Aristel AN1603-08 User manual

ARISTEL NETWORKS
AN1603-08 3G Audio Intercom (E2.2) 1/16
AN1603-08
INTERCOM &ACCESS CONTROL
OPERATING MANUAL
For your protection, read these instructions completely
Keep for future reference.

ARISTEL NETWORKS
AN1603-08 3G Audio Intercom (E2.2) 2/16
TABLE OF CONTENTS
Important Safety Instructions........................................................................................3
Introduction ................................................................................................................... 4
Parts List........................................................................................................................4
Installation.....................................................................................................................5
Wiring Diagram.............................................................................................................8
Using the AN1603-08....................................................................................................9
1.
Setting your call out numbers.......................................................................9
2. Setting your call in numbers (Guest List ) .................................................9
5.App on iOS and Android..............................................................................9
Programming by text message ....................................................................................10
Command Codes .........................................................................................................12
How to reset the hardware if you forget your password.............................................15
How to change the name plate ....................................................................................14
Troubleshooting (Q &A).............................................................................................15
Specification................................................................................................................16

ARISTEL NETWORKS
AN1603-08 3G Audio Intercom (E2.2) 3/16
Thank you for purchasing AN1603-08 3G/4G audio intercom. Please read this manual carefully
before using.
Be sure to keep this manual for future reference in case of any problem or questions.
Important Safety Instructions
When using this intercom, basic safety precautions should always be followed to reduce the risk of
fire, electric shock and personal injury. Please read the following before using your equipment.
1. Follow all warning and instructions on the product.
2. Unplug all the connections of product before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
3. Do not use this product near water.
4. Do not use this product near an area where there is a potential of gas leaks or near any fumes that
can be explosive.
5. Do not place this equipment near or over a radiator or any other heat source.
6. Do not overload the wall outlet or power cord where the power adapter is installed. This can result
in fire or electric shock
7. Avoid spilling liquid on this equipment and do not insert any objects through the ventilation slots.
8. Avoid using the equipment during an electrical storm. There is a remote risk of electrical shock
from lighting.

ARISTEL NETWORKS
AN1603-08 3G Audio Intercom (E2.2) 4/16
Introduction
AN1603-08 3G audio intercom system is designed for units or multi tenanted premises. It can dial
up to 8 different destinations. By pressing the relevant call button, a visitor can be connected to
the occupier whether they are on or off the site. The intercom will sequentially call 3 numbers that
are associated with the occupier. After the call is answered the door or gate can be opened by
password.
Up to 1150 guests’ numbers can be programmed into this intercom. Any guest calling the intercom
will cause the gate or door to open without the call being answered. This is a free call.
This intercom supports all Telstra, Optus & Vodafone CSFB networks.
Parts List
Item Description Q’ty
1 AN1603-08 3G4G audio intercom 1
2 Power adapter 1
3 Antenna with 3 metre tail 1
4 Mounting Bracket for antenna 1
5 Operating manual 1
6 6 Pin Cable 1
7 Terminal Blocks 1
Mounting Bracket

ARISTEL NETWORKS
AN1603-08 3G Audio Intercom (E2.2) 5/16
Installation
This intercom is suitable for both flush mounting and surface mounting.

ARISTEL NETWORKS
AN1603-08 3G Audio Intercom (E2.2) 6/16
1. SIM card installation (Fig 1)
1.1 Disconnect the power from the intercom.
1.2 Remove the rear plastic cover
1.3 Remove the SIM card cover from the bottom of the unit
1.4 Slide the SIM card holder towards the front of the unit
1.5 Lift up the holder
1.6 Before inserting the SIM card, ensure that it is not PIN number locked. (If
locked, use a mobile phone to unlock it).
1.7 Insert the SIM card (Note orientation of notched corner)
1.8 Replace holder and slide towards the rear of the unit to lock in place
1.9 Replace rear plastic cover

ARISTEL NETWORKS
AN1603-08 3G Audio Intercom (E2.2) 7/16
2. Connecting with the door lock system (Fig 2)
2.1 According your door lock type, see wiring options below.
3. Connecting the Antenna (Fig 3)
3.1 Plug in the antenna cord to the connector on the rear of the unit
3.2 Place antenna away from electrical/electronic systems (computers, microwave ovens,
etc.)

