Desa SPC170-F User manual

PROPANE CONSTRUCTION FORCED AIR HEATER
OWNER’S MANUAL
170,000 BTU/HR VARIABLE WITH BUILT-IN THERMOSTAT
IMPORTANT: Read and understand this manual before
assembling, starting or servicing heater. Improper use
of heater can cause serious injury. Keep this manual for
future reference.
GENERAL HAZARD WARNING:
Failure to comply with the precautions and instructions
provided with this heater, can result in death, serious
bodily injury and property loss or damage from hazards
of fire, explosion, burn, asphyxiation, carbon monoxide
poisoning and/or electrical shock.
Only persons who can understand and follow the in-
structions should use or service this heater.
If you need assistance or heater information such as an in-
structions manual, labels, etc. Contact the manufacturer.
Save this manual for future reference.
For more information, visit www.desatech.com
TABLE OF CONTENTS
Safety Informa ion ............................................... 2
Product Identification ........................................... 3
Unpacking ........................................................... 3
Theory of Operation ............................................ 4
Propane Supply ................................................... 4
Installation ........................................................... 4
Ventilation ........................................................... 5
Operation ............................................................. 5
Storage ................................................................ 6
Maintenance ........................................................ 6
Troubleshooting ................................................... 7
Service Procedures ............................................. 8
Specifications .................................................... 10
Wiring Diagram .................................................. 10
Accessories ........................................................11
Technical Service ...............................................11
Replacement Parts .............................................11
Illustrated Parts Breakdown and Parts List ....... 12
Warranty and Repair Service ............................ 14

www.desatech.com 113959-01B
2
SAFETY INFORMATION
WARNING: This product
contains and/or generates
chemicals known to the State
of California to cause cancer or
birth defects or other reproduc-
tive harm.
WARNING: Fire, burn, inha-
lation and explosion hazard.
Keep solid combustibles, such
as building materials, paper or
cardboard, a safe distance away
from the heater as recommended
by the instructions. Never use
the heater in spaces which do or
may contain volatile or airborne
combustibles or products such
as gasoline, solvents, paint thin-
ner, dust particles or unknown
chemicals.
WARNING: Not for home or
recreational vehicle use.
The heater is designed for use as a construction
heater in accordance with ANSI Z83.7/CGA2.14.
Other standards govern the use of fuel gases
and heating products for specific uses. Your lo-
cal authority can advise you about these. The
primary purpose of construction heaters is to
provide temporary heating of buildings under
construction, alteration or repair. Properly used,
the heater provides safe economical heating.
Products of combustion are vented into the area
being heated.
We cannot foresee every use which may be made of
our heaters. Check with your local fire safety au-
thority if you have questions about heater use.
Other standards govern the use of fuel gases and
heat producing products for specific uses. Your
local authorities can advise you about these.
Carbon Monoxide Poisoning: Some people are
more affected by carbon monoxide than others.
Early signs of carbon monoxide poisoning re-
semble the flu, with headaches, dizziness and/or
nausea. If you have these signs, the heater may not
be working properly. Get fresh air at once! Check
for proper ventilation and have heater serviced.
Propane Gas: Propane gas is odorless. An odor-
making agent is added to propane gas. The odor
helps you detect a propane gas leak. However, the
odor added to propane gas can fade. Propane gas
may be present even though no odor exists.
Make certain you read and understand all warn-
ings. Keep this manual for reference. It is your
guide to safe and proper operation of this heater.
1. This product has been approved for use in the
Commonwealth of Massachusetts.
2. Install and use heater with care. Follow all
local ordinances and codes. In the absence
of local ordinances and codes, refer to the
Standard for Storage and Handling of Lique-
fied Petroleum Gas, ANSI/NFPA 58 and the
Propane Gas Installation Code, CAN/CGA
B149.2. This instructs on the safe storage and
handling of propane gases.
3. Use only the electrical voltage and frequency
specified on model plate. The electrical con-
nections and grounding of the heater shall fol-
low the National Electric Code, ANSI/NFPA
70 or the Canadian Electrical Code, Part 1.
4. Electrical grounding instructions — This
appliance is equipped with a three-prong
(grounding) plug for your protection against
shock hazard and should be plugged directly
into a properly grounded three-prong recep-
tacle or extension cord.
5. Use only the hose and factory preset regulator
provided with the heater.
6. Use only propane gas set up for vapor with-
drawal.
7. Provide adequate ventilation. Before using
heater, provide at least a three-square-foot
opening of fresh, outside air for each 100,000
Btu/Hr (105,500 k/j) of rating.
8. For indoor use only. Do not use heater out-
doors.
9. Do not use heater in occupied dwellings or in
living or sleeping quarters.
10. Do not use heater in a basement or below
ground level. Propane gas is heavier than air.
If a leak occurs, propane gas will sink to the
lowest possible level.
11. Keep appliance area clear and free from com-
bustible materials, gasoline, paint thinner and
other flammable vapors and liquids. Dust is
combustible. Do not use heater in areas with
high dust content.
12. Minimum heater clearances from combustible
materials:
Outlet: 8 Ft. (2.4 m), Sides: 2 Ft. (.6 m), Top:
6 Ft. (1.8 m), Rear: 2 Ft. (.6 m)

