arcelik MD 260 AF DB User manual

Kullanma Kılavuzu
01M-9207131100-0523-02
MD 260 AF DB
Mikrodalga Fırın
EN - TR

Microwave Oven / User Manual
2 / EN
CONTENTS
1 Important safety and
environmental instructions 4
1.1 Safety warnings..................................4
1.2 Compliance with the WEEE Directive
and Disposing of the Waste Product: 10
1.3 Compliance with RoHS Directive. 10
1.4 Package information...................... 10
2 Your microwave oven 11
2.1 Overview ........................................... 11
2.2 Technical data ................................. 11
2.3 Installing the turntable ................... 12
3 Installation 13
3.1 Installation........................................ 13
4 Operation 14
4.1 Control panel.................................... 14
4.2 Clock setting .................................... 15
4.3 Kitchen timer ................................... 15
4.4 Microwave cooking ........................ 15
4.5 Grill cooking ..................................... 15
4.6 Convection cooking........................ 16
4.7 Combination cooking..................... 16
4.8 Defrost by weight ........................... 16
4.9 Defrost by time................................ 17
4.10 Multi-Stage cooking ..................... 17
4.11 Express microwave cooking....... 17
4.12 Child lock........................................ 17
4.13 Deodoriser...................................... 17
4.14 Steam clean................................... 17
4.15 Healthy dish................................... 18
4.16 Daily dish........................................ 18
4.17 Auto menu...................................... 19
4.18 A Fry ................................................ 20
5 Cleaning and maintenance 22
5.1 Cleaning and care........................... 22
5.2 Storage.............................................. 23
5.3 Handling and transportation......... 23
6 Troubleshooting 24

Please read this user manual first!
Dear Valued Customer,
Thank you for preferring this Arçelik appliance. We hope that you get the
best results from your appliance which has been manufactured with
high quality and state-of-the-art technology. For this reason, please
read this entire user manual and all other accompanying documents
carefully before using the appliance and keep it as a reference for
future use. If you handover the appliance to someone else, give the
user manual as well. Follow the instructions by paying attention to all
the information and warnings in the user manual.
Remember that this user manual may also apply to other models.
Differences between models are explicitly described in the manual.
Meanings of the Symbols
Following symbols are used in various sections of this user manual:
CImportant information and useful hints about usage.
AWarnings for dangerous situations concerning
the safety of life and property.
Warning for hot surfaces.

Microwave Oven / User Manual
4 / EN
1Important safety and environmental
instructions
Important Safety Instruc-
tions Read Carefully And
Keep For Future Reference
1.1 Safety warnings
This section contains safe-
ty instructions that will help
protect from risk of fire,
electric shock, exposure
to leak microwave energy,
personal injury or property
damage. Failure to follow
these instructions shall void
any warranty.
•Arçelik Microwave Ovens
comply with the applicable
safety standards; there-
fore, in case of any dam-
age on the appliance or
power cable, it should be
repaired or replaced by the
dealer, service center or a
specialist and authorized
service alike to avoid any
danger. Faulty or unqual-
ified repair work may be
dangerous and cause risk
to the user.
•This appliance is intended
to be used in household
and similar applications
such as:
–Staff kitchen areas in
shops, offices and other
working environments;
–Farm houses
–By clients in hotels, and
other residential type
environments;
–Bed and Breakfast type
environments.
•Microwave oven is in-
tended used freestanding.
•It is not intended for indus-
trial or laboratory use.
•Do not attempt to start
the oven when its door is
open; otherwise you may
be exposed to harmful
microwave energy. Safety
locks should not be disa-
bled or tampered with.
•The microwave oven is
intended for heating food
and beverages. Drying of
food or clothing and heat-
ing of warming pads, slip-
pers, sponges, damp cloth

