Argo NEWAGE 9000 UI User manual

V 11/22
NEWAGE
SINGLE SPLIT AIR CONDITIONERS-R32
INDOOR UNIT
NEWAGE 9000 UI
NEWAGE 12000 UI
NEWAGE 18000 UI
OUTDOOR UNIT
NEWAGE 9000 UE
NEWAGE 12000 UE
NEWAGE 18000 UE
Please read this manual carefully before installing and using the air conditioner, and retain for future
reference.
EN
USER MANUAL and INSTALLATION GUIDE

33V 11/22
INDEX
General warnings
Safety precautions
Notices for usage
Description of parts
Remote control guide
WiFi guide (optional)
Cleaning and care
Troubleshooting
Notices for the installation
Indoor unit installation
Outdoor unit installation
Maintenance notes
Warnings for the refrigeration system specialist
3
4
6
7
8
12
15
16
17
21
23
26
27
REQUIREMENTS FOR INSTALLATION AND MAINTENANCE PERSONNEL
All personnel who carry out installation and/or maintenance operations on the units must be equipped with PEF
(European Refrigerators License) as required by the D.P.R. n. 146/2018 implementing Regulation (EU) no. 517/2014.
If another technician is required to maintain and repair the equipment, this will need to be supervised by the person
who is qualied to use ammable refrigerants. The repair must be performed according to the methodology indicated
by the manufacturer of the equipment. If you need to install, move or service the air conditioner, please contact your
dealer or local service center for the procedure rst. The air conditioner must be installed, moved or maintained by
authorized personnel. Failure to do so could result in serious damage, personal injury or death.

34V 11/22
THE REFRIGERANT R32
GENERAL WARNINGS
Appliance lled with ammable
gas R32.
• To realize the function of the air conditioner unit, a special refrigerant circulates in the system. The refrigerant is
the uoride R32 = GWP (Global warming potential). This refrigerant is ammable and inodorous. It can lead to
explosions under certain conditions, however the ammability of this refrigerant is very low and it can be ignited
only by re.
• Compared to other common refrigerants, R32 is a non-polluting refrigerant with no harm to the ozonosphere and
a lower effect upon the greenhouse effect. R32 has very good thermodynamic features which lead to a really high
energy efciency. The units therefore need less lling.
Warning:
Do not try to accelerate the defrosting process or to clean the appliance in different ways other than those recommended
by the manufacturer. Should repair be necessary, contact your nearest authorized Argoclima Service Centre. Any
repairs carried out by unqualied personnel may be dangerous. The appliance has to be stored in a room that doesn’t
have any continuously operating ignition sources. (for example: open ames, an operating gas appliance or an
operating electric heater.) Do not pierce or burn. Appliance has to be installed, operated and stored in a room with a
oor area larger than X m2. (Please refer to table “a” in section of “ Safety Operation of Inammable Refrigerant” for
Space X.) For repairs, strictly follow manufacturer’s instructions only for appliances lled with R32 ammable gas. Be
aware that refrigerants do not have any odour.
Before using the appliance,
read the owner’s manual.
Before installing the appliance,
read the installation manual. Before repairing the appliance, read the service manual.

35V 11/22
SAFETY PRECAUTIONS
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• The air conditioner must be grounded. Incomplete grounding may result
in electric shocks. Do not connect the earth wire to the gas pipeline,
water pipeline, lightning rod, or telephone earth wire.
• Always switch off the device and cut the power supply when the unit is
notin use for long time so as to ensure safety.
• Take care not let the remote control and the indoor unit watered or
being too wet. Otherwise, it may cause short circuit.
• If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualied persons in order to avoid a hazard.
• Don’t cut off main power switch during operating or with wet hands. It
may cause electric shock.
• Don’t share the socket with other electric appliance. Otherwise, it may
cause electric shock even re and explosion.
• Always switch off the device and cut the power supply before performing
any maintenance or cleaning. Otherwise, it may cause electric shock
or damage.
• Don’t pull the power cable. The damage of pulling power cord will
cause serious electric shock.
• A warning that ducts connected to an appliance shall not contain an
ignition source.
• Don’t install air conditioner in a place where there is ammable gas or
liquid. The distance between them should above 1 m. It may cause re
even explosion.
• Don’t use liquid or corrosive cleaning agent wipe the air conditioner
and sprinkle water or other liquid either.
• Don’t attempt to repair the air conditioner by yourself. Incorrect repairs
may cause re or explosion. Contact a qualied service technician for
all service requirement.
• Don’t use air conditioner in lightning storm weather. Power supply should
WARNING

