Arecont Vision MegaBall 2 User manual

1080p 1080p WDR 3Megapixel 3Megapixel WDR 5Megapixel
AV2245PM-D AV2246PM-D AV3245PM-D AV3246PM-D AV5245PM-D
AV2245PM-D-LG AV2246PM-D-LG AV3245PM-D-LG AV3246PM-D-LG AV5245PM-D-LG
AV2245PM-W AV2246PM-W AV3245PM-W AV3246PM-W AV5245PM-W
+1.818.937.0700 | 877.CAMERA.8 | www.arecontvision.com | [e-mail]
Made in the USA
1080p–5 Megapixels
MegaBall®2
1.3–5MP H.264 All-in-One Manual Lens or Motorized P-Iris Lens Day/Night Indoor IP Cameras
(WDR option in 1080p and 3MP)
Stylish MegaBall®2 multi-megapixel cameras provide ample
resolution to zoom-in for details in live or recorded video. These
indoor all-in-one solutions integrate a 1080p, 3 or 5-megapixel
camera with fast frame rates and an IR corrected motorized
vari-focal P-iris lens with an adjustable wall mount or flush and
surface mount dome housing. H.264 compression reduces network
bandwidth and storage requirements while delivering full frame
rates and full resolution without sacrificing image quality. Day/Night
functionality allows for 24-hour surveillance. Wide Dynamic Range
(WDR) up to 100dB at full resolution balances light and dark areas in
the same scene (AV2246 and AV3246). Binning mode for increased
low-light sensitivity is available for 3MP and 5MP cameras.
MegaBall®Cameras
Wall/Ceiling Mount
(-W)
Flush Mount
(-D)
Surface Mount
LG Version (-LG – Light Gray)
• Remote Focus/Zoom P-Iris Lens (-PM Models)
• P-Iris Control to Get Best Depth of Field and Image Clarity
(-PM Models)
• Optional True WDR up to 100dB at Full Resolution Available
on Some 1080p and 3MP Models: See Clearly in Shaded
and Bright Light Conditions Simultaneously
• Light Gray and Black Dome Options
• Casino Mode™ Guarantees Continuous 30fps Frame Rate
Required by Gaming Industry Regulations (AV2145 & 2245
Models)
• Binning Mode for Strong Low-Light Performance on 3MP
and 5MP Resolutions
• True Day/Night Functionality with Mechanical IR Cut Filter (DN Models)
• Tamper-Resistant Housing
• Installer Friendly Cable Management, 3-Axis Adjustment, In-Ceiling
and Surface Mount Dome
• PoE and Auxiliary Power: 12–48V DC/24V AC
• Dual Encoder H.264/MJPEG
• Privacy Mask, 1024 Zone, Motion Detection, Flexible Cropping,
Bit Rate Control, Multi-Streaming and Forensic Zooming
• Fast Frame Rates
• PSIA Conformant
• New User-Friendly Webpage
• Reduced Overall System Cost
• Made in the USA
Features:
All-in-One Ball
Solution
Pixel Binning Mode
on 3 and 5MP Models
Dual Encoder
H.264/MJPEG
Wide Dynamic Range
Available on AV2246 and
AV3246 Models
Casino Mode™
Maintains at Least 30fps
on AV2245 Models
True Day/Night
with IR Cut Filter
Integrated Motorized Lens
with Remote Focus
and Zoom
P-Iris Control for
Best Depth of Field
and Image Clarity

+1.818.937.0700 | 877.CAMERA.8 | www.arecontvision.com | [email protected]
Made in the USA
©2013 Arecont Vision. Specification sheets subject to change without notice.
MegaBall®2 Specifications
Camera Imaging Specifications
Model AV2245 AV2246 AV3245 AV3246 AV5245
Image Sensor (CMOS) 1080p 1080p* 3MP* 3MP 5MP
Optical Format 1/2.7" 1/3.2" 1/2.5" 1/3.2" 1/2.5"
Pixel Pitch 3μm 2.2μm 2.2μm 2.2μm 2.2μm
Minimum
Illumination
Color (day mode) 0.1 Lux 0.3 Lux 0.3 Lux 0.3 Lux 0.3 Lux
Color Binning (day mode) - - 0.15 Lux 0.15 Lux 0.15 Lu x
B/W (night mode) 0 Lux, IR sensitive 0 Lux, IR sensitive 0 Lux, IR sensitive 0 Lux, IR sensitive 0 Lux, IR sensitive
Full FOV Resolution 1920 H x 1080 V 1920 H x 1080 V 2048 H x 1536 V 2048 H x 1536 V 2592 H x 1944 V
1/4 Resolution 960 H x 540 V 960 H x 540 V 1024 H x 768 V 1024 H x 768 V 1296 H x 972 V
Dynamic Range 69dB WDR up to 100dB 70.1d B WDR up to 100dB 70.1dB
Maximum SNR 45dB 49dB 45dB 49dB 45dB
Frame Rates
At Max Resolution 31fps (1920 x 1080) 30fps (1920 x 1080) 21fps (2048 x 1536) 21fps (2048 x 1536) 14fps (2592 x 1944)
Cropped
42fps (1280 x 1024) 41fps (1280 x 1024) 29fps (1920 x 1080)
41fps (1280 x 1024)
30fps (1920 x 1080)
41fps (1280 x 1024)
21fps (2048 x 1536)
29fps (1920 x 1080)
41fps (1280 x 1024)
Binning Mode
- - 46fps (1024 x 768)
64fps (960 x 540)
21fps (1024 x 768)
27fps (800 x 600)
31fps (960 x 540)
32fps (640 x 512)
34fps (1296 x 972)
46fps (1024 x 768)
64fps (960 x 540)
Lens Motorized Lens
3-10mm, 1/2.7", F1.3
RZ, RF, P-iris
H-FOV = 117°–36°
3-10mm, 1/2.7", F1.3
RZ, RF, P-iris
H-FOV = 81°–26°
3-10mm, 1/2.7", F1.3
RZ, RF, P-iris
H-FOV = 86°–28°
3-10mm, 1/2.7", F1.3
RZ, RF, P-iris
H-FOV = 86°–28°
3.4-10mm, 1/2.5", F1.4
RZ, RF, P-iris
H-FOV = 102°–35°
Model Specific Features
Model Resolution Frame Rate Features
AV2245 1080p 31fps - Casino Mode™-
AV2246 1080p 30fps WDR - -
AV3245 3MP 21fps - - Binning
AV3246 3MP 21fps WDR - Binning
AV5245 5MP 14fps - - Binning
Build-to-Order Options
-W Wall Mount Model
-D Dome or Recessed Dome Model
-LG Light Gray Dome
Create Your Model (Example: AV3246-PM-D-LG)
AV 42
3
2
5
Megapixel
Resolution Generation Body Type Compression Lens Mount Light Gray Body
* WDR for AV2246 and AV3246 only.
** “4” Represents MegaBall product line—which are then defined by “W” or “D”
*** LG only available on Dome version
5
6
PM
D
W
WDR*
Standard
Motorized Lens
P-iris Day/Night
Wall Mount
Dome
LG
Light Gray Dome***
**
WDR WDR
*effective