Microwave Oven / User Manual 5 / EN
1Important safety and environmental
instructions
and similar may lead to risk
of injury, ignition or fire.
•Do not place any object
between the front side and
the door of the oven. Do
not allow dirt or cleaning
agent remnants to build up
on the closure surfaces.
•Any service works involv-
ing removal of the cover
that provides protection
against exposure to mi-
crowave energy must be
performed by authorized
persons/service. Any other
approach is dangerous.
•Your product is intended
for cooking, heating and
defrost food at home. It
must not be used for com-
mercial purposes.
•Your oven is not designed
to dry any living being.
•Do not use your appliance
to dry clothes or kitchen
towels.
•Do not use this appliance
outdoors, bathrooms, humid
environments or in places
where the it can get wet.
•No responsibility or war-
ranty claim shall be as-
sumed for damages
arising from misuse or
improper handling of the
appliance.
•Never attempt to disman-
tle the appliance. No war-
ranty claims are accepted
for damage caused by im-
proper handling.
•Only use the original parts
or parts recommended by
the manufacturer.
•Do not leave this appli-
ance unattended while it
is in use.
•Always use the appliance
on a stable, flat, clean dry,
and non-slip surface.
•The appliance should not
be operated with an exter-
nal clock timer or separate
remote control system.
•Before using the appliance
for the first time, clean all
parts. Please see the de-
tails given in the “Cleaning

Microwave Oven / User Manual
6 / EN
and Maintenance” section.
•Operate the appliance for
its intended purpose only
as described in this manual.
•Appliance becomes very
hot while it is in use. Pay
attention not to touch the
hot parts inside the oven.
•Do not operate the oven
empty.
•Cooking utensil may get
hot due to the heat trans-
ferred from the heated
food to the utensil. You
may need oven gloves to
hold the utensil.
•Utensils shall be checked
to ensure that they are
suitable for use in micro-
wave ovens.
•Do not place the oven on
stoves or other heat gener-
ating appliances. Otherwise,
it may be damaged and the
warranty becomes void.
•Steam may come out
while opening the covers
or the foil after cooking the
food.
•The appliance and its ac-
cessible surfaces may be
very hot when the appli-
ance is in use.
•Door and outer glass may
be very hot when the appli-
ance is in use.
•Make sure that your mains
power supply complies
with the information sup-
plied on the rating plate of
the appliance.
•The only way to discon-
nect the appliance from
the power supply is to re-
move the power plug from
the power outlet.
•Use the appliance with a
grounded outlet only.
•Never use the appliance if
the power cable or the ap-
pliance itself is damaged.
•Do not use this appliance
with an extension cord.
•Never touch the appliance
or its plug with damp or
wet hands.
•Place the appliance in a
way so that the plug is al-
1Important safety and environmental
instructions

Microwave Oven / User Manual 7 / EN
ways accessible.
•Prevent damage to the
power cable by not squeez-
ing, bending, or rubbing it
on sharp edges. Keep the
power cable away from
hot surfaces and naked
flame.
•Make sure that there is
no danger that the power
cable could be acciden-
tally pulled or that some-
one could trip over it when
the appliance is in use.
•Unplug the appliance be-
fore each cleaning and
when the appliance is not
in use.
•Do not pull the power cable
of the appliance to dis-
connect it from its power
supply and never wrap its
power cable around the
appliance.
•Do not immerse the ap-
pliance, power cable, or
power plug in water or any
other liquids. Do not hold it
under running water.
•When heating food in plas-
tic or paper containers,
keep an eye on the oven
due to the possibility of ig-
nition.
•Remove the wire strings
and/or metal handles of
paper or plastic bags be-
fore placing bags to the
oven.
•If smoke is observed,
switch off or unplug the
appliance if safe to do so
and keep the door closed
in order to stifle any
flames.
•Do not use microwave
oven for storage. Do not
leave paper items, cooking
material or food inside the
oven when it is not being
used.
•The contents of feeding
bottles and baby food
jars should be stirred or
shaken and the tempera-
ture checked before con-
sumption, in order to avoid
burns.
1Important safety and environmental
instructions

