arcelik MA 2030 S User manual

Kullanma Kılavuzu
MA 2030 S - MA 2030 B
Mikrodalga Fırın
EN - TR
01M-9207601100-3922-01
01M-9207611100-3922-01

Microwave Oven / User Manual
2 / EN
CONTENTS
1 Important safety and
environmental instructions 4
1.1 Safety warnings..................................4
1.2 Compliance with the WEEE Directive
and Disposing of the Waste Product: 11
1.3 Package information...................... 11
1.4 What to do for energy saving ....... 11
2 Your microwave oven 12
2.1 Overview ........................................... 12
2.2 Technical data ................................. 12
2.3 Turntable installation...................... 13
3 Installation and connection 13
3.1 Installation and connection .......... 13
3.2 Built-in installation parts................ 14
3.2 Built-in furniture............................... 14
3.3 Prepare the caibinet ....................... 15
3.4 Install the oven ................................ 15
4 Operation 17
4.1 Control panel.................................... 17
4.2 Usage ................................................ 17
5 Cleaning and maintenance 18
5.1 Cleaning and care........................... 18
5.2 Storage.............................................. 19
5.3 Handling and transportation......... 19
6 Troubleshooting 20

Please read this manual first!
Dear Customer,
Thank you for selecting a Arçelik product. We hope that you get the
best results from your product which has been manufactured with
high quality and state-of-the-art technology. Therefore, please read this
entire user manual and all other accompanying documents carefully
before using the product and keep it as a reference for future use. If
you handover the product to someone else, give the user manual as
well. Follow all warnings and information in the user manual.
Remember that this user manual may also apply to other models.
Differences between models are explicitly described in the manual.
Meanings of the symbols
Following symbols are used in the various section of this user manual:
CImportant information and useful hints about usage.
AWarnings for dangerous situations concern-
ing the safety of life and property.
BWarning for electric shock.
Warning for hot surfaces.

Microwave Oven / User Manual
4 / EN
1 Important safety and environmental instructions
Important Safety
Instructions Read Carefully
And Keep For Future
Reference
1.1 Safety warnings
This section contains
safety instructions that
will help protect from risk
of fire, electric shock, ex-
posure to leak microwave
energy, personal injury or
property damage. Failure
to follow these instruc-
tions shall void any war-
ranty.
•Arçelik Microwave Ovens
comply with the appli-
cable safety standards;
therefore, in case of any
damage on the appli-
ance or power cable, it
should be repaired or
replaced by the dealer,
service center or a spe-
cialist and authorized
service alike to avoid any
danger. Faulty or unqu-
alified repair work may
be dangerous and cause
risk to the user.
•This appliance is in-
tended to be used in
household and similar
applications such as:
–Staff kitchen areas in
shops, offices and other
working environments;
–Farm houses
–By clients in hotels, and
other residential type
environments;
–Bed and Breakfast type
environments.
•It is not intended for in-
dustrial or laboratory
use.
•Do not attempt to start
the oven when its door is
open; otherwise you may
be exposed to harmful
microwave energy. Sa-
fety locks should not be
disabled or tampered
with.
•The microwave oven is
intended for heating food

5 / ENMicrowave Oven / User Manual
1 Important safety and environmental instructions
and beverages. Drying of
food or clothing and he-
ating of warming pads,
slippers, sponges, damp
cloth and similar may
lead to risk of injury, igni-
tion or fire.
•Do not place any object
between the front side
and the door of the oven.
Do not allow dirt or cle-
aning agent remnants to
build up on the closure
surfaces.
•Any service works invol-
ving removal of the cover
that provides protection
against exposure to mic-
rowave energy must be
performed by authorized
persons/service. Any
other approach is dan-
gerous.
•Your product is intended
for cooking, heating and
defrost food at home.
It must not be used for
commercial purposes.
•Your oven is not desig-
ned to dry any living
being.
•Do not use your appli-
ance to dry clothes or
kitchen towels.
•Do not use this appliance
outdoors, bathrooms,
humid environments or
in places where the it
can get wet.
•No responsibility or war-
ranty claim shall be as-
sumed for damages
arising from misuse or
improper handling of the
appliance.
•Never attempt to dis-
mantle the appliance.
No warranty claims are
accepted for damage
caused by improper
handling.
•Only use the original
parts or parts recom-
mended by the manu-
facturer.
•Do not leave this appli-