36V 11/22
be cut in time to prevent the occurrence of danger.
• Don’t put hands or any objects into the air inlets or outlets. This may
cause personal injury or damage to the unit.
• Please note whether the installed stand is rm enough or not. If it is
damaged, it may lead to the fall of the unit and cause the injury.
• Don’t block air inlet or air outlet. Otherwise, the cooling or heating
capacity will be weakened, even cause system stop operating.
• Don’t letthe air conditioner blow against the heater appliance. Otherwise
it will lead to incomplete combustion, thus causing poisoning.
• The appliance shall be installed in accordance with national wiring
regulations. An earth leakage breaker with rated capacity must be
installed to avoid possible electric shocks.
• Don’t open the windows and doors for long time when the air
conditioner is running. Otherwise, the cooling or heating capacity will
be weakened.
• Don’t stand on the top of the outdoor unit or place heavy things on it.
This cloud cause personal injuries or damage the unit.
• Don’t use the air conditioner for other purposes, such as drying clothes,
preserving foods, etc.
• Don’t apply the cold air to the body for a long time. It will deteriorate
your physical conditions and cause health problems.
• Set the suitable temperature. It is recommended that the temperature
difference between indoor and outdoor temperature should not be too
large. Appropriate adjustments of the setting temperature can prevent
the waste of electricity.
• If your air conditioner is not tted with a supply cord and a plug, an
anti-explosion all-pole switch must be installed in the xed wiring and
the distance between contacts should be no less than 3.0 mm.
Fuse Type: T3.15AH250V, the electricity passing through the fuse cannot
be higher than 3.15A. For the air conditioner permanently connected to
an outlet, equip the line with a power switch. The current switch must be
single-pole, with a distance between the contacts greater than 3 mm and
a residual nominal value not greater than 30 mA. The power supply circuit
must have a leakage protection device and an air switch whose rated
capacity should be greater than 1.5 times the maximum current.

37V 11/22
NOTICES FOR USAGE
OPERATING RANGE
Cooling mode: from +16 °C to +49 °C (outdoor temperature)
Heating mode: from -15 °C to +30 °C (outdoor temperature)
• When the temperature is too high, the air conditioner may activate the automatic protection device, so that the
air conditioner could be shut down.
• When the temperature is too low, the heat exchanger of the air conditioner may freeze, leading to water dripping
or other malfunction.
• In long-term cooling or dehumidication with a relative humidity of above 80% (doors and windows are open),
there may be water condenses or dripping near the air outlet.
NOTES FOR HEATING FUNCTION
• When the heating function is started, the indoor unit fan will not work immediately to avoid the introduction of
insufciently hot air into the environment.
• When the outdoor temperature is very low and the humidity is high, ice may form on the heat exchanger of the
outdoor unit. Then the air conditioner will start defrost function.
• During defrost, the air conditioner will stop heating for about 5-12 minutes.
• Vapor may come out from the outdoor unit during defrost. This is not a malfunction, but a result of fast defrost.
• Heating will resume after defrost is complete.
NOTES FOR TURNING OFF
• When the air conditioner is turned off, the unit may continue to ventilate for a few minutes to help dry the battery
of the indoor unit.
EMERGENCY OPERATION
• If the remote control is faulty, use the emergency button located under the front
panel of the indoor unit (see image).
• If this button is pushed with the unit OFF, the air conditioner will operate in Auto
mode.
• If this button is pushed with the unit ON, the air conditioner will stop running.
AIRFLOW DIRECTION ADJUSTMENT
1. Use the vertical oscillation button on the remote control to set the direction of
the air ow.
2. It is possible to direct the air ow also horizontally; this operation is only
possible manually, by moving the air delivery aps as desired (see image).
Note: move the air aps before the unit is in operation, or your nger might be
injured.
Never place your hand into the air inlet or outlet when the air conditioner is in operation.
INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH THE
EUROPEAN DIRECTIVE 2012/19/EU
At the end of its working life this equipment must not be disposed of as an household waste. It must be
taken to special local community waste collection centres or to a dealer providing this service. Disposing
of electrical and electronic equipment separately avoids possible negative effects on the environment
and human health deriving from an inappropriate disposal and enables its components to be recovered
and recycled to obtain signicant savings in energy and resources. In order to underline the duty to
dispose of this equipment separately, the product is marked with a crossed-out dustbin
Emergency
button