Compliance Industry Standard PSIA Conformant
Listings UL (CB)
FCC Compliance 47 CFR 15 Class A
Environmental RoHS, REACH, WEEE
Markings (CE) EN55022 Class A, EN55024,
EN61000-3-2, EN61000-3-3, EN60950
Programmability Remote focus, remote zoom and P-iris control
Motion Detection and privacy mask with 1024 detection zones
Auto adjustment between WDR and LDR modes (WDR models only)
Programmable shutter speed to help control motion blur
Pixel Binning Mode (3MP and 5MP)
Casino Mode™maintains 30fps (AV2245 model)
Flexible Cropping (resolution windowing down to 1x1 pixel for JPEG and
2x2 pixels for H.264)
Low light noise filter control
Bit rate and bandwidth limitation control
Backlight compensation and multi-matrix white balance
50/60Hz selectable flicker control
Electronic pan, tilt, zoom (PTZ) and image flip 180°
Programmable resolution, brightness, saturation, gamma, sharpness, tint
+1.818.937.0700 | 877.CAMERA.8 | www.arecontvision.com | [email protected]
Made in the USA
©2013 Arecont Vision. Specification sheets subject to change without notice.Revi sed 11/13
Data Transmission Compression Type H.264 (MPEG-4, Part 10)/Motion JPEG
21 levels of quality
Transmission Protocols RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP
100Base-T Ethernet Network Interface
Multi-Streaming 8 non-identical streams
Environmental Operating temperature -5°C (-23°F) to +50°C (122°F)
Humidity 0% to 90% (non-condensing)
Stable image temperature 0°C (32°F) to +50°C (122°F)
Storage temperature -20°C (-4°F) to +60°C (140°F)
General Electrical Alarm Input/Output General purpose opto-coupled
Power Over Ethernet PoE 802.3af, Class 2
Auxiliary Power 12–48V DC, 24V AC
Max Power Consumption AV2245 5.9 Watts DC Power
AV3245 / AV5245 6.3 Watts DC Power
AV2246 / AV3246 6.8 Watts DC Power
Mechanical Casing -W Die-cast aluminum 3" metal ball and mount
-D Plastic surface/in-ceiling dome w/ Acrylic bubble
Gimbal Easy 3-axis camera adjustment w/360° pan, 90° tilt and
360° z-axis
Dimensions -W Ø 3" (76.2mm) x 6.15" H (156.2mm)
-D (in-ceiling) Ø 5.1" (130mm) x 1.74" H (44mm)
-D (surface
mount w/ bubble) Ø 5.1" (130mm) x 3.85" H (98mm)
Camera Unit Packaged
Weight -W 1.2lbs (0.54kg) 2.0lbs (0.9kg)
-D 1.2lbs (0.54kg) 1.9lbs (0.86kg)
Dome Color -LG Light Gray Dome
Accessories D4S-WMT-B Black wall mount with 3/4"NPT standard
D4S-CMT-B Black ceiling mount with 3/4"NPT standard
D4S-WMT Light Gray Wall mount with 3/4"NPT standard
D4S-CMT Light Gray Ceiling mount with 3/4"NPT standard
SV-EBA Light Gray Electrical box adapter
SV-JBA Light Gray Junction box adapter
MegaBall®2 Specifications
-W
-D
(in-ceiling)
-D
(w/Bubble)
-W
-D
(in-ceiling)
-D
6.15"
(156.2mm)
Ø 3"
(76.2mm)
Ø 5.1"
(130mm)
Ø 5.1"
(130mm)
Ø 5.1"
(130mm)
Ø 5.1"
(130mm)
1.74"
(44mm)
3.85"
(98mm)