www.desatech.com
113959-01B 3
13. Keep heater at least six feet from propane
tank(s). Do not point heater at propane tank(s)
within 20 feet (6.1 m).
14. Keep propane tank(s) below 100 F (38 C).
15. Check heater for damage before each use. Do
not use a damaged heater.
16. Check hose before each use of heater. If highly
worn or cut, replace with hose specified by
manufacturer before using heater.
17. Locate heater on stable and level surface if
heater is hot or operating.
18. Never block air inlet (rear) or air outlet (front)
of heater.
19. Keep heater away from strong drafts, wind,
water spray, rain or dripping water.
20. Keep children and animals away from
heater.
21. This heater is equipped with a thermostat.
Heater may start at anytime.
22. Never move, handle or service a hot or operat-
ing heater. Severe burns may result. You must
wait 15 minutes after turning heater off.
23. To prevent injury, wear gloves when handling
heater.
24. Never attach duct work to heater.
25. Do not alter heater. Keep heater in its original
state.
26. Do not use heater if altered.
27. Turn off propane supply to heater and unplug
heater when not in use.
28. Use only original replacement parts. This
heater must use design-specific parts. Do
not substitute or use generic parts. Improper
replacement parts could cause serious or fatal
injuries.
SAFETY INFORMATION
Continued
Hot Air Outlet (Front)
Variable
Heat Control
Power
Cord
Hose/Regulator
Assembly
Inlet
Connector
Thermostat
Knob
PRODUCT
IDENTIFICATION
Figure 1 - 170,000 Btu/Hr Model
Handle
Fan
Guard
UNPACKING
1. Remove all packing items applied to heater for
shipment. Keep plastic cover caps (attached to
inlet connector and hose/regulator assembly)
for storage.
2. Remove all items from carton.
3. Check all items for shipping damage. If heater
is damaged, promptly inform dealer where you
bought heater.

www.desatech.com 113959-01B4
THEORY OF OPERATION
The Fuel System: The hose/regulator assembly
attaches to the propane gas supply. The propane
gas moves through the solenoid valve and out
the nozzle.
The Air System: The motor turns the fan. The
fan pushes air into and around the combustion
chamber. This air is heated and provides a stream
of clean, hot air.
Air For Combustion
And Heating
Fuel
Combustion Chamber Spark Plug
Figure 2 - Cross Section Operational View (Heater may vary from illustration)
Clean
Heated
Air Out
(Front) Cool
Air In
(Back)
Fan Motor
Power
Cord
Hose/Regulator
Assembly
Solenoid
Valve
Nozzle
The Ignition System: The direct spark ignitor
(DSI) sends voltage to the spark plug/ignitor.
The spark plug/ignitor ignites the fuel and air
mixture.
The Safety Control System: This system causes
the heater to shut down if the flame goes out.
PROPANE SUPPLY
Propane gas and propane tank(s) are to be fur-
nished by the user.
Use this heater only with a propane vapor
withdrawal supply system. See Chapter 5 of the
Standard for Storage and Handling of Liquefied
Petroleum Gas, ANSI/NFPA 58. Your local library
or fire department will have this booklet.
The amount of propane gas ready for use from
propane tanks varies. Two factors decide this
amount:
1. The amount of propane gas in tank(s)
2. The temperature of tank(s)
The chart below shows the number of 100 pound
(45 kg) tanks needed to run this heater.
Do not operate this product with any tank smaller
than 100 pounds.
Temperature Number
at tank location of tanks
above 20 F (-7 C) 2
20 F (-7 C) to -10 F (-23 C) 3
below -10 F (-23 C) (Use larger tank)
Less gas is vaporized at lower temperatures. You
may need two or more 100 lb. (45 kg) tanks or one
larger tank in colder weather. Your local propane
gas dealer will help you select the proper supply
system. The minimum surrounding-air tempera-
ture rating for each heater is -20 F (-29 C).
INSTALLATION
WARNING: Review and un-
derstand the warnings in the
Safety Information section, page
2. They are needed to safely op-
erate this heater. Follow all local
codes when using this heater.
WARNING: Test all gas piping
and connections for leaks after
installing or servicing. Never use
an open flame to check for a leak.
Apply a mixture of liquid soap
and water to all joints. Bubbles
forming show a leak. Correct all
leaks at once.

