Argoclima New Tower User manual

V - 06/16
12
OPERATING INSTRUCTIONS
Read the instructions carefully before operating the appliance or carrying out maintenance operations.
Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or
damage. Store these instructions in a safe place for future reference.
CERAMIC FAN HEATER
EN

V - 06/16
13
GENERAL SAFETY INFORMATION
Use this fan heater only as outlined in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock or
injury to persons.
Make sure that the type of mains power complies with the electrical
requirements of the fan heater (220-240V~/50Hz).
This appliance can be used by children aged from 8 years and above
and people with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without
supervision.
This product is not a toy. Children under the age of 3 years must be
kept away unless properly supervised to ensure they do not play with
the appliance.
Children aged between 3 and 8 years must only be able to turn the
appliance on/off, provided that the appliance has been placed in its
normal operating position, that instructions have been given on how to
use the equipment safely, and that its risks have been understood.
Children aged between 3 and 8 years must not be able to plug in,
adjust, clean or do any maintenance on the appliance.

V - 06/16
14
WARNING: Some parts of this product may become very hot and
cause burns. Special care should be taken around children and
vulnerable people.
To avoid the risk of accidentally resetting the thermal protection, this
appliance must not be powered through an external switching device,
such as a timer, or connected to a circuit that is switched on and off by
the utilities.
WARNING: Do not use the fan heater with a controller or any
other device that activates the appliance automatically, as there
may be a risk of fire if the fan heater is covered or incorrectly
positioned.
Do not restrict the air inlet and outlet grilles.
The appliance heats up significantly when in use and can cause burns.
Avoid unprotected contact with the hot surface.
Keep flammable materials, such as furniture, cushions, blankets,
paper, cloths, curtains and suchlike at least 1 m away from the front,
sides and back.
Disconnect the mains power when the appliance is not in use or during
cleaning.
Avoid using the fan heater in dusty environments or in the presence of
flammable vapours (e.g. in workshops or garages).
Do not place anything on the product; avoid placing wet garments on
the fan heater.

V - 06/16
15
Use the heater in a well-ventilated area.
Avoid placing fingers or foreign objects in the air inlet/outlet grilles, as
this may lead to electric shock or fire and may damage the appliance.
To avoid the risk of fire, do not block the grilles or tamper with them in
any way while the fan heater is in use.
Do not use the appliance if the power cord or plug are damaged.
If the power supply cord is damaged, it must be replaced by the
manufacturer, dealer or a similarly qualified person so as to avoid any
safety risks.
Do not use the appliance if it has fallen from a certain height or if it has
been damaged in any way. Contact a service centre to check the fan
heater or make any electrical or mechanical repairs.
The most common cause of overheating is the build-up of dust in the
appliance. Remove the accumulated dust by removing the plug and
cleaning the grilles using a vacuum cleaner.
Do not use any abrasive products to clean the appliance. Clean it
using a damp cloth (not wet) rinsed with soapy water. Remove the
plug from the socket before doing any maintenance.
To disconnect the fan heater, turn the switch to OFF and remove the
plug from the socket. Pull on the plug only. Do not pull on the cord
when turning off the heater.
Do not place any objects on the cable and do not bend it.

V - 06/16
16
It is not advisable to use extension cords, as these may overheat and
cause the risk of fire. Never use a single extension cord to operate
multiple appliances.
Do not immerse the power cord, plug or any other part of the appliance
in water or other liquids.
Do not touch the plug with wet hands.
Do not place the fan heater above or near another heat source.
WARNING: AVOID COVERING THE FAN HEATER TO PREVENT IT
FROM OVERHEATING.
The symbol below signals this warning
The fan heater may cause the risk of fire if, while in operation, is
covered by or comes into contact with inflammable material including
curtains, drapery, blankets, etc. KEEP THE FAN HEATER AWAY
FROM THESE MATERIALS.
Do not connect the fan heater to the power supply until it has been
correctly assembled or positioned.
Do not run the cord under carpets. Do not cover the cord with
blankets, carpets or similar materials. Place the cord far away from
busy areas, or in a place where it cannot be accidentally pulled-out.
Do not operate the fan heater in close proximity to bathtubs, showers,
washbasins or pools.

V - 06/16
17
Do not position the fan heater below a socket outlet.

Do not operate the appliance outdoors.
Upon initial start-up, the fan heater may emit a slight, harmless smell.
This smell is a normal effect of the initial heating up of the internal
heating elements, and should not recur later on.
WARNING:
THE ON/OFF SWITCH IS NOT THE ONLY METHOD OF
DISCONNECTING THE MAINS POWER.
ALWAYS UNPLUG THE APPLIANCE DURING MAINTENANCE
OPERATIONS, WHEN MOVING IT OR WHILE IT IS NOT IN USE.
A fan heater contains parts that generate electrical arcs and sparks. It
must not be used in potentially dangerous areas such as areas at risk
of fire or explosion, or areas loaded with chemical substances or
humidity.
Do not use the appliance on soft surfaces such as beds, where the
grilles may become covered. Always stand the fan heater on a flat,
stable surface when in operation to prevent it from overturning.
Arrange the cord so that the fan heater and other objects do not rest
on it.
Always unplug the appliance when it is not in use.
Turn the appliance off if unattended in order to avoid accidents.
In the event of any anomalies (abnormal noise, or a strange smell),
immediately turn off the appliance; do not attempt to repair it, and take
it to your local service centre.

