arcelik MD 2310 W User manual

Kullanma Kılavuzu
01M-9206811100-2322-01
MD 2310 W
Mikrodalga Fırın
EN- TR

Microwave Oven / User Manual
2 / EN
CONTENTS
1 Important safety and environmental
instructions 4
1.1 Safety warnings . . . . . . . . . . . . . . . . . . . 4
1.2 Compliance with the WEEE Directive and
Disposing of the Waste Product: . . . . . . . . . . 8
1.3 Compliance with RoHS Directive . . . . . . . 8
1.4 Package information . . . . . . . . . . . . . . . . 8
2 Your microwave oven 9
2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2 Technical data. . . . . . . . . . . . . . . . . . . . . 9
2.3 Installing the turntable. . . . . . . . . . . . . . 10
3 Installation and connection 10
3.1 Installation . . . . . . . . . . . . . . . . . . . . . . 10
3.2 Radio interference. . . . . . . . . . . . . . . . . 10
3.3 Grounding instructions . . . . . . . . . . . . . 11
3.4 Before you call for service . . . . . . . . . . . 11
3.5 Utensils guide. . . . . . . . . . . . . . . . . . . . 11
4 Operation 13
4.1 Control panel . . . . . . . . . . . . . . . . . . . . 13
4.2 How to set the oven controls . . . . . . . . . 14
4.3 Setting the clock. . . . . . . . . . . . . . . . . . 14
4.4 Express cooking . . . . . . . . . . . . . . . . . . 14
4.5 Microwave cooking . . . . . . . . . . . . . . . . 14
4.6 Grill . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.7 Combination . . . . . . . . . . . . . . . . . . . . 14
4.8 Jet defrost . . . . . . . . . . . . . . . . . . . . . . 15
4.9 Weight defrost . . . . . . . . . . . . . . . . . . . 15
4.10 Preset . . . . . . . . . . . . . . . . . . . . . . . . 15
4.11 Multi-stage cooking . . . . . . . . . . . . . . 15
4.12 Child lock . . . . . . . . . . . . . . . . . . . . . . 15
4.13 Cooking techniques. . . . . . . . . . . . . . . 16
5 Cleaning and maintenance 17
5.1 Cleaning and care. . . . . . . . . . . . . . . . . 17
5.2 Storage . . . . . . . . . . . . . . . . . . . . . . . . 17
5.3 Handling and transportation. . . . . . . . . . 18
6 Troubleshooting 18

Please read this user manual first!
Dear Valued Customer,
Thank you for preferring this Arçelik appliance. We hope that you get the best results
from your appliance which has been manufactured with high quality and state-of-
the-art technology. For this reason, please read this entire user manual and all other
accompanying documents carefully before using the appliance and keep it as a
reference for future use. If you handover the appliance to someone else, give the user
manual as well. Follow the instructions by paying attention to all the information and
warnings in the user manual.
Remember that this user manual may also apply to other models. Differences between
models are explicitly described in the manual.
Meanings of the Symbols
Following symbols are used in various sections of this user manual:
CImportant information and useful
hints about usage.
AWarnings for dangerous situations
concerning the safety of life and
property.
Warning for hot surfaces.
BWarning for electric shock.
This appliance has been produced in environmentally friendly facilities without harming the nature.