ARISTEL NETWORKS
AN1603-08 3G Audio Intercom (E2.2) 8/16
4. Power on.
4.1 Connect the 12-24v power source to the connector marked AC
4.2 The blue indicator of call button should be on and you will hear Du Du tone.
4.3 Position the intercom where it will be installed.
4.4 When the Du Du tone has ceased, the device is ready.
Wiring Diagram

ARISTEL NETWORKS
AN1603-08 3G Audio Intercom (E2.2) 9/16
Using the AN1603-08
1. Setting your call out numbers
1.1 Send the text SMS to the number of device.
1.2 The format of text SMS is
*12*1234#1[XX][Y][phone number]#1[XX][Y][phone number]#...
XX=01-08, it means the 8 call buttons.
Y=~1~3, it means three phone numbers
1.3 When the setting is finished, the sender will receive the reply as below.
1[XX][Y][ phone number]#1[XX][Y][ phone number]#...OK
1.4 If you press the call button of device, it will call to the numbers of call buttons in
sequence.
2. Setting your dial in numbers ( Guest List )
2.1 Send the text SMS to the number of device.
2.2 The format of text SMS is
*12*1234#71[country code]#72[relay][call in number 1]# 72[relay][call in number 2]#...
2.3 When the setting is finished, the sender will receive the reply as below.
71[country code]#72[relay][call in number 1]# 72[relay][call in number 2]#...OK
2.4 If a guest calls the number of the device, it will trigger the relay to control the door
latch.
2.5 If the calling number is not on the guest list, the device will answer and sound a
beep. Then the administrator can enter the programming mode by password.
3. App on iOS and Android
3.1 Please search 3G intercom on Apple store or Google Play
3.2 The App can help you to program the device more easily.
3.3 You can use the App to unlock the door via calling or SMS.

ARISTEL NETWORKS
AN1603-08 3G Audio Intercom (E2.2) 10/16
Enter System Menu
1. Please call the number of the intercom device.
2. The device will answer and sound one beep to enter system menu.
3. Enter the password of the mode you would like to enter.
3.1 Listener monitoring mode. 【*13*1212
#
】
3.2 Access control mode 【*33*5678
#
】
3.3 Program setting mode 【*12* 1234
#
】
4. Password correct is one beep, password error is 3 beeps.
5. The device will hand up after 3 failed attempts.
Enter Listener Monitoring Mode
1. You will hear a “Do” tone to enter listener monitoring mode by pressing【*13*1212
#
】
where 1212 is the monitoring password.
2. Then you can hear the live sound of the device’s surrounding environment.
* Under this mode speaker is OFF. (35
#
: To turn on speaker)
* You can still control the relay output under listener monitoring mode but speaker must be
ON status.
EnterAccess Control Mode
1. You will hear a “Do” tone to enter access control mode by pressing【*33*5678
#
】where
5678 is the access control password.
2. The door will be opened after entering the correct password
*(To open the door by password, if the number is not stored in the access control section)
Enter Program setting Mode
1. You will hear a “Do” tone to enter into program setting mode by pressing【*12* 1234
#
】where 1234 is the setting password.
2. You are now in the “program setting mode”
Note: At the end of each command there can be one of the two indications:
Successful: a long “beep” tone, failed: three short “beep” tone.
3. To make changes on settings please refer to the command codes in page 12.
4. To end program setting mode just hang up.
NOTE:
*To be successful in programming, originate a call from a land line and enter the
digits slowly or using programming by text message.

ARISTEL NETWORKS
AN1603-08 3G Audio Intercom (E2.2) 11/16
Programming by text message
Programming by text message is the simplest way to customize the settings of the intercom and add
or delete telephone numbers. Simply send texts in the format to the telephone number of the SIM
within the intercom.
Note:
1. A Single SMS text messages is limited to 140 characters.
2. You can program many different user command codes in one text message with SMS
command format.
*12*1234 # [command Code 1] # [command Code 2] # [command Code 3] #...
3. Each SMS must start with the pass code *12, default setting password 1234 in the following
format *12*1234 # followed immediately by a command.
4. To program a call button numbers DO NOT enter country code, just the complete number as
you would dial it.
Example:
Store a call button phone numbers (Max 3 numbers) and delete 2&3 phone numbers.
058 57235 .(landline number 1)
086 5682554 (mobile number 2)
086 2235644 (mobile number 3)
SMS format: (store a call button phone numbers)
*12*1234#108105857235#10820865682554#10830862235644#
SMS format: (delete 2&3 phone numbers of a call button)
*12*1234#1082*#1083*#
User command code CORRECT
SMS format:
*12*1234#108105857235#10820865682554#10830862235644#
SMS reply:
108105857235#10820865682554#10830862235644# OK
User command code ERROR (user command 192 error)
SMS format: *12*1234#108105857235#1920865682554#10830862235644#
SMS reply: 108105857235#1920865682554# Error
Command to use: *12*1234#1[
XX][Y][phone number]#
XX= call button 01~08
Y=
number 1~3

