Armal WAVE User manual

WAVE Toilet
Assembly Instruction

2
Required tools

Sommario
1USE AND MAINTENANCE MANUAL..............................................................5
1.1 Required tools....................................................................................................................5
1.2 Assembly Instructions........................................................................................................6

4
Required tools

5
Required tools
1 USE AND MAINTENANCE MANUAL
1.1 REQUIRED TOOLS
Allen Key
Star Srewdriver
Drill
Armal Key
Wrench
Regolable Key

6
Assembly Instructions
1.2 ASSEMBLY INSTRUCTIONS
1.2.1 HOLDING TANK ASSEMBLY
Place the floor on the toilet holding tank
Insert No. 5 screws 4,8x35
Fix first the central screw
N° 8

7
Assembly Instructions
Complete fixing the two parts together by using No.
4 additional screws
N° 8
Take the holding tank cover and place it on the
holding tank
Fix first the central rivet

8
Assembly Instructions
Complete fixing the two parts together by using No.
2 rivets more
Attention: do not insert rivets on the rear
holding tank cover
Take the toilet seat and seat cover
Place first the toilet seat and seat cover; then insert
the seat metal bar inside the designated hole

9
Assembly Instructions
Fix the seat metal bar with ring
Fix the seat metal bar with ring

10
Assembly Instructions
1.2.2 WALLS ASSEMBLY
Take one wall panel and position it on the rear floor
Fix first the lower central rivet to the floor
Drill the wall panel central point
ø 5.25

11
Assembly Instructions
Insert the rivet
Drill the left position
ø 5.25
Drill the right position
ø 5.25

12
Assembly Instructions
Insert No. 2 rivets
Place the right panel
Fix first the lower central rivet to the floor

13
Assembly Instructions
Drill the wall panel central point
ø 5.25
Insert rivet
Drill the right position
ø 5.25

14
Assembly Instructions
Insert the rivet in the previous right position and
along the entire junction edge with the back panel
Place the left panel
Fix first the lower central rivet to the floor

15
Assembly Instructions
Drill the wall panel central point
ø 5.25
Insert the rivet
Drill the left position
ø 5.25

16
Assembly Instructions
Insert the rivet in the previous left position and along
the entire junction edge with the back panel
Place the door frame
Rivet along the left door frame side

17
Assembly Instructions
Rivet along the lower door frame side
Rivet along the right door frame side

18
Assembly Instructions
1.2.3 DOOR ASSEMBLY
Assembly the adjustable door noise deflector
Insert the adjustable door noise deflector in
the door frame
Use a screwdriver for adjust the noise
deflector

19
Assembly Instructions
Place the bottom door pin
Insert the door into the bottom pin
Place the upper hinge on the door frame

20
Assembly Instructions
Drill the upper hinge position
ø 5.25
Fix the upper hinge with No. 2 rivets