Microwave Oven / User Manual
4 / EN
1 Important safety and environmental
instructions
Important Safety Instruc-
tions Read Carefully And
Keep For Future Reference
1.1 Safety warnings
This section contains safety instruc-
tions that will help protect from risk
of fire, electric shock, exposure to
leak microwave energy, personal in-
jury or property damage. Failure to
follow these instructions shall void
any warranty.
•Arçelik Microwave Ovens comply
with the applicable safety stand-
ards; therefore, in case of any
damage on the appliance or power
cable, it should be repaired or re-
placed by the dealer, service center
or a specialist and authorized ser-
vice alike to avoid any danger.
Faulty or unqualified repair work
may be dangerous and cause risk
to the user.
•This appliance is intended to be
used in household and similar ap-
plications such as:
– Staff kitchen areas in shops,
offices and other working en-
vironments;
– Farm houses
– By clients in hotels, and other
residential type environments;
– Bed and Breakfast type envi-
ronments.
•It is not intended for industrial or
laboratory use.
•Do not attempt to start the oven
when its door is open; otherwise
you may be exposed to harmful mi-
crowave energy. Safety locks should
not be disabled or tampered with.
•The microwave oven is intended for
heating food and beverages. Drying
of food or clothing and heating of
warming pads, slippers, sponges,
damp cloth and similar may lead to
risk of injury, ignition or fire.
•Do not place any object between
the front side and the door of the
oven. Do not allow dirt or cleaning
agent remnants to build up on the
closure surfaces.
•Any service works involving re-
moval of the cover that provides
protection against exposure to mi-
crowave energy must be performed
by authorized persons/service. Any
other approach is dangerous.
•Your product is intended for cook-
ing, heating and defrost food at
home. It must not be used for com-
mercial purposes.
•Your oven is not designed to dry
any living being.

Microwave Oven / User Manual 5 / EN
1 Important safety and environmental
instructions
•Do not use your appliance to dry
clothes or kitchen towels.
•Do not use this appliance outdoors,
bathrooms, humid environments or
in places where the it can get wet.
•No responsibility or warranty claim
shall be assumed for damages
arising from misuse or improper
handling of the appliance.
•Never attempt to dismantle the
appliance. No warranty claims are
accepted for damage caused by
improper handling.
•Only use the original parts or parts
recommended by the manufac-
turer.
•Do not leave this appliance unat-
tended while it is in use.
•Always use the appliance on a
stable, flat, clean dry, and non-slip
surface.
•The appliance should not be oper-
ated with an external clock timer or
separate remote control system.
•Before using the appliance for the
first time, clean all parts. Please
see the details given in the “Clean-
ing and Maintenance” section.
•Operate the appliance for its in-
tended purpose only as described
in this manual.
•Appliance becomes very hot while
it is in use. Pay attention not to
touch the hot parts inside the oven.
•Do not operate the oven empty.
•Cooking utensil may get hot due to
the heat transferred from the heated
food to the utensil. You may need
oven gloves to hold the utensil.
•Utensils shall be checked to ensure
that they are suitable for use in mi-
crowave ovens.
•Do not place the oven on stoves or
other heat generating appliances.
Otherwise, it may be damaged and
the warranty becomes void.
•Steam may come out while open-
ing the covers or the foil after cook-
ing the food.
•The appliance and its accessible
surfaces may be very hot when the
appliance is in use.
•Door and outer glass may be very
hot when the appliance is in use.
•Make sure that your mains power
supply complies with the informa-
tion supplied on the rating plate of
the appliance.
•The only way to disconnect the ap-
pliance from the power supply is to
remove the power plug from the
power outlet.

Microwave Oven / User Manual
6 / EN
•Use the appliance with a grounded
outlet only.
•Never use the appliance if the
power cable or the appliance itself
is damaged.
•Do not use this appliance with an
extension cord.
•Never touch the appliance or its
plug with damp or wet hands.
•Place the appliance in a way so
that the plug is always accessible.
•Prevent damage to the power cable
by not squeezing, bending, or rub-
bing it on sharp edges. Keep the
power cable away from hot sur-
faces and naked flame.
•Make sure that there is no danger
that the power cable could be ac-
cidentally pulled or that someone
could trip over it when the appli-
ance is in use.
•Unplug the appliance before each
cleaning and when the appliance is
not in use.
•Do not pull the power cable of the
appliance to disconnect it from its
power supply and never wrap its
power cable around the appliance.
•Do not immerse the appliance,
power cable, or power plug in
water or any other liquids. Do not
hold it under running water.
•When heating food in plastic or
paper containers, keep an eye on
the oven due to the possibility of
ignition.
•Remove the wire strings and/or
metal handles of paper or plastic
bags before placing bags to the
oven.
•If smoke is observed, switch off
or unplug the appliance if safe to
do so and keep the door closed in
order to stifle any flames.
•Do not use microwave oven for
storage. Do not leave paper items,
cooking material or food inside the
oven when it is not being used.
•The contents of feeding bottles and
baby food jars should be stirred
or shaken and the temperature
checked before consumption, in
order to avoid burns.
•This appliance is a Group 2 Class
B ISM equipment. Group 2 contains
all ISM (Industrial, Scientific and
Medical) equipment in which ra-
dio-frequency energy is intention-
ally generated and/or used in the
form of electromagnetic radiation
for the treatment of material, and
spark erosion equipment.
1 Important safety and environmental
instructions