Microwave Oven / User Manual
8 / EN
•This appliance is a Group
2 Class B ISM equipment.
Group 2 contains all ISM
(Industrial, Scientific and
Medical) equipment in
which radio-frequency en-
ergy is intentionally gen-
erated and/or used in the
form of electromagnetic
radiation for the treatment
of material, and spark ero-
sion equipment.
•Class B equipment is suit-
able for use in domestic
establishments and es-
tablishments directly con-
nected to a low voltage
power supply network.
•Do not use cooking oil in
the oven. Hot oil may dam-
age the components and
materials of the oven, and
it may even cause skin
burns.
•Pierce food with thick
crust such as potatoes,
courgettes, apples and
chestnuts.
•Appliance must be placed
so that the rear side is fac-
ing the wall.
•Before moving the appli-
ance, please secure the turn-
table to prevent damage.
•Eggs in their shell and whole
hard-boiled eggs must not
be heated in microwave
ovens since they may ex-
plode, even after microwave
heating has ended.
WARNING: If the door or door
seals are damaged, the
oven must not be operated
until it has been repaired by
a competent person.
WARNING: It is hazardous for
anyone other than a compe-
tent person to carry out any
service or repair operation
which involves the removal
of a cover which gives pro-
tection against exposure to
microwave energy.
WARNING: Liquids and other
foods must not be heated
in sealed containers since
they are liable to explode.
•The oven should be
cleaned regularly and any
1Important safety and environmental
instructions

Microwave Oven / User Manual 9 / EN
food deposits removed.
•There should be min 20
cm free space above the
top surface of the oven.
•Do not over-cook foods;
otherwise, you may cause
a fire.
•Do not use chemicals and
steam assisted cleaners
to clean the appliance.
•Extreme caution is ad-
vised when being used
near children and persons
who are restricted in their
physical, sensory or men-
tal abilities.
•This appliance can be
used by the children who
are at the age of 8 or over
and by the people who
have limited physical, sen-
sory or mental capacity or
who do not have knowl-
edge and experience, as
long as they are super-
vised with regard to safe
use of the product or they
are instructed accordingly
or understand the risks of
1Important safety and environmental
instructions
using the product. Chil-
dren should not play with
the appliance. Cleaning
and user maintenance
shall not be made by chil-
dren unless they are older
than 8 and supervised.
•Danger of choking! Keep all
the packaging materials
away from children.
•Due to excessive heat that
arises in grill and combi-
nation modes, children
should only be allowed to
use these modes under
supervision of an adult.
•Keep the product and its
power cable so that they
are inaccessible by chil-
dren under 8 years old.
•Do not cook food directly
on the glass tray. Put the
food in / on appropriate
kitchen utensils before
placing them in the oven.
•Metallic containers for
food and beverages are
not allowed during micro-
wave cooking. Otherwise,

Microwave Oven / User Manual
10 / EN
sparking may occur.
•This product is not de-
signed to be built-in. Do not
place the product in a cabi-
net or box while it is in use.
•Failure to maintain the oven
in a clean condition could
lead to deterioration of the
surface that could adversely
affect the life of the appli-
ance and possibly result in a
hazardous situation.
•The appliance shall not
be cleaned with a steam
cleaner.
•Microwave heating of
beveranges can result in
delayed eruptive boiling,
therefore care must be
taken when handling the
container.
1.2 Compliance with the WEEE
Directive and Disposing of the
Waste Product:
This product complies with EU WEEE
Directive (2012/19/EU). This product
bears a classification symbol for waste
electrical and electronic equipment
(WEEE).
This symbol indicates that this
product shall not be disposed
with other household wastes at
the end of its service life. Used
device must be returned to offi-
cal collection point for recycling of electri-
cal and electronic devices. To find these
collection systems please contact to your
local authorities or retailer where the
product was puchased. Each household
performs important role in recovering and
recycling of old appliance. Appropriate
disposal of used appliance helps prevent
potential negative consequences for the
environment and human health.
1.3 Compliance with RoHS
Directive
The product you have purchased com-
plies with EU RoHS Directive (2011/65/
EU). It does not contain harmful and
prohibited materials specified in the
Directive.
1.4 Package information
Packaging materials of the
product are manufactured from
recyclable materials in accord-
ance with our National
Environment Regulations. Do not dis-
pose of the packaging materials togeth-
er with the domestic or other wastes.
Take them to the packaging material col-
lection points designated by the local au-
thorities.
1Important safety and environmental
instructions