www.desatech.com
113959-01B 5
1. Provide propane supply system (see Propane
Supply, page 4).
2. Connect POL fitting on hose/regulator as-
sembly to propane tank(s). Turn POL fitting
counterclockwise into threads on tank. Tighten
firmly using wrench. Tighten regulator with
vent pointing down.
3. Connect hose to inlet connector. Tighten firmly
using a wrench.
IMPORTANT: Extra hose or piping may be
used if needed. Install extra hose or piping
between hose/regulator assembly and propane
tank. You must use the regulator supplied with
heater.
4. Open propane supply valve on propane tank(s)
slowly. Note: If not opened slowly, excess-
flow check valve on propane tank may stop
gas flow. If this happens, close propane supply
valve and open again slowly.
5. Check all connections for leaks.
WARNING: Never use an
open flame to check for a leak.
Apply a mixture of liquid soap
and water to all joints. Bubbles
forming show a leak. Correct all
leaks at once.
6. Close propane supply valve.
INSTALLATION
Continued
Figure 4 - Hose and Inlet Connector
(Heater may vary from illustration)
Hose
Inlet Connector
Figure 3 - Regulator With Vent Pointing
Down
Propane
Tank
Hose
Regulator
Vent
(pointing
down)
POL
Fitting
Supply
Valve
VENTILATION
WARNING: Follow the mini-
mum fresh, outside air ventila-
tion requirements. If proper
fresh, outside air ventilation is
not provided, carbon monoxide
poisoning can occur. Provide
proper fresh, outside air ventila-
tion before running heater.
Provide a fresh air opening of at least 3 ft2
(0.28 m2) for each 100,000 Btu/Hr (105,500 k/j)
rating. Provide extra fresh air if more heaters are
being used.
OPERATION
WARNING: Review and un-
derstand the warnings in the
Safety Information section, page
2. They are needed to safely op-
erate this heater. Follow all local
codes when using this heater.
TO START HEATER
1. Follow all installation, ventilation and safety
information.
2. Locate heater on stable and level surface.
Make sure strong drafts do not blow into front
or rear of heater.