Microwave Oven / User Manual
6 / EN
ance unattended while it
is in use.
•Always use the appli-
ance on a stable, flat,
clean dry, and non-slip
surface.
•The appliance should
not be operated with an
external clock timer or
separate remote control
system.
•Before using the appli-
ance for the first time,
clean all parts. Please
see the details given in
the “Cleaning and Main-
tenance” section.
•Operate the appliance
for its intended purpose
only as described in this
manual.
•Appliance becomes very
hot while it is in use. Pay
attention not to touch
the hot parts inside the
oven.
•Do not operate the oven
empty.
•Cooking utensil may get
hot due to the heat trans-
ferred from the heated
food to the utensil. You
may need oven gloves to
hold the utensil.
•Utensils shall be chec-
ked to ensure that they
are suitable for use in
microwave ovens.
•Do not place the oven
on stoves or other heat
generating appliances.
Otherwise, it may be da-
maged and the warranty
becomes void.
•Steam may come out
while opening the covers
or the foil after cooking
the food.
•The appliance and its ac-
cessible surfaces may
be very hot when the
appliance is in use.
•Door and outer glass
may be very hot when
the appliance is in use.
•Make sure that your
1 Important safety and environmental instructions

7 / ENMicrowave Oven / User Manual
mains power supply
complies with the infor-
mation supplied on the
rating plate of the appli-
ance.
•The only way to discon-
nect the appliance from
the power supply is to
remove the power plug
from the power outlet.
•Use the appliance with a
grounded outlet only.
•Never use the appliance
if the power cable or the
appliance itself is dama-
ged.
•Do not use this appliance
with an extension cord.
•Never touch the app-
liance or its plug with
damp or wet hands.
•Place the appliance in a
way so that the plug is
always accessible.
•Prevent damage to the
power cable by not squ-
eezing, bending, or rub-
bing it on sharp edges.
Keep the power cable
away from hot surfaces
and naked flame.
•Make sure that there is
no danger that the power
cable could be acciden-
tally pulled or that so-
meone could trip over it
when the appliance is in
use.
•Unplug the appliance be-
fore each cleaning and
when the appliance is
not in use.
•Do not pull the power
cable of the appliance
to disconnect it from its
power supply and never
wrap its power cable
around the appliance.
•Do not immerse the
appliance, power cable,
or power plug in water
or any other liquids. Do
not hold it under running
water.
•When heating food in
plastic or paper contai-
1 Important safety and environmental instructions

Microwave Oven / User Manual
8 / EN
ners, keep an eye on the
oven due to the possibi-
lity of ignition.
•Remove the wire strings
and/or metal handles of
paper or plastic bags be-
fore placing bags to the
oven.
•If smoke is observed,
switch off or unplug the
appliance if safe to do so
and keep the door clo-
sed in order to stifle any
flames.
•Do not use microwave
oven for storage. Do not
leave paper items, coo-
king material or food in-
side the oven when it is
not being used.
•The contents of feeding
bottles and baby food
jars should be stirred or
shaken and the tempe-
rature checked before
consumption, in order to
avoid burns.
•This appliance is a Group
2 Class B ISM equip-
ment. Group 2 conta-
ins all ISM (Industrial,
Scientific and Medical)
equipment in which ra-
dio-frequency energy is
intentionally generated
and/or used in the form
of electromagnetic radi-
ation for the treatment
of material, and spark
erosion equipment.
•Class B equipment is su-
itable for use in domestic
establishments and es-
tablishments directly con-
nected to a low voltage
power supply network.
•Do not use cooking oil in
the oven. Hot oil may da-
mage the components
and materials of the
oven, and it may even
cause skin burns.
•Pierce food with thick
crust such as potatoes,
courgettes, apples and
chestnuts.
1 Important safety and environmental instructions

