Aquatic SERENITY STUDIO 23 User manual

91
SPECIFICATIONS:
The manufacturer accepts a 1/4” variance. There are variations on each tub and specifications are subject to change as we improve upon our product as required. The dimensions needed for site preparation
and structure building should be measured from the tub; Aquatic Industries, Inc. assumes no responsibility for preparatory work. www.aquaticwhirlpools.com 800.555.5324
February 2008
Rough-In Plumbing
Measurements
SErENITy STudIO 23
SErENITy STudIO MODEL # AI23AIR7242F / AI23AIR7242FTO (Tub Only)
GENERAL SPECIFICATIONS:
Tub Size 71 1/4” x 41 1/2” x 25 1/2”
181 cm x 105 cm x 65 cm
Bathing Well 48 1/2” long
24 1/2” wide
21 3/4” interior depth
Maximum Water Depth 17 3/4”
Shipping Weight 303 lbs. / 138 kg
Tub Weight Filled 1351lbs. / 614 kg
Tub Weight Only 228 lbs. / 104 kg
Gallons to Overow 113 gal. / 618 L
ELECTRICAL SPECIFICATIONS:
Blower/Heater 1 HP; 10.5 AMP; 120V
Requirement 15 AMP; 120V, separate circuit
required protected w/ Class A GFCI
Each Serenity Studio model is equipped with a 600 watt air heating system to raise the temperature of the air going into the bath. This air tem-
perature will be less than the bathing temperature of the water, but will help to reduce a rapid decrease in water temperature. In addition, the air
coming from the air jets will feel cool against the skin, just as a breeze on a warm day cools your body. This system does not heat the water.
Deck Width
4 1/2”
41 1/2”
Deck Width 4”
48 1/2”
24 1/2”
Deck Width 4”
Back Angle 22º
41 1/2”
22 1/2”
26”
Fax-On-Demand
Document # 1003
Air Bath System:
- 84 Air Jets
- 1 HP Variable Speed Remote Air Blower with 20-Minute Timer
- 600 Watt Air Heating System
- Electronic Control Package with Wave and Pulse Features
- Automatic Purge and Dry Cycle
- Waterproof Remote Control with Infrared Sensor and 25’ cord
Aquatic Quality Features:
- Slip Resistant Floor
- Air Channels Lined with Antimicrobial Coating
- Extra Deep Bathing Well
- Durable, Easy to Clean, Lucite® Cast Acrylic Surface
- Available in 8 Standard No-Charge Colors
UL & IAPMO Listed, Factory Tested
Limited Lifetime Warranty
STANDARD EQUIPMENT: • Comfort Pillow - Oval or Rectangle
• Waste and Overow for Freestanding Models
- Chrome, Polished Brass, Satin Nickel,
Polished Nickel, Oil Rubbed Bronze or White
• Premium Colors
All acrylic colors featured by Aquatic match the
industry’s leading xture manufacturers.
OPTIONAL EQUIPMENT:
71 1/4”
3 1/4”
55”
25 1/2”
23 3/4”
3 1/2”
12 1/2”
Note: The interior of bathing well and outside of bathing well can each
be specied in a different color. Only one premium color upcharge will be
applied if one or more premium colors are used.
Note: This model requires a remote blower location. The connection for the
air blower is under the tub; the blower may be placed up to 15 feet away
and connected by piping under the oor. Please refer to the Owner’s Manual
for detailed installation instructions. Document #1184 on our Fax-on Demand
System or on our website at www.aquaticwhirlpools.com.