Microwave Oven / User Manual 7 / EN
•Class B equipment is suitable for
use in domestic establishments
and establishments directly con-
nected to a low voltage power sup-
ply network.
•Do not use cooking oil in the oven.
Hot oil may damage the compo-
nents and materials of the oven,
and it may even cause skin burns.
•Pierce food with thick crust such
as potatoes, courgettes, apples and
chestnuts.
•Appliance must be placed so that
the rear side is facing the wall.
•Before moving the appliance,
please secure the turntable to pre-
vent damage.
•Eggs in their shell and whole hard-
boiled eggs must not be heated in
microwave ovens since they may
explode, even after microwave
heating has ended.
WARNING: If the door or door seals
are damaged, the oven must not be
operated until it has been repaired
by a competent person.
WARNING: It is hazardous for anyone
other than a competent person to car-
ry out any service or repair operation
which involves the removal of a cover
which gives protection against expo-
sure to microwave energy.
WARNING: Liquids and other foods
must not be heated in sealed con-
tainers since they are liable to ex-
plode.
•The oven should be cleaned reg-
ularly and any food deposits re-
moved.
•There should be min 20 cm free
space above the top surface of the
oven.
•Do not over-cook foods; otherwise,
you may cause a fire.
•Do not use chemicals and steam
assisted cleaners to clean the ap-
pliance.
•Extreme caution is advised when
being used near children and per-
sons who are restricted in their
physical, sensory or mental abilities.
•This appliance can be used by the
children who are at the age of 8 or
over and by the people who have
limited physical, sensory or mental
capacity or who do not have knowl-
edge and experience, as long as
they are supervised with regard to
safe use of the product or they are
instructed accordingly or under-
stand the risks of using the prod-
uct. Children should not play with
the appliance. Cleaning and user
maintenance shall not be made by
1 Important safety and environmental
instructions

Microwave Oven / User Manual
8 / EN
children unless they are older than
8 and supervised.
•Danger of choking! Keep all the
packaging materials away from
children.
•Due to excessive heat that arises in
grill and combination modes, chil-
dren should only be allowed to use
these modes under supervision of
an adult.
•Keep the product and its power
cable so that they are inaccessible
by children under 8 years old.
•Do not cook food directly on the
glass tray. Put the food in / on ap-
propriate kitchen utensils before
placing them in the oven.
•Metallic containers for food and
beverages are not allowed during
microwave cooking. Otherwise,
sparking may occur.
•This product is not designed to be
built-in. Do not place the product in
a cabinet or box while it is in use.
•Failure to maintain the oven in a
clean condition could lead to dete-
rioration of the surface that could
adversely affect the life of the ap-
pliance and possibly result in a
hazardous situation.
•The appliance shall not be cleaned
with a steam cleaner.
1.2 Compliance with the WEEE
Directive and Disposing of the Waste
Product:
This product complies with EU WEEE Directive
(2012/19/EU). This product bears a classification
symbol for waste electrical and electronic equip-
ment (WEEE).
This symbol indicates that this product
shall not be disposed with other
household wastes at the end of its ser-
vice life. Used device must be returned
to offical collection point for recycling
of electrical and electronic devices. To find these
collection systems please contact to your local au-
thorities or retailer where the product was pu-
chased. Each household performs important role
in recovering and recycling of old appliance.
Appropriate disposal of used appliance helps pre-
vent potential negative consequences for the envi-
ronment and human health.
1.3 Compliance with RoHS Directive
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
1.4 Package information
Packaging materials of the product are
manufactured from recyclable materi-
als in accordance with our National
Environment Regulations. Do not dis-
pose of the packaging materials together with the
domestic or other wastes. Take them to the pack-
aging material collection points designated by the
local authorities.
1 Important safety and environmental
instructions

