Arbor Technology ELIT-1060 User manual

I
ELIT-1060
Digital Signage Player Powered by
Intel®Celeron®N6210 Processor
User’s Manual
Version 1.0
2023.03
P/N: 4016106000100P

- II -
Revision History
Version Date Description
1.0 2023.03 Initial release

- i -
Contents
Revision History ................................................................................II
Contents..............................................................................................i
Preface...............................................................................................iii
Copyright Notice .....................................................................................iii
Declaration of Conformity .......................................................................iii
CE....................................................................................................iii
FCC Class A ....................................................................................iii
RoHS .............................................................................................. iv
SVHC / REACH .............................................................................. iv
Important Safety Instructions .................................................................. v
Warning.................................................................................................. vi
Lithium Battery Replacement................................................................. vi
Technical Support .................................................................................. vi
Warranty.................................................................................................vii
Chapter 1 - Introduction....................................................................1
1.1. Features...........................................................................................2
1.2. About this Manual ...........................................................................2
1.3. Specications...................................................................................3
1.4. Inside the Package ..........................................................................4
1.5. Ordering Information ........................................................................5
1.5.1. Congure-to-Order Service.................................................... 5
Chapter 2 - Getting Started...............................................................7
2.1. Dimensions ......................................................................................8
2.2. Overview ..........................................................................................9
2.3. Driver Installation Note................................................................... 10
Chapter 3 - Engine of the Computer.............................................. 11
3.1. Board Layout..................................................................................12
3.1.1. Internal Diagram-Top Side: ..................................................12
3.1.2. Internal Diagram-Bottom Side: ............................................13
3.1.3. Connectors ..........................................................................13
3.1.4. Headers ...............................................................................14
3.1.5. Jumper.................................................................................14
3.1.6. Jumper Setting.....................................................................15
3.1.7. Pin Denition........................................................................17
3.1.8. Maximum Voltage & Current Limit ....................................... 20
Chapter 4 - Installation and Maintenance......................................21
4.1. Access the Inside of the Computer ................................................22
4.1.1. Disassemble the Computer .................................................22
4.1.2. Reassemble the Computer ..................................................24
Contents

- ii -
Contents
4.2. Install Hardware .............................................................................24
4.2.1. Install M.2 M-key Storage ....................................................24
4.2.2. Install Wi-Fi Module .............................................................26
4.2.3. Install Memory Module......................................................... 30
4.3 Mount the Computer .......................................................................32
4.3.1 ELIT-1060 Wall Mounting .....................................................32
4.3.2 ELIT-1060 DIN Rail Mounting ............................................... 33
Chapter 5 - BIOS..............................................................................35
5.1. Main ...............................................................................................38
5.2. Advanced .......................................................................................39
5.2.1. CPU Conguration...............................................................40
5.2.2. Intel(R) Time Coordinated Computing ................................. 42
5.2.3. Trusted Computing .............................................................. 43
5.2.4. ACPI Settings.......................................................................44
5.2.5. Super IO Conguration ........................................................45
5.2.6 Serial Port Console Redirection............................................ 47
5.2.7. PC Health Status .................................................................49
5.2.8. USB Conguration ...............................................................50
5.2.9. Network Stack Conguration ...............................................52
5.2.10. NVMe Conguration ..........................................................53
5.2.11. Wake-up Function Settings ................................................ 54
5.2.12. PTT Conguration.............................................................. 56
5.3. Chipset...........................................................................................57
5.3.1. System Agent (SA) Conguration ........................................ 58
5.3.2. PCH-IO Conguration..........................................................59
5.4. Security ..........................................................................................61
5.5. Boot................................................................................................63
5.6. Save & Exit ....................................................................................64

- iii -
Preface
Copyright Notice
All Rights Reserved.
The information in this document is subject to change without prior notice in
order to improve the reliability, design and function. It does not represent a
commitment on the part of the manufacturer.
Under no circumstances will the manufacturer be liable for any direct, indirect,
special, incidental, or consequential damages arising from the use or inability
to use the product or documentation, even if advised of the possibility of such
damages.
This document contains proprietary information protected by copyright. All rights
are reserved. No part of this document may be reproduced by any mechanical,
electronic, or other means in any form without prior written permission of the
manufacturer.
Declaration of Conformity
CE
The CE symbol on your product indicates that it is in compliance with the
directives of the Union European (EU). A Certicate of Compliance is available
by contacting Technical Support.
This product has passed the CE test for environmental specications when
shielded cables are used for external wiring. We recommend the use of shielded
cables. This kind of cable is available from ARBOR. Please contact your local
supplier for ordering information.
Warning
This is a class B product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.