38V 11/22
DESCRIPTION OF PARTS
INDOOR UNIT
OUTDOOR UNIT
Note: all the illustrations in this manual are for explanation purpose only. Your air conditioner may be slightly
different. The actual shape shall prevail.
Air inlet
Air outlet
Emergency button
Pipe protection
ring
Air inlet grille
Air filter
Air flap
Air louver
Panel
Remote controller
Air outlet
Air inlet
Air outlet grille
Power cable
Connecting
pipe
Drain hose
Uscita aria
REMOTE CONTROL USER GUIDE
1. At rst time use of the remote controller, install the batteries and ensure that the “+”and “-” poles are correctly
positioned. To insert the batteries, follow the instructions below:
• Slide to open the cover according to the direction indicated by the arrowhead (Fig.1)
• lnsert two brand new batteries, and position the batteries to the right electric poies (Fig.2).
• Put back the cover according to the direction indicated by the arrowhead (Fig.3)
2. Ensure the remote controller is pointed to the signal receiving window, and that there is no obstruction in between
and the distance is 8m at the maximum.
3. Do not let the remote controller drop or ing it at will. Do not let any liquid in the remote controller.
4. Do not expose the remote controller directly to the sunlight or excessive heat.
5. lf the remote controller does not work normally, remove the batteries far 30 seconds before reinstall them. lf that
doesn’t work, replace the batteries.
6. When replacing the batteries, do not mix the new batteries with old ones or mix batteries of different types, which
could cause failure of the remote controller.
Fig.1 Fig.2 Fig.3

39V 11/22
INFORMATION FOR THE CORRECT DISPOSAL OF BATTERIES IN ACCORDANCE WITH EUROPEAN
DIRECTIVE 2006/66/EC and MODIFICATIONS INTRODUCED BY DIRECTIVE 2013/56/EU
Replace batteries when they are depleted. At the end of their life, batteries must be disposed of separately
from unsorted waste. They must be taken to designated recycling centres or returned to a retailer
providing this service. Separate disposal of batteries helps to reduce the potential harmful effects on the
environment and human health caused by their improper disposal and also enables the recovery and
recycling of component materials, saving signicant energy and resources. The requirement for separate
disposal is indicated by the crossed-out wheelie bin label afxed to the appliance. Illegal disposal of the
product by the user is subject to administrative penalties as per current regulations.
7. lf the remote controller is not to be used far a long period of time, remove the batteries rst, lest the leakage from
them may damage the remote controller.
8. Properly dispose the discarded batteries.
BUTTONS DESCRIPTION
1. ON/OFF BUTTON
With this button you can turn the unit on or off. This button can also be used to reset the timer and the SLEEP
function.
2. °C/°F BUTTON
Press this button to select the temperature unit of measurement, the selectable units are Fahrenheit (°F) or Celsius
(°C) which is the default unit. When pressed for the rst time, °F will be selected, and the °C symbol will no longer
appear on the display. Press again to select °C.
Note: some models do not have the possibility to select the temperature in °F; this means that when the °C/°F”
button is pressed, the °F symbol may appear on the remote control display, but the temperature will continue to be
displayed in °C on that of the air conditioner.

40V 11/22
3. SPEED BUTTON
Press this button, you can select the fan speed as follows:
Note: AUTO air speed is not available in FAN mode.
4. DISPLAY BUTTON
It is possible to turn the remote control display on or off, while the unit is running, to extend the life of the batteries.
5. iFEEL BUTTON
Pressing this button activates the IFeel function. The LCD screen shows the room temperature and when the function
is canceled it shows the set temperature. This function is not active in AUTO and FAN mode.
6. TIMER BUTTON
When the air conditioner is on, press this button to deactivate the TIMER function, or when it is off to activate it.
When the button is pressed, the display will show “ON (OFF)” ashing. It is possible to press the “ “ and “
“ buttons to set the timer, each press will increase or decrease the timer by 0.5 h up to 10 h, then the time
interval will be 1h. The settable range is 0.5-24 h. Press the “TIMER” button again to activate the function, the
“ON (OFF)” symbol will stop ashing. If the “TIMER” button is not pressed for 10 seconds while the “ON (OFF)”
symbol ashes on the display, the TIMER function will be canceled. If the TIMER function is active, pressing this
button will deactivate it.
Note: when the TIMER function is active, all function buttons (except SLEEP, DISPLAY and iFEEL) are usable.
7. HEALTH/iCLEAN BUTTON
This button has two functions:
• HEALTH: function not available.
• iCLEAN: When the remote control is off, press the “iClean” button to activate the “iClean” function with a
maximum duration of 30 minutes. The purpose of this function is to clean the evaporator from dust, dry the
water inside the evaporator and prevent the formation of mold which can cause the spread of bad odors.
After setting the “iClean” function, press the “iClean” button again to cancel the function or press the ON/
OFF button to cancel the “iClean” function and turn on the appliance. The “iClean” function is deactivated
after 30 minutes of operation if no operation takes place.
Note: the iClean function can be set in parallel with the “Timer on” function; in this case, the “Timer on”
function will be executed after the “iClean” function.
8. BUTTONS
Press the / button to adjust the temperature from 16 °C to 32 °C; the screen will change each time the
button is pressed. Each time you press “ “ the temperature will increase by 1 °C and each time you press “
“ the temperature will decrease by 1 °C.
Note: the temperature cannot be set in AUTO and FAN mode, so these two buttons will have no effect.
9. TURBO BUTTON
Press this button only in COOL or HEAT mode to select the TURBO function and set the maximum fan speed. When
TURBO mode is active, the fan is at maximum speed; When TURBO mode is off, the dispensing speed is restored
to the previous state.
10. MODE BUTTON
Press this button, you can select the running mode as follows:
Note: HEAT mode is not available for cool only units.
11. SLEEP BUTTON
When you press the SLEEP button, the display turns off.
After setting the Sleep mode, in the cooling function, the temperature will increase by 1 ºC in an hour, then
automatically increase by 1 ºC again after another hour. After setting the Sleep mode, in the heating function, the
temperature will decrease by 2 ºC after an hour, then automatically decrease by 2 ºC again after another hour.
After 10 hours of operation in SLEEP mode the air conditioner returns to the previous functions and automatically