Microwave Oven / User Manual 9 / EN
Markings on the product or the values stated in other documents supplied with the product are values obtained under laboratory
conditions as per relevant standards. These values may vary according to the usage of the appliance and ambient conditions.
Power values are tested at 240V.
2 Your microwave oven
2.1 Overview
Controls and parts
1. Door safety lock system
2. Oven window
3. Roller ring
4. Shaft
5. Glass tray
6. Control panel
7. Door release button
8. Metal rack
2.2 Technical data
Power consumption 230-240V~,50Hz
1400W (Microwave)
1000W (Grill)
Output 900 W
Operating frequency 2450 MHz
Outside dimensions
(H*W*D)
281*483*360 mm
Oven capacity 23 litres
Technical and design modification rights are
reserved.
1
2
34 5
7
6
8

Microwave Oven / User Manual
10 / EN
2.3 Installing the turntable
•Never place the glass tray upside down. The
glass tray should never be restricted.
•Both glass tray and turntable support must al-
ways be used during cooking.
•All food and containers of food must always
place on the glass tray for cooking.
•If glass tray or turntable support crack or break,
contact your nearest authorized service center.
2 Your microwave oven
Göbek (alt kısım)
Cam tabla
Döner tabla desteği
Döner tabla mili
Hub (underside)
Glass tray
Turntable shaft
Turntable support
3 Installation and connection
3.1 Installation
1. Make sure that all the packing materials are re-
moved from the inside of the door.
A
WARNING: Check the oven for any
damage, such as misaligned or bent
door, damaged door seals and seal-
ing surface, broken or loose door
hinges and latches and dents inside
the cavity or on the door. If there
is any damage, do not operate the
oven and contact qualified service
personnel.
2. This microwave oven must be placed on a flat,
stable surface to hold its weight and the heavi-
est food likely to be cooked in the oven.
3. Do not place the oven where heat, moisture, or
high humidity are generated, or near combus-
tible materials.
4. For correct operation, the oven must have suf-
ficient airflow. Allow minimum 20cm of free
space necessary above the top surface of the
oven and 5cm at both sides. The microwave
oven rear plate must be placed close to the
wall. Do not cover or block any openings on the
appliance. Do not remove feet.
5. Do not operate the oven without glass tray, roller
support, and shaft in their proper positions.
6. Make sure that the power supply cord is un-
damaged and does not run under the oven or
over any hot or sharp surface.
7. The socket must be readily accessible so that it
can be easily unplugged in an emergency.
8. Do not use the oven outdoors.
3.2 Radio interference
Operation of the microwave oven can cause in-
terference to your radio, TV, or similar equipment.
When there is interference, it may be reduced or
eliminated by taking the following measures:
1. Clean door and sealing surface of the oven.
2. Reorient the receiving antenna of radio or tel-
evision.
3. Relocate the microwave oven with respect to
the receiver.
4. Move the microwave oven away from the re-
ceiver.
5. Plug the microwave oven into a different outlet
so that microwave oven and receiver are on dif-
ferent branch circuits.