9 / ENMicrowave Oven / User Manual
•Appliance must be pla-
ced so that the rear side
is facing the wall.
•Before moving the appli-
ance, please secure the
turntable to prevent da-
mage.
•Eggs in their shell and
whole hard-boiled eggs
must not be heated in
microwave ovens since
they may explode, even
after microwave heating
has ended.
WARNING: If the door or
door seals are damaged,
the oven must not be op-
erated until it has been
repaired by a competent
person.
WARNING: It is hazardous
for anyone other than
a competent person to
carry out any service or
repair operation which
involves the removal of a
cover which gives protec-
tion against exposure to
microwave energy.
WARNING: Liquids and
other foods must not be
heated in sealed contain-
ers since they are liable
to explode.
•The oven should be cle-
aned regularly and any
food deposits removed.
•There should be min 20
cm free space above the
top surface of the oven.
•Do not over-cook foods;
otherwise, you may
cause a fire.
•Do not use chemicals
and steam assisted cle-
aners to clean the appli-
ance.
•Extreme caution is ad-
vised when being used
near children and per-
sons who are restricted
in their physical, sensory
or mental abilities.
•This appliance can be
used by the children
who are at the age of 8
1 Important safety and environmental instructions

Microwave Oven / User Manual
10 / EN
or over and by the people
who have limited physi-
cal, sensory or mental
capacity or who do not
have knowledge and ex-
perience, as long as they
are supervised with re-
gard to safe use of the
product or they are ins-
tructed accordingly or
understand the risks of
using the product. Child-
ren should not play with
the appliance. Cleaning
and user maintenance
shall not be made by
children unless they are
older than 8 and supervi-
sed.
•Danger of choking! Keep
all the packaging mate-
rials away from children.
•Due to excessive heat
that arises in grill and
combination modes,
children should only be
allowed to use these
modes under supervi-
sion of an adult.
•Keep the product and its
power cable so that they
are inaccessible by child-
ren under 8 years old.
•Do not cook food directly
on the glass tray. Put the
food in / on appropriate
kitchen utensils before
placing them in the oven.
•Metallic containers for
food and beverages
are not allowed during
microwave cooking. Ot-
herwise, sparking may
occur.
•Microwave oven must
not be placed in a cabi-
net that is not in compli-
ance with the installation
instructions.
•Microwave oven is inten-
ded for built-in use only.
•If built-in appliances
being used equal or hig-
her than 900 mm above
the floor, care should be
taken not to displace the
turntable when removing
1 Important safety and environmental instructions

11 / ENMicrowave Oven / User Manual
containers from the app-
liance.
•If the built-in product is in
a cabinet with a door, the
product must be opera-
ted with the cabinet door
open.
•Failure to maintain the
oven in a clean condition
could lead to deteriora-
tion of the surface that
could adversely affect
the life of the appliance
and possibly result in a
hazardous situation.
•The appliance shall not
be cleaned with a steam
cleaner.
1.2 Compliance with the WEEE
Directive and Disposing of the
Waste Product:
This product complies with EU WEEE
Directive (2012/19/EU). This product
bears a classification symbol for was-
te electrical and electronic equipment
(WEEE).
This symbol indicates that this
product shall not be disposed
with other household wastes at
the end of its service life. Used
device must be returned to offi-
1 Important safety and environmental instructions
cal collection point for recycling of elect-
rical and electronic devices. To find the-
se collection systems please contact to
your local authorities or retailer where
the product was puchased. Each house-
hold performs important role in recove-
ring and recycling of old appliance.
Appropriate disposal of used appliance
helps prevent potential negative conse-
quences for the environment and human
health.
1.3 Package information
Packaging materials of the pro-
duct are manufactured from
recyclable materials in accor-
dance with our National
Environment Regulations. Do not dispo-
se of the packaging materials together
with the domestic or other wastes. Take
them to the packaging material collecti-
on points designated by the local autho-
rities.
1.4 What to do for energy saving
Turn off and unplug the appliance after
use.

Microwave Oven / User Manual
12 / EN
2 Your microwave oven
2.1 Overview
Controls and parts
1. Control panel
2. Turntable shaft
3. Turntable ring assembly
4. Glass tray
5. Oven window
2.2 Technical data
Model MA 2030 S MA 2030 B
Rated voltage 230V~50 Hz
Rated input power
(Microwave)
1250 W
Rated output power
(Microwave)
800 W
Microwave frequency 2450 MHz
Turntable diameter 245 mm
External dimensions 595*344*388 mm
Oven capacity 20 Litre
Net weight 14,5 kg
Color Black White
Technical and design modification rights
are reserved.
1
32
5
4
Markings on the product or the values stated in other documents supplied with the product are values
obtained under laboratory conditions as per relevant standards. These values may vary according to the
usage of the appliance and ambient conditions. Power values are tested at 230V.