ARISTEL NETWORKS
AN1603-08 3G Audio Intercom (E2.2) 12/16
Command Codes
You can program many different command codes in one text message with SMS command format.
*12*1234 # [command Code 1] # [command Code 2] # [command Code 3] #........
No. Feature Command Description Default
1 Change setting Password 01 [ password ] # password:4 digit codes 1234
2 Change access control password 02 [ password ] # password:4 digit codes 5678
3 Change monitoring password 03 [ password] # password:4 digit codes 1212
4 Store or delete a call button
phone numbers
1 [XX][ Y ] [ phone number ] #
XX= 01~08
Y= phone number 1,2 or 3
Phone number= 3~20 digits
(One * can be delay 3 seconds) None
1 [XX][ Y ]
* # Delete phone number1, 2, 3
5 Speaker Volume 3 [ speaker volume] # speaker volume level= 0 ~ 4 3
6 Microphone Volume 4 [ microphone volume] # microphone volume level= 0 ~ 4 3
7 Relay 1 Trigger Time 51 [ relay1 time ] # Relay 1 time= 1~9999 sec 1
8 Relay 2 Trigger Time 50 [ relay 2 time ] # Relay 2 time= 1~9999 sec 1
9 Call Divert to next number time 52 [ call divert time ] # Call divert time= 10~99 sec 20 sec
10 Max Call Time 53 [ max call time] # Max call time= 005~999 sec 060 sec
11 Max Monitoring time 55[ duration time] # duration time= 00 ~ 60 mins
00 ( no limit time) 10 mins
12
Call in to open the door numbers
(Max: 1150 numbers)
Guest List.
71 [ country code ] # Country code= 1~3 digit codes
None
72[relay] [ phone number ] # Relay= 1 or 2
73 [phone number ] # Delete phone number
73*# Delete all phone numbers
13 Add administrator phone number 74 [ admin number ] # admin number= 3~15 digits
( no number no restriction) None
14 Del administrator phone number 74*# delete admin phone number None
15 SMS reply notice of Relay status 894[X]# X=0 (disable SMS reply)
X=1 (enable SMS reply) 0

ARISTEL NETWORKS
AN1603-08 3G Audio Intercom (E2.2) 13/16
16 Dial tone volume 898[X]# X=1~3 ( levels) 2
17 Set Egress Pin output relay 900[X]# X=0 (relay 1)
X=1 ( realy2) 0
18 Set Detect pin output relay
(Detect Pin is egress mode) 901[X]# X=0 (relay 1)
X=1 ( realy2) 1
19 Detect pin on PCB setup 902[X]#
X=0~3
0:disable
1:egress mode (901)
2:trigger
3.resistance=10KΩ(7.5K~13K)
0
20 Emitting beep when correct PIN
code entered 903[X]# X=0 (disable)
X=1 (enable) 1
21 Intercom moving Detection
(Theft Proof) 904[X]# X=0 (disable)
X=1 (enable) 0
22 Set Alert phone number
(moving & trigger) 905[ Y ][ phone number ] # Y= phone number 1,2 or 3
Phone number=3~15 digits None
23 Intercom LED light
(optional LED board installed) 906[X]# X=0 (disable)
X=1 (enable) 0
24 Enable or disable IN1 907[X]# X=0 (disable)
X=1 (enable) 0
25 Change the length of open code 940[X]# X=1 (1 code open code)
X=2 (2 codes open code) 1
26
Change open codes of relay 1&2
including trigger / hold / release
for independent apartment
93[X]*[ABCDEF]#
X= apartment number
A,B,C,D,E,F= 0~9 and *
A= trigger relay 1
B= hold relay 1
C= release relay 1
D= trigger relay 2
E= hold relay 2
F= release relay 2
1
code
2
code
1
2
3
4
5
6
10
20
30
40
50
60
27 Send SMS message
(when Detect Pin is triggered) *26*[ password ] #[content] Password=setting password
content= up to 100 characters
Detect PIN
Trigger
28 Send SMS message
(when Intercom is moved) *27*[ password ]#[content] Password=setting password
content= up to 100 characters Case open
29
Send SMS message
(when external power is off )
(works for inside battery)
*28*[ password ]#[content] Password=setting password
content= up to 100 characters Power loss
30 Send SMS message
(when external power is active) *29*[ password ]#[content] Password=setting password
content= up to 100 characters
Power
active