Microwave Oven / User Manual 11 / EN
3.3 Grounding instructions
This appliance must be grounded. This oven is
equipped with a cord having a grounding wire with
a grounding plug. It must be plugged into a wall
receptacle that is properly installed and grounded.
In the event of an electrical short circuit, ground-
ing reduces risk of electric shock by providing an
escape wire for the electric current. It is recom-
mended that a separate circuit serving only the
oven be provided. Using a high voltage is dan-
gerous and may result in a fire or other accident
causing oven damage.
BWARNING: Improper use of the
grounding plug can result in a risk of
electric shock.
B
If you have any questions about the
grounding or electrical instructions,
consult a qualified electrician or ser-
vice person.
B
Neither the manufacturer nor the
dealer can accept any liability for
damage to the oven or personal
injury resulting from failure to ob-
serve the electrical connection pro-
cedures.
The wires in this cable main are colored in accord-
ance with the following code:
Green and Yellow = EARTH
Blue = NEUTRAL
Brown = LIVE
3.4 Before you call for service
If the oven fails to operate:
1. Check to ensure that the oven is plugged in
securely. If it is not, remove the plug from the
outlet, wait 10 seconds, and plug it in again
securely.
3 Installation and connection
2. Check for a blown circuit fuse or a tripped main
circuit breaker. If these seem to be operating
properly, test the outlet with another appliance.
3. Check to ensure that the control panel is pro-
grammed correctly and the timer is set.
4. Check to ensure that the door is securely
closed engaging the door safety lock system.
Otherwise, the microwave energy will not flow
into the oven.
IF NONE OFTHEABOVE RECTIFIESTHE SITUATION,
THEN CONTACT A QUALIFIED TECHNICIAN.
DO NOT TRY TO ADJUST OR REPAIR THE OVEN
YOURSELF.
3.5 Utensils guide
1. Microwave cannot penetrate metal. Only use
utensils that are suitable for use in microwave
ovens. Metallic containers for food and bever-
ages are not allowed during microwave cook-
ing. This requirement is not applicable if the
manufacturer specifies size and shape of me-
tallic containers suitable for microwave cooking.
2. Microwave cannot penetrate metal, so metal
utensils or dishes with metallic trim should not
be used.
3. Do not use recycled paper products when mi-
crowave cooking, as they may contain small
metal fragments which may cause sparks and/
or fires.
4. Round /oval dishes rather than square/oblong
ones are recommend, as food in corners tends
to overcook.
5. Narrow strips of aluminum foil may be used to
prevent overcooking of exposed areas. But be
careful don’t use too much and keep a distance
of 1 inch (2.54cm) between foil and cavity.

Microwave Oven / User Manual
12 / EN
3 Installation and connection
The list below is a general guide to help you select the correct utensils.
Cookware Microwave Grill Combination
Heat–Resistant Glass Yes Yes Yes
Non Heat–Resistant Glass No No No
Heat–Resistant Ceramics Yes Yes Yes
Microwave–Safe Plastic Dish Yes No No
Kitchen Paper Yes No No
Metal Tray No Yes No
Baking plate No Yes No
Aluminum Foil & Foil Container No Yes No

Microwave Oven / User Manual 13 / EN
Display screen
Cooking time, power, indicators and present time
are displayed.
Number pads (10 minute1, 10 second 1)
Press to set clock, cooking time or enter food
weight.
Power level
Press to set microwave cooking power level.
Weight defrost
Press to program defrost program based on
weight.
Microwave
Press to set microwave cooking program.
Jet defrost
Press to program defrost program based on time.
Clock
Press to set the oven clock of time.
Memory
Press to set multistage cooking program.
Combi.1/Combi.2
Press to set combination cooking program.
Grill
Press to set grill cooking program.
Preset
Press to set preset function.
Express
Simply press it a number of times to set cooking
time and cook immediately at full power level.
Cancel
Clears all previous settings before setting another
function.
Press once to temporarily stop cooking or twice to
cancel cooking.
Start
Press to start cooking program.
4 Operation
4.1 Control panel
Ağırlık Seçimi
Buz Çözme d1 Et
d2 Kümes Hayvanları
d3 Deniz Ürünleri
Güç
Seviyesi
Ağırlık Seçimi
Buz Çözme
Mikrodalga HızlıBuz
Çözme
Saat Hafıza
Dakika
Saniye
Kombine
Izgara
Izgara
Program Hızlı
İptal Başla