41V 11/22
turns off. The ventilation speed will automatically switch to the lowest level available to ensure maximum quiet
operation during night rest.
Note: press the MODE button or the ON/OFF button to cancel the SLEEP function setting. The SLEEP function
cannot be activated in FAN mode.
12. SWING BUTTON (vertical oscillation)
Press this button to set the automatic vertical swing mode, which allows the outer aps to swing from top to bottom
and vice versa. Press this button again to deactivate the SWING function.
13. SWING BUTTON (horizontal oscillation)
This function is not available. However, it is possible to direct the air ow manually, by moving the aps of the
indoor unit horizontally.
14. ANTI-F BUTTON
This air conditioner has a special drying and anti-mold function. This function is controlled by the remote control in
the COOLING, DRY and AUTO modes. When the air conditioner is operating in the heating mode, the indoor
fan runs for three minutes on weak ventilation before stopping. The purpose of this function is to dry the water
inside the evaporator and prevent the formation of mold which can cause the dispersion of a strange odor. This
function is not set by default, it can be freely set and deactivated. The setting method is as follows: when the air
conditioner and remote control are off, point the remote control at the unit and press the “Anti-F” button, the unit
will beep ve times and then indicate that this function is set. Once set, this function remains valid unless the air
conditioning is completely switched off or the function is manually deactivated.
To deactivate the function:
• Turn off the unit.
• When the air conditioner and the remote control are off, point the remote control at the unit and press this
button, the device emits a sound three times and this indicates that the function is disabled.
Note: when this function is active, it is advisable not to restart the air conditioner before it is completely stopped.
This function will not be active if the unit is switched off or stopped by the “SLEEP” function.
15. ELE.H/ECO BUTTON
• ELE.H (function not available)
• ECO: if you press this button in COOL mode, the unit will activate the ECO mode which has the lowest
electricity consumption and that is automatically deactivated after 8 h. If you change the mode or turn off the
remote control, the function ECO will be automatically canceled. Press the ECO button in ECO mode to exit
this mode.
OPERATION MODE
Automatic mode (AUTO)
• Press the “MODE” button, select the automatic operation mode.
• By pressing the “SPEED” button, you can select the fan speed from LOW, MID, HIGH, AUTO.
• Press the “ON/OFF” button, the air-conditioner starts to operate.
• Press the “ON/OFF” button again, the air-conditioner stops.
COOLING mode: The default set temperature is 20 °C. When the ambient temperature exceeds 20 °C the unit starts
to operate in cooling. Below 20 ºC it only works in ventilation.
HEATING mode: The default set temperature is 25 °C. When in room the temperature is below 25 °C the unit starts
working in heating.
COOLING/HEATING mode
• Press the “MODE” button, select the Cooling or Heating operation mode.
• By pressing the “ “ or “ “ you can set the temperature from 16 °C to 32 °C, the display changes as you
touch the button.
• By pressing the “SPEED” button, you can select the fan speed from LOW, MID, HIGH, AUTO.
• Press the “ON/OFF” button, the air-conditioner starts to operate.
• Press the “ON/OFF” button again, the air-conditioner stops.
FAN mode
• Press the “MODE” button, select the fan operation mode.
• By pressing the “SPEED” button, you can select the fan speed from LOW, MID, HIGH.
• Press the “ON/OFF “ button, the air-conditioner starts to operate in FAN mode.