www.desatech.com 113959-01B
6
3. Plug power cord of heater into a three-prong,
grounded extension cord. Extension cord must
be at least six feet long. Extension cord must
be UL listed.
Extension Cord Size Requirement
Up to 50 feet (15 m) long, use 18 AWG rated
cord.
51 to 100 feet (15.5 to 30.5 m) long, use 16
AWG rated cord.
101 to 200 feet (30.78 to 61 m) long, use 14
AWG rated cord.
4. Plug extension cord into a 120 volt/60 hertz,
three-hole, grounded outlet.
5. Open propane supply valve on propane tank(s)
slowly.
Note: If not opened slowly, excess-flow check
valve on propane tank may stop gas flow. If
this happens, close propane supply valve and
open again slowly.
6. Turn thermostat control knob fully coun-
terclockwise to the “cooler” position. Turn
thermostat control knob slowly clockwise
until electric motor and fan begin to run.
Heater will start in approximately 3 seconds.
Adjust thermostat control knob to warmer or
cooler setting as needed. To control the heat
output, adjust the gas valve to the desired
temperature.
Note: If heater does not start after 3 seconds,
the ignition control will automatically attempt
to start heater one time. If heater fails to start
on this attempt, the safety control will "lock
out" and no further automatic restarts will be
attempted. This could occur if air remains in
fuel line. If heater fails to start on this attempt,
turn thermostat knob to the “cooler” position
until the motor stops turning. Wait ten seconds
for safety control to reset, then turn control
knob to the “warmer” position and try to start
heater again.
7. Thermostat Operation Only: During normal
thermostat operation, heater will cycle off
when air temperature rises to thermostat set-
ting. When air temperature drops sufficiently
below thermostat setting, the electric motor
and fan will begin to run. After 15 to 60
seconds, heater burner should automatically
ignite and provide heat to maintain tempera-
ture setting.
OPERATION
Continued
TO STOP HEATER
1. Tightly close propane supply valve on propane
tank(s).
2. Wait a few seconds. Heater will burn gas left
in supply hoses.
3. Turn thermostat knob fully counterclockwise
to the “cooler” position.
4. Unplug heater.
STORAGE
CAUTION: Disconnect heater
from propane supply tank(s).
1. Store propane tank(s) in safe manner. See
Chapter 5 of Standard for Storage and Han-
dling of Liquefied Petroleum Gases, ANSI/
NFPA 58 and/or CAN/CGA B149.2. Follow
all local codes.
2. Place plastic cover caps over brass fittings on
inlet connector and hose/regulator assembly.
3. Store in dry, clean and safe place. Do not
store hose/regulator assembly inside heater
combustion chamber.
4. When taking heater out of storage, always
check inside of heater. Insects and small
animals may place foreign objects in heater.
Keep inside of heater free from combustible
and foreign objects.
MAINTENANCE
WARNING: Never service
heater while it is plugged in,
connected to propane supply,
operating or hot. Severe burns
and electrical shock can occur.
1. Keep heater clean. Clean heater annually or
as needed to remove dust and debris. If heater
is dirty or dusty, clean heater with a damp
cloth.
2. Inspect heater before each use. Check connec-
tions for leaks. Apply mixture of liquid soap
and water to connections. Bubbles forming
show a leak. Correct all leaks at once.
3. Inspect hose/regulator assembly before each
use. If hose is highly worn or cut, replace.
4. Have heater inspected yearly by a qualified
service agency.
5. Keep inside of heater free from combustible
and foreign objects.

www.desatech.com
113959-01B 7
POSSIBLE CAUSE
1. No electrical power to heater
2. Fan hitting inside of heater
shell
3. Fan blades bent
4. Defective motor
1. User did not follow installa-
tion or operation instructions
properly
2. No spark at spark plug. To test
for spark, follow step 8 under
Spark Plug, page 8. If you see
spark at spark plug, have heater
serviced by qualified service
person. If no spark seen:
A) Loose or disconnected
spark plug wire
B) Bad spark plug
C) Bad spark transformer
1. Propane supply may be inad-
equate
2. High surrounding air tem-
perature causing thermal limit
device to shut down heater.
3. Restricted air flow
4. Damaged fan
5. Excessive dust or debris in
surrounding area
REMEDY
1. Check voltage to electrical
outlet. If voltage is good,
check heater power cord for
breaks
2. Adjust motor/fan mount to
keep fan from hitting inside of
heater shell. Bend fan mount
if necessary
3. Replace fan. See Fan, page 8
4. Replace motor. See Motor,
page 8
1. Repeat installation and opera-
tion instructions. See Instal-
lation, page 4 and Operation,
page 5
2. A) Check spark plug wire.
Tighten or reattach loose spark
plug wire. See Figure 8, page
9 for spark plug wire location
B) Replace spark plug. See
Spark Plug, page 9
C) Replace spark transformer.
See Spark Transformer, page 9
1. A) Refill tank
B) Provide additional and/or
larger tanks. See Propane
Supply, page 4
2. This can happen when running
heater in temperatures above
85 F (29 C). Run heater in
cooler temperatures
3. Check heater inlet and outlet.
Remove any obstructions
4. Replace fan. See Fan, page 8
5. Clean heater. See Mainte-
nance, page 6
OBSERVED PROBLEM
Fan does not turn when heater
is plugged in
Heater will not ignite
Heater shuts down while run-
ning
TROUBLESHOOTING
WARNING: Never service heater while it is plugged in, connected
to propane supply, operating or hot. Severe burns and electrical
shock can occur.
WARNING: Use only in areas
free of high dust content.

