Archos kuno 4 User manual

1
ENEN
Table of contents
For more information, please contact us at www.mykuno.com/contact.php
Package contents...................................................................................................................................
Getting started........................................................................................................................................
Description of the device.....................................................................................................................
Startup wizard........................................................................................................................................
Connecting to a WiFi network...........................................................................................................
The AndroidTM interface.......................................................................................................................
Getting familiar with AndroidTM......................................................................................................
Troubleshooting....................................................................................................................................
2
3
4
6
7
8
12
14

2
Warranty
KUNO 4
AN8G4
21-11-2012
lastmodification:
CONFIDENTIAL
Drawing
Rev
1
scale1:1 mm
USB cable Charger
User Manual
Warranty,
legal & safety booklet
Package Contents
KUNO 4

3
EN
Getting Started
Charging
1. Connect the supplied power cable to the KUNO and to a wall outlet.
The KUNO device will start charging.
2. Press the ON/OFF button to turn on the device.
You can use your KUNO while it charges.
-Let your device charge completely the rst time you use it.
-Use only the supplied charger.

4
4
5
7
6
8
9
10
321 12
11
Description of the device

5
EN
Volume buttons
Home button
Front Camera
Speakers
Headphone jack
Micro-USB port
Micro-SD card slot
Mini-HDMI video output*
Power connector
Power button
Reset button
Rear Camera
19
210
3
4
5
6
7
8
12
11
*With optional Mini-HDMI to HDMI cable
13
Bluetooth

6
Startup Wizard
TIPS:
We recommend that you set up your device in the WiFi zone of the network that you will regularly be
using.
The rst time you start up your KUNO, the startup wizard will help you set up your device:
-Language
-Date & time
-WiFi connection
-Location service options
-3rd party apps

7
EN
Connecting to a WiFi Network
TIPS:
-When entering a WiFi password, we recommend that you select “Show password”so you can see the
characters you are typing.
-To get the correct WiFi password (or settings) for the network, contact the WiFi network provider.
-If your WiFi is on and you are in range of a network that you previously connected to, your KUNO
will automatically attempt to connect to it.
WARNING: Make sure that you are in a WiFi zone. You can access the WiFi settings quickly from
the status bar in the bottom right corner of the screen.
1. Touch the time in the status bar.
The status dashboard is displayed.
2. Touch the time a second time in the status dashboard.
The quick settings will be displayed.
3. Touch "Settings" to open the WiFi settings menu.
4. If the WiFi is o, slide the WiFi switch to the "ON" position.
Once the WiFi is on, the KUNO will scan for WiFi networks in range.
5. Touch the name of network you want to connect to.
Private networks are shown with a lock icon and will require you to enter your password.

8
1
2
3
5
6
7
8
4
The AndroidTM Interface

9
EN
1
2
3
4
5
6
7
8
GoogleTM Search
>Touch "Google" for text search or touch the microphone icon for voice search.
"Recent apps" button
"Home" button
"Back" button
"All Apps" button
> Touch this icon to show all the applications and widgets installed on your KUNO.
All your downloaded applications are here.
Widget
AndroidTM apps shortcuts
> Touch to start an application.
The status bar
> Displays notications and quick settings.

10
The AndroidTM Interface
The Quick settings
-Airplane mode:
-WiFi:
-Auto-rotate screen:
To activate/deactivate automatic screen
orientation as you turn your KUNO.
-Brightness:
To adjust the screen brightness.
-
-Settings:
To access all your settings.
- Bluetooth
To turn on/off your Bluetooth connection
