ONE-BOX™ Non-Metallic Outlet Boxes
The Versatile Outlet Box for New or Old Work
Fast and asy to install, Arlington’s v rsatil
outl t box is th ONE-BOX™ for n w or
old work.
It mounts dir ctly to a wood or st l stud
for a sup r s cur installation.
Angl d scr ws insid th ONE-BOX affix it
firmly to th stud. It has no wings so
th r ’s no wobbl .
NEW WORK
ONE-BOX s t too far forward or back? No
probl m. Back th scr ws out and adjust
it.
OLD WORK
ONE-BOX
provid s
a s cur
installation.
It mounts
dir ctly to th
stud, not just
th drywall.
•Extra-larg cubic inch capacity
•cULus List d
•Singl gang (horizontal and v rtical)
and multipl gang styl s
•For pow r and low voltaqg
applications with th F102D voltag
s parator install d
•Install d NM cabl conn ctor
NEW SIZES
Available
1 Stauffer Industrial Park
Scranton, PA 18517
800/233.4717
Fax [phone]
www.aifittings.com
Arlington
R
Patents pending.
F101
T e Versatile
Outlet Box
F104
4-gang
F102
2-gang

Catalog UPC/DEI/NAED Description Cubic Inch Unit Std
Number Mfg. #01899 Non-Metallic Outlet Box Capacity Pkg Pkg
F101 4 626 Single gang Vertical 22.0 50 50
F102 4 640 2-gang 42.1 25 25
F103 4 641 -gang 61.2 20 20
F104 4 642 4-gang 80.5 20 20
F102D 4 544 Separator 25 25
F101H 4 641 Single gang Horizontal 22.0 20 20
Distributed by
ONE-BOX 0207/30M
1 Stauffer Industrial Park
Scranton, PA 18517
800/233.4717
Fax [phone]
www.aifittings.com
Arlington
©2007 Arlington Industries, Inc.
R
1Attach ONE-BOX to wood or steel stud with
captive installation screws. If the box is too
far forward or back, simply back the screws
out and reposition it.
ONE-BOX™ Non-Metallic Outlet Boxes
Secure Installation •Mounts Directly to a Wood or Steel Stud
F102
2-gang
Patents
pending 2Pull wire through the connector.
(ships with installed NM cable connector)
42.
cubic
inch
capacity
Combination
/2" and 3/4" knockout
in the back of the box
(not visible)
Installed
NM cable
connector
Ships with captive installation screws
2Pull wire. Insert ONE-BOX. 3Mount ONE-BOX directly to stud with
shipped in place screws.
NEW WORK
1For old work, position ONE-BOX adjacent to
stud. Use box as the template to cut hole.
OLD WORK
F101 F102 F10 F104 F101H