Microwave Oven / User Manual
14 / EN
4.2 How to set the oven controls
•When the oven first plugged in, beep will sound
and the display will show “1:01” and “ ”.
•In the process of setting, broke about 20 sec-
onds the oven will return to standby mode.
•During cooking, if press “Cancel” pad once, the
program will be paused, then press “Start” pad
to resume, but if press “Cancel” pad twice, the
program will be canceled.
•After ending cooking, the screen will display End
with sound every two minutes until user press
any pad or open the door.
4.3 Setting the clock
This is a 12 or 24 hour clock. You can choose to
set the clock time in 12 or 24 hour cycle by press-
ing the “Clock” pad.
1. In standby mode, press “Clock” pad once or
twice to choose 12 or 24 hour clock.
2. Use the number pads to set the correct time.
3. Press “Clock” pad to confirm.
CDuring cooking, you can check
the current clock time by pressing
“Clock” pad.
4.4 Express cooking
1. Use this feature to program the oven to start at
100% power conveniently.
2. In standby mode, press “Express” pad in quick
succession to set time (each press for 30 sec-
onds, and up to 10inutes).
3. The oven starts cooking automatically at full
power.
4. During cooking, you can add the cooking time
by pressing “Express” pad.
4.5 Microwave cooking
1. In standby mode, press “Power Level” pad re-
peatedly to set cooking power level.
2. Press “Microwave” pad once, and then use the
number pads to enter cooking time. The longest
time is 99 minutes and 99 seconds.
3. Press “Start” pad to confirm.
Press Power Level pad to set a cooking pow-
er level:
Press Power Level Power Level
Once 100%
Twice 80%
3 times 60%
4 times 40%
5 times 20%
6 times 0%
C
During cooking, you can check the
current power level by pressing
“Power Level” pad. If you want to
cook at full power level, omit the
first step.
4.6 Grill
1. In standby mode, press “Grill” pad once.
2. Use number pads to set cooking time.The long-
est time is 99 minutes and 99 seconds.
3. Press “Start” pad to confirm.
4.7 Combination
1. In standby mode, press “Combi.1 or Combi.2”
pad once.
2. Use number pads to set cooking time.The long-
est time is 99 minutes and 99 seconds.
3. Press “Start” pad to confirm.
4 Operation

Microwave Oven / User Manual 15 / EN
4.8 Jet defrost
1. In standby mode, press “Jet Defrost” pad once.
2. Use the number pads to enter defrosting time.
The longest time is 99 minutes and 99 seconds.
3. Press “Start” pad to confirm.
4.9 Weight defrost
The defrosting time and power level are automat-
ically set once the food category and weight are
programmed
1. In standby mode, press “Weight Defrost” re-
peatedly to select food code.
2. Use the number pads to select food weight.
3. Press “Start” pad to confirm.
Weight defrost code description:
Press
Weight
Defrost
Display Food type Maximum
weight
Once d1 Meat 2300 g
Twice d2 Poultry 2300 g
3 times d3 Seafood 900 g
10 Minute=1kg 1 Minute=100 g
10 Second=10 g 1 Second=1 g
C
During cooking, the system will
pause to remind you to turn over the
food, and then press “Start” pad to
resume. User must enter the correct
weight, otherwise the microwave
oven will not start.
4.10 Preset
Preset function allows the oven to start up in a
later time.
1. Set a cooking program (except jet defrost, ex-
press cooking and weight defrost program).
2. Press “Preset” pad once.
3. Use the number pads to enter preset time.
4. Press “Start” pad to start
C
You can check the preset time dur-
ing cooking by pressing “Preset”
pad once. Time countdown can be
seen in display for 5 seconds, and
then press “Cancel” pad within 5
seconds to cancel the program.
4.11 Multi-stage cooking
Your oven can be programmed for up to 2 auto-
matic cooking sequences.
Example: Suppose you want to set the following
cooking program.
Microwave-cooking

Microwave-cooking (with lower power level)
1. Input the first stage of microwave cooking pro-
gram. Do not press “Start” pad.
2. Press “Memory” pad once.
3. Input the second stage microwave cooking pro-
gram.
4. Press “Start” pad to start.
CExpress cooking, jet defrost and
weight defrost cannot be set in a
multistage cooking program.
4.12 Child lock
Use to prevent unsupervised operation of the oven
by children.
To set the child lock: In standby mode, one min-
ute without any operation the oven will auto enter
child lock mode and the lock indicator light will
turn on. In the lock state, all pads are disabled.
To cancel the child lock: In child lock mode,
open or close the oven door to cancel the pro-
gram.
4 Operation