Microwave Oven / User Manual 11 / EN
Markings on the product or the values stated in other documents supplied with the product are values obtained under laboratory
conditions as per relevant standards. These values may vary according to the usage of the appliance and ambient conditions.
Power values are tested at 230V.
2 Your microwave oven
2.1 Overview
1. Control panel
2. Turntable ring assembly
3. Glass tray
4. Oven window
5. Bake tray (Cannot be used in con-
junction with microwave function
and can be placed on the bake rack)
6. Lower Wire Rack( For the microwa-
ve and for baking and roasting in the
oven. )
7. Higher Wire Rack( For grilling, e.g.
steaks, sausages and for toasting
bread.As a support for shallow
dishes. )
1
2
3
4
5 6 7
2.2 Technical data
Model MD 260 AF DB
Voltage / Frequency 230V~ 50Hz
Power input - Microwave 1450W
Power output - Microwave 900W
Grill 1000W
Convection 2100W
Microwave frequency 2450MHz
Turntable diameter 288 mm
External dimensions 495*424*290 mm
Oven capacity 27 L

Microwave Oven / User Manual
12 / EN
2 Your microwave oven
2.3 Installing the turntable
•Never place the glass tray upside
down. The glass tray should never be
restricted.
•Both glass tray and turntable ring as-
sembly must always be used during
cooking.
•All food and containers of food must
always place on the glass tray for cook-
ing.
•If glass tray or turntable ring assembly
crack or break, contact your nearest
authorized service center.
Hub (underside)
Glass tray
Turntable ring assembly
Turntable shaft

Microwave Oven / User Manual 13 / EN
3 Installation
3.1 Installation
•Remove all packing material and ac-
cessories. Examine the oven for any
damage such as dents or broken door.
Do not install if oven is damaged.
•Remove any protective film found on
the microwave oven cabinet surface.
•Do not remove the light brown Mica
cover that is attached to the oven cav-
ity to protect the magnetron.
•Select a level surface that provide
enough open space for the intake and/
or outlet vents.
20 cm
30 cm
20 cm
min.85 cm
20 cm
•Minimum installation height is 85 cm.
•The rear surface of appliance shall be
placed against a wall. Leave a mini-
mum clearance of 30cm above the
oven, a minimum clearance of 20cm
is required between the oven and any
adjacent walls.
•Do not remove the legs from the bot-
tom of the oven.
•Blocking the intake and / or outlet
openings can damage the oven.
•Place the oven as far away from radios
and TV as possible. Operation of mi-
crowave oven may cause interference
to your radio or TV reception. 2. Plug
your oven into a standard household
outlet. Be sure the voltage and the fre-
quency is the same as the voltage and
the frequency on the rating label.
A
WARNING: Do not
install oven over a
range cooktop or
other heat-produc-
ing appliance. If in-
stalled near or over
a heat source, the
oven could be dam-
aged and the war-
ranty would be void.
The accessible sur-
face may be hot
during operation.

