Argo APOLLO User manual

ERROR CODES LIST
air conditioner without outdoor unit
APOLLO

ERROR CODES LIST
Fault name Fault definition Code
Condensate drain
protection (float)

1
APOLLO
air conditioner without outdoor unit
COMPONENTS DISASSEMBLY MANUAL

2
1.Removing the rear panel
1. Remove 6 screws on the left and right sides of the front panel, then remove
the screws fixed on the rear panel.
2. Manually pull the rear panel outward to make sure that the top and bottom
attachment positions of the front and rear panel are
disconnected.
There is a hook in the connection between the front and the
rear panel; be careful when removing.
There is a hook in the connection between the front and the
rear panel; be careful when removing.

3
2.Removing the front components
1. After moving the deflector to a horizontal position, remove the three screws
2. Remove the 2 screws of the electrical panel cover, remove the cover and the
connection terminals for subsequent disassembly and
maintenance.

4
3. Lift the base slightly and pull the front outwards. Make sure that the joints
between the left and right sides of the front and the left and right sides of the
machine are blocked and that the lower part of the front and the base are
blocked. Make sure it is disengaged, move the front case horizontally and be
careful to loosen the connection cable when removing it.
3. Disassembly of the electrical panel and main board
1. Remove the 2 screws that fix the electrical box

5
2. Remove the screws that fix the main control board. Remove the screws that
fix the PCB heat sink and the electrical panel.
3. Remove the 2 screws that fix the cooling fan bracket.

6
4. Remove the screws that fix the reactor and remove it.

7
4. Disassembly of the evaporator duct assembly
1. Remove the screws that fix the motor lock plate and pull it out.

8
2. Remove the screws that fix the connection between the evaporator and the
air duct assembly.

9
3. Remove the 4 screws on the front and rear sides of the base of the internal
machine connected to the central support

10
4. After lifting the evaporator assembly, move the base unit of the indoor unit
out of the tilt.

11
5. Internal division of components
1. Remove the screws that connect the front plate (1) and the components of
the indoor unit.
2. Remove the screws that connect the center support cross plate (2) and the
center support side plate.
3. Lift the evaporator assembly and move it horizontally out of the central
partition.
4. Remove the screws that connect the base and side plates on both sides.
1
2

12
6. Dismantling the components of the exhaust pipe
1. Remove the screws that fix the fan assembly and remove it.
2. Remove the 4 screws on the outside of the volute, loosen the nut fixed on the
motor shaft, remove the nut and extract the fan with both hands, then remove
the other 4 screws that secure the motor. Remove the fan motor

13
7. Removing the refrigerant circuit
Remove the three screws that connect the end plates on both sides of the
condenser and the base.
1. Unscrew the three nuts that fix the compressor feet respectively, remove the
nuts and gaskets and lift the refrigerant circuit consisting of the compressor,
condenser and evaporator to disengage from the frame assembly (note that the
protection pipe must not be broken)
8. Removing the water pump switch and motor
1. Remove the 2 screws that fix the switch and the 2 screws that fix the water
pump motor.

14
9. Eletrical wiring diagram
