Argo POLIFEMO TALAO User manual

8
V 01/21
POLIFEMO TALAO
OPERATING INSTRUCTIONS
Read the instructions carefully before operating the appliance or carrying out maintenance operations.
Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage.
Keep these instructions in a safe place for future reference.
EVAPORATIVE AIR COOLER
EN

9
V 01/21
GENERAL SAFETY INFORMATION
•Only use this appliance as described in this manual. Any other
use not recommended by the manufacturer may cause
fire, electric shock or injury to people.
•Make sure that the type of mains power complies with the
electrical requirements of the appliance (220-240V~/50 Hz).
•This appliance can be used by children aged from 8 years and
above and people with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
•Children shall not play with the appliance.
•Cleaning and user maintenance shall not be made by children
without supervision.
•This product is not a toy. Children should be adequately
supervised to ensure that they do not play with the appliance.
•Disconnect the mains power when the appliance is not used or for
cleaning operations.
In the event of any problems, switch off the appliance
immediately, do not attempt to repair it, and take it to
your local After-Sales Service Centre.
Do not remove or replace individual parts, as this
could affect product safety.
Do not touch the power cord with wet or damp
hands; risk of electric shock.
Do not use the appliance near flammable or explosive
gases
Place the device at a distance of at least 1 meter
from TV and radio to avoid interference.
Do not disassemble the
appliance!
Warning!!! Do not touch
Risk of electric shock!

10
V 01/21
Do not use the appliance if the cord or plug is
damaged. Do not attempt to change the power cord
yourself. If the power cord is damaged, it must be
replaced by the manufacturer, dealer or a similarly
qualified person so as to avoid any safety risks.
Do not bend or stand heavy objects on the power
cord.
Do not use extension cord.
Turn the switch off and unplug before carrying out
any maintenance work or moving the appliance.
Always unplug from the socket when the appliance is
not in use.
To disconnect the appliance, press STOP button
and unplug from the socket. Only pull on the plug.
Do not pull the cord. Otherwise the cable may be
damaged or leaks, etc. may occur.
Do not place the appliance under a power socket, do
not use the appliance in a bathroom or near a
swimming pool.
Do not block the air inlet and outlet grille
Do not pour water over the product: risk of short-
circuits and damage to the product.
Do not leave the airflow directed towards children
for long periods of time: it is not good for their
health.
Warning!!! Do not touch
Risk of electric shock!

11
V 01/21
DESCRIPTION OF PARTS
FRONT VIEW REAR VIEW
1. Control panel
2. Air outlet
3. Air outlet cover plate
4. Front panel
5. Water level display window
6. Castors
7. Rear panel
8. Air filter and evaporative panel
9. Honeycomb filter
10. Cable reel
11. Drain condensate hole
HOW TO USE THE APPLIANCE
The device does not require installation.
Place the unit on a flat and stable surface and connect the power cord to an appropriate power outlet (220-240V ~): the
device can be started by pressing the STOP button and it will start operating in ventilation mode.
Given the small size of the product, to transfer it from one room to another, it is advisable to push it gently by taking it on
the sides with both hands. Do not use this cooler in an area with high humidity, rich in dust or with a temperature above
40 ° C.
This product can be used both as a fan, with 3 possible ventilation speeds (low, medium, high), and as a cooler /
humidifier: in this case, the rear tank must be filled with demineralized water, without exceeding the maximum limit
indicated on the front. through a transparent window. When the water in the tank drops below the minimum limit, marked
on the tank, the appliance stops cooling mode and continues to operate in ventilation mode.
The fan sucks air from the environment and passes it through the anti-dust filter and the evaporative panel, which is kept
constantly humidified thanks to a system that draws water from the tank and sprays it on the panel. The incoming hot air
evaporates part of the water which is soaked in the panel and is returned to a cooler environment, producing a decrease
in the perceived temperature.