13 / ENMicrowave Oven / User Manual
2 Your microwave oven
2.3 Turntable installation
•Never place the glass tray upside
down. The glass tray should never be
restricted.
•Both glass tray and turntable support
must always be used during cooking.
•All food and containers of food must
always place on the glass tray for co-
oking.
•If glass tray or turntable support crack
or break, contact your nearest authori-
zed service center.
Göbek (alt kısım)
Cam tabla
Döner tabla desteği
Döner tabla mili
Hub (underside)
Glass tray
Turntable shaft
Turntable ring assembly
3.1 Installation and connection
•Remove all packing material and ac-
cessories. Examine the oven for any
damage such as dents or broken door.
Do not install if oven is damaged.
•Remove any protective film found on
the microwave oven cabinet surface.
•Do not remove the light brown Mica
cover that is attached to the oven ca-
vity to protect the magnetron.
•This appliance has been designed for
domestic use only.
•This oven is intended for built-in use
only. It is not intended for counter-top
use or for use inside a cabinet.
•Please observe the special installation
instructions.
•The appliance can be installed in a 60
cm wide wall-mounted cabinet (at least
55 cm deep and 85 cm off the floor).
•The appliance is fitted with a plug and
must only be connected to a properly
installed grounded socket.
•The mains voltage must correspond
to the voltage specified on the rating
plate.
•If the plug is no longer accessible after
installation, an all-pole isolating switch
must be present on the installation side
with a contact gap of at least 3 mm.
•Adapters, multi-way sockets and ex-
tension cords must not be used. Over-
loading can result with a risk of fire.
The accessible
surface may be
hot during opera-
tion.
BDo not trap or
bend the power
cable.
3 Installation and connection

Microwave Oven / User Manual
14 / EN
3 Installation and connection
3.2 Built-in installation parts
Vida A
Vida B
Montaj plakası
Trim kiti plastik kapak
Screw A
Screw B
Mounting Plate
Trim-kit plastic cover
3.2 Built-in furniture
380+2
340
CThe bracket and bottom ca
net template are needed
when installating in both ins-
tallations.

15 / ENMicrowave Oven / User Manual
3.3 Prepare the caibinet
1.Read the instruction on the bottom ca-
bınet template, put the template on the
bottom plane of cabinet.
2.Make the marks on the bottom plane
of cabinet according to marks ”a” of
the template.
aa
Merkez çizgi
Centre line
3.Remove the bottom cabinet template
and fix the mounting plate with screw
A.
Montaj
plakası
Vida A
Mounting
Plate
3.4 Install the oven
1.Install the oven to the cabinet.
A
WARNING: Make
sure the back of
the oven is locked
by mounting plate.
BWARNING: Do not
trap or kink the
power cord.
3 Installation and connection

Microwave Oven / User Manual
16 / EN
3 Installation and connection
montaj
plakası
Mounting
Plate
2.Open the door, fix the oven to the ca-
binet with Screw B, at the installation
hole. Then fix the Trim-kit plastic cover
to the installation hole.
Montaj deliği
Vida B
Screw B
Installation hole

17 / ENMicrowave Oven / User Manual
4 Operation
4.1 Control panel
Güç
düğmesi
Zaman
düğmesi
Power
button
Timer
button
4.2 Usage
1.To set cooking power by turning the
power knob to desired level.
2.To set the time of cooking by turning
the timer knob to desired time per your
food cooking guide.
3.The microwave oven will automatically
start cooking after power level and
time are set.
4.After the cooking time is up, the unit
will “Dong” to stop.
5.If the unit is not in use, always set time
to “0”.
Function/
Power
Output Application
17%
micro. Soften ice cream
33%
micro. Soup stew, soften butter or defrost
55%
micro. Stew, fish
77%
micro. Rice, fish, chicken, ground meat
100%
micro. Reheat, milk, boil water, vegetables,
beverage
C
When removing food from
the oven, please ensure that
the oven power is switc-
hed off by turning the timer
switch to 0 (zero). Failure to
do so, and operating the mic-
rowave oven without food in
it, can result in overheating
and damage to the magnet-
ron.