Microwave Oven / User Manual
14 / EN
4.1 Control panel Display
Cooking time, power, indicators and
clock time are displayed.
Microwave
Convection
Grill
Defrost by weight
Defrost by time
Auto menu
A Fry
Alarm
Clock/ Childlock
Mute
Child lock
Gram
Temperature
Menu
•Auto cook buttons: Instant settings to
cook popular foods.
Function
•Koku Giderme / Deodorizer : Press to re-
move food odors in microwave.
•Buharlı Temizleme / Steam Clean: Press to
steam clean the microwave.
•Saat / Clock: Press to set clock time.It is
also used to set child lock.
•Mikrodalga / Microwave: Press to set mi-
crowave power level.
•Zamanlayıcı / Timer: Press to set the
alarm timer.
•Buz çözme / Defrost: Press to defrost
food based on time/weight.
4 Operation

Microwave Oven / User Manual 15 / EN
•Izgara / Grill: Press to set grill cooking
program.
•Kombinasyon / Combi.: Press to set mi-
crowave, grill and convection combina-
tion cooking program.
•Konv. / Conv.: Press to set convection
cooking.
•-/+ : Press to set time. Long press to
increase/decrease speed.
•Mute - : Press to mute
•DURDUR / İPTAL - STOP / CANCEL: Press
to Pause/cancel at any settings. Press
twice to turn off the display
•BAŞLAT/+30 SANİYE - START / +30SEC:
Press to start/confirm at any settings.
Press for express cooking at standby
mode
When the microwave oven firstly be
powered on, the screen will display
"0:00 ", and buzzer will ring once to enter
the standby mode.
4.2 Clock setting
1.In waiting state, press "Saat" once, and
then the screen displays "00:00". The
hour figures will flash.
2.Press "+/-" to adjust the hour figures.
The input time should be within 0-23.
3.Press "Saat" to confirm, and the min-
ute figures will flash.
4.Press "+/-" to adjust the minute figures.
The input time should be within 0-59.
5.Press "Saat" to finish clock setting.
C
•The clock will not work if it
is not set when powered.
•After step 4, if you do not
press "Saat" within 1 min-
utes, the oven will go back
to the previous status auto-
matically.
4 Operation
4.3 Kitchen timer
1.In waiting state, press "Zamanlayıcı"
once, and the screen displays "0:00".
2.Press "+/-" to adjust the enter time. The
maximum value is 95:00.
3.Press "BAŞLAT/+30 SANİYE" to con-
firm setting.
CDuring kitchen timer, any oth-
er programs cannot work.
4.4 Microwave cooking
1.In waiting state, press "Mikrodalga",
and “P100” will display.
2.Press "+/-" or press "Mikrodalga" re-
peatedly to set the power level. “P100,
P90, P80, P70, P60, P50, P40, P30, P20,
P10” are available.
3.Press "BAŞLAT/+30 SANİYE" to confirm.
Default cook time 15:00 will display.
4.Press "+/-" to set the cook time. The
maximum value is 95:00.
5.Press "BAŞLAT/+30 SANİYE" to start
cooking.
4.5 Grill cooking
1.Press "Izgara" once, and "G" will display.
2.Press "BAŞLAT/+30 SANİYE" to confirm,
default cook time 15:00 will display.
3.Press "+/-" to set the cook time. The
maximum value is 95:00.
4.Press "BAŞLAT/+30 SANİYE" to start
cooking.

Microwave Oven / User Manual
16 / EN
4 Operation
C
•If half the grill time passes, the oven sounds to remind you to turn the food
over. In order to have a better effect of grilling food, you can turn the food
over, close the door and then press "BAŞLAT/+30 SANİYE" to continue
cooking. If no operation, the oven will work automatically.
•In the cooking process, when you increase or reduce the time, half time
prompt is no affected.
4.6 Convection cooking
1.Press "Konv." once. and "150°C" will display.
2.Press "Konv." repeatedly to choose temperature from 150°C to 240°C.
3.Press "BAŞLAT/+30 SANİYE" to confirm the temperature, if you press "BAŞLAT/+30
SANİYE" again, the oven will start preheating. when preheating temperature is
reached the buzzer will sound twice. You can open the oven door and place food
in it.
4.Or press "+/-" to set the cook time directly. The maximum value is 95:00.
5.Press the " Start/+30SEC" to start working.
4.7 Combination cooking
1.Press "Kombinasyon" once, the screen will display "C-1", and press "Kombinasyon"
repeatedly to choose the power you want, and "C-1, C-2, C-3, o C-4" will display.
2.Press "BAŞLAT/+30 SANİYE" ton confirm the mode, default cook time 15:00 will
display.
3.Press "+/-" to set the cook time. The maximum value is 95:00.
4.Press "BAŞLAT/+30 SANİYE" to start cooking.
Combination instructions Instructions display Microwave Grill Convection
1 C-1 • •
2 C-2 • •
3 C-3 • •
4 C-4 • • •
4.8 Defrost by weight
1.In waiting state, press "Buz Çözme" once, and the screen displays "dEF1".
2.Press "BAŞLAT/+30 SANİYE" to confirm,100g displays.
3.Press "+/-" to set the defrost weight within 100~2000g.
4.Press "BAŞLAT/+30 SANİYE" to start defrosting.
CThe buzzer will sound to remind of turning over the food during defrost-
ing.