12
V 01/21
CONTROL PANEL
After turning on the power supply, the unit starts operating in ventilation mode
BUTTON
Press this button to stop the appliance from operating
BUTTON
Press this button to set the high fan speed.
BUTTON
Press this button to set the medium fan speed.
BUTTON
Press this button to set the low fan speed.
BUTTON
Press this button to activate cooling and humidification.
FILLING AND EMPTYING THE WATER TANK
THE TANK MUST BE FILLED WITH DEMINERALIZED WATER FOR THE APPLIANCE TO
OPERATE IN COOLER/HUMIDIFIER MODE.
Before connecting the power cord to the power outlet, add demineralized water directly to the water tank, which is located
inside the appliance, by opening the hook of the filter assembly located at the rear of the appliance. Fill the tank up to the
maximum limit indicated, it will be possible to view the water level through a transparent window, located on the front panel
of the unit.
If you want to keep the temperature of the water in the tank below the ambient temperature for a long time, in order to favor
cooling in the hottest season, add a tablet of synthetic ice supplied to the water in the tank, after having left it in the freezer
for the time necessary for its complete consolidation. Ice absorbs heat from water.
Continuous use of ice is recommended to optimize the cooling capacity.
It is possible that the first time you use it, you will notice a perfume or the water takes on a particular color: there are no
health risks.
After turning off the unit, if it is not expected to be used soon, proceed with the elimination of the water remaining in the
internal tank.
With the power supply disconnected, place a container under the lower hole, remove the cap that closes it and let the
remaining water flow out.
Always do this before putting the appliance away at the end of the season.
In this case it is also recommended to clean the tank with a dry cloth.

13
V 01/21
MAINTENANCE AND STORAGE
WARNING: ALWAYS UNPLUG THE APPLIANCE BEFORE CLEANING OR MAINTENANCE
PROCEDURES. IMPORTANT: DO NOT SUBMERGE THE PRODUCT IN WATER
Cleaning the outside surface of the appliance
Use a soft cloth to remove any dust from the product.
If this is not enough, use a soft cloth dampened with water and a mild detergent at a temperature not exceeding 50°C. Let
the appliance dry completely before using it.
Do not use corrosive detergents or solvents such as petrol. Do not wash the appliance with water. Do not use oils,
chemical substances or other items that may damage the surface to clean it.
Use a vacuum cleaner to remove dust from the air inlet/outlet grilles.
Cleaning the dust filter and the honeycomb panel
Clean the dust filter frequently, at least once a month.
Gently remove the anti-dust filter from the filter assembly and extract the honeycomb panel, as shown in the drawing below.
Elimination of residual water from the integrated tank
To eliminate the residual water from the integrated tank, refer to the "Filling and emptying the water tank" section.
Clean the dust filter with a soft brush or vacuum cleaner and wash it in water with
a neutral detergent.
Also remove the honeycomb filter.
Allow the filter to dry completely after washing; then reinstall the components.
Remove the cap and empty the tank
Clean the water tank with a dry cloth
Honeycomb panel
Filter assembly

14
V 01/21
STORAGE
If the appliance is not used for prolonged periods, disconnect the power cord and store the appliance with this manual in its
original packaging, in a cool and dry place.
Before packaging, the honeycomb filter and dust filter should be dry, and there is no water in the tank.
INFORMATION FOR THE CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH
EUROPEAN DIRECTIVE 2012/19/EU
This appliance may not be scrapped with domestic waste at the end of its life cycle. We call your attention to the crucial role
played by the consumer in the re-use, recycling and other forms of recovery of such waste.
The appliance must be scrapped by a sorted waste disposal centre or by returning it to the retailer (no charge is levied for this
service), when you purchase a new equivalent appliance.
Sorted disposal of electric and electronic equipment prevents the negative effects on the environment and human health
resulting from improper scrapping, and also allows the materials from which it is made to be recovered and recycled, with
significant savings in terms of energy and resources. The sorted disposal requirement is indicated by the crossed waste bin
label affixed to the appliance.