www.desatech.com 113959-01B
8
SERVICE PROCEDURES
WARNING: Never service
heater while it is plugged in,
connected to propane supply,
operating or hot. Severe burns
and electrical shock can occur.
MOTOR
1. With heater on its side, remove access panel.
2. Access ground screw through underside of
heater base. Remove ground screw. Disconnect
the green motor wire and the green power cord
wire from underside of shell (see Figure 5).
3. Remove two black wires from motor to ter-
minal board.
4. Carefully push motor wires through hole in
bottom of shell.
5. Remove screws holding motor mount to shell.
Use nut-driver (see Figure 5).
6. Carefully pull motor and fan out of shell.
IMPORTANT: Be careful not to damage fan.
Do not set motor and fan down with the weight
resting on fan. This could damage fan pitch.
7. Use hex wrench to loosen setscrew which
holds fan to motor shaft.
8. Remove fan. Be careful not to damage the fan
blade pitch.
9. Use nut driver to remove two nuts that attach
motor to motor mount.
10. Discard old motor.
11. Attach motor to motor mount with two nuts.
Tighten nuts firmly.
12. Replace fan on motor shaft. Make sure set
screw contacts flat surface on motor shaft.
13. Tighten set screw firmly (40-50 inch-pounds
[46.08-57.60 kilogram-centimeters]).
14. Carefully route motor wires through hole in
shell. Place motor, motor mount and fan guard
into rear of heater shell, as shown in Figure 5.
15. Insert screws through heater shell and into
motor mount. Tighten screws firmly.
16. Turn heater on its side to access opening in
bottom of base. Connect green wires from
motor, transformer and power cord to heater
shell using ground nut.
17. Attach two black wires from motor to terminal
board (see Wiring Diagram, page 10, for cor-
rect locations).
18. Replace access panel.
Figure 5 - Removing Motor and Fan
Guard from Heater (Heater may vary
from illustration)
Screw
Screw
Motor and
Fan Guard
FAN
1 Remove motor, motor mount and fan (see
Motor, steps 1 through 8).
2. Clean fan using soft cloth moistened with
kerosene or solvent.
3. Dry fan thoroughly.
4. Replace fan on motor shaft. Make sure set-
screw is touching back of flat surface on motor
shaft (see Figure 6).
5. Place setscrew on flat of shaft. Tighten set-
screw firmly (40-50 inch-pounds [46.08-57.60
kilogram-centimeters]).
6. Place motor, motor mount and fan guard
into rear of heater shell (see Motor, steps 14
through 18).
Motor Shaft
Fan Setscrew
Figure 6 - Fan, Motor Shaft and
Setscrew Location
Figure 7 - Fan Cross Section
Fan
Hub
Setscrew Motor
Shaft

www.desatech.com
113959-01B 9
SERVICE PROCEDURES
Continued
SPARK TRANSFORMER
1. Remove access panel.
2. Locate and disconnect white, black and
orange wires from spark transformer.
3. Remove screw holding spark transformer to
base. Remove sheet metal nut on transformer
and install on new transformer. Discard spark
transformer.
4. Install new spark transformer. Position new
spark transformer in same manner as old
transformer.
5. Connect white, black and orange wires to new
spark transformer. Connect wires to correct ter-
minals as noted in Wiring Diagram, page 10.
6. Replace access panel.
Figure 9 - Removing Spark Plug Nut
and Spark Plug (Heater may vary from
illustration)
Rear Head
Spark Plug
3/4" Hex
Head Nut
SPARK PLUG
1. Remove motor, motor mount and fan guard
(see Motor, page 8, steps 1 through 6).
2.
Remove orange
spark plug
wire from spark
plug.
3. From front of heater loosen 3/4" hex nut hold-
ing spark plug in place (see Figure 9).
4. Remove spark plug from rear head.
5. Install new spark plug. Attach spark plug to rear
head with ignitor hex nut removed in step 3.
6. Attach spark plug wire.
7. Test for spark.
WARNING: Make sure heater
is disconnected from propane
supply. Heater could ignite caus-
ing severe burns.
Plug into extension cord and watch for spark
at spark plug.
8. Place motor, motor mount and fan guard into
rear of heater shell (see Motor, page 8, steps
14 through 18).
Figure 8 - Removing Spark Plug Wire
from Spark Transformer (Heater may
vary from illustration)
Bushing
Spark Plug
Wire