Microwave Oven / User Manual 17 / EN
4 Operation
4.9 Defrost by time
1.In waiting state, press "Buz Çözme" twice, and the screen displays "dEF2".
2.Press "BAŞLAT/+30 SANİYE" to confirm,15:00 displays.
3.Press "+/-" to set the defrost time. The maximum value is 95:00.
4.Press "BAŞLAT/+30 SANİYE" to start defrosting.
CThe buzzer will sound to remind of turning over the food during defrost-
ing.
4.10 Multi-Stage cooking
Two stages can be maximumly set. If one stages is defrosting, it should be put in
the first stage automatically. The buzzer will ring once after each stage and the next
stage will begin. Kitchen Timer, Auto menu ,Speed cooking or Preheating cannot be
set as one of the multi-stage.
Example: If you want to defrost the food for 10 minutes, then grill them for 10 minutes
and 30 seconds. You can follow these steps.
1.Press "Buz Çözme" twice, and the screen will display "dEF2".
2.Press "BAŞLAT/+30 SANİYE" to confirm,15:00 displays.
3.Press "+/-" to adjust the defrost time until 10:00 displays.
4.Press "Izgara" once, "G" displays, press "BAŞLAT/+30 SANİYE" to confirm
5.Press "+/-" to adjust the grill time until 10:00 displays.
6.Press "BAŞLAT/+30 SANİYE" to start cooking.
4.11 Express microwave cooking
In standby state, press "BAŞLAT/+30 SANİYE" to start cooking with 100% power for
30 seconds directly.
4.12 Child lock
Lock: In standby state, press "Saat" for 3 seconds. The buzzer will sound to enter the
children-lock state,and the lock indicator will light.
Lock quitting: In locked state, press "Saat" for 3 seconds.The buzzer will sound denot-
ing that the lock is released, and the lock indicator will disappear.
4.13 Deodoriser
1.In standby state, press "Koku Giderme", and the screen displays "dE" .
2.Press "BAŞLAT/+30 SANİYE" to start working.
4.14 Steam clean
1.In standby state, press "Buharlı Temizleme", and the screen displays "SC".