Microwave Oven / User Manual
18 / EN
5.1 Cleaning and care
A
WARNING: Never use gasoline, solvent, abrasi-
ve cleaning agents, do not use harsh abrasive
cleaners or sharp metal scrapers to clean the
oven door glass since they can scratch the
surface, which may result in shattering of the
glass.
BWARNING: Never immerse the appliance or its
power cable in water or in any other liquid.
1.Turn off the oven and remove the power plug from the wall socket before cleaning.
2.Wait for the appliance to completely cool down.
3.Keep the inside of the oven clean. When food splatters or spilled liquids adhere to
oven walls, wipe with a damp cloth. Mild detergent may be used if the oven gets
very dirty. Avoid the use of spray and other harsh cleaners as they may stain, streak
or dull the door surface.
4.The outside surfaces should be cleaned with a damp cloth. To prevent damage to
the operating parts inside the oven, water should not be allowed to seep into the
ventilation openings.
5.Wipe the both sides of the door and window, the door seals and adjacent parts
frequently with a damp cloth to remove any spills or spatters. Do not use abrasive
cleaner.
6.A steam cleaner is not be used.
7.Do not allow the control panel to become wet. Clean with a soft, damp cloth. When
cleaning the control panel, leave oven door open to prevent oven from accidentally
turning on.
8.If steam accumulates inside or around the outside of the oven door, wipe with a
soft cloth. This may occur when the microwave oven is operated under high humi-
dity condition. And it is normal.
9.It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in
warm sudsy water or in a dishwasher.
10. The roller ring and oven floor should be cleaned regularly to avoid excessive no-
ise. Simply wipe the bottom surface of the oven with mild detergent. The roller
ring may be washed in mild sudsy water or dishwasher. When removing the roller
ring from cavity floor for cleaning, be sure to replace in the proper position.
5 Cleaning and maintenance

19 / ENMicrowave Oven / User Manual
5 Cleaning and maintenance
11. Remove odors from your oven by combining a cup of water with the juice and
skin of one lemon in a deep microwaveable bowl, microwave for 5 minutes. Wipe
thoroughly and dry with a soft cloth.
12. When it becomes necessary to replace the oven light, please consult a dealer to
have it replaced.
13. The oven should be cleaned regularly and any food deposits removed. Failure to
maintain the oven in a clean condition could lead to deterioration of the surface
that could adversely affect the life of the appliance and possibly result in a ha-
zardous situation.
14. Please do not dispose this appliance into the domestic rubbish bin; it should be
disposed to the particular disposal center provided by the municipalities.
15. When the microwave oven with grill function is first used, it may produce slight
smoke and smell. This is a normal phenomenon because the oven is made of a
steel plate coated with lubricating oil, and the new oven will produce fumes and
odor generated by burning the lubricating oil. This phenomenon will disappear
after a period of using.
5.2 Storage
•If you do not intend to use the appliance for a long time, please store it carefully.
•Please make sure that the appliance is unplugged, cooled down and totally dry.
•Store the appliance in a cool and dry place.
•Keep the appliance out of the reach of children.
5.3 Handling and transportation
•During handling and transportation, carry the appliance in its original packaging.
The packaging of the appliance protects it against physical damages.
•Do not place heavy loads on the appliance or the packaging. The appliance may
be damaged.
•Dropping the appliance will render it non-operational or cause permanent damage.

Microwave Oven / User Manual
20 / EN
6 Troubleshooting
Problem Possible Reason Solution
Oven cannot be started. 1) Power cable is not plugged
in properly. Unplug. Then plug again after 10 seconds.
2) Fuse is blown or circuit bre-
aker is activated. Replace fuse or reset circuit bre- aker (repaired by professional
personnel of our company).
3) Trouble with outlet. Test the outlet with other electri-
cal appliances.
Oven does not heat. 4) Door is not closed properly. Close the door properly.
If none of the above rectifies the situation, then contact a qualified technician. Do not try to
adjust or repair the oven yourself.