Microwave Oven / User Manual
16 / EN
4 Operation
4.13 Cooking techniques
•Arrange food carefully. Place thickest areas to-
wards outside of dish.
•Watch cooking time. Cook for the shortest
amount of time indicated and add more as
needed. Food severely overcooked can smoke
or ignite.
•Cover foods while cooking. Covers prevent spat-
tering and help foods to cook evenly.
•Turn foods over once during microwave cooking
to speed cooking of such foods as chicken and
hamburgers. Large items like roasts must be
turned over at least once.
•Rearrange foods such as meatballs halfway
through cooking both from top to bottom and
from the center of the dish to the outside.

Microwave Oven / User Manual 17 / EN
5.1 Cleaning and care
AWARNING: Never use gasoline, sol-
vent, abrasive cleaning agents, met-
al objects or hard brushes to clean
the appliance.
BWARNING: Never immerse the ap-
pliance or its power cable in water
or in any other liquid.
1. Turn off the oven and remove the power plug
from the wall socket before cleaning.
2. Wait for the appliance to completely cool down.
3. Keep the inside of the oven clean. When food
splatters or spilled liquids adhere to oven walls,
wipe with a damp cloth. Mild detergent may be
used if the oven gets very dirty. Avoid the use
of spray and other harsh cleaners as they may
stain, streak or dull the door surface.
4. The outside surfaces should be cleaned with a
damp cloth. To prevent damage to the operat-
ing parts inside the oven, water should not be
allowed to seep into the ventilation openings.
5. Wipe the both sides of the door and window, the
door seals and adjacent parts frequently with a
damp cloth to remove any spills or spatters. Do
not use abrasive cleaner.
6. A steam cleaner is not be used.
7. Do not allow the control panel to become wet.
Clean with a soft, damp cloth. When cleaning
the control panel, leave oven door open to pre-
vent oven from accidentally turning on.
8. If steam accumulates inside or around the out-
side of the oven door, wipe with a soft cloth.
This may occur when the microwave oven is
operated under high humidity condition. And it
is normal.
9. It is occasionally necessary to remove the glass
tray for cleaning. Wash the tray in warm sudsy
water or in a dishwasher.
5 Cleaning and maintenance
10.The roller ring and oven floor should be
cleaned regularly to avoid excessive noise.
Simply wipe the bottom surface of the oven
with mild detergent. The roller ring may be
washed in mild sudsy water or dishwasher.
When removing the roller ring from cavity floor
for cleaning, be sure to replace in the proper
position.
11.Remove odors from your oven by combining
a cup of water with the juice and skin of
one lemon in a deep microwaveable bowl,
microwave for 5 minutes. Wipe thoroughly
and dry with a soft cloth.
12.When it becomes necessary to replace the
oven light, please consult a dealer to have it
replaced.
13.The oven should be cleaned regularly and any
food deposits removed. Failure to maintain
the oven in a clean condition could lead
to deterioration of the surface that could
adversely affect the life of the appliance and
possibly result in a hazardous situation.
14.Please do not dispose this appliance into the
domestic rubbish bin; it should be disposed to
the particular disposal center provided by the
municipalities.
15.When the microwave oven with grill function
is first used, it may produce slight smoke
and smell. This is a normal phenomenon
because the oven is made of a steel plate
coated with lubricating oil, and the new oven
will produce fumes and odor generated by
burning the lubricating oil. This phenomenon
will disappear after a period of using.
5.2 Storage
•If you do not intend to use the appliance for a
long time, please store it carefully.
•Please make sure that the appliance is un-
plugged, cooled down and totally dry.
•Store the appliance in a cool and dry place.
•Keep the appliance out of the reach of children.