www.desatech.com 113959-01B10
SPECIFICATIONS
• 125,000 - 170,000 Btu/Hr (36.6 - 49.8 kW)
• Propane/LP Fuel
• Gas Supply Pressure to Regulator
Max - Bottle Pressure, Min - 5 psig (34.5 kPa)
• Gas Supply Pressure Regulator out
28" WC (6.97 kPa)
• Electrical Input - 115V, 60 Hz, 1Ø, 3a
• Direct Spark Ignition, interrupted type
• Primary Flame Control - Solid State
• High Temperature Control - 240 F (116 C)
• Minimum Ambient Temp. Rating - 0 F (-17.8 C)
• Fuel Consumption - 5.8 - 7.9 lbs/hr (2.6 - 3.6 kg/hr)
• Fuel Orifice Port No. - 18
• Fuel Orifice Port Size - 0.80 mm
• Heated Air Output - 450 CFM (12.74 cu m/m)
WIRING DIAGRAM
Orange**
CONNECTION DIAGRAM
Green
Spark Plug
If any original wiring as supplied with the heater must
be replaced, it must be replaced with type AWG 105° C
wire or its equivalent except as indicated
(*Type SF2 200. **SGI 250° C)
High Limit
Switch
Gas
Valve
Green
Green
Motor
Flame Control
Line
Neut
Valve
Ground
Wh te
Wh te
White
White
Red
Red
Red
Red
Red
Black
Black
Thermostat
Chassis
Ground
Chassis
Ground
Chassis
Ground
Line Cord

www.desatech.com
113959-01B 11
ACCESSORIES
Purchase accessories and parts from your nearest
dealer or service center. If your dealer or service
center can not supply an accessory or part, either
contact your nearest Parts Central (listed in the
separate Authorized Service Center booklet) or
call DESA Heating Products at 1-866-672-6040
for referral information. You can also write to the
address listed on the back page of this manual.
TECHNICAL SERVICE
You may have further questions about this heater.
If so, contact DESA Heating Productsʼ Technical
Service Department at 1-866-672-6040. When
calling, please have your model and serial numbers
of your heater ready.
You can also visit DESA Heating Products' Techni-
cal Service web site at www.desatech.com.
REPLACEMENT PARTS
WARNING: Use only original
replacement parts. This heater
must use design-specific parts.
Do not substitute or use generic
parts. Improper replacement
parts could cause serious or fa-
tal injuries. This will also protect
your warranty coverage for parts
replaced under warranty.
PARTS UNDER WARRANTY
Contact authorized dealers of this product. If they
canʼt supply original replacement part(s), either
contact your nearest Parts Central or call DESA
Heating Productsʼ Technical Service Department
at 1-866-672-6040.
When calling DESA Heating Products, have
ready:
• your name
• your address
• model and serial numbers of your heater
• how heater was malfunctioning
• purchase date
In most cases, we will ask you to return the part
to the factory.
PARTS NOT UNDER WARRANTY
Contact authorized dealers of this product. If
they canʼt supply original replacement part(s),
either contact your nearest Parts Central or call
DESA Heating Products for referral information
at 1-866-672-6040.
When calling DESA Heating Products, have
ready:
• model number of your heater
• the replacement part number

www.desatech.com 113959-01B
12
ILLUSTRATED PARTS BREAKDOWN
MODELS BLP170VT, REM170VT, RLP170VT, SBLP170VT, 170-F AND SPC170-F
7
8
1
2
3
4
23
6
21
5
9
11
12 22
33
30
28
15
14
13
34
29
27
32
31
24
25
26
16
18
17
20
19
10