V - 06/16
18
ASSEMBLY INSTRUCTIONS
Open the packaging, pull the unit and unscrew the fastening element.
Insert the glass base onto the lower part of the appliance and tighten the fastening element.
Stand the appliance up vertically on a level surface before switching it on.
DESCRIPTION OF PARTS
HOW TO USE THE FAN HEATER
Set up the fan heater in a vertical position on a level and stable surface.
Connect the power cord to a suitable electric socket (220-240V~/50Hz).
On/off button (at the base of the rear cover, below the removable air filter).
Place the on/off button to the “I” position. When the appliance sounds a beep, this means that the fan heater
is ready for use. Place the button to the “0” position to switch off the fan heater.
1. Control Panel and LED
display
2. Air supply grille
3. On/off button
4. Carrying handle
5. Air filter and filter cover
Unit Glass base Fastening element
Unit
Front Side Back
Fastening element

V - 06/16
19
Control panel and display
ON/OFF button (STAND-BY)
Pressing the “ ” button will cause the power LED to light up, and the appliance will begin to operate at low
heating power (1300W). Press the button once again to lock all functions and place the unit in stand-by. The
power LED will switch off. To switch off the fan heater completely, place the on/off button in the “0” position.
MODE button (power/mode switch)
When the appliance is operating at the low heating power setting (1300W), touch the “ ” button to switch to
COMFORT mode (2500W) and the LED "2500" will turn on. Press the button once again to switch to ECO
mode (1300W) and the LED "1300" will turn on. The heat power/mode can also be adjusted using the remote
control by pressing the “ ” button.
SWING button
When the unit is running, press the “ ” button to automatically direct the air to the left or right. The LED is
switched on simultaneously.
Press the button once again to interrupt the swing and the LED will turn off.
TIMER button
While the appliance is running, press the “ ” button to set the time. You can programme an operation time
from 30 minutes to 7½ hours. The time increases by 30 minutes each time you press the button. At the same
time, the display shows the set time. The appliance will switch off automatically at the end of the set time.
The appliance is equipped with an anti-tipping device which interrupts operations when the product is tilted. Do
not position the appliance on its side or upside down.
REMOTE CONTROL

V - 06/16
20
Use Lithium/Manganese button cells, model no. CR2032 -3 V, compliant with Battery Directive no. 2006/66/EC
(supplied with the remote control).
HOW TO INSERT / REMOVE THE REMOTE CONTROL BATTERIES (refer to the diagram below). Open the battery
cover at the back of the remote control (press the back and pull the flap). Place the battery inside the cover, making sure
the polarity is correct. Slot the cover back into position on the remote control.
TIRA
PREMI
Inserimento pila
––
TIMER button
ON/OFF button
INFORMATION FOR THE CORRECT DISPOSAL OF BATTERIES IN ACCORDANCE WITH EUROPEAN DIRECTIVE
2006/66/EC
Replace batteries when they are depleted. At the end of their life, batteries must be disposed of separately from unsorted waste.
They must be taken to designated recycling centres or returned to a retailer providing this service. Separate waste disposal of
batteries prevents potential negative effects on the environment and human health resulting from inadequate disposal, and also
allows the materials from which it is made to be recovered and recycled in order to achieve significant savings in terms of energy
and resources. The separate disposal obligation is underlined by the crossed-out dustbin symbol appearing on the battery. Illegal
disposal of the product by the user shall result in administrative sanctions being applied as per current regulations.
MODE Button to
select the heat
power/mode (ECO
1300W o COMFORT
2500W)
SWING

V - 06/16
21
CAUTION: ALWAYS UNPLUG THE APPLIANCE BEFORE CLEANING OR MAINTENANCE OPERATIONS.
IMPORTANT: DO NOT SUBMERGE THE FAN HEATER IN WATER
Cleaning the outside surface of the appliance
Use a soft cloth to remove any dust from the fan heater.
If the fan heater is excessively dirty, use a soft cloth dampened with water and neutral detergent at a temperature
below 50°C. Leave the fan heater to dry completely before using it again.
Do not use corrosive detergents or solvents such as petrol. Do not wash the appliance with water.
Do not use oils, chemical substances or other items that may damage the surface to clean it.
Use a vacuum cleaner to remove dust from the air inlet/outlet grilles.
Cleaning the air filter, on a monthly basis if necessary.
Remove the air filter for cleaning as shown in the diagram below.
If you clean the appliance with water, make sure that the air filter is dry before re-installing it onto the appliance.
STORAGE
If the appliance is not used for prolonged periods, it must be stored together with this manual in its original
packaging, in a cool and dry place.
MAINTENANCE
Filter Cover

V - 06/16
22
.
INFORMATION ON THE CORRECT DISPOSAL OF THE PRODUCT, PURSUANT TO DIRECTIVE 2012/19/EU ON
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT
At the end of its useful life, this appliance must not be disposed of together with household waste. We call your attention to
the crucial role played by the consumer in the reuse, recycling and other forms of recovery of such waste.
The appliance must be disposed of at a registered local authority collection point or returned free of charge to the retailer on
purchase of a new like-for-like product.
Sorted disposal of electric and electronic equipment prevents potentially negative consequences on the environment and
human health due to improper scrapping, and also allows the constituent materials to be recovered and recycled, with
significant savings in terms of energy and resources.
The sorted disposal requirement is indicated by the crossed out waste bin label displayed on the appliance.