Microwave Oven / User Manual
18 / EN
Problem Possible Reason Solution
Oven cannot be started. 1) Power cable is not plugged in
properly.
Unplug. Then plug again after 10
seconds.
2) Fuse is blown or circuit breaker
is activated.
Replace fuse or reset circuit breaker
(repaired by professional personnel
of our company).
3) Trouble with outlet. Test the outlet with other electrical
appliances.
Oven does not heat. 4) Door is not closed properly. Close the door properly.
Glass turntable makes noise when
microwave oven operates
5) Turntable and bottom of the
oven is dirty.
Refer to “Cleaning and
Maintenance" section to clean dirty
parts.
5 Cleaning and maintenance
5.3 Handling and transportation
•During handling and transportation, carry the
appliance in its original packaging. The packag-
ing of the appliance protects it against physical
damages.
•Do not place heavy loads on the appliance or
the packaging. The appliance may be damaged.
•Dropping the appliance will render it non-oper-
ational or cause permanent damage.
6 Troubleshooting

Lütfen önce bu kılavuzu okuyun!
Değerli Müşterimiz,
Arçelik ürününü tercih ettiğiniz için teşekkür ederiz.Yüksek kalite ve teknoloji ile üretilm-
iş olan ürününüzün size en iyi verimi sunmasını istiyoruz. Bunun için, bu kılavuzun
tamamını ve verilen diğer belgeleri ürünü kullanmadan önce dikkatle okuyun ve bir
başvuru kaynağı olarak saklayın. Ürünü başka birisine verirseniz, kullanma kılavuzunu
da birlikte verin. Kullanma kılavuzunda belirtilen tüm bilgi ve uyarıları dikkate alarak
talimatlara uyun.
Bu kullanma kılavuzunun başka modeller için de geçerli olabileceğini unutmayın. Mod-
eller arasındaki farklar kılavuzda açık bir şekilde belirtilmiştir.
Sembollerin anlamları
Bu kullanma kılavuzunun çeşitli kısımlarında aşağıdaki semboller kullanılmıştır:
CCihazın kullanımıyla ilgili önemli bilgiler
ve faydalı tavsiyeler.
AUYARI: Can ve mal güvenliğiyle ilgili
tehlikeli durumlar konusunda uyarılar.
BElektrik çarpması uyarısı.
Sıcak yüzeylerle ilgili uyarı.
Bu ürün çevreye saygılı modern tesislerde doğaya zarar vermeden üretilmiştir.
AEEE Yönetmeliğine Uygundur. PCB içermez.

Mikrodalga Fırın / Kullanım Kılavuzu
20 / TR
İÇİNDEKİLER
1 Önemli güvenlik ve çevre
talimatları 21
1.1 Güvenlik uyarıları ...................................21
1.2 AEEE Yönetmeliğine Uyum ve Atık Ürünün
Elden Çıkarılması .........................................26
1.3 Ambalaj bilgisi ....................................... 26
2 Mikrodalga fırınınız 27
2.1 Genel bakış ...........................................27
2.2 Teknik veriler .........................................27
2.3 Döner tabla montajı................................ 28
3 Kurulum ve bağlantı 29
3.1 Kurulum ................................................29
3.2 Radyo paraziti........................................ 29
3.3 Topraklama talimatları ............................29
3.4 Servis çağırmadan önce .........................30
3.5 Pişirme gereçleri kılavuzu .......................30
4 Kullanım 31
4.1 Kontrol paneli ........................................31
4.2 Fırın kontrollerinin ayarlanması................32
4.3 Saatin ayarlanması.................................32
4.4 Hızlı pişirme...........................................32
4.5 Mikrodalgada pişirme.............................32
4.6 Izgara ...................................................32
4.7 Kombinasyon ........................................33
4.8 Çok hızlı buz çözme................................33
4.9 Ağırlıklı buz çözme .................................33
4.10 Program..............................................33
4.11 Çok aşamalı pişirme............................. 33
4.12 Çocuk kilidi..........................................34
4.13 Pişirme teknikleri .................................34
5 Temizlik 35
5.1 Temizlik ve bakım...................................35
5.2 Saklama................................................35
5.3 Taşıma ve nakliye................................... 36
6 Sorun giderme 36
7 Tüketici hizmetleri 37
