Important - Please read this instructions fully before starting assembly
Dimensions
Width - 50 cm
Depth - 16 cm
Height - 36 cm
2
1. Heating Element Assembly
2. Body
3. Pull Switch
4. ST4*35mm x 4
5. Position Indication Plate
6. Wall plugs x 4
Please check you have all the panels listed below
Parts Description
1
2
3
5
6
4
3
WARNING: In order to avoid overheating, do not cover the heater.
Do not cover
■ Thiselectricalappliancecomplieswithtechnicalsafetyandelectromagnetic
compatibility standards.
■ Nevertouchyourheaterwheninoperation(riskofburns).
■ Nevertouchtheheaterwithawethands.
■ Neverrotatetheheaterduringoperation.Tochangetheangleoftheheater,
wewaitingatleast15minutesaftertheheaterhasbeenturnedotoallowthe
heater to cool down.
■ Neverplaceanythingontheheaterssafetyguard(e.g.Towel)asthiscould
leadtotheheateroverheatingorare.
■ Neveruseyourappliancetodrywashing.
■Althoughtheheatingelementhasstoppedglowing,itmaystillbehotand
potentiallydangerous.Checkthattheselectionindicator(5)isinpositiono
before taking any action.
■Switchoyourappliance:
- After use
- In the event of malfunction
- Before cleaning it.
■Neveroperateyourapplianceifithasfallenover.
■Neverdismantleyourappliance.Anincorrectlyrepairedappliancemaybe
dangerous to the user. If you encountor any problems seek advice from a
suitablyqualiedprofessional.
Warning Symbols
Warnings
4
■Thewarrantywillbevoidintheeventofdamagearisingfromimproperuse.
■Donotusethisheaterintheimmediatesurroundingofabath,ashowerora
swimming pool.
■ Thismovableapplianceisdesignedforuseingardens,andcanbeused
indoor and outdoor. The warranty will not apply to appliances used for
professional usage. Although the heater may be used outdoors, the main plug
must only be connected to the supply indoors.
■ Theheaterisprovidedwithananti-tiltswitchwillswitchotheheaterifitis
overturned, and will switch it on again automatically when it is restored to its
upright position.
■ Theinstrumentsintheminimuminstallationheight2.0meters.
■ Thiselectricalappliancecomplieswithtechnicalsafetyandelectromagnetic
compatibility standards.
■ Donotcoverheater.
■ Thisheaterisnotequippedwithadevicetocontroltheroomtemperature.
Do not use this heater in small rooms when they are occupied by persons
not capable of leaving the room on their own, unless constant supervision is
provided.(IEC 60335-2-30)
■ Thisheatermustnotbeusedonornearcombustiblematerials,suchas
wooden decking or fencing.
Warnings
5
Beforeusingtheapplianceatthersttime,ensurethatyourmainsvoltage
corresponds to voltage indicated on the appliance. It is a class I appliance and
must be earthed.
CAUTION: Before tting or removing the appliance, ensure that the
heater's power line supplying the heater is disconnected. Check that the
power line is connected to a 30A dierential circuit breaker.
■Thisapplianceisdesignedforuseingardens,andanyroominyourhouse,
including those where there is a risk of splashing. The installation and use of
your appliance must comply with the applicable standards in your country.
■Whenitisswitchon,anelectricalheatingappliancereachesveryhigh
temperature liable to cause burns. Make sure that all other users are aware of
the risks.
■Ifyouhaveanydoubtsconcerningtheinstallationprocessforthisheater,
pleaseconsultaqualiedelectrician.
■Children,theelderlyandtheinrmmaynotalwaysbeawareofthedanger
involved in using electrical appliances. Never allow this appliance to be used
without supervision.
■Theappliancemustbepositionedsothattheplugisaccessible.
■Donotuseifthecordisdamaged.
■Theheatermustnotbelocatedimmediatelybelowasocket-outlet.
■Donotusethisheaterwithaprogrammer,timeroranyotherdevicethat
switchestheheateronautomatically,sinceareriskexistsiftheheateris
covered or positioned incorrectly.
■Donotplacetheapplianceclosetocurtainsandothercombustiblematerials.
Before Using
Safety
6
Appliance location
Step 1
Step 2
Please pay attention
during installation: the
distance between the
top of the product and
ceiling should be more
than 0.5m, the distance
between the side of
the product and corner
should be more than
0.5m, the distance
between the bottom of
theproductandoor
should be more than
2m. In summary, To
ensure safe use of the
product. ( As shown on
the right)
DO NOT install inversely
on a wall or on a ceiling.
Heater MUST ONLY be
operated when correctly
xedtoawall.
7
WARNING! Before installing your appliance, you must disconnect the
electrical supply at the circuit breaker.
Step 1
Step 2
Fitting Instructions
Punch corresponding
holes on the wall which
are the same as the
back of the product
wall-mounted holes.( As
shown on the right)
Use the diameter 8 drill
to punch holes on the
wall where is already
marked. ( As shown on
the right)
8
Fitting Instructions
Step 3
Step 4
Put the 4 plastic
expansion screws into
the holes of the wall one
by one, make the plastic
expansion screws’
outside diameter and
thewallareush.(As
shown on the right)
IMPORTANT- please
ensure wall type is
strong enough
Fasten the four
ST4*35mm screws into
the plastic expansion
screws one by one,
make the 4-5mm of
screws higher than
metope. ( As shown on
the right)
9
Fitting Instructions
Step 5
Step 6
To wall mount the heater
present the back of the
heater to the wall and
insert the screw heads
into the corresponding
holes on the back of
the heater. Move the
product to the left to
secure the screw heads
into the keyhole slots.
The head of the heater
can be tilted to direct
heat downwards. DO
NOT ADJUST THE
HEAD WHILE IT IS
HOT
WARNING! Before installing your appliance, you must disconnect the
electrical supply at the circuit breaker.
10
The appliance is switched on by means of the pull switch . The slight vibration
noticeable when the appliance is switched on will stop after a few seconds.
- Power rate:2000W
- Cable length:1.5m
- Position 0: Stop
- Position 1: 650W (normal power)
- Position 2: 1300W (intermediate power)
- Position 3: 2000W (full power)
Operation
Specication
The product complies with the applicable UK directives
and an evaluation method of conformity for these
directives was done.
The product complies with the applicable European
directives and an evaluation method of conformity for
these directives was done.
WEEE symbol. Waste electrical products should not be
disposed of with household waste. Please recycle where
facilities exist. Check with your local authority or local
store for recycling advice.
Read the instruction manual before operating this machine.
The product complies with the RoHS directives and an evaluation
method of conformity for these directives was done.
The product complies with IP34 standard.
11
Your appliance dose not requires any particular maintenance. However, in the
event of a malfunction, please consult a suitably qualied electrician.
Maintenance