www.desatech.com
113959-01B 13
PARTS LIST
MODELS BLP170VT, REM170VT, RLP170VT, SBLP170VT, 170-F AND SPC170-F
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 11 of this manual.
KEY
NO. PART NO. DESCRIPTION QTY.
1 113938-01 Outer Shell Orange 1
113938-02 Outer Shell, Red 1
113938-03 Outer Shell, Yellow 1
113938-04 Outer Shell, Green 1
113938-05 Outer Shell, Black 1
2 ** Middle Cylinder 1
3 113940-01 Orifice Assembly 1
4 113937-01 Flame Holder Assembly 1
5 115324-01 High Limit Switch 1
6 113888-01 Orifice Nut 1
7 097917-01 Handle 1
8 097918-01 Handle Mounting Clips 2
9 113948-01 Set Screw, Nyloc 1
10 113950-01 Fan 1
11 113941-01 Motor Assembly 1
12 113942-01 Inlet/Motor Mounting Grille 1
13 113776-01 Hose Assembly 1
14 113862-01 Regulator, 28" WC 1
15 113791-01 POL Excess Flow Valve 1
16 113952-01 Male Fitting Conn. 3/8 MPT x 3/8 SAE FLR 1
17 113951-01 Solenoid Valve, Goyen 1
18 113964-01 Fitting Close Nipple 1
19 113966-01 Burn Rate Adjustment Valve 1
20 113965-01 E bow Fitting, 3/8 MPT x 1/2 SAE FLR 1
21 113943-01 Fuel Tube Assembly 1
22 113963-01 Spark Plug, Flame Sensor 1
23 113886-01 Spark Plug Nut 1
24 113947-01 Thermostat Mounting Bracket 1
25 113944-01 Thermostat Assembly 1
26 113949-01 Loop Clamp, 5/16 1
27 110287-01 Flame Control 1
28 113864-01 Power Cord Assembly 1
29 113960-01 Terminal Board 1
30 113865-01 Bushing Strain Relief 1
31 113961-01 Knob, Thermostat 1
32 113962-01 Burn Rate Adjustment Knob 1
33 113945-01 Control Box 1
34 113946-01 Access Panel 1
PARTS AVAILABLE - NOT SHOWN
113883-01 Snap Bushing, 5/8 2
113802-07 Model Data Decal 1
113933-04 Operating Instructions Decal, English/Spanish 1
113984-03 Warning Decal, English/Spanish 1
113984-04 Operating Instructions/Warning Decal, French 1
099504-08 Thermostat Warning Decal 1
113907-01 Warning Electrical Decal 1
113953-01 Wiring Schematic Decal 1
097650-01 Tradename Decal, Master 1
113858-04 Tradename Decal, All-Pro 1
113858-05 Tradename Decal, Universal 1
109111-03 Tradename Decal, Reddy 1
110789-01 Tradename Decal, Remington 1
113914-01 Hang Tag, English 1
113914-02 Hang Tag, Spanish 1
113914-03 Hang Tag, French 1
**Not a field
replaceable
part.

2701 Industrial Drive
P.O. Box 90004
Bowling Green, KY 42102-9004
ATTN: Customer Service Department
WARRANTY AND REPAIR SERVICE
KEEP THIS WARRANTY
LIMITED WARRANTIES FOR NEW AND FACTORY
RECONDITIONED PRODUCTS
New Products: DESA Heating Products warrants this heater and any parts thereof, to be free of defects in materials
and workmanship for one (1) year from the date of first purchase, when operated and maintained in accordance
with the manufacturer's instructions. These warranties are extended only to the original retail purchaser, when
proof of purchase is provided.
Factory Reconditioned Heaters: DESA Heating Products warrants this factory reconditioned heater and any parts
thereof, to be free of defects in materials and workmanship for thirty (30) days from the date of first purchase,
when operated and maintained in accordance with the manufacturer's instructions. These warranties are extended
only to the original retail purchaser, when proof of purchase is provided.
These warranties cover only the cost of parts and labor required to restore the product to proper operating condition.
Transportation and incidental costs associated with warranty repairs are not reimbursable under this warranty.
Warranty service is available only through authorized dealers and service centers.
This warranty does not cover defects resulting from misuse, abuse, negligence, accidents, lack of proper mainte-
nance, normal wear, alteration, modification, tampering, contaminated fuels, repair using improper parts or repair by
anyone other than an authorized dealer or service center. Routine maintenance is the responsibility of the owner.
THIS EXPRESS WARRANTY IS GIVEN IN LIEU OF ANY OTHER WARRANTY EITHER EXPRESSED
OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE.
DESA Heating Products assumes no responsibility for indirect, incidental or consequential damages. Some states
do not allow the exclusion or limitation of incidental or consequential damages or limitations or exclusions may
not apply to you. This limited warranty gives you specific legal rights and you may also have other rights which
vary from state to state.
We reserve the right to amend these specifications at any time without notice. The only warranty applicable is our
standard written warranty. We make no other warranty, expressed or implied.
WARRANTY SERVICE
Should your heater require service, return it to your nearest authorized service center. Proof of purchase must be
presented with the heater. The heater will be inspected. A defect may be caused by faulty materials or workman-
ship. If so, DESA Heating Products will repair or replace the heater without charge.
REPAIR SERVICE
Return your heater to your nearest authorized service center. Repairs not covered by the warranty will be billed at
standard prices. Each Service Center is independently owned and operated. We reserve the right to amend these
specifications at any time without notice. When writing, always include model number and serial number. For
information, write:
Model
Serial No.
Date of Purchase