Microwave Oven / User Manual
18 / EN
4 Operation
2.Press "BAŞLAT/+30 SANİYE" to start working.
CPour equal parts of water into a wide open microwave-safe container.
when finished working, wipe the steamed surfaces with a clean sponge
to help remove food and odors from the surfaces.
4.15 Healthy dish -
1.In waiting state, press " " once, and "dd01" will display.
2.Press " " repeatedly to choose the menu from "Hd01" to "Hd05".
3.Press "BAŞLAT/+30 SANİYE" to confirm the submenu.the default weight or serv-
ings of the menu will display.
4.Press "+/-" to set the weight or servings.
5.Press "BAŞLAT/+30 SANİYE" to start cooking.
Health dish chart
MENU/ Display Weight/ Display Time (min' sec") Power
Hd01
Quinoa
100g 3'00"/15'00" P100/P50
200g 5'00"/15'00"
Hd02
Couscous
200g 4'00"/8'00" P100/P50
300g 5'00"/10'00"
Hd03
Macaroni
100g 10'00" P80
200g 12'00"
Hd04
Brown Rice
200g 5'30"/25'00" P100/P50
300g 8'00"/30'00"
Hd05
Oatmeal
2 servings 3'30"/3'30" P100/P50
4 servings 5'30"/5'30"
4.16 Daily dish -
1.In waiting state, press " " once, and "dd01" will display.
2.Press " " repeatedly to choose the menu from "dd01" to "dd12".
3.Press "BAŞLAT/+30 SANİYE" to confirm the submenu.the default weight or serv-
ings of the menu will display.
4.Press "+/-" to set the weight or servings.
5.Press "BAŞLAT/+30 SANİYE" to start cooking.
Daily dish chart
MENU/ Display Weight/ Display Time (min' sec") Power
dd01
Frozen Peas
200g 4'00" P100
400g 7'00"

Microwave Oven / User Manual 19 / EN
4 Operation
dd02
Couscous
200g 4'00" P100
400g 7'00"
dd03
Frozen Broccoli
200g 5'00" P100
400g 8'00"
dd04
Fresh Spinach
200g 2'30" P100
400g 4'30"
dd05
Frozen green beans
200g 5'00" P100
400g 8'00"
dd06
Potatoes without skin
400g 6'00" P100
800g 10'00"
dd07
Potatoes with skin
2 (~200g/pc) 8'30" P100
4 (~200g/pc) 15'00"
dd08
Frozen lasagna
300g 15'00" C-1
600g 20'00"
dd09
Grill chicken breasts
200g 16'00" Grill 60% +
Conv. 240°C
400g 20'00"
dd10
Lamb rack 900g 35'00" C-4
dd11
Roast beef 900g 35'00" C-4
dd12
Grill garlic bread 200g 9'00" C-4
4.17 Auto menu
For example set the fish menu for 350g;
1.In waiting state, press "Fish" once, and "150g" will display.
2.Press "Fish" repeatedly until 350g displays.
3.Press "BAŞLAT/+30 SANİYE" to start cooking.
Menu Chart
MENU/ Display Weight/ Display Time (min' sec") Power
A01
Popcorn -
50g 1'40" P100
100g 2'00"

Microwave Oven / User Manual
20 / EN
A02
Fish -
150g 3'00"
P80
250g 4'00"
350g 5'30"
450g 6'30"
650g 8'30"
A03
Chicken -
500g 29'00"
C-4 (beep to turn the
food over)
750g 34'00"
1000g 39'00"
1200g 44'00"
A04
Cake - 475g 60'00" Preheat 160°C / Conv.160°C
A05
Pizza -
100g 8'00"
C-4200g 10'00"
300g 12'00"
A06
Pasta -
50g (cold water 450g) 18'00"
P80100g (cold water 800g) 20'00"
150g (cold water 1200g) 22'00"
C
•The buzzer will sound to remind of turning over the food during chicken
menu.
•In Cake Menu, the oven will start preheating, when preheating temper-
ature is reached the buzzer will sound twice. You can open the oven
door and place food in it. Press "BAŞLAT/+30 SANİYE" to start cooking.
4.18 A Fry -
1.In waiting state, press " " repeatedly to choose the menu, and "AF01~AF10" will
display in order.
2.Press "BAŞLAT/+30 SANİYE" to start cooking.
MENU/ Display Weight/ Display Time (min' sec") Power
AF01
Frozen French Fries 300g 6'00"/16'00" G-100% + Conv.-240°C / G-60% + Conv.-240°C
AF02
Frozen Potato Wedges 450g 15'00"/15'00" G-100% + Conv.-240°C / G-60% + Conv.-240°C
AF03
Frozen Chicken nuggets 350g 22'00" G-60% + Conv.-240°C
AF04
Frozen Fried Squid 250g 16'00" G-60% + Conv.-240°C
4 Operation