ARISTEL NETWORKS
AN1603-08 3G Audio Intercom (E2.2) 14/16
(works for inside battery)
31 Send SMS message
(when IN1 is triggered) *30*[ password ]#[content] Password=setting password
content= up to 100 characters IN1 trigger
32 Reset 999# reset default None
How to change the name plate

ARISTEL NETWORKS
AN1603-08 3G Audio Intercom (E2.2) 15/16
How to reset the hardware if you forget your password
1. Keep both reset and egress buttons pressed
2. Release all buttons after you hearing continuous “Dou” tones
3. The device will restart and hardware reset is done
Troubleshooting (Q &A)
Q. The unit keeps beeping.
A. This means the unit is not able to detect the network for some reason.
-Check the SIM card is activated and has calling credit.
-Power off the unit, remove the SIM and check it in a mobile phone to verify it can make a call.
-Check if the PIN code of SIM disable when put in a phone.
-Check the signal strength to ensure reception is good.
-Check the antenna has been mounted as high as possible, not near large metal objects, or wet green
shrubs etc.
Q. The unit calls the first number, but there is not enough time to answer before it diverts to
the next number.
A. Increase the no answer time as per programming instructions.
Q. The unit calls the first number but voicemail comes on before it can ring the second
number.
A. Decrease the no answer time as per programming instructions.
Q. The caller ID part does not work.
A. Be sure to program the caller ID part under 72 feature. If your number is a private or number
withheld, then it will not work.
Even if you have already programmed a number to receive a call from the intercom, if you also want
that number to have caller ID access, it must be programmed under the 72 feature also.
Ensure the number is entered as you would normally dial it from another phone.
Q. There is no audio from the gate, but the person at the gate can hear ok.
A. This can be due to low reception.
-Check reception level by *20#.
-Change SIM card if necessary, to another network which may have better coverage.

ARISTEL NETWORKS
AN1603-08 3G Audio Intercom (E2.2) 16/16
Q. The audio quality that can be heard on the remote telephone is poor or humming
(buzzing).
A. A small amount of GSM buzz can be considered normal on audio intercoms, but not so much that
causes inability to hear the person speaking. This can be caused by the GSM antenna being mounted
too close to the speech panel or not mounted high enough.
-Try earthing the speech panel chassis to 0V of the power supply.
-This is also a symptom of poor reception. Try above steps on checking and improving reception.
Q. The 1 or 2 key does not work when the intercom calls a phone.
A. Check if you can hear the relay clicking at the gate when the 1 or 2 key is pressed during a call. If
it can be heard, then the system is working, check wiring between the relay and the lock or gate panel.
If the relays do not make a clicking sound, then check this feature on a different mobile cell phone or
landline. If it works on a different phone, check the settings on the phone in question under DTMF
tones. Failure of DTMF tones to operate correctly is also a symptom of low reception. Check steps
above on improving reception. Try pressing the buttons longer when attempting to activate the gates
or door.
Specification
Model AN1603-08 3G/4G Audio Intercom
GSM / WCDMA Frequency GSM 850/900/1800/1900 MHz,
WCDMA 800/850/900/1900/2100 MHz
Face plate 180 (H) x 109 (W) mm
Surface back box 189 (H) x 118 (W) x 65(D) mm
Length of antenna tail 3 metre cable
Power requirements 12~24VAC/ DC
Design and material Vandal resistant / die cast aluminum
Humidity Less than 80% RH
Operating Temperature -20℃ to 50℃
Operating Current Maximum 250mA, Typically 55mA
E. & O.E. www.aristel.com.au
Table of contents
Other Aristel IP Access Controllers manuals