- iv -
Preface
NOTE:
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense.
RoHS
ARBOR Technology Corp. certies that all components in its products are
in compliance and conform to the European Union’s Restriction of Use of
Hazardous Substances in Electrical and Electronic Equipment (RoHS) Directive
2002/95/EC.
The above mentioned directive was published on 2/13/2003. The main purpose
of the directive is to prohibit the use of lead, mercury, cadmium, hexavalent
chromium, polybrominated biphenyls (PBB), and polybrominated diphenyl
ethers (PBDE) in electrical and electronic products. Member states of the EU are
to enforce by 7/1/2006.
ARBOR Technology Corp. hereby states that the listed products do not contain
unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed
a maximum concentration value of 0.1% by weight or for cadmium exceed
0.01% by weight, per homogenous material. Homogenous material is dened as
a substance or mixture of substances with uniform composition (such as solders,
resins, plating, etc.). Lead-free solder is used for all terminations (Sn(96-96.5%),
Ag(3.0-3.5%) and Cu(0.5%)).
SVHC / REACH
To minimize the environmental impact and take more responsibility to the earth
we live, Arbor hereby conrms all products comply with the restriction of SVHC
(Substances of Very High Concern) in (EC) 1907/2006 (REACH --Registration,
Evaluation, Authorization, and Restriction of Chemicals) regulated by the
European Union.
All substances listed in SVHC < 0.1 % by weight (1000 ppm)

- v -
Preface
Important Safety Instructions
Read these safety instructions carefully
1. Read all cautions and warnings on the equipment.
2. Place this equipment on a reliable surface when installing. Dropping it or
letting it fall may cause damage
3. Make sure the correct voltage is connected to the equipment.
4. For pluggable equipment, the socket outlet should be near the equipment
and should be easily accessible.
5. Keep this equipment away from humidity.
6. The openings on the enclosure are for air convection and protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
7. Position the power cord so that people cannot step on it. Do not place
anything over the power cord.
8. Never pour any liquid into opening. This may cause re or electrical shock.
9. Never open the equipment. For safety reasons, the equipment should be
opened only by qualied service personnel.
10. If one of the following situations arises, get the equipment checked by
service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work according
to the user’s manual.
e. The equipment has been dropped or damaged.
f. The equipment has obvious signs of breakage.
11. Keep this User’s Manual for later reference.

- vi -
Preface
Warning
The Box PC and its components contain very delicately Integrated Circuits (IC).
To protect the Box PC and its components against damage caused by static
electricity, you should always follow the precautions below when handling it:
1. Disconnect your Box PC from the power source when you want to work on
the inside.
2. Use a grounded wrist strap when handling computer components.
3. Place components on a grounded antistatic pad or on the bag that came
with the Box PC, whenever components are separated from the system.
Lithium Battery Replacement
Incorrect replacement of the lithium battery may lead to a risk of explosion.
The lithium battery must be replaced with an identical battery or a battery type
recommended by the manufacturer.
Do not throw lithium batteries into the trash can. It must be disposed of in
accordance with local regulations concerning special waste.
Technical Support
If you have any technical difculties, please consult the user’s manual rst at:
http://www.arbor-technology.com
Please do not hesitate to call or e-mail our customer service when you still cannot
nd out the answer.
http://www.arbor-technology.com
E-mail:[e-mail]

- vii -
Preface
Warranty
This product is warranted to be in good working order for a period of one year
from the date of purchase. Should this product fail to be in good working order
at any time during this period, we will, at our option, replace or repair it at no
additional charge except as set forth in the following terms. This warranty does
not apply to products damaged by misuse, modications, accident or disaster.
Vendor assumes no liability for any damages, lost prots, lost savings or any
other incidental or consequential damage resulting from the use, misuse of, or
inability to use this product. Vendor will not be liable for any claim made by any
other related party.
Vendors disclaim all other warranties, either expressed or implied, including but
not limited to implied warranties of merchantability and tness for a particular
purpose, with respect to the hardware, the accompanying product’s manual(s)
and written materials, and any accompanying hardware. This limited warranty
gives you specic legal rights.
Return authorization must be obtained from the vendor before returned
merchandise will be accepted. Authorization can be obtained by calling or faxing
the vendor and requesting a Return Merchandise Authorization (RMA) number.
Returned goods should always be accompanied by a clear problem description.

- viii -
This page is intentionally left blank.

- 1 -
1Chapter 1
Introduction
Chapter 1 - Introduction

- 2 -
Introduction
1.1. Features
• Fanless and Ultra Compact Design
• Intel® Celeron® N6210 (1.5M Cache, up to 2.60 GHz)
• Support Triple Display: 2 x HDMI, 1 x DisplayPort
• Onboard 32GB eMMC
• Dual 2.5Gb ethernet & Support TPM 2.0
• 1 x COM, 2 x USB3.2 (Gen.2), 1 x USB2.0, 2 x USB Type-C
• 1 x M.2 M-key, (2260/2280), 1 x M.2 E-key (2230)
• Supports Windows® 10 / Windows® 11
1.2. About this Manual
This manual is meant for the experienced users and integrators with hardware
knowledge of personal computers. If you are not sure about the description in
this manual, consult your vendor before further handling.
We recommend that you keep one copy of this manual for the quick reference
for any necessary maintenance in the future. Thank you for choosing ARBOR
products.

