screened two-wire cable.
• Connect device in accordance with the following diagram.
• Screw down housing cover.
• Switch on supply voltage.
P01-xMx7xxxx-04-xx-xx-xx-001
Fig. 17: Electrical connection 4...20 mA HART
Observe also Section 4.2.1 "Supply voltage", Page 22.
1 Housing
2 Jumper for 4...20 mA test signal.
See also Page 22, Section 4.2.1, "Taking 4...20 mA test signal" part.
3 Internal earth terminal
4 External earth terminal
5 4...20 mA test signal between plus and test terminal
6 Minimum supply voltage = 10.5 V DC, jumper is inserted in accordance with the illustration.
7 Minimum supply voltage = 11.5 V DC, jumper is inserted in "Test" position.
8 Devices with integrated overvoltage protection are labelled OVP (overvoltage protection) here.
4…20 mA
➅10.5 V DC
➆11.5VDC
4... 20mA Test
Test
➀
➁
➂
➃
➄
Test
➇
4... 20mA Test