- 3 -
Introduction
1.3. Specications
System
CPU Soldered onboard Intel®Celeron®N6210, 1.20GHz
Memory 1 x 260 pin DDR4 SO-DIMM socket up to 32GB
(4GB DDR4 SO-DIMM pre-installed)
LAN Chipset 2 x Intel®i225V controller
Chipset SoC Integrated
Graphics Intel®UHD Graphics for 10th Gen Intel®Processors
ATA 1 x Serial ATA port with 600MB/s HDD transfer rate
Watchdog Timer 1~255 levels reset
TPM Support TPM 2.0
Storage
Type Onboard 32GB eMMC
1 x M.2 M-key (2260/2280, PCIe Gen.3 x2/SATA interface) support NVMe
Audio
Type Line-out/ MIC-in combo
Button
Button Power on/off button
Power System
Power Input DC 12V input by lockable DC Jack
Power
Consumption Typical 24W (w/o I/O cards)
Qualication
Certification CE, FCC Class A
I/O
Serial Port 1 x DB-9 connectors for RS232/422/485 (RI/5V/12V)
USB Ports
2 x Type-A USB 3.2 (Gen 2)
1 x Type-A USB 2.0
2 x Type-C USB 3.2 (Gen 2)
LAN 2 x RJ-45 ports for 2.5 GbE LAN
Video Ports 1 x DP (Max Resolution: 4096x2160@60Hz)
2 x HDMI 2.0 (Max Resolution: 4096x2160@60Hz)
Expansion Bus 1 x M.2 E-key (2230, PCIe Gen.3 x1/ USB2.0 interface) for Wireless
connective
Others 2 x Antenna holes

- 4 -
Introduction
Mechanical
Mounting Type Desktop (default)
Wall-mount and DIN-Rail mount (optional)
Chassis Aluminum alloy
Dimensions
(W x D x H) 118 x 108 x 49.5mm
Weight (Net) 0.66kg
Environmental
Operating Temp. -20 ~ 60°C
Storage Temp. -20 ~ 60°C
Operating
Humidity 10%-95% RH @ 60°C (non-condensing)
Vibration 3 Grms/5~500Hz/random operation
Shock Operating 50G (11ms) with eMMC
OS Support
Windows®10 / Windows®11
1.4. Inside the Package
Upon opening the package, carefully inspect the contents. If any of the items
is missing or appears damaged, contact your local dealer or distributor. The
package should contain the following items:
1 x ELIT-1060
Standard Accessories contain the following
items:
• 1 x DDR4 4GB SO-DIMM Memory
(pre-installed)
• User’s manual

- 5 -
Introduction
1.5. Ordering Information
ELIT-1060 Ultra Compact Controller by Intel® Celeron N6210 w/32GB eMMC
1.5.1. Congure-to-Order Service
Make the computer more tailored to your needs by selecting one or more
components from the list below to be fabricated to the computer.
PAC-60W1A-
FSP-ES
AC/DC ADAPTER KIT, 12V, 60W, 2.5 DC JACK
LOCKABLE w/ EU & USA POWER CORD
MM-4C-8G/16G DDR4-2400 8GB/16GB SO-DIMM MEMORY
64GB M.2 SSD M.2 M-key 2280, 64GB, SATA3.0
WiFi-AT3550 Atheros QCNFA364A M.2 WiFi module w/ 2*30cm
internal wiring
ANT-D11 1 x Wi-Fi Dual-band 2.4G/5G antenna
DRK-1060 ELIT-1060 DIN Rail Kitt
WMK-1060 Wall Mount Kit For ELIT-1060

- 6 -
This page is intentionally left blank.

- 7 -
2Chapter 2
Getting Started
Chapter 2 - Getting Started

- 8 -
Getting Started
2.1. Dimensions
118.00
Unit: mm
48.00
108.00
48.50

- 9 -
Getting Started
2.2. Overview
Take a look around the computer and nd the external controls and connectors.
Front
USB 2.0 Port
Power on/off
Line-Out/Mic
Combo Port
USB 3.2 (Gen 2) Port
Type-C
USB 3.2 (Gen 2) Ports
Rear
COM Port
Antenna Hole
Ground
Antenna Hole
2.5Gbps RJ-45
LAN Ports
Display Port
USB 3.2 (Gen 2) Port
HDMI Port
HDMI Port
12V DC-in
Power Jack

- 10 -
Getting Started
2.3. Driver Installation Note
To install the drivers, please visit our website at
www.arbor-technology.com and download the driver pack from the product
page. If you need login access, please contact your local ARBOR sales
representative.
Device Driver Path
Audio \\audio_ehl\Setup.exe
Ethernet \\intellan_ehl\Autorun.exe
Graphic \\gfx_ehl\Installer.exe
ME \\ime_ehl\SetupME.exe
Chipset \\inf_ehl\SetupChipset.exe
